Keiser 3110 Series User manual

ASSEMBLY INSTRUCTIONS
3110XX
8-foot ceiling
3111XX
9-foot ceiling
Height Clearance 96 in
(2,439 mm)
108 in
(2,743 mm)
Footprint (DxW) 103 in x 71 in
(2,616 mm x 1,804 mm)
Insert Platform
conguration (DxW)
108 in x 71 in
(2,743 mm x 1,804 mm)
Olympic Lifting
Insert Platform
conguration (DxW)
183 in x 100 in
(4,648 mm x 2,540 mm)
Free Space
around Equipment
(recommended) *Multiple Racks may share side Free Space.
INSTALLATION REQUIREMENTS
Note to Installer: Be sure to leave Assembly Instructions with the customer.
Note to Customer: Keep Assembly Instructions for future reference.
Skill level: Professional installation is required by qualied personnel.
Product failure due to improper installation is not covered under warranty.
READ CAREFULLY. KEEP THESE INSTRUCTIONS.
KEISER CORPORATION
2470 S. Cherry Ave.
Fresno, CA 93706
CUSTOMER SUPPORT
If you have any questions regarding the Assembly Instructions
after reading this guide, contact Keiser Customer Support:
1 559 256 8000
[e-mail]
keiser.com/support
Keiser, the Keiser logo, and other trademarks associated with Keiser products referred to in this publication are trademarks of Keiser Corporation.
© Copyright 2020, Keiser Corporation. All rights reserved.
Distribution and copying of this document, use and communication of its contents is not permitted without written authorization from Keiser Corporation. The content
of this document is furnished for informational use only, may be subject to change without notice, and should not be construed as a commitment by Keiser Corporation.
Every effort has been made to ensure that the information in this manual is accurate. Keiser Corporation is not responsible for printing or clerical errors.
315502_A
POWER RACK
KEISER STRENGTH
MODELS 3110XX, 3111XX
3111XX model
Verify planned equipment location is a solid, level, and structurally
sound surface and meets the following dimensions criteria:
72 inches
(1,829 mm)
Sides*
48 inches
(1,219 mm)
Front
12 inches
(305 mm)
Rear

POWER RACK ASSEMBLY INSTRUCTIONS 02
02 — GENERAL INFORMATION
02_INTRODUCTION
02_RECORD YOUR SERIAL NUMBER
02_REGISTER YOUR PURCHASE
03 — IMPORTANT SAFETY
INFORMATION
03_SAFETY & SERIAL NUMBER LABELS
04 — EQUIPMENT SPECIFICATIONS
04_TRAINING SPACE
05 — ASSEMBLY
05_BEFORE YOU BEGIN
05_TOOLS AND MATERIALS REQUIRED
06_PARTS LIST
07_UNPACKING
08_ASSEMBLY PROCEDURE
19 — FINAL INSTALLATION CHECKLIST
Register your product to stay informed of safety notications
and for faster, more accurate warranty service.
Scan the QR Code below to access the interactive online
warranty registration.
https://www.keiser.com/forms/warrantyregistration
KEISER CUSTOMER SUPPORT
1 559 256 8000
[e-mail]
keiser.com/support
After assembly, please record the serial number in the
space provided below.
Extra lines provided for multiple units.
Serial Nos.:
RECORD YOUR SERIAL NUMBER
REGISTER YOUR PURCHASE
Congratulations on the purchase of your new Keiser Power
Rack and welcome to the Keiser family. For your safety,
and to ensure optimal equipment performance, please
read and understand this manual before assembly. If you
have any questions regarding assembly after reading this
manual, our Keiser Customer Support team will be happy
to assist by telephone at 1 559 256 8000, online 24/7 at
keiser.com/support, or by email at [e-mail].
Yours in Health,
Keiser Corporation
INTRODUCTION
GENERAL INFORMATION
CONTENTS
SCAN
KEISER CORPORATION
2470 S. Cherry Ave.
Fresno, CA 93706
Serial Number Location
│ │ │ │ │ │ │ │ │ │ │ │ ││ │ │ │ │ │ │ │ │ │ │ │ ││ │ │ │ │ │ │ │ │ │ │ │ ││ │ │ │ │ │ │ │ │ │ │ │ ││ │ │ │ │ │ │ │ │ │ │ │ ││ │ │ │ │ │ │ │ │ │ │ │ ││ │ │ │ │ │ │ │ │ │ │ │ │
│ │ │ │ │ │ │ │ │ │ │ │ ││ │ │ │ │ │ │ │ │ │ │ │ ││ │ │ │ │ │ │ │ │ │ │ │ ││ │ │ │ │ │ │ │ │ │ │ │ ││ │ │ │ │ │ │ │ │ │ │ │ ││ │ │ │ │ │ │ │ │ │ │ │ ││ │ │ │ │ │ │ │ │ │ │ │ │
│ │ │ │ │ │ │ │ │ │ │ │ ││ │ │ │ │ │ │ │ │ │ │ │ ││ │ │ │ │ │ │ │ │ │ │ │ ││ │ │ │ │ │ │ │ │ │ │ │ ││ │ │ │ │ │ │ │ │ │ │ │ ││ │ │ │ │ │ │ │ │ │ │ │ ││ │ │ │ │ │ │ │ │ │ │ │ │
SERIAL NO.: 888888-88888
MODEL: 003110XXXX

03
POWER RACK ASSEMBLY INSTRUCTIONS
IMPORTANT SAFETY INFORMATION
1. Read these instructions. Keep these instructions.
2. Heed all warnings. Follow all instructions.
3. Professional installation is required by qualied personnel
as dictated by authority having jurisdiction.
4. Safety Glasses required during assembly.
5. For easier installation and personal safety, two people are
required to assemble this equipment.
6. All hardware required for assembly of the equipment has
been provided by Keiser Corp. Use only hardware specied
by Keiser Corp.
7. Tighten all bolts and carefully examine your installation
prior to use of the Power Rack to ensure that it is securely
fastened in place.
8. Never connect Keiser pneumatic equipment to an air
source that is capable of exceeding 120 psi (pounds per
squareinch)/8.27bar.OverpressurizingKeiserpneumatic
equipment may cause tubing to burst, breakage of
equipment,abnormaloperation, orseriousinjury.Useonly
clean, dry, regulated compressed air at the rated pressure
range of 100–120 psi / 6.89–8.27 bar.
9. Replacedamaged,worn,orbrokenpartsimmediatelyusing
only Keiser supplied components. Keep the Power Rack
out of use until repaired.
10. Only use attachments/accessories specied by Keiser
Corporation.
11. Failure to perform the nal installation checklist before
use of the Power Rack will void the warranty and could
result in serious injury.
12. KeiserCorporationisnotresponsiblefordamageorserious
injury caused by incorrect installation, assembly, or use.
13. Use of the Power Rack or any purpose not explicitly
specied by the manufacturer will void the warranty and
could result in serious injury.
14. It is the responsibility of the facility owner or owner of
the Power Rack to instruct users on the safe and proper
operation of the equipment.
15. Users,agents,and/oranyonedirectingtheuse ofthePower
Rackshalldetermine thesuitabilityoftheequipmentforits
intended use, and said parties are specically put on notice
that they shall assume all risk and liability in connection
herewith.
CONVENTIONS USED
This Assembly Instruction contains the following marks:
WARNING: Indicates a hazardous situation that, if not
avoided, could result in death or serious injury.
CAUTION: Indicates a hazardous situation that, if not
avoided, could result in minor or moderate injury.
HEAVY OBJECT: Indicates help is required during lifting
to avoid muscle strain or back injury.
TWO-PERSON PROCEDURE: Indicates help is required
to safely and successfully complete installation.
IMPORTANT: Indicates information considered critical,
but not hazard-related.
Maintain safety and serial number labels. Do not remove
labels for any reason. They contain important information.
If unreadable or missing, contact Keiser Corporation for a
replacement by telephone at 1 559 256 8000, online 24/7
at keiser.com/support, or by email at [email protected].
SAFETY & SERIAL NUMBER LABELS
│ │ │ │ │ │ │ │ │ │ │ │ ││ │ │ │ │ │ │ │ │ │ │ │ ││ │ │ │ │ │ │ │ │ │ │ │ ││ │ │ │ │ │ │ │ │ │ │ │ ││ │ │ │ │ │ │ │ │ │ │ │ ││ │ │ │ │ │ │ │ │ │ │ │ ││ │ │ │ │ │ │ │ │ │ │ │ │
│ │ │ │ │ │ │ │ │ │ │ │ ││ │ │ │ │ │ │ │ │ │ │ │ ││ │ │ │ │ │ │ │ │ │ │ │ ││ │ │ │ │ │ │ │ │ │ │ │ ││ │ │ │ │ │ │ │ │ │ │ │ ││ │ │ │ │ │ │ │ │ │ │ │ ││ │ │ │ │ │ │ │ │ │ │ │ │
│ │ │ │ │ │ │ │ │ │ │ │ ││ │ │ │ │ │ │ │ │ │ │ │ ││ │ │ │ │ │ │ │ │ │ │ │ ││ │ │ │ │ │ │ │ │ │ │ │ ││ │ │ │ │ │ │ │ │ │ │ │ ││ │ │ │ │ │ │ │ │ │ │ │ ││ │ │ │ │ │ │ │ │ │ │ │ │
SERIAL NO.: 888888-88888
MODEL: 003110XXXX
315615

POWER RACK ASSEMBLY INSTRUCTIONS 04
EQUIPMENT SPECIFICATIONS
935 lbs
(424 kg)
94 in
(2,388 mm)
3110 Power Rack
8-foot ceiling
71 in
(1,804 mm)
103 in
(2,616 mm)
955 lbs
(433 kg)
3111 Power Rack
9-foot ceiling
103 in
(2,616 mm)
71 in
(1,804 mm)
106 in
(2,693 mm)
Additional specications, 3110 & 3111 Power Racks:
Cable Resistance Range: 0 - 200 lbs / 0 - 91 kg
Power: Size D Battery, quantity 2
Frame: Powder-coated steel (matte black nish, standard)
Size and weight specications:
Figure 1. Equipment Size and Weight Specication
Figure 2. Training Space
The minimum recommended amount of Free Space around the equipment is 72 inches (1,829 mm) for the sides, 48 inches
(1,219 mm) for the front, and 12 inches (305 mm) for the rear (see Figure 2). Power Racks arranged side by side may share the
Free Space.
TRAINING SPACE
NOTE: Optional Accessories (Dip Bar Station, Land Mine, Chin Up Bar) may require additional Free Space, depending on the accessory type and exercise
routine. Plan space accordingly to allow for a safe workout, free from obstruction.
FOOTPRINT FREE SPACE
12 in
(305 mm)
72 in
(1,829 mm)
72 in
(1,829 mm)
48 in
(1,219 mm)
Power Rack
with Olympic Lifting Insert Platform
Footprint (DxW):
183 in x 100 in (4,648 mm x 2,540 mm)
Footprint (DxW):
108 in x 71 in (2,743 mm x 1,804 mm)
Power Rack
with Insert Platform
Footprint (DxW):
103 in x 71 in (2,616 mm x 1,804 mm)
Power Rack
12 in
(305 mm)
72 in
(1,829 mm)
72 in
(1,829 mm)
48 in
(1,219 mm)
12 in
(305 mm)
72 in
(1,829 mm)
72 in
(1,829 mm)
48 in
(1,219 mm)

POWER RACK ASSEMBLY INSTRUCTIONS 05
ASSEMBLY
BEFORE YOU BEGIN
IMPORTANT:
• Ensure the oor is a solid, level, structurally-sound surface.
• Clear around and above the assembly area of any obstructions.
• Check location meets the Training Space criteria (see Training Space section, page 4).
• Insert Platform or Olympic Lifting Insert Platform congurations: Assemble platform rst as the Power Rack will be
assembled and mounted onto the platform.
EQUIPMENT ANCHORING
The standard Power Rack assembly conguration may be anchored directly onto concrete ooring at the four anchor points
(see Figure 3; anchor bolts not supplied). All other assembly congurations (Insert Platform and Olympic Lifting Insert Platform)
requires the Power Rack to be bolted onto the platform (hardware supplied by Keiser Corp.).
All Anchors Fasteners:
• Use only anchors that are suitable for equipment height
and weight.
• Minimum concrete thickness: 5 in (127 mm).
• Anchors must reach minimum embedment as specied
by the manufacturer to ensure design values are kept.
• Do not reuse anchors as they are designed for one-time
use only.
• Covered oors (wood, carpet, rubber, etc.) — cut out the
oor mount plate pattern to mount equipment directly
onto concrete. Ensure equipment makes full contact with
the concrete oor; no gaps.
• It is the responsibility of the facility owner to adhere to
building codes and ordinances.
All Keiser Racks are designed for stability when used as intended.
Professional installation is required by qualied personnel. Read through these instructions carefully before assembling the
equipment. Heed all warnings and safety information presented in this Assembly Instruction. Do not skip, substitute, or modify
any assembly procedure or steps. Doing so could result in serious injury. Product failure due to improper installation is not covered
under warranty.
TOOLS AND MATERIALS REQUIRED
25 ft-lbs
(34 Nm)
9/16-inch Combination
Ratcheting Wrench
1/2-inch Combination
Ratcheting Wrench
Ratchet Wrench, Extension
with 9/16-inch Socket
Safety Blade
Driver with Phillips Bit
(Required for closed crate only)
Cutting PliersSafety Glasses
Figure 3. Anchor Points of the Power Rack
Hole diameter:
0.50 in / 13 mm
IMPORTANT: Avoid the use of a power drill/driver for driving bolts during assembly to prevent damaging equipment.
OK, so then 9/16" combo ratcheting wrench and 9/16 socket wrench, plus 1/2" socket wrench.
3/16-inch
Allen Wrench
Lint-free cloth9/16-inch Torque Wrench
(Open-End or Crowfoot attachment)

POWER RACK ASSEMBLY INSTRUCTIONS 06
PARTS LIST
Description Description
Qty Qty
FCross Braces 2
CWeight Stacks 2
ERear Posts 2
J
K
L
M
N
O
Top Frames
Power Displays
eChip Set
Extension Strap Set
Barbell Attachment Set
Weight Stack Decals Set
2
2
1
1
1
1
DFront Posts 2
BBottom Frames 2
A
A
B
C
D E
H
G
FJ
K
L
M N
O
I
Power Modules 2
G
H
I
Bench Positioner Bar with Cable Tray
Bar Catch Set
Spotting Bars
1
1
2
NOTE: Optional Olympic Lifting Insert and Insert Platforms (including optional accessories) not shown. Check for any damage or missing
parts. If parts are damaged or missing, contact your local dealer, distributor, or Keiser Customer Support by telephone at 1 559 256 8000.
IMPORTANT:
Power Modules and
Bottom Frames
are connected by
Cables and Wires.
Keep Connected.
Items not to scale
POWER RACK
3110XX model shown, 3111XX similar.
All hardware required for assembly included and fastened on parts (anchor fasteners not included).
Figure 4. Power Rack Parts List

POWER RACK ASSEMBLY INSTRUCTIONS 07
UNPACKING
TWO-PERSON PROCEDURE: Due to the size of the equipment parts, help is required to safely and successfully complete
the assembly procedure.
HEAVY OBJECT: Help is required during lifting to avoid muscle strain or back injury.
IMPORTANT: Crate conguration varies based on customer order and shipping destination. Do not discard shipping crate
materials or hardware until assembly is successfully completed.
UNPACKING: Position the shipping crate in a cleared area. Open crate to expose the equipment as shown in Figure 5. Remove
all parts from the crate by releasing all cable ties, shipping material, and wood screws.
Unbolt Weight Stacks from Posts
Keep bolts/washers for assembly
Figure 5. How to Unpack the Power Rack
TOOLS REQUIRED:
Cutting
Pliers
*Drill Driver with
Phillips Bit
Safety
Blade
1/2 in. and 9/16 in.
Combo Ratcheting
Wrenches
Ratchet Wrench with
1/2 in. and 9/16 in. Sockets
*Required for closed crate only

POWER RACK ASSEMBLY INSTRUCTIONS 08
ASSEMBLE YOUR INSERT PLATFORM OR OLYMPIC LIFTING INSERT PLATFORM FIRST
See platform assembly diagram included with the platform.
Proceed to Step 1 to assemble and mount your Power Rack on your platform type.
Insert Platform Olympic Lifting Insert Platform

FRONT FRONT
ASSEMBLY PROCEDURE
TWO-PERSON PROCEDURE: Due to the size of the equipment parts, help is required to safely and successfully complete
the assembly procedure.
HEAVY OBJECT: Help is required during lifting to avoid muscle strain or back injury.
RIGHT
LEFT
REAR
FRONT
x4
Anchor Points
1BOTTOM FRAME PLACEMENT
Lay the Bottom Frames at the desired location. Remove Base Plate Screws and Washers.
Base Plate
Screws and Washers
PLATFORM CONFIGURATIONS: Set the Bottom Frames on the Platform. Align the four Anchor Points to the
Platform mount holes. DO NOT INSTALL MOUNTING HARDWARE SCREWS (included with the Platform) until after
Steps 2 through 4 have been completed.

POWER RACK ASSEMBLY INSTRUCTIONS 09
Align mount holes and attach the Power Module using
the Screws/Washers removed in Step 1. Repeat the
process for the opposite side.
Connect and install the Power Display.
2INSTALL POWER MODULES AND DISPLAY
Have your helper raise the Actuator Tab (press Foot Pedal) as you begin to position the Power Module on the Base Plate.
Release the Foot Pedal before the Actuator Tab enters the Power Module; pull the wire and air lines through the Bottom
Frame. Position the Actuator Tab to rest under the Thumb Button. Repeat the process for the opposite side.
RIGHT
LEFT
REAR
FRONT
RIGHT
Power Module
LEFT
Power Module
Actuator Tab
Foot Pedal Thumb Button
Base Plate
Power Module
A
B C
IMPORTANT: Click sound
conrms proper connection.
Power Display
with Mount Arm

POWER RACK ASSEMBLY INSTRUCTIONS 10
3
A
CONNECT AIR LINES AND COMMUNICATION WIRE
Remove the Bolts and Washers at the Bottom Frame. Tilt a Power Module with Bottom Frame to position the Cable
Tray. Then, route the Air Lines / Communication Wires and install the Cable Tray.
RIGHT SIDE
LEFT SIDE
AIR LINES AND PUSH-IN FITTINGS COMMUNICATION WIRES
Connect the Air Lines and Communication Wires.
Push-in Fittings Method of Assembly:
1. Check that the end tube
is cut square and is free
from burrs.
2. Push the tube through
the release ring button
and grab ring into the
tting.
3. Push the tube rmly
through the 'O' ring until
it bottoms on the tube
stop, then pull back.
4. To disconnect, push the
tube into the tting, hold
down the release button
and withdraw the tube.
IMPORTANT: Click sound
conrms proper connection.
B
LEFT SIDE
RIGHT SIDE
Cable Tray
Bottom Frame
Power Module

POWER RACK ASSEMBLY INSTRUCTIONS 11
ANOTE: Air Compressor not required to turn on the Power Display.
Turn on the Power Display by momentarily pressing both +and –Foot Pedals.
RESISTANCE window change from OFF to CLEr > 0= proper connection.
Once proper connection to the Power Display has been conrmed, neatly organize the Air Lines and Communication
Wires using the Cable Tray Tabs; push any excess lines back into the Bottom Frames.
Tilt a Power Module with Bottom Frame for clearance to position and install the Bench Positioner.
B
4POWER DISPLAY CONNECTION CHECK AND BENCH POSITIONER INSTALLATION
Power Display enters sleep mode (OFF)
after 1 minute of inactivity.
If the Power Display does not turn on,
check Communication Wire connection
points (refer to STEP 2C and STEP 3B).
Bench Positioner
Cable Tray Tabs
PLATFORM CONFIGURATIONS: You may now
install the mounting hardware screws at the four
Anchor Points (included with Platform).
x4
Anchor Points

POWER RACK ASSEMBLY INSTRUCTIONS 12
5SET REAR POSTS
Comm. Port and Decals
face inward
Tall end facing Power Module
REAR POST
4-bolt pattern
on rear face
Repeat the process for the Left Rear Post.
NOTE: There is no Communication Wire connection
at the Left Rear Post.
RIGHT
REAR POST
(with COMM. WIRE)
IMPORTANT: Click sound
conrms proper connection.
RIGHT
REAR
POST
BOTTOM
FRAME
LEFT
REAR POST
RIGHT
POWER MODULE
IMPORTANT: DO NOT TIGHTEN BOLTS UNTIL FINAL INSTALLATION. PARTS MUST BE ABLE TO
ADJUST FOR EASY BOLT HOLE ALIGNMENT.
CONNECT COMMUNICATION WIRE
Push excess line back into the Bottom Frames.

POWER RACK ASSEMBLY INSTRUCTIONS 13
Power Display
with Neck Mount
6INSTALL REAR CROSS BRACE AND TOP POWER DISPLAY
ARoute Communication Wire with Coupler through Display Port and install the Rear Cross Brace.
Connect and install the Top Power Display. Check for Proper Connection. NOTE: Air Compressor not required to turn
on the Power Display.
Turn on the Power Display by momentarily pressing both +and –Foot Pedals.
RESISTANCE window change from OFF to CLEr > 0= proper connection.
B
Communication Wire
IMPORTANT: Click sound
conrms proper connection. Power Display enters sleep mode
(OFF) after 1 minute of inactivity.
If the Power Display does
not turn on, check the
Communication Wire connection.
IMPORTANT: BEFORE INSTALLATION, CHECK BOLTS AT THE BASE OF THE POSTS ARE NOT FULLY
TIGHTENED TO ALLOW FOR EASY BOLT HOLE ALIGNMENT.
IMPORTANT: DO NOT TIGHTEN BOLTS TO
ALLOW FOR EASY BOLT HOLE ALIGNMENT.
Rear Cross Brace
with Display Port
(rear view)

POWER RACK ASSEMBLY INSTRUCTIONS 14
7SET FRONT POSTS
Short end facing Power Module
Decals face inward
RIGHT FRONT POST
LEFT FRONT POST
IMPORTANT: DO NOT TIGHTEN BOLTS UNTIL FINAL INSTALLATION. PARTS MUST BE ABLE TO
ADJUST FOR EASY BOLT HOLE ALIGNMENT.

POWER RACK ASSEMBLY INSTRUCTIONS 15
8INSTALL FRONT CROSS BRACE
Suspension Trainer Hook
face inward
IMPORTANT: BEFORE INSTALLATION, CHECK BOLTS AT THE BASE OF THE POSTS ARE NOT FULLY
TIGHTENED TO ALLOW FOR EASY BOLT HOLE ALIGNMENT.
IMPORTANT: DO NOT TIGHTEN BOLTS TO
ALLOW FOR EASY BOLT HOLE ALIGNMENT.

POWER RACK ASSEMBLY INSTRUCTIONS 16
9INSTALL TOP FRAMES
IMPORTANT: BEFORE INSTALLATION, CHECK BOLTS AT ALL POST CONNECTION POINTS ARE NOT
FULLY TIGHTENED TO ALLOW FOR EASY BOLT HOLE ALIGNMENT.
IMPORTANT: DO NOT TIGHTEN
BOLTS TO ALLOW FOR EASY BOLT
HOLE ALIGNMENT.
IMPORTANT: DO NOT TIGHTEN
BOLTS TO ALLOW FOR EASY BOLT
HOLE ALIGNMENT.

POWER RACK ASSEMBLY INSTRUCTIONS 17
10 INSTALL WEIGHT STACK
IMPORTANT: BEFORE INSTALLATION, CHECK BOLTS AT ALL POST CONNECTION POINTS ARE NOT
FULLY TIGHTENED TO ALLOW FOR EASY BOLT HOLE ALIGNMENT.

POWER RACK ASSEMBLY INSTRUCTIONS 18
11 FINAL ASSEMBLY
A
3110 Power Rack (3111 model similar)
IMPORTANT: PROPERLY TIGHTENED ALL BOLTS.


BSet Bar Catches, Spotting Bars, and Barbell Attachments.
Bar Catch
Spotting Bar
Left side shown. Set the right-side components
to corresponding position setting.
NOTE: eChip, Extension Strap, and Weight Stack Decal sets
are packaged in a kit, attached to the Power Module.
Barbell Attachments
TORQUE SPECIFICATION
3/8-16 IN. (FRAME BOLTS):
25 ft-lbs (34 Nm)
Reference Step 5 through Step 10
for all frame bolt locations.

19
POWER RACK ASSEMBLY INSTRUCTIONS
1. Connect the Quick Disconnect of the Power Rack to the Outlet (see Figure 6).
Figure 6. Air System Setup Reference
WARNING: Never connect Keiser pneumatic equipment to an air source that is capable of exceeding 120 psi / 8.27 bar.
Over pressurizing Keiser pneumatic equipment may cause tubing to burst, breakage of equipment, abnormal operation, or serious
injury. Use only clean, dry, regulated compressed air at the rated pressure range of 100–120 psi / 6.89–8.27 bar.
2. Plug the Compressor into a power source to power the Compressor ON. Allow the Compressor to build up to a minimum of
100 psi / 6.89 bar.
3. Press the +and then the –Thumb Buttons and Foot Pedals a few times to ensure air cycles through and both Power Displays
power ON.
Keiser Air Compressor manuals are available at keiser.com/support (search: Air Compressor manuals).
1. Make sure the Power Rack has been installed according to the instructions and check all bolts are properly tightened
and torqued to specication (see items checklist with reference pages below):
2. Ensure the Power Rack is connected to the Compressor/Air Supply and the Compressor/Air Supply is powered ON.
3. Read the Operation Manual before using the equipment (enclosed with the product and also available keiser.com/
support, search: Power Rack Manual).
4. Store Assembly Instructions for future reference.
12 AIR SYSTEM SETUP & FINAL INSTALLATION

Connect Quick-Disconnect
to the Outlet
Keiser Compressor
(air supply)
Power Display
Powered ON
Press Thumb Buttons and
Foot Pedals to Cycle Air
□Power Modules (page 9)
□Power Displays (pages 9 and 13)
□Bench Positioner (page 11)
□Platform (if applicable, page 11)
□Front and Rear Posts (pages 12 and 14)
□Front and Rear Cross Braces (pages 13 and 15 )
□Front and Rear Top Frames (page 16)
□Weight Stacks (page 17)
FINAL INSTALLATION CHECKLIST

CUSTOMER SUPPORT
If you have any questions regarding the Assembly Instructions
after reading this guide, contact Keiser Customer Support:
315502_A
KEISER CORPORATION
2470 S. Cherry Ave.
Fresno, CA 93706
1 559 256 8000
[e-mail]
keiser.com/support
20
POWER RACK ASSEMBLY INSTRUCTIONS
