Keba KeTop T50VGA User manual

KEMRO
KeTop T50VGA
User's Manual V1.50
Translation of the original instructions

Document : V1.50 / article no.: 1000459
Filename : t50vga_bhen.pdf
Pages : 163
.
© KEBA 2009
Specifications are subject to change due to further technical developments. Details presented may be subject to correction.
All rights reserved.
A: KEBA AG, Gewerbepark Urfahr, A-4041 Linz, Tel.: [phone], Fax: [phone], E-Mail: [email protected]
D: KEBAGmbHAutomation,Leonard-Weiss-Straße40,D-73037Göppingen,Tel.:[phone],Fax:[phone],
E-Mail: [email protected]
US: KEBA Corp., 100 West Big Beaver Road, Troy, MI 48084, US, Tel.: [phone], Fax: [phone], E-Mail:
[email protected]
CN: Beijing Austrian KEBA Science and Technology Development Ltd., Room B516, Nan Xin Cang Tower, A22 Dong Si Shi Tiao, Dong Cheng District, Beijing, 100027, P.R. China, Tel. [phone], Fax [phone], E-Mail: chi-
[email protected]
www.keba.com

Record of Revision
Version Date Change in chapter Description changed by
V1.00 08-2006 all newly created sam
V1.10 08-2006 chap. "Introduction",
"Power supply",
"Technical data"
Inserted chap. "Notes on this document", "Power sup-
ply": The WARNING has been changed, "Technical da-
ta / Enabling device ratings": Changes in data
sam
V1.10a 10-2006 chap. "Enabling
switch" Chap. "Example of Connection with PILZ PST1 Control Relay": Con-nector has been renamed in drawing: S19
-> S22
sam
V1.20 03-2007 all Type of USB connector has been added (Mini-B), chap.
"Hardware": correct Windows CE-version (5.0 instead
of 5.2), chap." EU Conformity and Type Examination"
has been added.
sam
V1.30 08-2007 all The style sheet of the document has been changed; The
chap. "Standard keypad", "Back-up battery" and "Junc-
tion Box JB 001" have been added.
sam
V1.40 03-2009 all Insert or adapt requirements (2006/42/EC, EN ISO
13849-1, ZT 05) lb
V1.50 08-2009 all Release lb, kreu,
mahr
KeTop T50VGA Record of Revision
© KEBA 2009
User's Manual V1.50 3

Table of Contents
1 Introduction..................................................................................................................... 11
1.1 Purpose of the document...................................................................................... 11
1.2 Target groups, pre-conditions............................................................................... 11
1.3 Intended Use of the Handheld Terminal............................................................... 11
1.4 Notes on this document........................................................................................ 12
1.4.1 Contents of document............................................................................ 12
1.4.2 Not contained in this document.............................................................. 13
1.5 Documentation for further reading........................................................................ 13
1.6 Definition of terms................................................................................................. 13
1.7 Information about MD 2006/42/EC........................................................................ 13
1.7.1 Which devices have to comply with the new machine directive?........... 14
1.7.2 Quantitative safety relevant specifications for emergency stop-
button and enabling control device......................................................... 14
1.7.3 Relationship between Performance Level and Safety Integrity
Level....................................................................................................... 14
1.7.4 Abbreviations.......................................................................................... 15
2 Safety notes.................................................................................................................... 16
2.1 Representation...................................................................................................... 16
2.2 2.2 General safety instructions.............................................................................. 16
2.3 Personnel safety instructions................................................................................ 18
3 General product description.......................................................................................... 20
3.1 Construction.......................................................................................................... 21
3.2 Ergonomic Features.............................................................................................. 21
3.3 Housing................................................................................................................. 22
3.4 Chemical resistance KeTop T50VGA................................................................... 22
3.5 Operating and Display Panel................................................................................ 22
3.6 Hardware............................................................................................................... 22
3.7 Type Plate............................................................................................................. 23
4 Connection...................................................................................................................... 24
4.1 Cable Entrance Area............................................................................................. 24
4.2 Cable Routing in Cable Entrance Area................................................................. 24
4.2.1 Cable outlet RS-422-A or RS-232-C...................................................... 26
4.2.2 Cable outlet Ethernet.............................................................................. 26
4.3 Power Supply........................................................................................................ 26
4.4 Emergency Stop Button and grey Stop Button..................................................... 27
4.5 Enabling Switch..................................................................................................... 28
4.5.1 Functioning............................................................................................. 29
4.5.2 Example of Connection with PILZ PNOZ s6.1 Control Relay................. 31
4.6 Foreseeable Misuse of Enabling Switch............................................................... 32
4.7 Ethernet................................................................................................................. 33
4.7.1 Wiring diagram....................................................................................... 34
4.8 RS-422-A.............................................................................................................. 34
4.8.1 Wiring diagram....................................................................................... 35
Table of Contents
© KEBA 2009
User's Manual V1.50 5

4.8.2 General information about the RS-422-A interface................................ 35
4.9 RS-232-C.............................................................................................................. 35
4.9.1 Wiring diagram....................................................................................... 36
4.10 Serial port female connector S2 for Debug Interface (RS-232-C)......................... 36
4.11 USB memory sticks............................................................................................... 37
4.11.1 Plug-in the USB memory stick................................................................ 37
4.11.2 Unplug the USB memory stick............................................................... 38
5 Membrane Keypad.......................................................................................................... 39
5.1 Standard Keypad.................................................................................................. 39
5.1.1 Keypad left............................................................................................. 39
5.1.2 Keypad right........................................................................................... 40
5.1.3 Keypad below......................................................................................... 41
5.1.4 Tabulated overview................................................................................ 41
5.2 Robotic keypad..................................................................................................... 44
5.2.1 Keypad left............................................................................................. 44
5.2.2 Keypad right........................................................................................... 45
5.2.3 Keypad below......................................................................................... 46
5.2.4 Tabulated overview................................................................................ 46
5.3 Numbering of LEDs............................................................................................... 48
5.3.1 Standard Keypad.................................................................................... 49
5.3.2 Robotic Keypad...................................................................................... 49
6 Display............................................................................................................................. 50
6.1 Touch Screen........................................................................................................ 50
6.1.1 Touch stylus and cord (KeTop ETP 002)............................................... 50
6.1.2 Touch screen re-calibration.................................................................... 51
7 Software........................................................................................................................... 52
7.1 Windows CE.......................................................................................................... 52
7.2 Generation of Program for Windows CE............................................................... 53
7.3 KeTop API Design................................................................................................. 53
7.3.1 Common data types............................................................................... 53
7.3.2 Handling of Errors.................................................................................. 54
7.4 Functions............................................................................................................... 54
7.4.1 Functions for starting and closing........................................................... 54
7.4.2 Functions for Configuration.................................................................... 55
7.4.3 Functions for Reading the Configuration................................................ 56
7.4.4 Peripheral Functions.............................................................................. 57
7.4.5 LED Functions........................................................................................ 59
7.4.6 Other functions....................................................................................... 60
7.4.7 Functions for Subscribing Events........................................................... 61
7.5 Update API Design................................................................................................ 66
7.5.1 Handling of Errors.................................................................................. 66
7.6 Initialising.............................................................................................................. 66
7.6.1 Functions................................................................................................ 67
7.7 Program for Starting the Application and KeTop API............................................ 70
7.7.1 Functional description............................................................................ 70
7.7.2 Registry entries...................................................................................... 70
7.7.3 Example................................................................................................. 71
7.8 RDP - Connection via Remote Desktop Protocol.................................................. 72
7.8.1 RDP-Server (Remote-PC)...................................................................... 73
Table of Contents KeTop T50VGA
© KEBA 2009
User's Manual V1.506

7.8.2 RDP-Client (PC)..................................................................................... 73
7.8.3 RDP-Client (KeTop)............................................................................... 73
7.9 KVC - KEBA Virtual Channel................................................................................ 78
7.9.1 Events of Server..................................................................................... 79
7.9.2 Data Transmission................................................................................. 79
7.9.3 Example: Interface on Server................................................................. 81
7.10 Remote Software ActiveSync................................................................................ 86
7.10.1 Data connection via RS-232-C debug interface..................................... 86
7.10.2 Data connection via USB client.............................................................. 87
8 KeTop - Specific Operating Instructions...................................................................... 88
8.1 Setting of Date and Time...................................................................................... 88
8.2 KeTop Configuration Tool (ConfigTool)................................................................ 89
8.2.1 Calibration of Joystick............................................................................ 89
8.2.2 Calibration of Potentiometer................................................................... 90
8.2.3 Display Settings...................................................................................... 90
8.2.4 Setting the Handwheel to Zero............................................................... 91
8.2.5 Actions on next Startup.......................................................................... 91
8.2.6 Control of Buttons (Pushbuttons)........................................................... 92
8.2.7 Loading an Image File............................................................................ 93
8.2.8 Version Info............................................................................................ 94
8.2.9 Checking the virtual key code of keys.................................................... 94
8.3 Installation of Programs........................................................................................ 94
8.4 Saving Files........................................................................................................... 95
8.5 Transfering Files................................................................................................... 95
8.5.1 Transfer via external storage device (USB-Stick).................................. 95
8.5.2 Transfer via network connection by SMB acces from PC to KeTop....... 95
8.5.3 Transfer via network connection by access from KeTop to the PC........ 95
8.5.4 Transfer via ActiveSync.......................................................................... 96
8.6 Changeover from KeTop T100.............................................................................. 96
9 Options............................................................................................................................ 97
9.1 Override Potentiometer......................................................................................... 97
9.2 Electronic Handwheel........................................................................................... 97
9.3 Illuminated Push-Button........................................................................................ 97
9.4 Key Switch............................................................................................................ 97
9.5 Joystick................................................................................................................. 98
10 Accessories..................................................................................................................... 99
10.1 Wall Bracket without Height Adjustment plate KeTop WB090, WB095,
WB120.................................................................................................................. 99
10.1.1 10.1.1 Dimensions (mm)...................................................................... 100
10.2 Wall Bracket with Height Adjustment plate KeTop WB 110................................ 101
10.2.1 Height adjustment plate........................................................................ 101
10.3 Junction Box JB 001........................................................................................... 102
10.3.1 Device description................................................................................ 103
10.3.2 Connection........................................................................................... 104
10.3.3 Connection diagram............................................................................. 104
10.3.4 Shielding inside the Control Cabinet.................................................... 108
10.3.5 Mounting Instructions........................................................................... 109
10.3.6 Technical data of Junction Box JB 001................................................ 110
10.4 KeTop CB211 Connection Box........................................................................... 110
Table of Contents
© KEBA 2009
User's Manual V1.50 7

10.4.1 Construction......................................................................................... 111
10.4.2 Interior view.......................................................................................... 112
10.4.3 Technical data of the connection terminals.......................................... 112
10.4.4 Drilling template for wall mounting....................................................... 114
10.4.5 DIN Rail Holder Mounting Set KeTop DR200...................................... 115
10.4.6 Use of Connection Box......................................................................... 116
10.4.7 Minimum Bending Radius of Cable...................................................... 116
10.4.8 Technical Data of Connection Box KeTop CB211............................... 116
10.5 Connection Cable KeTop TTxxx......................................................................... 117
10.6 Intermediate Cable KeTop IC2xx........................................................................ 119
10.7 Download Cable KeTop XD040.......................................................................... 120
10.8 Back-up battery KeTop EPA 001........................................................................ 121
10.8.1 General product description................................................................. 122
10.8.2 Installing the back-up battery in the KeTop.......................................... 122
10.8.3 Run-up behaviour................................................................................. 123
10.8.4 Back-up cycle, battery capacity............................................................ 124
10.8.5 Safety notes......................................................................................... 124
10.8.6 Disposal of the back-up battery............................................................ 124
10.8.7 Technical data...................................................................................... 125
11 Transport Conditions................................................................................................... 126
12 12 Disposal of the KeTop............................................................................................. 127
13 Technical data............................................................................................................... 128
13.1 General data....................................................................................................... 128
13.2 Environmental conditions.................................................................................... 128
13.3 Housing............................................................................................................... 128
13.4 Processor and interfaces.................................................................................... 129
13.5 E-Stop ratings..................................................................................................... 129
13.6 Enabling device................................................................................................... 129
13.7 Accessories......................................................................................................... 130
14 CE Conformity, Directives and Standards................................................................. 132
14.1 European Union Directives................................................................................. 132
14.2 Machinery Safety................................................................................................ 132
14.2.1 "Hazard and Risk Analysis".................................................................. 133
14.2.2 "Principles for the Integration of Safety"............................................... 133
14.2.3 "Technical Construction File"............................................................... 134
14.2.4 "State of the Art"................................................................................... 135
14.2.5 "Recognition of Conformity by means of Harmonised Standards"....... 135
14.2.6 Selection of Performance Level and Safety Categories in ac-
cordance with EN ISO 13849-1............................................................ 135
14.2.7 Application of Handheld Terminals in Special Operating Modes......... 136
14.2.8 Information about the Emergency Stop Button.................................... 137
14.2.9 Application of Emergency Stop Button and Stop Button on the
Handheld Terminal............................................................................... 138
14.2.10 Information about Enabling Devices..................................................... 140
14.3 Electromagnetic Compatibility............................................................................. 142
14.3.1 The electromagnetic environment – interference sources, in-
terference sinks and coupling paths..................................................... 142
14.3.2 EMC measures..................................................................................... 145
14.3.3 EMC measures on KeTop.................................................................... 149
Table of Contents KeTop T50VGA
© KEBA 2009
User's Manual V1.508

14.4 List of the appropriate EC directives and applied standards............................... 153
14.4.1 EC directives........................................................................................ 153
14.4.2 Standards............................................................................................. 153
15 Conformity and Type Examination............................................................................. 155
15.1 EC Conformity Declaration.................................................................................. 155
15.2 EC Type-Examination Certificate........................................................................ 156
16 Test for chemical resistance....................................................................................... 157
16.1 Test procedure.................................................................................................... 157
16.1.1 Test 1................................................................................................... 157
16.1.2 Test 2................................................................................................... 157
16.2 Test results.......................................................................................................... 157
16.3 Touch screen - tested by manufacturer.............................................................. 163
Table of Contents
© KEBA 2009
User's Manual V1.50 9

1 Introduction
1.1 Purpose of the document
This document describes the hand-held terminal KeTop T50VGA.
This document contains all specifications required by machinery directive
2006/42/EC.
1.2 Target groups, pre-conditions
This document is intended for the following persons with corresponding pre-
conditions:
Target group Prerequisite knowledge and ability
Project engineer
Technical basic education (advanced technical education, engineering
degree or corresponding professional experience),
Knowledge about:
●the method of operation of a PLC,
●safety regulations,
●the application.
Start-up technician
Technical basic education (advanced technical education, engineering
degree or corresponding professional experience),
Knowledge about:
●safety regulations,
●the method of operation of the machine or system,
●fundamental functions of the application,
●system analysis and troubleshooting,
●the setting options at the operating devices.
Service technician
Technical basic education (advanced technical education, engineering
degree or corresponding professional experience),
Knowledge about:
●the method of operation of a PLC,
●safety regulations,
●the method of operation of the machine or system,
●diagnosis possibilities,
●systematic error analysis and troubleshooting
1.3 Intended Use of the Handheld Terminal
The intended use of the Handheld Terminal covers tasks like watching and
parametrizing up to operating of machines e.g.:
●Injection moulding machine
●Robots
Introduction
© KEBA 2009
User's Manual V1.50 11

●Machine tools
●Textile machines
●Printing machines
●Theater backdrops
●and similar
in normal operating modes
●Automatic
as well as
●Setting
●Teaching
●Testing
●and similar
in half automatic or manual mode.
Enablingswitchesandanemergencystopbutton(orhalt-button)arethesafety
elements of the device.
The Handheld Terminal is intended for fixed connection to a robot. Handheld
Terminals for temporary connection must not have a red-yellow emergency
stop button. In this case a handheld terminal with grey halt-button is available.
To meet the safety category 3 PL d in accordance with EN ISO 13849-1, the
safety functions are realized with 2 circuits.
The selection of the Handheld Terminal which is suitable for the machine and
the projecting of the additional functions must obey the necessary hazard
analyses and risk assessment bounded by law.
ForintendeduseoftheHandheldTerminalalsopleasepayattentiontochapter
14 "CE Conformity, Directives and Standards" on page 132.
1.4 Notes on this document
This manual is integral part of the product. It is to be retained over the entire
life cycle of the product and should be forwarded to any subsequent owners
or users of the product.
1.4.1 Contents of document
●Safety Precautions
●General Instructions
●Connection
●Membran Keypad
●Display
●Software
●Specific Operating Instructions
Introduction KeTop T50VGA
© KEBA 2009
User's Manual V1.5012

●Options
●Accessories
●Transport Conditions
●Disposal
●Technical Data
●CE Conformity, Directives and Standards
1.4.2 Not contained in this document
●Mask description of the application
1.5 Documentation for further reading
Doc.No. Description Target group
- - -
1.6 Definition of terms
Thisuser'smanualcorrespondstomachinery directive 2006/42/EC.Theterms
used in this manual that come from the machinery directive are the same as
in the preceding MD 98/37/EC.
Within standard EN 60204-1 the following term has changed:
EN 60204-1:1997 EN 60204-1:2006
Enabling device Enabling control device (chapter 10.9)
In order to avoid ambiguity for users this manual still uses the term of
EN 60204-1:1997.
1.7 Information about MD 2006/42/EC
Themachine directive (MD) 2006/42/EC will be valid from 2009-12-29 (without
any transition period). This means that all machines and safety components
that will be brought to market after this date have to confirm this new MD and
its harmonised standards.
For handheld terminals from KEBA this means that besides the new machine
directive also the standard EN ISO 13849-1:2008 will be used.
EN ISO 13849-1 demands for the safety relevant component "enabling switch"
the specification of category and Performance Level (PL) and for emergency
stop-buttons and grey stop-buttons the specification of the B10d-value.
These values can be found within the manuals in chapter 13.5 "E-Stop rat-
ings" on page 129 and chapter Technical data, Enabling device.
Introduction
© KEBA 2009
User's Manual V1.50 13

1.7.1 Which devices have to comply with the new machine directive?
This rule is valid for KEBA and its customers:
Depending on the date the product has been put into circulation the new ma-
chine directive has to be applied or not. If the KeTop will be delivered in its end
use after 2009-12-29, it will be put into circulation newly - even if it has been
sold by KEBA at an earlier date.
●Devices complying with the old MD and that will be sent to KEBA for repair,
can be repaired and delivered in compliance with the old MD.
●Customer sends old device for repair and will receive the same or another,
equal device.
●DevicescomplyingwiththenewMDandthatwillbesenttoKEBAforrepair,
must be repaired and delivered in compliance with the new MD.
1.7.2 Quantitative safety relevant specifications for emergency stop-button
and enabling control device
●Emergency stop-button:
KEBA specifies a B10d-value. Other values (e.g. SIL, PL, Category) can-
not be specified by KEBA.
Explanation: KEBA solely delivers the control element, but no evaluation
of the element. The customer has to connect the emergency stop to his
application on his own. Depending on the connection of the emergency
stop to the machine the SIL- or category and PL-value can be determined.
●Enabling control device:
KEBA specifies category and PL in accordance to EN ISO 13849-1. De-
rived from this value KEBA also specifies a PFH- and MTTFd-value in
accordance to EN ISO 13849-1. SIL (in accordance to EN 62061 or
EN 61508) cannot be specified by KEBA.
Explanation: The enabling control devices has been evaluated in accord-
ance to EN ISO 13849-1. A B10d-value is not available for the enabling
control device, as this device consists of the mechanic element and the
electronic evaluation. This means that KEBA specifies MTTFd- and DC-
values (and derived from these values also Category, PL and PFH) for the
enabling control device as a whole (starting from the pushbutton up to the
clamps within the junction box).
1.7.3 Relationship between Performance Level and Safety Integrity Level
When evaluating safety functions by IEC EN 62601 the PL can be transformed
into SIL by following the equivalence table of EN ISO 13849-1.
Table 4 (EN ISO 13849-1) - Relationship between Performance Level (PL) and
Safety Integrity Level (SIL)
Performance Level (PL) by
EN ISO 13849-1 Safety Integrity Level (SIL) by IEC 61508-1
a no corresponding value
Introduction KeTop T50VGA
© KEBA 2009
User's Manual V1.5014

b 1
c 1
d 2
e 3
Table 3 (EN ISO 13849-1) - Performance Level (PL)
Performance Level (PL) Average probability of a dangerous
breakdown per hour 1/h
a≥10-5 to < 10-4
b≥3 x 10-6 to < 10-5
c≥10-6 to < 3 x 10-6
d≥10-7 to < 10-6
e≥10-8 to < 10-7
1.7.4 Abbreviations
Abbreviation Term
B10d -
MTTFdMean Time to Dangerous Failure
DC Diagnostic Coverage
PL Performance Level
PFH Probability of Failure per Hour
SIL Safety Integrity Level
Introduction
© KEBA 2009
User's Manual V1.50 15

2 Safety notes
2.1 Representation
At various points in this manual you will see notes and precautionary warnings
regarding possible hazards. The symbols used have the following meaning:
DANGER!
●indicates an imminently hazardous situation which will result in death or
serious bodily injury if the corresponding precautions are not taken.
WARNING!
●indicates a potentially hazardous situation which can result in death or se-
rious bodily injury if the corresponding precautions are not taken.
CAUTION!
●means that if the corresponding safety measures are not taken, a potentially
hazardous situation can occur that may result in property injury or slight
bodily injury.
CAUTION
●CAUTION used without the safety alert symbol indicates a potentially haz-
ardous situation which, if not avoided, may result in damage to property.
●This symbol reminds you of the possible consequences of touching elec-
trostatically sensitive components.
Information
Useful practical tips and information
on the use of equipment are identified by the “Information” symbol. They do
notcontain anyinformation thatwarns aboutpotentially dangerousor harmful
functions.
2.2 2.2 General safety instructions
The device was developed, manufactured, tested and documented in ac-cord-
ance with the applicable safety standards. If you follow the instructions re-
garding safety and use as described in this manual (see chapter 1.3 "Intended
Use of the Handheld Terminal" on page 11), the product will, in the normal
case, neither cause personal injury nor damage to machinery and equipment.
The instructions contained in this manual must be precisely followed in all cir-
cumstances. Failure to do so could result in the creation of potential sources
ofdangerorthedisablingofsafetyfeaturesintegratedinthehandheldterminal.
Safety notes KeTop T50VGA
© KEBA 2009
User's Manual V1.5016

Apart from the safety instructions given in this manual, the safety precautions
andaccidentpreventionmeasuresappropriatetothesituationinquestionmust
also be observed.
Handling of KeTop
You have chosen a high-quality KeTop that is equipped with highly sensitive
state-of-the-art electronics. To avoid malfunctions or damage through improp-
er handling, follow these instructions during operation.
WARNING!
The following application areas are expressly excluded for the KeTop:
●Use in areas prone to explosion or fire
●Use in mining
●Outdoor use
Other products must be used for these applications!
The KeTop housing must not be opened (acception: cable entrance area) , as
the KeTop is sensitive to electrostatic discharge.
Safety notes
© KEBA 2009
User's Manual V1.50 17

CAUTION
●Turn off the power supply before opening the cable entrance area of the
KeTop. Otherwise the components could be destroyed or undefined signals
could occur.
●Make sure that nobody can fall over the cable to avoid that the device falls
to ground.
●Take care not to squeeze and thus damage the cable with any object.
●Do not lay the cable over sharp edges to avoid damaging the cable sheath.
●If you do not use the device, hang it into the wall bracket KeTop WBxxx
provided for storage.
●Do not lay down the device with the operating side facing down to avoid
damaging the operating elements.
●Never lay the device onto unstable surfaces. It could fall to ground and thus
be damaged.
●Never lay the device close to heat sources or into direct sunlight.
●Avoid exposing the device to mechanical vibrations, excessive dust, hu-
midity or to strong magnetic fields.
●Never clean the device, operating panel and operating elements with sol-
vents, scouring agent or scrubbing sponges. For cleaning the device, use a
soft cloth and a bit of water or a mild cleaning agent.
●Make sure that no foreign objects or liquids can penetrate into the device.
Check at regular intervals the protective covers of the device, if all housing
screws are firmly tightened and if the housing or the cable entry is damaged.
●If the device shows any defect, please send it, including a detailed error de-
scription, to your supplier or the relevant after-sales service office.
●If the KeTop is equipped with a touch screen, then operate the touch screen
withfingersoruseatouch-pen.Neverusesharpobjects(e.g.screwdriver,...)
for operating the touch screen. This could damage the touch screen.
2.3 Personnel safety instructions
WARNING!
Danger to persons by electric shock!
●Only supply the device with power from voltage sources having protective
extra-low voltage (e.g. SELV or PELV acc. to IEC 61131-2)
●Only connect voltages and circuits which are safely separated from danger-
ous voltages (e.g. by means of sufficient insulation) to connections, termi-
nals or interfaces up to a rated voltage of 50 V.
CAUTION!
Danger of fire in case of component failure!
●In final application, make sure the 24 V DC power supply to the operator
panel is adequately fused! Max. permissible fuse is 3.15 A!
Safety notes KeTop T50VGA
© KEBA 2009
User's Manual V1.5018

WARNING!
●For the right projecting of the Handheld Terminal the manufactorer must
enforce a hazard and risk analysis. The following safety aspects must be
considered:
- Right cable length for limitation of workspace.
- Is an emergency stop button necessary and permissible?
- Is the safety category for the application sufficient?
●From the operating place the operator must have a good view at the hazard
area.
●The device may be operated in faultless condition only and the operating
instructions must be observed.
●The operator must have a sufficient educational level and must know details
of intended use described in the user’s manual.
●The safety advices in the following chapters must be considered absolutely.
●Further informations to safety and EMC are included in chapt. "CE Con-
formity, Directives and Standards". They must be considered absolutely.
Safety notes
© KEBA 2009
User's Manual V1.50 19

3 General product description
The handheld terminal KeTop is a portable operating and display device with
rugged design and Windows-CE compatible electronics. Using a high-per-
formance processor and providing a serial interface and Ethernet, the KeTop
is ideal for a great variety of applications (see chapter 1.3 "Intended Use of
the Handheld Terminal" on page 11).
All tasks can be solved graphically and in color, and operation is intuitive using
a touch screen.
Instead of rotating mass memories such as floppy disk and hard disk drives
that are not suitable for rough environmental conditions, the KeTop uses scal-
able FLASH and RAM banks.
The KeTop provides a Windows CE platform for applications generated with
common visualization tools or with C#, Visual Basic.NET or Visual C++. More-
over, the KeTop can be connected as a client to a Win NT, Win 2000 or
Windows XP server.
Through the use of optional operating and control elements, the KeTop can
easily be adapted to the specific application.
General product description KeTop T50VGA
© KEBA 2009
User's Manual V1.5020
