FDY10 Battery Tester
User Manual
Version: 2.0

SUMMARIZE:
FDY10 S Battery tester structural design in reasonable, easy to carry, may detection battery capacity, can
measure battery discharge time and discharge AH. Comprehensive detection and measure two function new
type measure equipment . Can adaptive from 1V to 20V voltage range different varieties different types,
measure battery varieties: Ni Cd, Li Ion, Pb, Ni Mh, Ag Zn, LMP, Li po, Pb... Measure current range from
0.1A to 10A auto constant current, set stop discharge voltage range from 0V to 20V,when discharging LED can
real time display battery voltage ,Current, Power, AH and total time. When stop discharge LED display AH and
FEATURES:
Structure extremely compact, easy to carry.
Main tester and heating load kit separation desig
Use 4 wire measurement, eliminating the voltage drop due to the internal resistance of the cable (the connection
between the battery and the tester) measurement error, more accurate measurements.
Display part use 6 LED indicator and 4 Digital display, 6LED indicator show display details, 4
battery parameter in resolution 0.01V, 0.01A.
Automatic switching display all the battery main parameter: volt, amp, watt, AH, running hour.
With BUZZER warning when discharge process stop.
Support 2 Wire and 3 Wire connection mode, 3 wiring mode provides wider voltage measure range.
Battery voltage automatically adapt, product automatically adapt to 12V and 16V, automatically set stop discharge
voltage to 10.5V or 14V.
With quickly test function, in 1 to 10 minutes test battery capacity.
Constant resistance mode, can shield PWM CC function, user can free to select different
to different battery.
discharge time.
Digital display show
resistance according
TESTER VIE

Battery over voltage protection: when connection battery voltage more than 20V, tester will lock the discharge process
over 40V will damage product
Build in reverse polarity protection function: When battery positive and negative polarities wiring wrong the test meter
will not damage, but please don't keep this condition in long time.
Display model: user free to change main display use and key. Or set automatic
switching mode show the battery parameter in turn.
SPECIFICATION:
Set the battery discharge current:
If the measured battery voltage is low, user can free to set current between 0.1A ~ 10A; If the battery
user can free to set current between 0.4A ~ 10A. Step value in setting
mode is 0.1A, press and hold can faster set step in
1A, If open the constant resistance function mode, the setting is invalid, actual discharging current is determined by the
resistance of the
battery voltage and external power, please refer the detail in OPERATION section.
Stop discharge voltage: 0.00V to 20.00V, voltage setting step in 10V is 0.01V; setting step over
voltage over 10V,
10V is 0.1V.
Measuring voltage accuracy: 4 Digital display, 10mV to 20, accurate 10mV, error 0.5%.
Measuring current accuracy: 4 Digital display,0A to 10A,accurate to 10mA, error 1%.
Measuring power accuracy: 4 Digital display, accurate to 100mW.
10mAH, more than 100AH, accurate mAH, maximum,
Battery capacity accuracy: less 100AH accurate to
Discharge time display: Hour (2 digital): Minute (2 digital), for example 02:15, means two hours fifteen minutes.
Voltage automatic recognition: in setup model open automatic recognition, less than 15V battery is recognition 12V
battery. More than 15V battery is recognition 16V battery.
Notes: This function only work when power on, please use 2 wire connections.

Star/Stop: Press "OK" key for start, press again stop. Time and capacity is accumulate, press and hold
reset the memory, or auto reset when power off.
Discharge warning’s: the display flick and buzzer warning when discharge stop, press any key to stop warning.
External power resistance cooling model: when discharge process the resistance is very hot!
Please avoid touch and place in safety place.
Dimensions: Product: 116*90*40mm, High power resistance: 165*60*30mm
Weight: 190g, High power resistance: 450g
key for
OPERATION:
This product can use external power, in 3 Wire model, if the battery voltage above 5V, do not need external
power, use 2 Wire.
Following operation guide use 2- ire model:
1.- Set Product wire jump to 2 Wire mode.
2.- First wiring 1Ω/200W resistance, then wire battery to tester, positive and negative polarities wiring correct.
Notes: please check reliable connection of the wiring, or will damage the connection terminal!!
3.- After power on the tester will automatic work, default display voltage value, stop discharge voltage is 10.5V.
Default discharge current is 10A.
4.- If want to change current, press key, LED lamp "A" is flashing
Then press and key, to set quick discharge amp value: 1A, 2A10A.
Press "OK" key enter quit. this is quickly setting mode, if want to set detail amp value in step
100mA, please access the setup mode.
Notes: If want to change stop discharge voltage, also need access setup mode.
5.- Access setup mode: press and hold "OK" key, voltage LED lamp flashing, means now In
setup mode. Press "
OK" key to select different setup function:
5.1.- Function 1 (setup battery stop discharge voltage):
Press key and key increase and decrease voltage value, press and hold key can
change value quickly. When voltage precision is 10mV less than 10V setting, over 10V, for
quickly setup voltage step value is 100mV.
Digital display Voltage Current ES-n AU-n F-00 Cr-n
LED "V" flashing "A" flashing / / / /
Function 1 2 3 4 5 6
Introduction Stop discharge
voltage
Discharge
Current
Save quit Automatic
voltage
recognition
Quickly test
time(min)
Constant
resistance

5.2.- Function 2 (setup battery discharge current):
Press key and key decrease and increase current value, press and hold can
change value step quickly.
5.3.- Function 3 (save and exit):
After setup finish, press and key change the display show "ES-y", press "OK" key,
means save change and exit setup mode. if you don't want save changes, please press and
hold "OK" key for exit without save.
5.4.- Function 4 (automatic voltage recognition):
Notes: This function default is off, battery voltage is 12V or 16V, and you can open this function.
Press or key change the display show "AU-y", save and exit.
In automatic voltage recognition mode:
5.4.1 If connected battery voltage is 12V, when tester power on, BUZZER will has 1 long
tweet and 1 short tweet;
5.4.2 If connect to battery voltage is 16V, when product on BUZZER 1 long tweet and 2 short tweet.
Notes: Automatic voltage recognition only work when tester power on, change the battery need
power off, so suit in the 2 Wire connection mode.
5.5.- Function 5 (quickly test setup):
Notes: This function default is off, display show "F-00", means not use quickly test function.
Setup value is "F-01" to "F-10", mean discharge time is “1minute” to “10minute”, press or
key set quickly test time, after setup save and exit. In quickly test, quick test time is the
configure time.
5.6.- Function 6 (constant resistance mode)
Notes: This function default is off, tester automatic set PWM, to make sure discharge amp equal
to setup value.
Press key or key, display show "Cr-y", after setup save and exit. The discharge ampere
will determine by the battery voltage and the external discharge resistor, more calculation method
please refer to supplementary explanation.
6.- Finish configure, press "OK" key, LED "RUN" is on, mean the tester start battery discharging,
current can arrive to configuration value in few seconds.
Now press can switch to show different parameters in main dis play. If you want automatic
display, long press key, the BUZZER tweet means tester in automatic display mode, will
show each battery parameter in 3 seconds interval
Notes: AH and discharging time is accumulated value, digital display "." flashing, time display ":"

flashing mean in running mode.
7.- In the process of discharge, battery voltage is decrease, when battery voltage less than
configuration voltage, tester will automatic stop discharge. If use quickly test model, when
time counter to zero will stop battery discharge, display flashing and BUZZER alarm user to
check the result. Tester will show battery capacity, user can press any key stop alarm. And
press key to see each parameter test result.
8.- can reset AH to zero; in discharging time
display screen, press and hold key can reset time to zero.
Notes: Both values will automatic reset to zero after power off.
9.- Remove battery clip, product automatic power off, then can start another battery test.
10.- If user want accurate test result or test low voltage battery like Li battery, we suggest to use
3 Wire connection, in this mode need connect AUX power, other configuration is the same as
the two wire mode.
Product wire jump to 3 Wire mode, connect the DC5V power adapter,(or use your local adapter,
DC output 5~30V) system start discharging.
Notes: In 3 Wire mode, first connected the aluminum resistor and the power adapter, then
configure the parameter values, finally connect the measured battery to start test.
need to manually cleared AH and discharging time when replace the battery.
In AH value display screen, press and hold key
SUPPLIMENTARY EXPLANATION
1. Quickly test is the unique function of FDY battery tester, do not need battery full charged, nor
discharge to stop voltage. If battery SOC is 25% -75%, the test result has higher accuracy.
Notes: Set a suitable discharge amp value and discharge time is necessary to increase the accuracy of test
specifically, because different battery have unique discharge curve, so please try to find the best configuration
value suit for your battery, user can following three principles:
1.1. Different battery has different stop discharge voltage.
1.2. Maximum discharging amp always 1C. For exampl e battery capacity is 3AH, maximum amp
set 3A, and battery discharge time can set 1minute. Set smaller discharge amp and longer
test time will make the test result has higher accuracy, Blue Jay listed below an experience
table, for reference:
Battery types Voltage is 12V Capacity is 12AH Voltage is 3.7V Capacity is 2.5AH
Stop Voltage 10.5V 10.5V 10.5V 3.0V 3.0V 3.0V
Current 10A 5A 3A 2A 1A 0.6A
Test Time 1minute 2minutes 3minutes 1minute 2minutes 3minutes

1.3. If quickly test battery capacity has deviation, you can charge battery full, and do the full time discharging test.
1.4. You can try different Quickly test amp and test time to find the experience value of correct capacity so that
you can establish your own experience in database for test such of similar battery in your application.
2.- If the battery voltage value less than 10V, maximum current is not to 10A,
Calculate Formula: Current = Voltage / Resistance(1 ohm)
For example battery voltage value is 3.7V, maximum current value is 3.7A, you can increase current in following
two method:
2.1. Change smaller resistance, according decrease resistance value can increase discharge amp value.
Notes: when test higher voltage battery must change resistance to 1 ohm or tester will not work.
2.2. If still using the 1 ohm resistor, user can p arallel a 100uH toroid inductor. Only to make sure the toroid
nductor can reach 10A maximum current. Blue Jay also provide this inductance for user testing.
3.- FDY tester provide constant resistance test mode.
In this mode do not use PWM automatic constant current. The battery discharge directly through the connected
resistance, in this model do not use constant current, but also affect the measurement accuracy of the AH.
Current calculation Formula: Current = Battery / Resistance.
ATTENTION:
Do not Reverse polarity when you wiring!!
Do not use this test in over measurement range!!
Under full load discharge mode, the high power resistors temperature is very high, please placed
in a safe place, to prevent scalding accidents.
PARKING LIST:
FDY10 S 1PCS
High power resistance (1Ω/200W) 1PCS
DC5V Power 1PCS
Test clip wire 1PCS
