Karol SIGNATURE User manual

SIGNATURE
Manuale d’installazione
Installation Manual

I
EN
ATTENZIONE
Si declina ogni responsabilità nel caso il montaggio non sia eseguito come da istruzioni ripoirtante nel presente documento.
ATTENTION
Karol Italia srl disclaims all liability in case of wrong installation.

Attenzione: Vericare, prima di completare l’installazione l’altezza nale desiderata.
 Tecnico qualicato in grado di installare il prodotto alle condizioni normali, di intervenire sugli organi meccanici per e󰀨ettuare tutte le
regolazioni, interventi di manutenzione e riparazioni necessarie.Non è abilitato ad intervenire su impianti elettrici in presenza di tensione.
Tecnico qualicato in grado di installare il prodotto alle condizioni normali. E’ preposto a tutti gli interventi di natura elettrica di regolazione,
di manutenzione e di riparazione. Previa aduzione di misure di protezioni idonee, in caso non sia possibile operare in assenza di tensione, che sia in grado di operare
in presenza di tensione all’interno di armadi o scatole elettriche.

Attention: Before completing the installation, check the nal height.
A skilled technician capable to install the product under normal conditions and carry out all adjustments, maintenance and repair jobs on
mechanical parts as necessary. The technician is not authorised to work on live electrical systems.
A Specialist technician capable of installing the product under normal conditions, is responsible for all electrical work, such as setting,
maintenance and repairs. After implementing suitable protection measures, if it is not possible to operate with the power supply disconnected, the electrical installer
is able to operate in the presence of live parts inside cabinets or electrical boxes.

ITALIANO
ENGLISH
INDICE
Montaggio basi ____________________ Pag.4-5
Giunzioni tra i mobili _________________ Pag.6
Regolazioni del cassetto ______________ Pag.7
Montaggio colonne _________________ Pag.8-9
Montaggio anchi di nitura_________ Pag.10-11
CONTENTS
Cabinets installation ________________ Pag.4-5
Connections between cabinets _________ Pag.6
Drawer adjustment __________________ Pag.7
Tall units installation_________________ Pag.8-9
Additional sides installation _________ Pag.10-11

IT
STEP 1
● Please follow the exemplifying drawing
to determinate the height of the bar, considering
the desired installation height of the basin
(in our drawing the basin is installed at 900 mm from
the oor and the top is thick 12 mm).
● Place the bar in line with the wall
(with the help of a spirit level).
Mark with a pencil the position of the holes (see image
1).
In our exemplifying drawing the holes on the
wall are at H.673 mm from the oor.
●The dowels and the screws supplied by Karol
can be used or not at the installer’s descretion
( this depends on the type of wall where the cabinet
should be mounted).
CABINETS INSTALLATION
Fig. 1
Detail of the wall bar and holes
ATTENTION
The bar’s width changes according

Side of the cabinet
holes of the bar
BASIN

IT
FASE 2
● Lean the cabinet against the wall and hook it to
the wall bar using the hanger ttings of the cabinet
(see image 1)
● Adjust the height of the cabinet (see Reg.1)
● Fix the cabinet on the wall bar using the horizontal
adjustment (see Reg.2)
CABINETS INSTALLATION
Fig. 1
Fig. 2
Reg.1
Reg.2
Position of the cabinet’s hangers
DETAIL OF THE ADJUSTMENTS
● Height Adjustment: to level the cabinet (see Reg.1)
● Fixing the cabinet on the wall bar (see
image Reg.2): moves the cabinet away from the wall
and it blocks the cabinet (horizontal adjustment)

IT
DRAWER ADJUSTMENT
Adjust the drawer/s using the mechanisms

Image A
1 - Height adjustment (up-down) of the drawer front
To adjust the vertical distance of the drawer
from the cabinet .
2 - Horizontal adjustment (right-left) of the drawer
front.
3 - Tilting adjustament of the drawer front.
Fig. B
Position of the covering plates for the adjustement
mechanisms.
Cabinet
Fig. A
Fig. B
Fig. A e B
Fig. A e B
