Karol K08 Assembly instructions

K08
Instructions of assembly

We disclaim all responsibility if the assembling is not carried out as advised.
Assembling instructions for hanging vanity units “K08”
Assembling
1) Fix the “A” bracket to the wall at wished height.
PLEASE NOTE: it is very important to mount the bracket levelled.
2) Open the drawers and the large pull-out drawers “B”
completely, push them up and take them out.
3) Place the cabinet on the bracket “A”, mark holes, drill and
insert screw anchors.
4) Place the cabinet on the bracket “A” again, insert screws
and screw.
5) Extract the metallic slides totally and place the drawers
or the pull-out drawers there on.
Then push them to closing. If the drawers do not perfectly
suit, open them totally and close them again.
PLEASE NOTE: If front doors are not perfectly levelled, that
is due to the irregular wall. So, please level them by adjusting
screws “C”.

We disclaim all responsibility if the assembling is not carried out as advised. 1
Assembling instructions for wall cupboards “K08”
Assembling
1) Fix the bracket “A” in line with the wall, mark holes, drill,
insert screw anchors and screw.
2) Connect the wires of the internal lighting kit “E” to the
electric installation.
3) Hang the cabinet on the bracket “A” .
4) If front doors are not perfectly levelled, that is due to
irregular wall. So, level them by adjusting screw “C”.

We disclaim all responsibility if the assembling is not carried out as advised.
2
Assembling instructions for wall cupboards “K08”
Assembling
1) Fix the bracket “A” in line with the wall, mark holes, drill,
insert screw anchors and screw.
2) Hang the cabinet on the bracket “A” by adjusting the
screws “B” from inside to level it.
3) Fix the cabinet by screw “C”.
4) If front doors are not perfectly levelled, that is due to
irregular wall.
So, level them by adjusting screws “B” and “C”.

We disclaim all responsibility if the assembling is not carried out as advised. 3
Assembling instructions for mirrors-cabinets “K08”
Assembling
1) Fix the bracket “A” in line with the wall, mark holes, drill,
insert screw anchors and screw.
2) Hang the cabinet on the bracket “A” .
Wall cabinet’s side
Wall
Wall
Wall cabinet’s side
