KEBCO COMBIVERT P6 User manual

COMBIVERT P6
INSTRUCTIONS FOR USE | INSTALLATION P6 PITCH INVERTER
18 / 19 / 23P6 HOUSING G, R
Translation of the original manual
Document 20095484 EN 02

3
PREFACE
Preface
The hardware and software described in this document are products of KEB. The infor-
mation contained in this document is valid at the time of publishing. KEB reserves the
right to update this document in response to misprints, mistakes or technical changes.
Signal words and symbols
Certain procedures within this document can cause safety hazards during the installati-
on or operation of the device. Refer to the safety warnings in this document when per-
forming these procedures. Safety signs are also located on the device where applicable.
A safety warning is marked by one of the following warning signs:
DANGER Dangerous situation, which will cause death or serious injury iif this safe-
ty warning is ignored.
WARNING Dangerous situation, which may cause death or serious injury if this
safety warning is ignored.
CAUTION Dangerous situation, which may cause minor injury if this safety warning
is ignored.
NOTICE Situation, which can cause damage to property if this safety warning is
ignored.
RESTRICTION
Used when the following statements depend on certain conditions or are only valid for
certain ranges of values.
Used for informational messages or recommended procedures.
More symbols
► Thisarrowstartsanactionstep.
• / - Enumerations are marked with dots or indents.
=> Cross reference to another chapter or another page.
Note to further documentation.
www.keb.de/service/downloads

4
PREFACE
Laws and guidelines
KEBAutomationKGconrmswiththeECdeclarationofconformityandtheCEmarkon
the device nameplate that it complies with the essential safety requirements.
The EC declaration of conformity can be downloaded on demand via our website.
Warranty and liability
The warranty and liability on design, material or workmanship for the acquired device is
given in the general sales conditions.
Hereyouwillndourgeneralsalesconditions.
www.keb.de/terms-and-conditions
Furtheragreementsorspecicationsrequireawrittenconrmation.
Support
Although multiple applications are referenced, not every case has been taking into ac-
count. If you require further information or if problems occur which are not referenced in
the documentation, you can request the necessary information via the local KEB agency.
The use of our units in the target products is outside of our control and therefore
lies exclusively in the area of responsibility of the customer.
Theinformationcontainedinthetechnicaldocumentation,aswellasanyuser-specic
advice in spoken and written and through tests, are made to best of our knowledge and
information about the intended use. However, they are regarded as being only informal
and changes are expressly reserved, in particular due to technical changes. This also
applies to any violation of industrial property rights of a third-party. Selection of our units
in view of their suitability for the intended use must be done generally by the user.
Tests can only be done within the intended end use of the product (application) by
the customer. They must be repeated, even if only parts of hardware, software or
the unit adjustment are modied.
Copyright
The customer may use the instructions for use as well as further documents or parts
from it for internal purposes. Copyrights are with KEB and remain valid in its entirety.
This KEB product or parts thereof may contain third-party software, including free and/
or open source software. If applicable, the license terms of this software are contained
in the instructions for use. The instructions for use are already available to you, can be
downloaded free of charge from the KEB website or can be requested from the respec-
tive KEB contact person.
Other wordmarks or/and logos are trademarks (™) or registered trademarks (®) of their
respective owners.

5
TABLE OF CONTENTS
Table of Contents
