Karma PA 8800 User manual

Instruction manual
E
www.karmaitaliana.it
PA 8800
Stereo Amplier

3
2
Congratulation for your choice!
Congratulations for your choice! The Karma product you have purchased
is the result of careful planning by specialized engineers.
High quality materials have been used for its construction, to ensure its
functioning over time. The product is manufactured in compliance with
strict regulations imposed by the European Union, a guarantee of reliability
and safety.
Please read this manual carefully before starting to use the xture in order
to exploit its full potential.
Karma has several products’ accessories that can complete your device.
We invite you to see the whole range of our products by visiting our website:
www.karmaitaliana.it
where you will nd , in addition to all our items, detailed descriptions and
further documents related to the product.
We hope that you will be satised with your purchase and we thank you
again for your trust in our brand.

Ulteriori informazioni su: www.karmaitaliana.it
3
2
Precauzioni ed avvertenze
Safety notes
• Keep this User Manual for future reference. If you sell the product to
another user, be sure to give this manual to the next owner.
• Make sure the voltage of the power source used for the product is
correct.
• This product is not suitable for outdoor use.
• To avoid the risk of re or short-circuits never expose the xture to
rain or moisture.
• Do not operate the product in an ambient temperature higher than
35°.
• In the event of a serious operating problem, stop using the product
immediately. Never try to repair the product, but contact the
authorized technical assistance center.
• Repairs carried out by untrained people can lead to damage both to
the xture and to persons.
• Make sure the power cord is not damaged.
• Never disconnect the product from the power source by pulling on
the cord
CAUTION:
When you receive the product you have to check carefully
that the parcel is not damaged from shipping or open. Even
if the packaging is not damaged you have to check the
product’s conditions within three (3) days from the reception.
For any kind of problem found on the item, it is necessary
to address a claim to the seller and to our o󰀩ces (also by
e-mail), describing in detail the damage. Any claim received
beyond the 3-day time limit, will not be accepted. It is
suggested to save all the packaging, labels, delivery bill and
all that can be useful to solve quickly the problem.

5
4
Simbologia
This symbol alerts you to the presence of important operating and
maintenance, in the manual or in the documentation accompanying
the product
This symbol indicates that the product complies with international
standards RoHS (Restriction of certain Hazardous Substances)
which restricts the use of certain hazardous substances in electrical
and electronic equipment put on the European market from 1 July
2006. It is part of a series of EU Directives and environment and
‘ closely connected to the WEEE Directive ( Waste Electrical and
Electronic Equipment).
The symbol of the crossed-out dustbin indicates that the product
at the end of its life must be collected separately from other waste
. The user must , therefore , take the remote control integrates the
essential components come to an authorized disposal center for
collection of waste electronic and electrical , or returning it to the
dealer when buying new equipment of equivalent type , at a rate of
one to one. Appropriate separate collection for the decommissioned
equipment to recycling , treatment and environmentally compatible
disposal helps to prevent negative impact on the environment and
human health and promotes recycling of the materials making
up the product. Illegal dumping of the product by the user entails
the application of administrative sanctions pursuant to Legislative
Decree n . 152/2006 ( Art.255 Part 4 )
The CE mark indicates that this product complies with the European
Community standards EMC ( Electromagnetic Compatibility)
and LVD ( Low Voltage Directive ). Compliance documentation in
complete form is available at the company Karma Italian Srl.

Ulteriori informazioni su: www.karmaitaliana.it
5
4
Prodotto
Pannello frontale
Pannello posteriore
N° Function / Description N° Function / Description
1 Rack holes 14 XLR input
2 Fans 15 Ground button
3 Level regulators 16 Stereo / Bridge selector
4 Dangerous volume level 17 Sensibility button
5 Alert volume level 18 XLR input
6 Normal volume level 19 jack 6,3 mm for IN signal
7 Tasto di accensione 20 Circuit breaker
8 Handles 21 Power cord
9 Led PAR 22 CH-B Speakon exit
10 Led Power 23 Exit
11 Led Bridge 24 CH-A Speakon exit
12 Limiter 25 Bridge plugs
13 jack 6,3mm input
13 14 15 16 17 1918
2524232221
12
20

7
6
Instructions
1. When you carry the amplier, use the handles (8) for a safe grip. In
case of mounting on a standard 19” rack use the holes (1) for correct
fastening.
2. By using the 6,3mm jack sockets (13-19) you connect the audio
signal coming from a source you wish to amplify. You can connect to
these sockets unbalanced signals. If you have devices with balanced
signal use the XLR sockets (14-20).
3. The switch (15) allows to enable or disable the connection of the
ground to the amplier’s chassis in case of background noises.
4. Connect your speaker to the back speakon sockets (22-24) or to the
clips (23). If you wish to use the amplier combined with a subwoofer
(mono) you can exploit the bridge socket (25), where the full power
of the amplier will be conducted. In this case put the switch (16) on
BRI.
5. Once completed the connections, plug the power cable (21) into the
230V mains.
6. Warning: check the level of the output signal coming from the audio
source and set the proper sensitivity level, through the selector (17)
on one of these values: 1,40V - 1,0V - 0,77V. The usual standard
value is 1,40V.
7. Use the limiter (12) to reduce the possibility of clipping or overloading
on the channels.

Ulteriori informazioni su: www.karmaitaliana.it
7
6
Instructions
1. To turn on the amplier use the ON/OFF button. The front POWER
led (10) will light on to indicate that the device is on.
2. If you use the amplier in bridge the BR front led (11) will light on.
Otherwise, with a stereo use, the PAR led (9) will be enabled.
3. Check, through the led Vu meters (6), that the amplied signal is
not too high. In this case the CLIP leds (5) will light on. Act on the
volume controls (3) on the right and left channels and reduce it.
4. In case of overloading a safety switch could spring to protect the
amplier. The PROT(4) leds will light on. If this happens, switch o󰀨
the amplier through the button (7) and use the button (12) to re-
enable the amplier.

9
8
Warranty certicate
The product is covered by
warranty, according to the current
regulations. We suggest to keep
the receipt or the invoice in order
to use it, in case of necessity, as
purchase proof.
Damages caused by negligence
or wrong use of the device are not
covered by warranty.
The warranty is no longer
e󰀨ective if the item is modied or
disassembled by not authorized
people.
This warranty doesn’t envisage the
product’s replacement.
External components, batteries,
knobs, switches and any removable
or subject to wear and tear parts
are excluded from warranty.
Shipment for the return of faulty
items is at expense and risk of the
owner.
For all intents and porpuses the
warranty is e󰀨ective only upon
exhibition of the invoice or of the
purchase receipt
COME PROCEDERE ALL’INVIO
DEL MODULO DI REGISTRAZIONE
PRODOTTO:
1) Nel caso in cui non abbiate e󰀨ettuato
la registrazione del prodotto sul nostro
sito www.karmaitaliana.it Vi invitiamo
a farlo ritagliando il modulo riportato
nella pagina accando e ad inviarlo
presso i nostri u󰀩ci.
2) Ricordatevi di compilare entrambi i
moduli in quanto una copia rimarrà
legata al manuale e potrà servirvi in
futuro.
Guarantee

Ulteriori informazioni su: www.karmaitaliana.it
9
8
CERTIFICATO DI GARANZIA GUARANTEE CERTIFICATE CERTIFICATO DI GARANZIA GUARANTEE CERTIFICATE MODULO DI REGISTRAZIONE REGISTRATION MODULE MODULO DI REGISTRAZIONE REGISTRATION MODULE
COPIA DA INVIARE A: COPIADACONSERVARE
Spett.le KARMA ITALIANA Srl Via Gozzano, 38 bis 21052 - Busto Arsizio (VA)
%

11
10
Speciche Tecniche
Speciche tecniche Speciche tecniche
MODELLO / MODEL MODELLO / MODEL
DATA D’ACQUISTO PURCHASING DATE DATA D’ACQUISTO PURCHASING DATE
N. SCONTRINO O FATTURA RECEIPT/INVOICENUMBER N. SCONTRINO O FATTURA RECEIPT/INVOICENUMBER
TIMBROEFIRMADELRIVENDITORE DEALER’S STAMPAND SIGNATURE TIMBROEFIRMADELRIVENDITORE DEALER’S STAMPAND SIGNATURE
ACQUISTATO DA / PURCHASED BY ACQUISTATO DA / PURCHASED BY COGNOME / SURNAME COGNOME / SURNAME
NOME/ NAME NOME/ NAME
VIA / ADDRESS VIA / ADDRESS
N° N°
PROV. PROV.
CITTÀ / CITY CITTÀ / CITY
C.A.P. / ZIP CODE C.A.P. / ZIP CODE
PA 8800 PA 8800

Ulteriori informazioni su: www.karmaitaliana.it
11
10
Technical specications
PA 8800
Max power: 2 x 1200W
Power supply: AC 230V - 50 Hz
Frequency responce: 10 Hz - 50 KHz
IN Plugs XLR + Jack 6,3mm
OUT Plugs Standard + Speakons
Rack space 2U
Bridge modality Si
Dimensions: 482 x 430 x 88 mm
Weight: 15 Kg
Karma Italiana srl, in order to improve its products, reserves the right to modify the
characteristics whether technical or aesthetic , at any time and without notice.
www.karmaitaliana.it

ver. 16.1
Via Gozzano 38 bis
21052, Busto Arsizio (VA) - Italy
Telefono +39 0331.628.244
Fax [phone]
www.karmaitaliana.it made in China
