Kärcher K 2.110 M User manual

English 2
Español 17
Français 32
5.962-721.0 (10/07)
K 2.26 M

2 English
Model Overview . . . . . . . . . . . . . . . . . . 3
Important Safety Instructions. . . . . . . 4
Assembly Instructions . . . . . . . . . . . . 5
Operating Instructions . . . . . . . . . . . . . 6
Using the Accessories . . . . . . . . . . . . . 7
Working with Detergents . . . . . . . . . . . 8
Taking a Break five minutes or more. 9
Shutting Down & Clean-Up . . . . . . . . . 9
Winterizing and Long-Term Storage 10
Care and Maintenance Instructions . 10
Cleaning Tips. . . . . . . . . . . . . . . . . . . . 11
Optional Cleaning Accessories . . . . 13
Troubleshooting. . . . . . . . . . . . . . . . 15
DANGER
indicates “an imminently hazardous sit-
uation which, if not avoided, will result in
death or serious injury.”
WARNING
indicates “a potentially hazardous situa-
tion which, if not avoided, could result in
death or injury.”
CAUTION
indicates “a potentially hazardous situa-
tion which, if not avoided, may result in
minor or moderate injury or in property
damage incidents.”
For household use only!
The owner and/or user must have an
understanding of the manufacturer’s
operating instructions and warnings be-
fore using this pressure washer.
Warning information should be empha-
sized and understood.
If the operator is not fluent in English,
the manufacturer’s instructions and
warnings shall be read to and discussed
with the operator in the operator’s native
language by the purchaser/owner, mak-
ing sure that the operator comprehends
its contents.
Owner and/or user must study and
maintain for future reference the manu-
facturers’ instructions.
Call: 1-800-537-4129 for help or visit
our website:
www.karcherresidential.com
Please take a moment to register your
pressure washer online at
www.karcherresidential.com/warranty
Call: 01-800-024-13-13 for help or visit
our website: www.karcher.com.mx
HIGH PRESSURE WASHER OPERATOR MANUAL
Safety Alert Symbols
Specifications
Max. Pressure 1500 PSI
Water Flow 1.3 GPM
Amp draw 13 AMPS
Voltage 120 V
Part No. 1.601-602.0
Serial no.
Owner/User Responsibility
Kärcher Customer Support
USA and CDN
Kärcher Customer Support
Mexico

English 3
1 High pressure outlet
2 Detergent suction tube with filter
3 ON/OFF switch
4 Hose/Cord Hook
5 Handle
6 Collapsable transport handle
7 Trigger Gun Holder
8 Power cord with Ground Fault Circuit
Interrupter (GFCI)
9 Water inlet with garden hose
connector
10 Wheels
11 Trigger gun
12 High pressure hose
13 Trigger gun safety lock
14 Dirtblaster® (Rotary spray wand)
15 Vario Power Spray wand
MODEL OVERVIEW

4 English
WARNING – When using this product
basic precautions should always be fol-
lowed, including the following:
Read all the instructions before us-
ing the product.
To reduce the risk of injury, close su-
pervision is necessary when a prod-
uct is used near children.
Know how to stop the product and
bleed pressures quickly. Be thor-
oughly familiar with the controls.
Stay alert – watch what you are do-
ing.
Do not operate the product when fa-
tigued or under the influence of alco-
hol or drugs.
Keep operating area clear of all per-
sons.
Do not overreach or stand on unsta-
ble support. Keep good footing and
balance at all times.
Follow the maintenance instructions
specified in the manual.
This Product Is Provided With A
Ground Fault Circuit Interrupter
Built Into The Power Cord Plug. If
Replacement Of The Plug Or Cord
Is Needed, Use Only Identical Re-
placement Parts.
WARNING – Risk of Injection or Injury –
Do Not Direct Discharge Stream At Per-
sons.
High pressure jets can be dangerous
if misused. The jet must not be di-
rected at persons, animals, electrical
devices, or the unit itself.
Wear safety goggles.
WARNING – Risk Of Explosion – Do
not spray flammable liquids.
Do not use acids and solvents in this
product. These products can cause
physical injuries to the operator and
irreversible damage to the machine.
CAUTION – Gun Kicks Back – Hold
with both hands.
The Trigger Gun Safety Lock pre-
vents the trigger from accidentally
being engaged. This safety feature
DOES NOT lock trigger in the ON
position.
WARNING – Risk of Electrocution –
Inspect cord before using – Do not
use if cord is damaged.
Keep all connections dry and off the
ground.
Do not touch plug with wet hands.
Do not use extension cord with this
product.
Connect to individual branch circuit
only.
SAVE THESE INSTRUCTIONS
In a double-insulated product, two sy-
stems of insulation are provided instead
of grounding. No grounding means is
provided on a double-insulated product,
nor should a means for grounding be
added to the product. Servicing a doub-
le-insulated product requires extreme
care and knowledge of the system, and
should be done only by qualified service
personnel. Replacement parts for a
double-insulated product must be iden-
tical to the parts they replace. A dou-
bleinsulated product is marked with the
words “DOUBLE INSULATION” or
“DOUBLE INSULATED”. The symbol
“ ” may also be marked on the product.
IMPORTANT SAFETY INSTRUCTIONS
SERVICING OF A DOUBLE-
INSULATED PRODUCT

English 5
This pressure washer is provided with a
ground-fault circuit-interrupter (GFCI)
built into the plug of the power-supply
cord. This device provides additional
protection from the risk of electric
shock. Should replacement of the plug
or cord become necessary, use only
identical replacement parts that include
GFCI protection.
CAUTION
When connecting the water inlet to the
water supply mains, local regulations of
your water company must be observed.
In some areas the unit must not be con-
nected directly to the public drinking wa-
ter supply. This is to ensure that there is
no feedback of chemicals into the water
supply. Direct connection via a receiver
tank or backflow preventer, for example,
is permitted.
Dirt in the feed water will damage the
unit. To avoid this risk, we recommend
fitting a water filter.
Garden hose must be at least 1/2
inch or 5/8 inch in diameter.
Flow rate of water supply must not
fall below 2 GPM (gallons per minu-
te).
Flow rate can be determined by run-
ning the water for one minute into an
empty 5-gallon container.
The water supply temperature must
not exceed 104°F/40°C.
Never use the pressure washer to
draw in water contaminated with sol-
vents, e.g. paint thinners, gasoline,
oil, etc.
Always prevent debris from being
drawn into the unit by using a clean
water source.
ÎSTEP 1:
Insert wheels into the side holes of
the unit.
GROUND FAULT CIRCUIT
INTERRUPTER PROTECTION
WATER SUPPLY
(Cold Water Only)
ASSEMBLY INSTRUCTIONS

6 English
ÎSTEP 1:
Connect the high pressure hose to
the unit’s high pressure outlet.
ÎSTEP 2:
Insert the spray wand of your choice
into the trigger gun. Press in against
the spring tension and twist into
locked position.
ÎSTEP 3:
Connect garden hose to unit’s water
inlet.
ÎSTEP 4:
Connect garden hose to the cold wa-
ter source and turn water on com-
pletely.
ÎSTEP 5:
Plug the Ground Fault Circuit Inter-
rupter (GFCI) into a working outlet.
– Press “RESET” button.
– Press “TEST” button.
Red indicator on “RESET” button
should appear.
– Press “RESET” button again for use.
WARNING
Do not use if above test fails.
Note: The actual appearance of the GFCI may
be different from this illustration.
ÎSTEP 6:
Unlock the trigger gun safety lock.
Trigger the gun to eliminate trapped
air, wait for a steady flow of water to
emerge from the spray nozzle.
ÎSTEP 7:
Turn on the high pressure washer (I/ON).
The motor starts only if the trigger
of the gun is pulled and shuts off
when the trigger is released.
OPERATING INSTRUCTIONS

English 7
WARNING
To avoid serious injury never point
spray nozzle at yourself, other per-
sons or animals.
Always test an inconspicuous area
before cleaning with high pressure.
The Vario Power Spray Wand allows
you to adjust the cleaning pressure.
To clean at maximum pressure, the
wand must be positioned to the high
pressure setting (Max).
For reduced pressure turn the wand
collar in the „Min“ direction.
To apply detergent, the wand
must be positioned to the low
pressure setting (Mix).
This nozzle features a 0º pencil jet
which rotates 360º for maximum dirt
cutting action, effectively increasing
cleaning performance up to 50%.
This nozzle combines the cleaning
performance of a 0º pencil jet with
the surface coverage of a wide angle
nozzle.
Not recommended for soft materi-
als, siding, painted surfaces,
decks or autos.
Always test an inconspicuous area
before cleaning with the Dirtblaster.
USING THE ACCESSORIES
Vario Power Spray Wand
Dirtblaster®

8 English
Detergents can only be applied at
low pressure setting (Mix).
ÎSTEP 1:
Install the Vario Power Spray Wand.
Set the spray wand to the low pres-
sure setting (Mix).
ÎSTEP 2:
Fill a container with Kärcher deter-
gent. Place the filter end of detergent
suction tube into the container.
ÎSTEP 3:
Turn on the pressure washer (I). Pull
trigger to operate unit. Liquid deter-
gent is drawn into the unit and mixed
with water. Apply detergent to work
area. Do not allow detergent to dry
on surface.
-STEP 4:
To rinse, move the VPS out of „Mix“
position and pull trigger to operate
unit.
ÎSTEP 5:
Cleaning up: Always draw fresh wa-
ter through the detergent tank or si-
phon tube when done to flush any
remaining detergents from the injec-
tion system.
For best results see Cleaning Tips
for specific information on how to
clean different surfaces.
CAUTION
This unit has been designed for use with
cleaning detergents recommended by
the manufacturer. The use of other clean-
ing detergents may affect the operation of
the machine and void the warranty.
Always Use Kärcher Detergent for
Best Results
Kärcher biodegradable detergents are
specially formulated to protect the envi-
ronment and your pressure washer. The
special formula won’t clog the suction
tube filter and will protect the internal
parts of the pressure washer for a lon-
ger life. For Kärcher Detergents, check
your retailer or visit our website:
www.soappac.com
The following Kärcher detergents are
available:
One Gallon ready to use
All Purpose & Vehicle Cleaner
Deck & Patio Cleaner
Heavy Duty Degreaser
Exterior House Cleaner
CAUTION
Never use:
– Bleach, Chlorine products and other
corrosive chemicals
– Liquids containing solvents (i.e.,
paint thinners, gasoline, oils)
– Tri-sodium phosphate products
– Ammonia products
– Acid-based products
These chemicals will harm the unit and
will damage the surface being cleaned.
Use of these items will void the war-
ranty.
WORKING WITH DETERGENTS

English 9
ÎSTEP 1:
Release trigger and engage gun
safety lock.
ÎSTEP 2:
Turn pressure washer to OFF (0)
position.
ÎSTEP 1:
Turn the switch to OFF (0) position
and unplug cord from outlet.
ÎSTEP 2:
Turn off the water source.
ÎSTEP 3:
Press trigger to release water pres-
sure.
ÎSTEP 4:
Release trigger and engage gun
safety lock.
ÎSTEP 5:
Disconnect the garden hose from
the water inlet on the unit.
ÎSTEP 6:
Disconnect the high pressure hose
from the high pressure outlet.
TAKING A BREAK five minutes or more
SHUTTING DOWN & CLEAN-UP

10 English
Î1: Disconnect all water connections.
Î2: Turn on the machine for a few se-
conds, until the water which had
remained in the pump exits, turn off
immediately.
Î3: Do not allow high pressure hose
to become kinked.
Î4: Store the machine and accesso-
ries in a room which does not reach
freezing temperatures. DO NOT
store near furnace or other sources
of heat as it may dry out the pump
seals.
CAUTION
Failure to follow the above directions
will result in damage to the pump as-
sembly and accessories and will void
the warranty.
Kärcher also recommends the regular
practice of using a pump protector like
“Kärcher Pump Guard” to prevent cold
weather damage during storage in the
winter months.
ÎSTEP 1:
Pull out washer from the water inlet.
ÎSTEP 2:
Pull out water inlet filter with flat-
nose pliers.
ÎSTEP 3:
Rinse out water inlet filter in warm
water.
ÎSTEP 4:
Reinsert water inlet filter and washer
into the water inlet.
The unit is maintenance-free.
WINTERIZING AND LONG-TERM STORAGE
CARE AND MAINTENANCE INSTRUCTIONS
Cleaning the water inlet filter Maintenance

English 11
CAUTION
Before cleaning any surface an in-
conspicuous area should be cleaned
to test spray pattern and distance for
maximum cleaning results.
If painted surfaces are peeling or
chipping, use extreme caution as
pressure washer may remove the
loose paint from the surface.
When using on surfaces which might
come in contact with food, flush sur-
faces with plenty of drinking water.
For additional cleaning tips and a
complete video library, visit our web-
site:
www.karcherresidential.com
(with or without detergent). Pre-rinse
deck and surrounding area with fresh
water. If using Kärcher Deck Wash, ap-
ply to surface at low pressure. For best
results, limit your work area to smaller
sections of approximately 25 square
feet. Allow Deck Wash to remain on sur-
face 1-3 minutes. Do not allow deter-
gent to dry on surface. Rinse at high
pressure in a long sweeping motion
keeping the spray nozzle approximately
3-6 inches from the cleaning surface.
Always clean from top to bottom and
from left to right. When moving on to a
new section of the cleaning surface, be
sure to overlap the previous section to
eliminate stop marks and ensure a more
even cleaning result.
(with or without detergent). Pre-rinse
cleaning surface with fresh water. If
using Kärcher Pressure Wash, apply to
surface at low pressure (for best results,
limit your work area to sections of ap-
proximately 6 feet and always apply de-
tergent from bottom to top). Allow
Pressure Wash to remain on surface 1-
3 minutes. Do not allow detergent to dry
on surface, if surface appears to be
drying, simply wet down surface with
fresh water. If needed, use special wash
brush attachment (not included) to re-
move stubborn dirt. Rinse at high pres-
sure from top to bottom in an even
sweeping motion keeping the spray
nozzle approximately 6 inches from the
cleaning surface.
(with or without detergent). Pre-rinse
cleaning surface with fresh water. If
using Kärcher Pressure Wash or De-
greaser, apply to surface at low pressu-
re. For best results, limit your work area
to smaller sections of approximately 25
square feet. Allow Pressure Wash or
Degreaser to remain on surface 1-3 mi-
nutes. Do not allow detergent to dry on
surface. Rinse at high pressure in a
sweeping motion keeping the spray
nozzle approximately 3-6 inches from
the cleaning surface. Always clean from
top to bottom and from left to right. For
removing extremely stubborn stains,
use the Dirtblaster Nozzle.
CLEANING TIPS
Deck Cleaning
House Siding
Cement Patios, Brick and Stone

12 English
(with or without detergent). Pre-rinse
vehicle with fresh water. If using
Kärcher Touchless Vehicle Wash, apply
to surface at low pressure. For best re-
sults, clean one side of vehicle at a time
and always apply detergent from bottom
to top, do not allow detergent to dry on
surface. If needed, use special wash
brush attachment (not included) to re-
move stubborn dirt. Rinse at high pres-
sure in a sweeping motion keeping the
spray nozzle approximately 6-8 inches
from the cleaning surface (distance
should increase when rinsing pin-stri-
ping or other sensitive surfaces). Al-
ways clean from top to bottom and from
left to right. For best results, wipe sur-
face dry with a chamois or soft dry cloth.
(with or without detergent). Pre-rinse
cleaning surface with fresh water. If
using Kärcher Pressure Wash or De-
greaser, apply detergent at low pressu-
re. Allow Pressure Wash to remain on
surface 1-3 minutes. Do not allow deter-
gent to dry on surface. Rinse at high
pressure keeping the spray nozzle ap-
proximately 3-6 inches from the cle-
aning surface. For removing extremely
stubborn dirt, it may be necessary to
move the spray nozzle even closer to
the surface for greater dirt cutting ac-
tion.
(with or without detergent). Pre-rinse
furniture and surrounding area with
fresh water. If using Pressure Wash, ap-
ply to surface at low pressure. Allow
Pressure Wash to remain on surface 1-
3 minutes. Do not allow detergent to dry
on surface. If needed use special Wash
Brush Attachment (not included) to re-
move stubborn dirt. Rinse at high pres-
sure in a sweeping motion keeping the
spray nozzle approximately 3-6 inches
from the cleaning surface. For best re-
sults, clean from top to bottom and from
left to right.
Cars, Boats & Motorcycles
Barbecue Grills, Outdoor Power
Equipment & Gardening Tools
Patio & Lawn Furniture

English 13
Optional accessories are available to
further enhance your cleaning capabili-
ties. These accessories are accurate as
of the printing date of this manual.
Please check our website for pricing
and up-to-date information.
Specially formulated to protect your
pressure washer from freezing, corrosi-
on and premature wear. The Pump
Guard also adds lubrication to valves
and seals to prevent sticking. Highly re-
commended for all Kärcher pressure
washers!
Part No. 9.558-998.0
Replacement hose fits Kärcher pressu-
re washer with screw-on type gun con-
nections from 2400 PSI to 2500 PSI,
Extension Hose for all Kärcher high
pressure washers between the original
equipment hose and machine up to
2500 PSI.
Part No. 2.640-850.0
Need to clean second story windows or
other high areas? Increase the reach of
your pressure washer by up to 66" with
this extension kit. Includes 4 aluminum
sections for variable length. 66" fully as-
sembled. Fits most Kärcher pressure
washers up to 2300 PSI. (bayonet)
Part No. 2.640-746.0
For more effortless cleaning of all
smooth surfaces (painted, glass and
plastic) try Kärcher's Rotating Wash
Brush. Use it on your automobile, house
siding or windows. The water pressure
from your pressure washer causes the
inner brushes to gently spin, making
your cleaning job much easier. The ang-
le of brush head is adjustable to help
you reach difficult areas. Excellent for
the application of detergent. A must-
have accessory designed for Kärcher
pressure washers up to 2300 PSI.
(bayonet)
Part No. 2.640-743.0
Made with soft bristles that will not harm
painted surfaces. Easily attaches direct-
ly to the trigger gun. Ideal for stubborn
dirt on cars, boats, patio furniture and
other surfaces. Great for applying deter-
gent. Fits most Kärcher pressure was-
hers up to 2300 PSI. (bayonet)
Part No. 2.640-740.0
Optional Cleaning Accessories
Pump Guard
25 Ft. Extension /Replacement
High-Pressure Hose
66" Extension Wand (Four piece)
Rotating Wash Brush (bayonet)
Soft Clean Washing Brush

14 English
Need to clean blocked pipes, drains or
downspouts? Kärcher's pipe cleaning
kit is the answer! The pipe cleaner pro-
pels itself forward while simultaneously
flushing out debris. For example, insert
the cleaning nozzle in the base of a
downspout, pull the trigger on the pres-
sure washer gun and watch as the
nozzle shoots out leaves and other de-
bris while climbing upward. Connects
directly to the trigger gun of most
Kärcher pressure washers up to
2300 PSI. (bayonet)
Part No. 2.640-747.0
Why spend hours stripping old paint and
rust by hand using harsh chemicals?
Let Kärcher's Wet Sandblasting Kit do
the work! Attach the kit to your pressure
washer, add abrasive material and at-
tack the rust and paint with our eco-fri-
endly alternative. Fits most Kärcher
pressure washers up to 2300 PSI.
(bayonet)
Part No. 2.638-792.0
Ideal for applications which require a
thick foam. Simply fill the resevoir cup
with liquid pressure washer detergent to
generate a foam spray. Connects di-
rectly to the trigger gun. Fits most
Kärcher pressure washers up to
2300 PSI. (bayonet)
Part No. 6.964-507.0
For cleaning surfaces such as patios,
terraces and driveways without splash-
back, there is no better solution than
Kärcher's T 100. It saves time by cle-
aning a one foot wide area gently as it
hovers, providing consistent, streak-
free cleaning. When you finish cleaning
the patio and driveway, remove the
wand and use the handle to clean gara-
ge doors and other vertical surfaces.
Includes two nozzles which spin at high
speed for optimum results. Our top sel-
ling accessory for Kärcher pressure wa-
shers up to 2300 PSI. (bayonet)
Part No. 2.640-959.0
25 ft. Pipe Cleaning Kit (bayonet)
Wet Sandblasting Kit (bayonet)
Detergent Foamer Attachment
T 100 Wide Area Surface Cleaner

English 15
CAUTION
Disconnect the machine from the power
source before making any repair.
Troubleshooting
Symptom Cause Solution
Motor will not start On/Off switch is in the “OFF”
(O) position.
Turn switch to the “ON” (I)
position
Tripped GFCI plug. Press “RESET” button on
GFCI plug.
Power cord is not plugged in. Plug in power cord.
Electrical outlet does not
supply adequate power.
Try a different outlet.
Unit does not reach
high pressure.
Diameter of garden hose is
too small.
Replace with a 5/8 inch or
larger garden hose.
Water supply is restricted. Check garden hose for kinks,
leaks and blockage.
Not enough inlet water
supply.
Open water source full force.
Water inlet filter is clogged. Remove filter and rinse out in
warm water.
Spray wand is on low
pressure position.
Turn spray wand to high
pressure position.
Output pressure
varies high and low.
Not enough inlet water
supply.
Turn water on full force.
Check garden hose for kinks,
leaks or blockage.
Pump is sucking air. Check that hoses and fittings
are air tight. Turn off machine
and purge pump by
squeezing trigger gun until a
steady flow of water emerges
through the nozzle.
Water inlet filter is clogged. Remove filter and rinse out in
warm water.
Discharge nozzle is
obstructed.
Blow out or remove debris
with a fine needle.
Calcified gun, hose or spray
wand.
Run distilled vinegar through
detergent suction tube.

16 English
Call: 1-800-537-4129 for help or visit
our website:
www.karcherresidential.com
Call: 01-800-024-13-13 for help or visit
our website: www.karcher.com.mx
No detergent. Detergent suction tube not
properly connected to the
machine.
Check connection.
Detergent is too thick. Dilute detergent, for best re-
sults use Kärcher detergent.
Filter on detergent suction
tube is clogged.
Run warm water through filter
to remove debris.
Damaged or clogged
detergent suction tube.
Remove obstruction or re-
place detergent suction tube.
Spray wand is in high
pressure position.
Turn spray wand tip to low
pressure position.
Discharge nozzle is
obstructed.
Blow out or remove debris
with fine needle.
Garden hose con-
nection leaks.
Loose fittings. Tighten fittings.
Missing/worn rubber washer. Insert new washer.
Spray wand leaks. Spray wand not properly
attached.
Insert the spray wand into the
trigger gun. Carefully press in
against the spring tension
and twist into the locked
position.
Broken o-ring or plastic insert. Call Customer Support
Pump is noisy. Pump is sucking air. Check that hoses and fittings
are air tight. Turn off machine
and purge pump by squeez-
ing trigger gun until a steady
flow of water emerges
through the nozzle.
Water leaks from
pump (up to 10 drops
per minute is permis-
sible).
Loose fittings. Check that all fittings are
tight.
Water seals are damaged or
worn.
Call Customer Support
Oil Drip. Oil seals are damaged or
worn.
Call Customer Support
Symptom Cause Solution
Kärcher Customer Support
USA and CDN
Kärcher Customer Support
Mexico

Español 17
Vista General del Modelo . . . . . . . . 18
Instrucciones de Seguridad
Importantes . . . . . . . . . . . . . . . . . . . 19
Instrucciones de Montaje . . . . . . . . 20
Instrucciones de Funcionamiento . . 21
Utilización de los Accesorios. . . . . . 22
Trabajar con Detergentes . . . . . . . . 23
Tomarse un Descanso de cinco
minutos o más . . . . . . . . . . . . . . . . . 24
Apagado y Limpieza . . . . . . . . . . . . 24
Instrucciones de Conservación y
Mantenimiento. . . . . . . . . . . . . . . . . 25
Consejos de Limpieza . . . . . . . . . . . 26
Accesorios de Limpieza Opcionales 28
Localicación y reparación de averías30
PELIGRO
indica “una situación de peligro inmi-
nente que, si no se evita, puede causar
lesiones graves e incluso la muerte”.
ADVERTENCIA
indica “una situación de peligro poten-
cial que, si no se evita, puede causar le-
siones e incluso la muerte”.
ATENCIÓN
indica “una situación de peligro poten-
cial que, si no se evita, puede causar le-
siones de poca importancia o leves", o
daños materiales.
Sólo para uso doméstico.
El propietario y/o el usuario deben com-
prender bien las instrucciones de servi-
cio y advertencias del fabricante antes
de empezar a utilizar este limpiador de
alta presión.
Debe prestarse especial atención y te-
ner muy claras las advertencias.
Si el operador no habla bien el español,
el propietario/comprador debe respon-
sabilizarse de leer y comentar las ins-
trucciones y las advertencias en su
lengua natal, y asegurarse de que en-
tienda a la perfección su contenido.
El propietario y/o el usuario deben leer
y guardar como referencia para el futuro
las instrucciones del fabricante.
Llame al: 1-800-537-4129 si necesita
ayuda o visite nuestra página Web:
www.karcherresidential.com
Por favor, dedique unos minutos a regis-
trar su aparato de lavado a presión en
www.karcherresidential.com/warranty
Llame al: 01-800-024-13-13 si necesita
ayuda o visite nuestra página Web:
www.karcher.com.mx
Manual de usario del Limpiador de Alta Presiòn
Símbolos de aviso de seguridad
Especificaciones
Presión max. 1500 PSI
Volumen de agua 1.3 GPM
Amperaje 13 AMPS
Voltaje 120 V
Nº de pieza 1.601-602.0
Nº de serie
Responsabilidades del
propietario/usuario
Soporte Kärcher USA / CDN
Soporte Kärcher Mexico

18 Español
1 Salida de alta presión
2 Manguera de succión de detergente
con filtro
3 Interruptor de encendido/apagado
4 Soporte para manguera/cable
5 Asa de transporte
6 Agarradera
7 Zona de recogida, pistola
8 Cable de potencia con interruptor de
circuito de avería por puesta a tierra
9 Toma de agua con conector para
manguera de jardín
10 Ruedas
11 Pistola de disparo
12 Manguera de alta presión
13 Pestillo de seguridad de la pistola de
disparo
14 Dirtblaster® (Lanza rotativa de alta
presión)
15 Lanza de alta presión variable
Vista General del Modelo

Español 19
ADVERTENCIA
Al utilizar este producto, tome
siempre las precauciones básicas, in-
cluidas las siguientes:
Lea todas las instrucciones antes de
utilizar el producto.
Para reducir el riesgo de lesiones,
es necesario extremar las precau-
ciones cuando se utilice el aparato
cerca de niños.
Tiene que saber cómo parar el apa-
rato y purgar la presión rápidamen-
te. Familiarícese con los controles.
 Esté alerta; mire lo que esté haciendo.
No haga funcionar el producto si
está cansado o si está bajo los efec-
tos del alcohol o las drogas.
Mantenga la zona en la que esté lim-
piando libre de personas.
No se alargue demasiado sobre una
base ni se ponga sobre una base
inestable. Mantenga en todo mo-
mento una buena base de apoyo y
un buen equilibrio.
Siga las instrucciones de manteni-
miento especificadas en el manual.
Este producto se suministra con un
interruptor de circuito de avería por
puesta a tierra, que está montado
en el enchufe del cable de potencia.
Si es necesario reemplazar el en-
chufe o el cable, utilice sólo piezas
de repuesto idénticas.
Riesgo de inyección o lesiones a
personas; no dé con el chorro direc-
tamente a personas.
Los chorros de alta presión pueden
ser peligrosos si se utilizan mal. El
chorro no debe ser enfocado a per-
sonas, animales, aparatos eléctricos
ni al aparato mismo.
Póngase gafas protectoras.
No utilice ácidos ni disolventes con
este producto.. Estos productos pue-
den causar lesiones físicas al usuario
y daños irreversibles al aparato.
Para reducir el riesgo de electrocu-
ción, mantenga todas las conexiones
secas y alejadas del suelo. No toque
el enchufe con las manos mojadas.
El pestillo de seguridad de la pistola
de disparo EVITA que la pistola se
dispare accidentalmente. Esta ca-
racterística de seguridad NO blo-
quea el disparo en la posición de
encendido.
No se debe usar el cable de exten-
sión para esta máquina.
GUARDE ESTAS INSTRUCCIONES.
Un aparato dotado de doble aislamiento
incorpora dos sistemas de aislamiento
en lugar de la puesta a tierra. Es decir,
los equipos dotados de doble aisla-
miento no incorporan ningún conductor
ni dispositivo des puesta a tierra ni hay
que acoplar adicionalmente a los mis-
mos una puesta a tierra. Los trabajos de
mantenimiento de un equipo dotado de
un sistema de doble aislamiento requie-
ren unos conocimientos particularmen-
te amplios y completos de dicho
dispositivo y del aparato en cuestión,
debiendo ser ejecutados exclusivamen-
te por personal especializado del Servi-
cio Técnico Postventa Oficial. En caso
de tener que sustituir piezas o compo-
nentes defectuosos del sistema de do-
ble aislamiento, las piezas de repuesto
deberán ser idénticas a las piezas de-
fectuosas que deben sustituir. Los arte-
factos con doble aislamiento están
Instrucciones de Seguridad Importantes
MANTENIMIENTO DE LOS EQUIPOS
DOTADOS DE DOBLE AISLAMIENTO

20 Español
marcados "DOUBLE INSULATION" o
"DOUBLE INSULATED". También po-
dría tener el símbolo “ ”.
Este producto se suministra con un inte-
rruptor de circuito de avería por puesta
a tierra montado en el enchufe del cable
de potencia. Este aparato proporciona
una protección adicional contra el ries-
go de electrochoque. Si la corriente se
interrumpe en la línea, el interruptor de
circuito de avería por puesta a tierra vol-
verá a cerrar, automáticamente, el cir-
cuito a la carga una vez restablecida la
corriente. Si es necesario reemplazar el
enchufe o el cable, utilice piezas idénti-
cas.
ATENCIÓN
Al conectar la toma de agua a la red de
suministro del agua, es obligatorio res-
petar la normativa local establecida por
la compañía del agua. En algunas zo-
nas, está prohibido conectar la unidad
directamente a la red pública de sumi-
nistro de agua potable. Esto es así para
garantizar que no penetren sustancias
químicas en la red de suministro del
agua. Sí se permite efectuar la co-
nexión directamente por ejemplo a tra-
vés de un depósito receptor o un
dispositivo antirretorno.
Si el agua de alimentación está sucia, la
unidad sufrirá daños. Para evitar este
riesgo, le recomendamos que monte un
filtro de agua.
La manguera de agua tiene que te-
ner al menos 1/2 (5/8) pulgadas de
diámetro.
El caudal de agua no debe ser infe-
rior a 450 l/h (litros por hora).
El caudal de agua se puede determi-
nar llenando de agua un recipiente
vacío de 8 litros durante un minuto.
La temperatura de la toma de agua
no debe sobrepasar los 104°F/40°C.
No utilice nunca el limpiador a pre-
sión para aspirar agua contaminada
con disolventes como, p. ej., diluyen-
tes de pintura, gasolina, aceite, etc.
Evite siempre que la unidad aspire re-
siduos utilizando una fuente de abas-
tecimiento cuya agua esté limpia.
ÎPASO 1:
Colocar y encajar las ruedas en el
alojamiento para los ejes.
Protección mediante interruptor de
circuito de avería por puesta a tierra
SUMINISTRO DE AGUA
(sólo agua fría)
Instrucciones de Montaje
