KARE design Edward 83370 User manual

83370-Edward Sideboard
1 x1 2 x2
T2 1 Piece
10 Pieces
H4
H3 2 Pieces
H2 4 Pieces
H1 2 Pieces T1 1 Piece
H1
H2 H3
T1

H4
T2

NOTE: Wall Fixings are not supplied with this product as different
wall materials require different types of fixing devices (such as
Rawl plugs on brick work) You must use fixing devices suitable for
the type of wall you intend to mount this product to. Please ensure
that the head of any screw used has a diameter greater than the
diameter of the mounting hole on the product and that the fixing is
safe and secure before use.
The strap and screw which to fix the strap on to the
furniture are provided only.
Insert screw through
washer into hole in wall
Drill a hole in the
wall and insert the
rawl plug .
HARDWARE LIST
2 X
Screw
2 X
Washer
STEP : 3
Rawl Plug
Wall
Make a mark on
the wall through
the strap .
STEP : 2
Wall
TIP STRAP FITTING INSTRUCTIONS
2 X
Strap
Wall
Cabinet Top
Cabinet Top
Cabinet
Top
Cabinet Top
