Kathrein AVH 06 User manual

1 / 4
AVH 06 207500001
Band III TV antenna, suitable for DAB+
Features
•Outdoor antenna
•Suiable for DAB+
•Suitable for vertical (pre-installed) and horizontal polarization
•Easy installation
About This Manual
This document is part of the product and describes how to
install and connect the AVH 06 Band III TV antenna.
►Do not install or use the device until you have read and
understood this document.
►Keep this document for reference throughout the service life
of the device and pass it on to any new owner or user.
For the most up-to-date version of this document, go to
www.kathrein-ds.com
Scope of delivery
•Band III TV antenna AVH 06
•F-type screw-on connector for cable LCD 90/111 A+/115 A+/120 A+/130 A+, KEC 120 A+
•Weather protection sleeve
•Instructions for use
Transport and Storage
►Use the original packaging for transporting the device.
►Store the antenna in a dry place and protect it from mechanical damage.
Intended use
The AVH 06 is a Band III TV antenna. The antenna is solely designed for the limited purpose of receiving terrestrial TV and DAB+
signals and as indoor antennas. Under the terms of DIN 4131, an indoor antenna is defi ned as an antenna if the mast length does not
exceed 6 meters and if its fi xed end moment is at 1,650 Nm maximum. Any other use or non-observance of these instructions und
der den Geräten beiliegenden Dokumentation will result in the loss of the warranty and guarantee. The following circumstances lead
to the loss of warranty and liability claims against the manufacturer:
►Improper installation
►Use of unlisted fixing material, which means that mechanical safety cannot be guaranteed
►Structural changes or interventions in the antenna, which can endanger both the mechanical and electrical as well as the func-
tional safety
►disregarding the assembly and safety instructions in this manual
Safety Instructions
ATTENTION! DANGER FOR LIFE!
Do not under any circumstances mount an antenna under power lines. Touching power supply lines with parts of your
body, with antenna parts or tools may cause an electrical shock or serious burns.
Ground the antenna installation according to DIN EN 60728-11!

2 / 4
Please read the following safety instructions carefully and thoroughly before you start installing the antenna, and keep
observing them during the installation!
The installation of the antenna demands a high degree of responsability for yourself and other people. For this reason, the instal-
lation must be executed by an electrician (expert in his/her trade). In order to assist you, some important safety instructions have
been compiled in the following. However, these instructions are not exhaustive, as we are not aware of the local conditions.
►Do not use the antenna for purposes other than intended by the manufacturer.
►Only use the components as prescribed by the manufacturer and do not modify them.
►When selecting the antenna site, take account of the building‘s structural characteristics. Installation on the edge of
cylindrical structures could lead to increased wind loads and vibration stress according to DIN 1055, part 4, DIN 4131.
Non-observance of these instructions may cause exceeding of the load limit or the vibration resistance.
►Do not mount the antenna on buildings with rooftops made of easily infl ammable materials (e.g. straw, reed or
similar materials).
►Only step on fi rm, dry rooftops and protect yourself against falling down
►To ensure safety, ladders, scaoldings, safety belts etc. must be in good structural order.
►Passers-by must not be endangered by falling objects. Secure the work/danger area!
►Ensure that the technical values (e.g. wind load) of the antenna mast are not exceed. Consult the manufacturer
if you do not know these values. See „Suitable Kathrein masts“ on page 4 for an overview of the masts oered by
KATHREIN Digital Systems.
►Mount the antenna mast on solid ground only (walls, concrete, rafters) using the clamps, dowels and screws recom-
mended by the manufacturer
►Immediately leave the roof in case of a thunderstorm!
Mast installation and mast calculation
•Make sure masts is in vertical position when installing it
•Only use masts or standpipes specially designed for antenna
installation. Other tubes mostly do not have the necessary
stability to withstand heavy wind or other climatical situations.
Kathrein masts and clamps fulfi ll these requirements. See
„Suitable Kathrein masts“ on page 4 for an overview of the
masts oered by KATHREIN Digital Systems.
•The clamping range of the AVH 06 masting clamps is 22 to
55 mm
•If the mast is to be mounted on a roof, at least 1/6 of its length
must be clamped
•Make sure that the mast holders (e.g. clamps) are mounted on
solid ground (wood, concrete, walls)
Never exceed the maximum load capacity of the
mast or clamps when mounting several antennas
on the mast.
The bending moment aects the mast on the
upper attachment point for all antennas. The wind
load on the mast must be included in the calcula-
tion.
The overall bending moment is not to exceed the
maximum permitted bending moment of the mast
and must not be greater than 1,650 Nm. If the
bending moment is greater, a static engineer is
required to provide verification of the transfer of
forces into the structure of the building.
CAS 80gr
SAT antenna
Olympia 150
AVH 06
ABA 20
Mast ZSH 59
AOP 65
1138 Nm
Admissible: 1280 Nm
25 N x 4,0 m = 100 Nm
33 N x 3,6 m = 119 Nm
103 N x 2,8 m = 289 Nm
450 N x 1,4 m = 630 Nm
1,4 m
(Middle of the reflector)
1,0 m
2,8 m
3,6 m
4,0 m
According to EN 60728-11, the fixing range
of the antenna mast be at least 1/6
of the total mast length.
M = W x a + W x a + W x a + ...
b
1
1
2
2
3
3
= Bending moment
= Given windload in catalogue
= Mast length from the antenna to
the mast fixing point
M
W
a
b
1,2,3
1,2,3

3 / 4
Antenna installation
1. Unpacking the antenna
2. Turn the rods by 90°, push them in the middle (observe
marking) and tighten the screws
3. Dipole mounting (Position according to picture)
4. Connect the cable to the F-socket, put the weather
protection sleeve on
The antenna can also be mounted horizontally. For this purpose the mast clamp must be turned by 90°.

www.kathrein-ds.com | [e-mail] 936500054/a/STM/0520/GB |Subject to change.
KATHREIN Digital Systems GmbH | Anton-Kathrein-Str. 1–3 | 83022 Rosenheim | Germany | Phone [phone]
Technical data
Type | Order no. AVH 06
207500001
Channels 5 - 12
Gain dB 4 - 6
Elements 4
Reception range MHz 174 - 230
Half-power beam width Horiz.°/vert.° 60/95
Front-to-back ratio dB 15
Mast clamp range mm ∅22 - 55
Length mm 755
Wind load N 33 (at 130 km/h wind speed)
Packing unit/weight pc./kg 1/0.61
Packing unit dimensions mm 1014 x 104 x 59
Electronic equipment
Electronic equipment is not domestic waste – in accordance with directive 2012/19/EC OF THE EUROPEAN PARLIAMENT
AND THE COUNCIL dated 04th July 2012 concerning used electrical and electronic appliances, it must be disposed of
properly. At the end of its service life, take this unit to a designated public collection point for disposal.
Disposal
Repair and replacement
autronic electronic-service GmbH
Hauptstraße 2a
35792 Löhneberg-Obershausen
Germany
Phone: [phone]
Fax: [phone]
Email: [e-mail]
Suitable Kathrein masts
1) Only the upper mast can be used, as the diameter of the lower mast is too large for the mast clamp.
Flat roof antenna mount:
• ZAS 140
Mast tubes:
• ZAS 05
• ZAS 06
Plug-in masts:
• ZSA 21
• ZSA 46
Booms:
• ZTA 11
• ZTA 12
The following masts can be used in conjunction with the AVH 06:
Extending masts:
• ZSD 48
• ZSF 47
• ZSF 48
• ZSH 47
• ZSH 48
• ZSH 59 1)
• ZSH 61 1)
Rafter brackets:
• ZAS 40
• ZAS 41
Further information and the technical data for the masts can be found at https://www.kathrein-ds.com.
