KEDSUM Mini Massager User manual

MINI MASSAGER
Relaxation, Anywhere, Anytime

Included in this standard package:
·Device x 1pc
·Large pad x 4pcs
·Small pad x 4pcs
·Electric wire x 2pcs
·USB cable & AC adapter x 1set
·Instruction manual x 1pc
·Collection board for pad and wire x 1pc
Features
·2 output with 16 modes
·20 level intensity
·20 minutes default timer, can adjustable from 10-60 minutes
·Rechargeable lithium battery
·Battery indicator to know when need to recharge battery
·AC adapter 110-240v, USB Charger 5v

Illustrations of the device and accessories:
1. Two output connector 2. USB port 3. LCD screen
4. Battery indicator 5. On/ off switch 6. Intensity adjustment
7. Mode selector 8. Time adjustment 9. Pause switch
10. Pads- sticking board 11. Charger 12. USB cable
13. Massage pads 14. Pad wires
Modes
There are sixteen modes to choose from, there are:
1.Knead: ①Lateral palm kneading ②Flat palm kneading ③Crosscut fist
kneading ④Vertical fist kneading
2.Acupuncture:⑤Acupuncture ⑥Moxibustion ⑦Acupuncture kneading
3.Cupping:⑧Rubbing reduction ⑨Tapping ⑩Fibrillation massage
4.Tapping:⑪Lifting-pinching manipulation ⑫Vibrating manipulation
5.Shiatsu-Deep:⑬Thai massage ⑭Shiatsu
6.Sensitive Parts Massage:⑮Sensitive Parts Massage Mode 1
⑯Sensitive Parts Massage Mode 2

Recommend massage points
LOWER BACK SCIATIC
Modes 1,4,5,6,7,10,11 Modes 1,2,3,4,5

Operating instructions
1. Connect the pads to the wire by snapping them on,
then remove the protective film.
2. Place pads where the massage sensations are desired. And plug
into one of the ports on the device.For additional relief use the
second port and repeat procedure to put on another two pads.
Make sure both pads on the skin and not overlapping. Make sure
your skin is free from any dirt, oil or lotion.
3. Turn the device on by sliding the on/ off switch on the top of the
unit. The unit will be now activated.
4. The "M" cycles through the 6 big
modes, the silver middle button allows choices (from 2 to 4 varietie
s) within that mode, totally 16 small modes.Remember the strength
will default to the lowest setting by each mode selection.
Note: Center button can also be used as a lock key.Press and hold
it for 3 seconds to lock the screen, 3 seconds again to unlock.
5. Once you select a mode, gradually increase the intensity by
pressing the + button; decrease it by pressing ‐button.
6. Recommended application is 10-60 minutes. Increase 10
minutes by each setting. The time remaining is automatically
counted down. Then the unit will automatically turn off after time
finish.

Note:
1.There are 16 modes on the LED screen of the device which are
pictures of rectangle (3 rows of 2 rectangle each). Each rectangle is
a selection of mode but has a selection of variations within it.So it
goes as follows, reading the rectangle from left to right and top to
bottom, like you read a sentence and paragraph.
Mode 1-4 Knead : the 1st rectangle and has 4 settings in it.
Mode 5-7 Acupuncture : the 2nd rectangle and has 3 settings in it
Mode 8-10 Cupping: 3rd rectangle with 3 settings
Mode 11-12 Tapping: 4th rectangle with 2 settings
Mode 13-14 Shiatsu-Deep: 5th rectangle with 2 settings
Mode 15-16 Sensitive Parts Massage : 6th rectangle with 2
settings.
2.To navigate through the modes - After you turn the unit on it starts
in the 1st rectangle. Press the 'M' on the circular directional button
and it will move to the 2nd rectangle and subsequent presses of M
will move it to the next rectangle after, and repeat..
When you are in the rectangle you want, pressing the CENTER
button just below the 'M' will select the settings within the rectangle
that you are in.
For example: to get to the Mode 5-7 Acupuncture, you turn on the

unit, then press the M once to move to the 2nd rectangle and then
use the CENTER button to select the setting you want (Modes 5, 6,
7) since there are 3 settings within that rectangle.
3.INTENSITY of the Mode you select is changed by pressing the " -
" or " + " on the Left and Right sides of that circular directional
button. Each mode starts at the lowest setting.
TIME is defaulted to 20 minutes after you turn the unit on. To
increase the amount of time, press the 'T' on the bottom of the
circular directional button and it will add 10 minutes with each
press.
IMPORTANT! Attach the pads to the wires first before putting on
your body. Plug in the wires to the unit BEFORE turning on the unit.
Turn the unit OFF BEFORE removing the pads or disconnecting
the wires from the pads or the unit.

Precautions
·Do not apply the massage pads near the heart,sensitive parts of
the brain,in the pubic region, over Scarred areas, on the throat or
over the mouth.
·Avoid touching the pads when the unit is on.
·Pregnant women must avoid using this massager.
·Do not use this massager if you have pacemaker or other life
support equipment such as an artificial lung or respirator.
·should not be used while driving, operating machinery, or during
any activity in which involuntary muscle contractions may put the
user at undue risk or injury
·Do not use if you have following medical conditions:
Acute disease, trauma or surgical procedure in past six month
Cardiac dysfunction
Epilepsy
High blood pressure
High fever
cancer
Infectious disease
Malignant tumors
Recent surgery
Skin problems

Pregnancy
Undiagnosed pain syndromes
Abdominal or inguinal hernia
Painful and /or atrophied muscles
Limited range of motion in skeletal joints
·Keep out of the reach of children.
·the unit is not intended for the application of any medical
condition or disease nor is it intended for physiotherapy or muscle
rehabilitation. It is contraindicated for use on any muscle that is
injured or diseased
Maintenance and care
1. When you have finished using the device, turn it off and take off
the pads. Store the unit in a cool, dry place until next use.
2. After usage, please cover the pads with the protective film and
put them back in their zip lock bags. Applying a few drops water
before and after usage will increase the longevity of the pads.
3. Charge the unit at least every 3 month in event it is not used
regularly. You can also use the unit with the wall charger or directly
from your computer using the USB cable.

Troubleshooting
Problem
Cause
Solution
One pad feels stronger than the
other.
This is normal. Different areas of
your body will react differently.
Nothing needs to be done. Make sure the
pads are moist and are making good contact.
During the massage, the skin
feels a painful burning sensation
or the stimulation becomes
weakened.
Adhesive gel pads are not adhering
firmly to the skin. Or the gel pads are
too dry.
Apply a few drops of water to adhesive
surface of each pad and make sure the pads
are pressed firmly to the skin during
application.
Unit is on, but no sensation is felt
in the pads.
Both pads are not firmly on the skin.
Or there is a loose connection. Or
the intensity level needs to be
increased.
Make sure both pads are firmly pressed to the
skin. Make sure all connections are secure
from the unit to the wires and the wires to the
pads. Increase the intensity level.
Adhesive gel pads do not stick to
skin even after cleaning and
moistening the gel pad.
Adhesive gel pads need to be
replaced.
Replace the set of pads. Pads can be
purchased from local distributor.
Unit does not turn on or the
screen is dim.
Battery is low.
Recharge the battery.
Does not provide adequate pain
relief.
Not using it long enough. Not lying
down then massaging neck.
Use your massager 20-30 minutes at a time,
3-6 times per day. Lie on your back for neck
support when you need relief for headaches
or neck pain.
