Kenmore 580.75100 User manual

Owners Manual
Manual del Propietario
®
ROOM AIR CONDITIONER
ACONDICIONADOR DE AIRE DE VENTANA
Model, Modelo 580.75100
Seam, Roebuck and Co., Hoffman Estates, IL 60179 U.S.A
www.sea_com

TABLE OF CONTENTS ........................2
WARRANTY ..............................................2
SAFETY .....................................................3
Important Safety Instructions...................... 3
ELECTRICAL REQUIREMENTS .......4
INSTALLATION ........................................5
Installation Requirements ......................... 5
Installation ................................................ 6
How to Install ............................................ 6
Removal fromW_ndow................................. 7
OPERATION ............................................. 8
How and Why ........................................... 8
Normal Sounds ........................................ 8
Capacityand RunningTime..................... 8
Features.................................................. 9
Using theAir Conditioner........................ 9
ControlPanel.......................................... 10
Remote Control ...................................... 11
MAINTENANCE ..................................... 12
Air Filter Cleaning................................... 12
Air Conditioner Cleaning ........................ 12
HowtoRemovetheFrontGrille.................. 12
HowtoReplacetheFrontGrille.................. 12
TROUBLESHOOTING ......................... 13
Before Calling for Service ...................... 13
ESPA_OL ................................................ 15
MASTER PROTECTION
AGREEMENTS ......................................31
SERVICE NUMBERS ............BackCover
FULL ONE YEAR WARRANTY ON
ROOM AIR CONDITIONER
For one year fromthe date of purchase,when this
air conditioneris operated and maintained for
normal room coolingaccording to the instructions
in this owner'smanual, Sears will repairthis air
conditioner, free ofcharge, ifdefective in materialor
workmanship.
FULL FIVE-YEAR WARRANTY ON
SEALED REFRIGERATION SYSTEM
For five years from the date of purchase, when this
air conditioner is operated and maintained for
normalroom cooling accordingto the instructions
inthis owner's manual, Sears will repair the sealed
refrigerationsystem (consistingofrefrigerant,
connectingtubing,and compressor), free of charge,
if dofective in material or workmanship.
WARRANTY SERVICE IS AVAILABLE BY
CONTACTING SEARS SERVICE AT
1-800-4-MY-HOME e.
Warranty coverage applies only to air conditioners
used for non-commercial, private household
purposes.
This warranty applies onlywhile this productis in
use in the United States.
This warranty gives you specificlegal dghts, and
you may also have other dght which varyfrom state
to state.
Sears, Roebuck and Co., DI817WA,
Hoffman Estates, IL 60179 U.S.A.
-2-

IMPORTANT SAFETY INSTRUCTIONS
The safety instructionsbelow willtellyou how to use yourroom air conditionerto avoid harm to yourselfor
damage toyour ROOM AIR CONDITIONER.
V_FORYOURSAFETY
Do not store or use gasoline or other flammable
vapors and liquidsin the vicinityofthis or any other
appliance. Read productlabels forflammabilityand
other wamings.
PREVENT ACCIDENTS
To reduce the riskof fire, electrical shock, or injury
to persons when usingyour air conditioner,follow
basic precautions,includingthe following:
•Be sure the electricalservice isadequate for the
model you have chosen.
•Ifthe air conditioneristo be installedina window,
you willprobablywant toclean bothsides ofthe
glass first. Ifthe window is a triple-tracktype witha
screen panel included, you may want to remove
the screen completely before installation.
•Be sure the air conditionerhas been securely and
correctlyinstalled according to the separate
installationinstructionsprovidedwith this manual.
Save this manual and installation instructionsfor
possiblefuture use in removing or reinstallingthis
unit.
•Use gloves when handlingthe airconditioner.
Be careful to avoid cutsfrom sharp metal finson
front and rear coils.
ELECTRICAL INFORMATION
The complete electrical rating of your new room air
conditioner is stated onthe sadal plate. Refer to the
rating when checkingthe electdcal requirements.
•Be sure the airconditioner is propedygrounded.
To minimize shock and fire hazards, proper
groundingisimportant. The power cord is
equipped with athree-prong groundingplugfor
protectionagainst shookhazards.
•Your air conditionermust be plugged intoa
properly groundedwall receptacle. If the wall
receptacle you intend to use is not adequately
grounded or protected by a time delay fuse or
circuit breaker, have a qualifiedelactdcian install
the proper receptacle.
•Do not runair conditionerwithaprotective
covering.This could resultin mechanical damage
within the sir conditioner.
• Do not use an extension cord or an adapter
plug.
_Avoid fire hazard or electdc shook.
Do not use an extension cord or an adapter plug.
Do notremove any prongfromthe power cord.
plug_
Reset _'_
Test
cord
--3-prong
grounding
type wall
receptacle
ENERGY SAVING IDEAS
•The capacity of the room air conditionermust fit
the room size forefficientand satisfactory
operation.
•Install the roomair conditioner on the shady side
of your home.A window that faces north is best
because it isshaded most of the day.
•Do not blockair conditionerflow insidewith blinds,
curtains, or furniture,or outsidewithshrubs,
enclosures,or other buildings.
•Close the floorand wall registersand the fireplace
damper so cool airdoes not escape upthe
chimneyor intothe ductwork.
•Keep blindsand drapes in other windowsclosed
dudngthe sunniest part of the day.
•Clean the air filter as recommended in the
MAINTENANCE section of this manual.
•Proper insulationand weather strippinginyour
home will help keep warm airout and cool air in.
•F-xtemalhouseshading withtrees, plants or
awnings will help reduce the air conditioner'swork
load.
•Operate heat producingappliances such as
ranges,washers, dryers,and dishwashers dudng
the coolest part of the day.
/
-3-

OBSERVE ALL LOCAL CODES AND
ORDINANCES.
DO NOT, UNDER ANY CIRCUMSTANCES,
REMOVE THE POWER SUPPLY CORD
GROUND PRONG.
ELECTRICAL GROUND IS REQUIRED ON
THIS APPLIANCE.
A 250-volt 60 Hz, AC only, 20A fused and
propedy groundedelectricalsupply is required.
A time delay fuse or time delay circuitbreaker
is recommended. Use a dedicatedcircuit,
serving onlythis appliance.
DO NOT USE AN EXTENSION CORD.
RECOMMENDED GROUNDING METHOD
Foryour personalsafety, thisappliance must
be grounded. This appliancehas a power
supplycordwith a 3-pronggroundingplug.To
minimizepossibleshock hazard, the cordmust
be plugged intoa matinggroundingtype wall
receptacleand groundedin accordance with
the National ElectricalCede (ANSI/NFPA 70)
latest edition and all localcedes and
ordinances. Ifa matingwall receptacle isnot
available, it isthe personalresponsibilityand
obligationofthe customerto have a properly
grounded3-prongwall receptacleinstalledby a
qualified electrician.
115V- 230V~ !Powercordmay includea currentinterrupter
device.A testandresetbutton isprovidedonthe
plugcase.Thedeviceshouldbe testedona
pedodicbasisbyfirst pressingtheTEST button
andthentheRESETbutton.IftheTESTbutton
doesnottriporiftheRESETbuttonwillnotstay
engaged,discontinueuseoftheair conditionerand
contactaqualifiedservicetechnician.
NOTE: The shapemaybe differentaccordingtoitsmodel.
Use Wall Receptacle Power Supply
©
@
©
Standard 125V,
3-wire grounding
receptaclerated
15A,125V AC
Standa_250V,
3-wiregrounding
rece_acle mud
15A,25OVAC
Use 15 AMP. time
delay fuse or 15 AMP.
circuitbreaker.
Standard 250V,
3-wire grounding Use 20 AMP, time
receDtacle rated delay fuse or 20 AMP.
20A, 250V AC circuitbreaker.
AWARNING
ElectricalShockHazard
Plugintoa grounded3 prongoutlet.
Donotremovegroundprong.
Donotuseanadapter.
Donotuseanextensioncord.
Failuretofollowtheseinstructionscanresultin
death,fire,orelectdcalshock.
-4-

INSTALLATION REQUIREMENTS
Yourairconditionerwillinstallintostandarddoublehung
windowswithactua]clearopeningwidthsof 22 to36
inches(559mmto914mm)(FIG. 1).
Lower sash must open sufficientlyto allow aclear
vertical opening of 13 inches (331mm). Side Iouvem
and the rear ofthe air conditionermust have clear
air space toallow enough airflowthrough the
condenser for heat removal. The rear of the unit
must be outdoors, not inside abuildingor garage.
I1_3,, _nE_ i_ Sash
13" min. Inner sill Winder
'•SilEx_
Interiorwall ",J....... Io°FIG. 1
ELECTRICAL SERVICE
Check your available electricalservice. The power
supplyavailable must be the same as that shown
on the unitnameplate (foundonrightsideof cabinet).
All models are equipped witha 3-prong serviceplug
to provide proper service and safe positive
grounding. Do notchange plugin any way. Do not
use an adapter plug. If your present wall outletdoes
not matchyour plug, call a qualifiedelectricianto
make the necessary correcttons.
SAVE CARTON and this OWNER'S MANUAL for
future reference. The carton isthe pest way to store
unitdudng winter or when not in use.
To avoidrisk ofpersonalinjury,propertydamage,
or productdamagedue totheweightofthis
device andsharpedgesthat may beexposed:
• Air conditionerscovered inthis manualposean
excessiveweight hazard.Twoor morepeople
are neededto move and installthe unit.
To preventinjuryor strain,useproper liftingand
carryingtechniqueswhenmovingunit.
Carefullyinspectlocationwhereair conditioner
will be installed.Be sure itwillsupportthe
weight ofthe unitoveran extendedperiodof
time.
Handleair conditionerwith care.Wear
protectivegloveswheneverliftingor carryingthe
unit.AVOIDthe sharpmetalfins offront and
rearcoils.
Makesureair conditionerdoes notfall dudng
installation.
INSTALLATION HARDWARE
S
ITEM NAME OF PARTS Q"I'Y
A SHORT SCREW 11
B WOOD SCREW 5
CL BRACKET 3
D FOAM STRIP 1
E FOAM SEAL 1
F SIDE CURTAIN 2
G DRAIN PIPE 1
H SUPPORT BRACKET 1
REQUIREDTOOLS:
•Tight Fiffing gloves
•Standard screwddver
•Phillipsscrewddver
•Pliers
•Sharp knife
•3/8-inch open end
wrench or adjustable
wrench
•1/4-inch hex socket
and ratchet
•Tape measure
•Electhcddll
•1/4-inch ddll bit
/
-5-

INSTALLATION
Pick a locationwhichwill allowyou to blow the cold
air into the area you want. Windows used for
installation must be strong enough to support the
weight of the airconditioner, Good installation with
special attention to the proper position of the unit will
lessen the chance that service will be needed.
Ifair onndiaomr bblocked bya st_m_window _m,_.,
see stap 9 on page 7 beforebeginning_oinstafl.
HOW TO INSTALL
_IsIDE CURTAINS
Insert the side curtainsintothe guidesof the air
conditioner.Fasten the curtainsto the unitwith
screws (ITEM A), as shown in FIG. 2.
ITEM A FIG. 2
_'_ FOAM STRIP
Cutthe adhesive-backedfoamstrip (ITEMD)to the
windowwidth.
Removethe backingfrom the foam stripandattachthe
foamstrip tothe undersideof the bottom window.(FIG. 3)
L_ ATTACH L BRACKET
• Use screws(ITEM A) toinstall the Lbrackets
on the outer sill as shown. See Fig. 5.
•The bracket helpsto hold unitsecurely in place.
Be sure to place bracket edge flush against back
of innersill. See FIG. 5.
•If air conditioneris blocked by stormwindow
frame, see step 9.
INNERSILL
OUTERSILL [TEMA INSIDE
OUTSIDE
LBRACKET FIG. 5
1=_'_DRAINAGE
First,be sure to insertthe drain pipeinto base pan
beforeinstallation.The airconditionermust be
installedwith a slighttilt(I/4") downwardfor proper
drainage of excess condensed water throughthe
drainpipe.
(ITEM D)
FIG. 3
_1 LOCATING UNIT IN WINDOW
Open the window and mark center linewith pencil
on the center of the inner sill,as shown in FIG. 4.
INNER SILL
ROOMSIDE
DRAINCAP
DRAINPIPE
_J_BASE PANREAR
DRAIN_BASE PANBOTTOM
"_H_////////////_
FIG. 6
-6-

r_ INSTALLTHE AIRCONDITIONERIN THE
WINDOW
•Carefullyliftthe airconditionerand slideit intothe open
window.Makesurethebot_m guideoftheaircondifJoner
drops intothe notchescreatedbythe L brackets.
• Whenthe air conditionerdrops intothe L brackets,the
air conditionerwill be canteredin windowopeningas
shown in FIG. 7.
•Wnile steadying the airconditioner,carefullybring the
windowsash downbehindthe upperguideof the air
conditioner,as shownin FIG.8.
I \ I FIG.7
CENTERLINE
W1RDOW FRAME
UPPERGIJEDE _,._STRIP -i ABOUT 1/4"
BD °_I
GUIDE
LBRACKETI_FIG. 8
f_ SECURETHE GUIDEPANELS
Extendthe guidepanels(ITEM F)tofill thewindow
openingusing4 screws(ITEMB) tosecure them,as
shownin FIG.9.
IL_ INSTALLTHE FOAMSEAL AND SASH LOCK
• Cut the foamseal(ITEME) tothewindowwidth.
Stuffthe foamsealbetweenthe lowerand upper
windowsashto preventairandinsectsfrom getting
intothe room,as showninFIG. 9.
• FastentheremainingLbracketoneithersideofthe
windowusingscrew(ITEMA). See FIG.9 inset.
Installingthisbracketpreventsunitfallingfromwindow
beingraised
LBRA_
FOAMSEAL
(ITEME)
ITEMI
FIG. 9
• Removethe screwon lower fight sideof cabinet.
• Use this screwto attachthe supportbracket(ITEMH)
tothe innerwindow sill asshown Fig. 10.
-ITEM B
}
FIG. 10
_IF AIRCONDITIONERIS BLOCKED BYSTORM
WINDOWFRAME
•Ifstormwindowpresentsinterference,fastena2"wide
woodstriptothe innerwindowsillacrossthefullwidthof
thesill.Thewoodstripshouldbe thickenoughtoraise
theheightofthewindowsillsothattheunitcanbe
installedwithoutinterferencefrom thethestormwindow
frame.See FIG. 11.
Topofwoodstripshouldbeapproximately3/4"higher
thanthestormwindowframeto helpcondensationto
drainproperlytothe outside.
•Installa secondwoodstrip(approximately6"longby
1_/2"wideandsamethicknessasfirst strip)inthecenter
oftheoutersinflush againstthe backoftheinnersill.
ScrewtheL bracketsintothisstdp.
ThiswillraisetheL bracketasshownin FIG. 11.
WOOD STRIP MOUNTED
ON TOP OF TNNER
--..,
INNER
SILL
1" MAX
INDOW _
LBI_C_r FRAME
WOOD S_IP
FOR LBRACKET O_ERsILL
_t,ms FIG, 11
REMOVALFROM WINDOW
Turntheairconditioneroff,anddisconnectthepower
cord.RemovetheL bracketandthescrewsinstalled
throughthetopandbottomofthesidepanels,andsave
forreinstallationlater.Closethesidepanels.Keepinga
firmgriponthe airconditioner,raisethesash,and
carefullytiltthe airconditionerawayfromyou,to drainany
condensatewater.Lifttheairconditionerfromthewindow
andremovethefoam sealfrom betweenthewindows.
•Airconditionerscoveredinthismanualposean
excessiveweighthazard.Twoor morepeopleare
neededtomoveandinstalltheunit.
Topreventinjuryorstrain,useproperliftingand
carryingtechniqueswhenmovingunit.
• Whenhandlingtheairconditioner,becarefultoavoid
cutsfromsharpmetalfinsonfrontandrearcoils.
•Makesureairconditionerdoesnotfallduringremoval.
-7-

HOW AND WHY
Your roomair conditionerprovidesthe following
functionsto make hot weather livingmore
comfortable:
•Cools and circulatesroom air.
•Lowers humidityby removing excess moisture.
•Filtersout summer'0medust, dirt, and some
airbome impurities.
The air conditioner performsthese functions by
drawing roomair through a filter whichtraps dust
and dirtparticles. The air then passes over a
coolingceil which refrigeratesthe air and removes
excess moisture. The same air isthen retumed to
the room- cooler, drier, and cleaner. Moisture
removed from the room air iscarried tothe outside
and evaporated.
Your air condi_oner isdesigned to be easy to
operate and to provide plenty of cooling power.
NORMAL SOUNDS FIG.12
Aside fromthe regular fan motor and compressor
soundscoming from your air conditioner,you will
once in a while hear a pingingsound. This is the
result ofmoisture being picked up from the air in the
room and thrown against the air conditioner's fan.
This isnormal and should not be cause forconcom.
Also, do not be alarmed if you hear a slighthissing
or gurglingsound coming from your air conditioner
after itis off. These are normal coolantnoises.
CAPACITY AND RUNNING TIME
Proper unitsize is importantin decidingthe desired
comfortforthe area youwant to cool.The proper
size isdetermined by the number of square feat
in the area to be cooled, indoorand outdoor
temperature and humidity.
Whenever the heat or humidity load is above normal
the air conditioner must run longer and more often
tokeep the desired temperature you have selected,
Under heavy heat load conditionsthe air conditioner
may need to run constantlyto keep the temperature
you want.
At times usingthe MED FAN settingto circulatethe
room air may make it comfortable even though the
air is not being cooled. This will decrease your cost
ofuse.
iompressor
The modem high efficiency
compressormay have a high
pitchedhum or pulsating
noisethat cycleson and off.
-- Unit Vibration
The unitmay vibrate
and make noise
because of poorwall
You may hear dropletsof water hitting
the condenser causing a pingingor
clickingsound.
Fan
You may hear air
movement from
the fan.
FIG. 12
-8-

FEATURES
115 6 5 4 32714
9 8 11 1210 13 16
FIG. 13
1. Cabinet
2. Vertical Air
Direction Louvers
3. Horizontal Air
Direction Louvers
4. Inlet Grille
5. Air Filter
6. FrontGdlle
7. Conb'olPanel
8. Power Cord
9. EvaporatorCoil
10. Condenser
11. Compressor
12. Base pan
13. Brace
14. Upper Guide
15. Curtain
16. Remote Control
USING THE AIR CONDITIONER
To reduce the dsk offire,electric
shook,or injuryto persons, read the important
SAFETY instructionssection beforeoperating this
appliance
To begin operating the air conditioner after
installation, follow these steps:
1. Plug in the air conditioner.(To prevent electrical
hazards, do not use an extension cord or an
adapter plug.)
2. Set the exhaust vent to the CLOSE position.
3. Set the TEMP Controltothe coolestsetting.
4. Set the MODE controlat the highestCOOL level.
5. Adjustthe louvers for comfortableair flow.
6. Once the room has cooled, adjust the TEMP and
Mode Controlto the setting youfind most
comfortable.
NOTE : Ifthe airconditioneris tumod off, wait 3
minutesbefore restarting.This allows pressure
insidethe compressor toequalize. Failure to wait 3
minutesbefore restartingmay cause inefficient
operation.
If you move the TEMP Controltoa warmer, then
immediately back toacooler setting,the unitwill
shutoff.Wait 3 minutes before restarting.
VENT CONTROL
The Vent Control allows the airconditionerto
either recimulate inside air (CLOSE) orexhaust
air to the outside (OPEN). (FIG. 14)
•The CLOSE position is usedwhen maximum
coolingis desired. Itmay also be usedfor air
recirculationwithoutcooling when the air
conditioner isset in the FAN position.
• The OPEN positionremoves stale airfrom the
roomand exhausts ittothe outside. Freshair is
drawn intothe roomthrough your home's
normal air passages.
•The OPEN or CLOSE position can be used with
any mode selection.
PULL OPEN IPUSH CLOSE FIG. 14
-9-

CONTROLPANEL
REMOTE CONTROL SIGNAL RECEIVER
ITIMER
- TEMPERATURE SETTING
•Usethese buttonsto automaticallycontrolthe
temperatureof the room.The temperature
can be set to one ofa temperature between
64°Fto 82°F.
•Push the TEMP up or down buttonsto shift
the temperature settingfrom
82°FIt,.76°F•70°F •64°F
- SHUT-OFFTIME
,,You willusuallyuse shut-offtime while yousleep.
• IfunitisnJnning,Usetimertosetnumberofhoursuntilshut-off.
• EverytimeyoupushTimerbutton,itadvancesthe Timer
settingasfollows:1Hour• 3Hours• 6 Hours1_10Hours
maximum.
"To tam the airconditionerON, pushthisbutton.
To turnthe airconditionerOFF,push
thebuttonagain.
•This buttontakes priorityoveranyotherbutton.
•Whenyoufirstturnit on,the airconditioneris on
the HighcoolmodeandtheTemp.at70°F.
AUTO RESTART
•Intheeventofa powerfailure,
theunitwillrunattheprevious.
-STARTTIME
•ifunitisoff, Usetimerto setnumberofhoursbeforeunitstarts.
• EverytimeyoupushTimerbutton,itadvancesthe Timersettingas follows:1Hour• 3Hours• 6 Hours• 10Hours
maximum.
MODE
•Pushthis buttontoshiftthe modeofoperationfromCOOL-HI• COOL-LOW•FAN ONLY-HI• FANONLY-
LOW.
HORIZONTAL AIR DIRECTION CONTROL
Thehorizontalairdirectionis adjustedbymovingthevertical
louversrightandleftwithyourfingertips.(FIG.15)
VERTICAL AIR DIRECTION CONTROL
Theverticalairdirectionisadiustadbymovingthe horizontal
louversupanddownwithyourfingertips.(FIG.16)
FIG. 15 FIG. 16
-10-

REMOTE CONTROL
NOTE: The Remote Control will not operate properly ifstrong lightshines onthe sensor window of the Air
Conditioner or ifthere are obstacles between the Remote Controland the Air Conditioner.
Every time you push button,you will hear a beep fromthe Air Conditioner.
POWER
•Toturnthe airconditionerON, pushthisbutton.ToturntheairconditionerOFF, pushthe
buttonagain.Thisbuttontakespdorityoveranyotherbutton.
Whenyoufirstturnit on,theairconditionerisonthe HighcoolmodeandtheTempat
70°F
TEMPERATURE SETTING
•Usethesebuttonsto automaticallycontrolthe temperatureoftheroom.
Thetemperaturecan beset within arangeof 64°Fto 82°F.
•Push the TEMP up or down buttons to shift the temperature setting from
82°F• 76°F• 70°F• 64°F
TIMER
-SHUT-OFFTIME
•You willusually useshut-offtimewhile you sleep.
• Ifunit isrunning, UseTimer toset the numberof hoursuntil shut-off.
• PushTimerbuttonsto advancethe Timer settingasfollows:
1Hour(1Hour-2Hours)• 3 Hours(3Hours-5Hours)• 6Hours(6Hours-9Hours)
• 10Hoursmaximum.
-START TIME
• Ifunit isoff, Use the Timertosetthe numberof hoursbeforeunitstarts.
• PushTimer buttonsto advancethe Timer settingasfollows :
1Hour(1Hour-2Hours)l, 3 Hours(3 Hours-5Hours)• 6 Hours(6Hours-9Hours)
• 10Hoursmaximum.
MODE
•Push this button to shiftthe mode of operation from:
COOL-HI •COOL-LOW •FAN ONLY-HI •FAN ONLY-LOW.
HOW TO INSERT BA'I-rERIES INTO REMOTE CONTROL
1. Removethe coverfrom the back ofthe remote
controller.
• Openthe coveraccordingtothe arrow directionon the
cover.
2. Inserttwo batteries.
• Be sure thatthe (+) and (-) directionsare correct.
• Be surethat both batteriesare new.
3. Re-attachthe cover.
• Do not use rechargeablebatteries.
Such batteriesdifferfrom standarddrycells in shape,
dimensions,and performance.
• Removethe batteriesfrom the remotecontrollerifthe air
conditioneris notgoingto be usedfor anextended
lengthof time.
/
-11 -

AIR FILTER CLEANING
The Air Filtorwill become dirtyas it removes dust
fromthe inside air. It should be washed at least
every 2 weeks. If the Air Filter remainsfull ofdust,
the air flow willdecrease and the coolingcapacity
willbe reduced, possiblydamaging the unit.
•Pullthe inlet grilleforward, grasping both tabs,
then pulloutthe air filter.(FIG. 17)
•Wash the Air Filter under the faucet withwarm
water. Be sure to shake off all the water before
replacing the filter. (FIG.18)
FIG . 17
HOWTOREMOVETHEFRONTGRILLE
•Open the inletgrilledownward.
•Remove the screw securing the FrontGdlle.
•Push the grille upfrom the bottom and pullthe top
ofthe grilleaway from the case toliftthe toptabs
outof their slots.
\
Inlet Grille
FIG. 20
AIR CONDITIONER CLEANING
Clean the front grilleand inlet gdlle by wipingwith a
cloth dampened in amild detergent solution.
The cabinet may be washed with mildsoap or
detergent and lukewarmwater, then polishedv_th
liquidappliance wax.
To ensure continued peak efficiency, the condenser
coils(outdoor side at the unit)should be checked
periodicallyand cleaned ifthey become clogged
with soot or dirtfrom the atmosphere, Brush or
vacuum extedor coils to remove debris fromfins.
FIG. 19
HOW TO REPLACE THE
FRONT GRILLE
Attachthe fi'ontgrille to the cabinet by inser_ngthe
tabson the grilleintothe slots on the front ofthe
cabinet. Push the grille in untilitsnaps into place,
ii _ FIG. 21
- 12-

BEFORE CALLING FOR SERVICE
Check the following list to be sure a service call is really necessary. A quick reference to this manual may
help you avoid an unneeded sentice cell.
THE AIR CONDITIONER WILL NOT OPERATE.
Check if...
Wallplug disconnected
Housefuseblownorcircuitbreakertripped
MODE selectoris OFFpositJon
Unitwasturnedoffandthenontooquicl_
TEMP Control set warmerthan roomtemperature
The current interrupter device is triped
Then,,.
Pushplug firmlyintowallouttsL
Replacefusewithtimedelaytypeorresetcircuitbreaker.
TurnMODEselectortothedesiredCOOLsetitng.
Turnunitoffandwait3 minutesbeforerestarting.
Tum TEMP Controlclockwisetoacoolerset_ng(highernumber)
Press the RESET button located on the power cordplug
Ifthe RESET button will not stay engaged, discontinue use of the air
conditionerand contact a qualified service technician
AIR FROM UNIT DOES NOT FEEL COLD ENOUGH.
Check If... Then...
MODE selectorin LOWCOOLposition
TEMP Control set toowarm(lower number)
Roomtemperaturebelow70°F (21°C).
Temperaturesensingtubetouchingevaporator coil,
locatedbehindfrontgitlle
Turnselectorto HiGHCOOL position
TurnTEMP Controlclockwisetoacoolersetting
Coolingmay notoccuruntilroomtemperaturerisesabove70°F (21°C)
Straightentubeawayfromevaporatorcoil
THE AIR CONDITIONER COOLING, BUT ROOM ISTOO WARM -ICE FORMING ON COOLING COIL BEHIND FRONT GRILLE.
Check If... Then...
Outdoor temperaturebelow 70°F(21°C) To defrostthe coil,setselector to FANposiben "rrren,turnTEMP control
counterclockwiseto awarmer setting,
Airfiltermaybe dirty CleanfilterRefertoMaintenancesectionofowner'smanual To defrost,
set selectorto FANposition
TEMP Controlset toocoldfor night-itrnecooling, To defrost_e ceil,setselectortoa FANposition.1ben,s_theMODE
controlatFANposi_onor'HighCool"wi_ theTEMPcontroltoawarmerpos_on
"&IEAIRCONDmONERCOOLING,BUTROOMISTOOWARM.
Check If.,.
Dirtyairfiiter- airrestricted
TEMP Control set toowarm.
Frontof unitis blockedby drapes,blinds,furniture,
etc AirdistdbL_Onisrestitcted
Doors,windows,regisfem,etc open Cold airescapes
Unitrecently turnedonin hot room
CleanairfiltenReferto Maintenancesec_onofowner'smanual
Turn TEMP controlcitx:kwiseto acoolerset_ng(highernumber)
Clearblockagein frontofunit
Closedoom,windows,re_isfers,etc
Allowaddil_nalitmetoremovestoredheatfromwalls,ceilng,floor,andfumitore
THE AIR CONDmONER TURNS ON AND OFF RAPIDLY.
Check If... Then...
I° detemperatureisextmmatybet" ISetMODEon HIGH speedtobringairpaslcoolingcoilsfasfer. I
NOISE WHEN UNIT IS COOLING.
Check if.,, Than...
IScondoftonhifitogwator-florathemoistoreremovalsystem This isOormalwhenhumidityis highClocedoors,windows,andregisturs
Windowvibrallan- poor installafion. J Refertoins_la_on instrucfionsorcheckwi_ installer, t
WATER DRIPPING INSIDE ROOM WHEN UNIT IS COOLING,
Check If... Then..,
J_e aircenditioneris improperlyinstelled J "nitaircenditionerslighfiyto theoutsidetoallowwaterdrainage Referto I
icetalla_oninstru_onsor check_installer. I
WATER DRIPPING OUTSIDE WHEN UNIT IS COOLING.
Check if... Than...
The unitis removinglargequanti_esof moisturefrom humidroom. j Thisis normalduringexcessivelyhumiddays. I
/
-13-

-14-

INDICE DE MATERIAS ............................. 15
GARANTiA ................................................ 15
SEGURID'AD.............................................. 16
ImpoYcantesinstruccionesdeseguridad 16
REQUERIMIENTOS ELECTRICOS .........17
INSTALACI_N ........................................... 18
Requerimientos para instalaci6n.......... 48
Installaci6n............................................ 19
C6mo instalarlo..................................... 19
La eliminacionde la ventana................. 20
OPERACnN .............................................. 21
Cbmo y porqu6 .................................... 21
Sonidos normales.................................. 21
Capacidad y tiempo de funcionamiento .--21
Caracterfsticas ..................................... 22
Uso del equipode aire acondicionado.-22
Panel de control.................................... 23
Control remoto...................................... 24
MANTENIMIENTO .................................... 25
Limpiezadel filtrodel aire...................... 25
Limpiezadelequipodeaireacondicionado..-25
COmosacar la rejillafrontal ................... 25
Cdmo a reemplaza el grilleanterior......25
CORRECCION DE FALLAS ...................... 26
AntesdeUamarparaservtcio...................... 26
ACUERDOS DE PROTECCI(_N
ESPECIALIZADA ...................................... 31
PARA PEDIR SERVICIO .......CubiertaTrasera
GARANTJA DE UN ANO POR EL
EQUIPO DE A!RE ACONDICIONADO
DE HABITACION
Durante unatio completoa partirde la fecha de
compra, si este equipo de aim acondicionado recibe
mantenimiento y se utiliza para el enfriamiento
normalde habitacibnseg0n las instrucciones
indicadasen este manual del propietario, Seam
reparar_ gratuitamente este equipo de aire
acondidonado, sitiene alg,',ndefecto en materiales
ofabricacibn.
GARANTI'ATOTAL DE CINCO A_IOS
POR EL SISTEMA DE REFRIGERACION
HERMI'--TICAMENTE SELLADO
Durante cincoai_osapartirde la fecha de compra,
si este equipo de aim acondicionado recibe
mantenimiento y se utiliza para el enfriamiento
normal de habitaci(_nseg0n las instrucciones
indicadas en este manual del propietario,Sears
repamr_ gratuitamente el sist_ma de refligeracibn
herm_,camentesellado(queconsisteenelagente
refdgerante,lostubosdeconexi6ny elcomprssor),
sitienealg0ndefectoenmat_rialesofabricacibn.
EL SERVlCIO DE GARAN'I'IA ES
DISPONIBLE CONTACTANDO AL SERVIClO
SEARS AL 1-800.4-MY-HOME °
La proteccionde gamntt'acubre unicamente a los
equiposde airs acondicionadousados para uso
domesticoy no pare uso comercial.
Esta gamnt_as61otiene vaiidez mientrasel producto
se este usandoen los Estados Unidos.
Esta garant a_leda derechos legales espec_'ficosy
usted puede tener otrosderechos que yah'an de
estado en estado.
Sears, Roebuck and Co., D/817WA,
Hoffman Estates, IL 60179 U.S.A.
/
-15-

IMPORTANTES INSTRUCClONES DE SEGURIDAD
Las siguientesinstruccionesde seguridad le indicardnc6mo usar su equipo de aim acondicionado de
habitaci6n para evitar da_os para usted mismoy para su EQUIPO DE AIRE ACONDICIONADO.
POR SU SEGURIDAD
No aimacene ni use gasolina u otros vaporesy
liquidosinflamables corca de dste o cualquierotto
electrodomdstico. Lea las etiquetas de los
productospara ver sicontienen advedencias sobre
el cardcter inflamablede los mismos y otras
advertencias.
PARA PREVENIR ACClDENTES
Para reducir el riesgo de incendios, descargas
el_r_:tricaso lesiones personales al usar su equipo
de aim acondicionado,tome las precauciones
bdsicas, entre las que estdn las siguientes:
•Aseg,',resede que laaiimentaci6n el6ctdca sea la
apropiada pare el modelo que usted ha elegido.
•Si el equipo de aire acondicionado debe instalarse
an una ventana, aust_d probablemante le
conviene limpiar primeroambos lados del vidrio.
Si la ventana es del _po de tres paneles con un
panel incluidode pantalla, ie convienesacar la
ventana completamente antes de la instalaci6n.
• Aseg,',resede que el equipo de aire
acondicionadoha side instalado correctamente y
con seguridad segt_nse sefiala an las
iostruccionesseparadas de instalacibnqua vienen
en este manual. Conserve este manual y las
instruccionesde instalacibnpara usados
posiblementaen el futuro al sacar o volver a
instalaresta unidad.
•Utiliceguantes al manejar el equipo de aim
acondicionedo,t_nga cuidado para evitar cortadas
con las afiladas aletas metdlicas que se hallan en
losserpentines fmntaies y posteriores,
INFORMACI(_N ELECTRICA
En la placa de serie del fabdcante se indica cudl es
lacapacidadel_,ctricanominalcompletadesu nuevo
equipode aire acondicionadopara habitaci6n.Consulte
estaplata cuandovayaa verfficarlos requerimientos
el_tricos.
•Aseg_rese deque el equipode aire acondicionado
tenga unaconexi6ncorrectaatierra.Para reduciral
minimo los nesgosde descargaseldctricaseicoendio,
es importanteconectar el equipacorrectarnentea tierra.
Elcord6nde alimentaci6nel6ctrP_,aestd equipadocon
unenchufedetres espigascon conexi6natierrapara
protegerlecontra desgosde descargasel6ctricas.
• Suequipa deaireacondicionadodebe enchufarseen
unatoma de corrientede paredquetenga unaconexion
correctaa tierra.Si la tomade corrientede paredque
ustedpiensa usarcoestd conectadacorrectamentea
tierrao noestd protegidacon un fusibledeacoi6n
retardadaocon un interruptordecircuito,hagaque un
electricistacalificadole instalelatoma decorrientede
paredenformacorrecta.
•No pongaafuncionarel equipode aireacondicionado
con una cubiertaprotectoraexteriorencima.Esto podria
coasionardaSosmecdnicosdentrodelaire
acondicionado.
• No use uncable de extensi6nni unenchufe
adaptador.
_ Evitelospeligrosdeincendiosy
descargaselectricas.Nouseuncablede extensiSnniun
enchufeadaptador.No elimineningunadelasespigas
delenchufedelcordSndealimentaci6nel_ctr_ca.
Toma de corriente
de pared con I _Cable de
conexi6n a lJerra. I _ aiimentaci6n
\I \_ _ -con clavija
- dotadade
.epong_ ] _conexibna
IL"_Y_ I\_ _ tierrade3
Pmeba_ _ terminales.
IIII Terminal de
_LI conexibna tierra.
J
I
Bajo ningunacimunstancia corte, quiteo evita
el uso de laconexi6n a tierra de esta clavija.
IDEAS PARA AHORRAR ENERG|A
•La capacidad del equipo de aim acondicionedo
debe corresponder ai tamaSo de la habitaci6n
para el funcionamientoeficiente y satJsfactedodel
equipo.
•Instale el equipo de aire acondicionado de
habitacibnen el ladosombreado de su hogar. Una
vantana oriantada haciael nortees la mejor
porque tiene sombre la mayor parte dald|a.
•No bloquae el aparato de aire acondicionado
tapdndotocon parsianas, cortJnas,muebles o en
el exterior con arbustos, recintosu otrosedificios.
•Cierre el reguladorde tire de la chimenea, las
rejillasde calefacci6n del pisoy la pared, de tal
modoque el aim frfo no se escape ni por la
chimenea ni por los conductos.
•Mantenga las parsianas y las cortinasde otras
vantanas cerrades durante la parte m_s soleada
deldia.
•Limpieel flltro del aire como se recomienda en la
secci6n "MANTENIMIENTO" de este manual.
•El aislamiento correctoy las juntas herm6ticas en
puertasy ventanas en su hogar le ayudardn a
mantener el aire caliente afuera y el aire frfo
adentro.
•AI darie sombre extemamente a la casa con
drboles, plantaso toldosayuderd a reducirla
carga de trabajo del equipo de aire acondicionade.
•Opere los aparatos que producencalor como,por
ejemplo, homos, lavedoras, secadoras y
lavaplatos durante la parte mdsfria del dfa.
-16-

RESPETE TODOS LOS C6DIGOS Y
REGLAMENTOS.
BAJO NINGUNA ClRCUNSTANClA CORTE,
QUITE O EVITE EL USO DE LA CONEXl6N
A TIERRA DE ESTA CLAVIJA.
ESTE APARATO NECESlTA SER
CONECTADO A TIERRA.
Se requiere una alimentaci6neldctdcaCA,
adecuadamente conectada a tierracon un
fusible de 20 A, de 60 Hz y de 250 V.
Se recomiendaun fusible de retardo o un
disyuntorde circuitoque alimente solamente a
este aparato.
NO USE CABLE ELECTRICO DE
EXTENSI(_N.
METODO RECOMENDADO DE CONEXI6N A
TIERRA
Per su propia seguridadeste aparato debe
conectarse a tierra. Este aparato viene
equipadocon un cable de alimentaciony una
clavijadetres terminales. Para reduciral
m&ximoel peligro de chequeel_ctrico,el cable
debe estarconectadoa unaconexi6nde pared
con conexi6na tierra, y esta conexi6ndebe
hacersede acuerdocon la L_ltimaediciondel
C6digo EldctricoNacional(ANSI/NFPA 70), asf
come con losc6digosy reglamentoslocales. Si
no existeunaconexi6n de paredadecuada, el
clientetiene la responsabilidady la obligaci6n
de mandarinstalar,con unelectricista
calificado,una conexi6nde pared adecuadade
tresterminalescon conexi6na tierra.
115V- 230V~
@
Elcabledealimentaci6npuedeincluirundispositivo
interrupterdecordente.Lacarcasadelenchufecuenta
conunbot6ndepruebayotrodereinicio.Eldispositivo
debecomprobarseperi6dicamentepresionando
primeroelbot6nTESTydespuesRESET.
Sielbot6nTESTnosedesconectaesielboton
RESETnopermaneceactive,suspendaelusedelaire
acondicionadoyp6ngaseencontactoconuntdcnico
deservicioeualificado.
NOTA:La formapuedeserdiferentesegdnsumodelo.
Utilieeelenehufedelapared Consumede Energfa
©
©
@
Standard 125V,
enchufe de 3
Uneas de
15A, 125V AC
Standard 125V,
enchufe de 3
L|neas de
15A, 125V AC
Utiliceun fusiblede
15AMP.o un
Interrupterde t5AMP.
Standard 250V,
enchufe de 3Utiliceun fusiblede
Uneas de 20AMP.o un
20A, 250V AC Interrupterde2OAMP.
AADVERTENCIA
Peligrodechequeel6ctrico
Conecteenunaconexi6ndeparedde3 terminales
Noquitelaterminaldeconexi6natierra
Nouseadap_.dores
Nousecableel_ctrieodeextensi6n
Sinosesiguenestasinstrucciones,puedeocasionarse
lamuerte,unincendioo unchequeel6ctrico.
-17-

REQUERIMIENTOS PARA
INSTALACION
SUequipadeairsacondicionadoseiastalaraanventanas
est_ndardedeblepanelconanehosdeaberturalibrade559mm
a914mm(22a36pulgadas).(Figure1)
ElmarcoinfadordebeabdrseIosuficientepareperrnitiruna
aberturaverticallibrade331mm(13pulgadas).Lasrejillas
desviadoraslateralesy laparteposteriordelequipodeairs
acondieianadodebentenerunespaciolibradeairsparepermitir
suficienteflujodeairsatrav_sdelcendensadorpareas{eliminar
el ealor.Lapartsposteriordelaunidaddebequedaralairslibrs,
nodentrodeunedificioogaraje.
Figura I
SERVICIOELECTRICO
Compruebecu:_lesla alimentaci6nelectdcaqueIlegaasu
domicilio.Laalimentaci6nelectricadisponibledebeserla misma
quesemuestraeelaplacedelfabricantedelaunidad(quase
halleenelladeizquierdodelgabinetedecordentealtema).
Todoslosmcdelosestdnequipsdosconunenchufedetins
espigasparesurninistrarunservieiocorrectoyunaconexi6na
tisrrsssguray positive.Nocambieel enchufedeningunafarina.
Nouseunenchufeadaptador.Sisutomadecorrientedepared
actualnopuedeusarseconelenchufedslequipo,Ilameaun
electdcistacalificadoparequeefect_elascorrecoiones
nacesades.
CONSERVELACAJAyesteMANUALDELPROPIETARIOpare
quale sirracomarefersncieenelfuture.Lacajaes lameier
maneradeconservar]aunidadduranteel inviemoo cuandono
estdenusa.
IF!_I _o]
Pareevitarel nasgode hendaspersonales,daSosen
los bienes,o daSoen el produetodebeset expuestoel
agudezdelos hordesy el pesoaptodel aparato:
Elairs acondicionadodelquesehablaen este
manualafirma peligrode pesoexcesivo.
Dos omas personasserequiereparamovere instalar
la unidad.Pareevitarheridasoagotamlento,use
tecnicasapropiadasparelevnt_ry moverla unidad.
•Cuidadosamenteinspeccioneei lugardondeel airs
acondicionadosere puesto.Aseguresequeel lugar
sostengael peso dela unidadsobrsunperiodode
tiempoprolongado.
Mantengasu airs acondicionadoconcuidado.Use
guantesproteetorescuandolevanteo muevala
unidad.EVITE1asaletasfiiosasde metalenel
serpentindelantemy de atras.
•Aseguresequael airs acondicionadonose caiga
dursntela instalacion.
INSTALACION PIEZAS DE MONTAJE
TIP0 NOMBREDELASPIEZAS CANTIDAD
ATORNILLOCaRTe 11
B TORNILLOMEDIANO 5
C SUPPORTENL3
D BANDAADHESIVA 1
E BANDADELMARCO 1
F PANELDEGU[A 2
G TUBa DEDRENAJE 1
H SOSTENGAPAR_NTESIS 1
HERRAMIENTASREQUERIDAS
• Guantes apretados
• Destornillador normal
•DestornilladorPhillips
• Pinsas
• Cuchillofiloso
• Llaveinglesa o Ilave
abiertade 3/8"
•Llavehexagonal de cuba
y trinquete de 1/4 de
pulgada
•Cinta para medir
•Taladro electrico
•Broca de taladro de 1/4"
-18-

INSTALACION
Escoja unlugarque lepermitaIlevarel aim frio al &rea
quedesea. LaBventanasque seusen para lainstalaci6n
deben tener la resistenciasuficienteparasoporiar el peso
del equipode aire acondicionado.Unabuena instalaci6n
con atenci6nespecial ala eorrectaposici6n dela unidad
disminuir_ la probabifidadde que seanecesarioefectuar
reparaciones.
COMO INSTALARLO
U CORTINAS LATERALES
InsertelaBcortinas lateralesen labguias de]aire
acondicionado. Fije las cortinas a la unidad con
tornillos (TIPO A), comb se muestra en Figura 2.
TIPOA Figura 2
_FAJA DE SELLANTE
Cortelacinta senadoraadhesiva (TIPOD) a la anchura
de laventana.
Quite el dorsode lacinta selladoray peque la cinta
selladora ala superficieinferiorde ia ventanade abajo.
Vea la Figura3.
BANDA
(TIPO D)
Figura 3
[] COLOCAR LA UNIDAD EN LA
VENTANA
Abra laventanaymarquela lineacentralenelcentrodel
alf izarinteriorcomose muestraenla Figura4.
ANTEPECH_
INTERIOR
jr
TABURETE Figura 4
L_I SOPORTE DE RJACI(_N L
• Utilice tomillos("rlPOA) para instalar los soportes
en L sot)rela plataforma exteriorcomo se
muestra. Consulte Figura 5.
• El soporte ayuda amantener la unidad
correctamente en su lugar. Aseg_rese de colocar
el borde del soporte nivelado con la partade atr'&s
del alfeizar interior.Vease la Figura5.
• Si el aire acondicionadoest&bloqueado pot el
marco de laventana de tormenta, yea el paso 9.
DESCANSO
IN*nERIOR
DESCANSO TIPO A
EXTERIOR INTERIOR
LINEA DEL CENTRO
EXTERIOR
M_NSULA EN L Figura 5
_'IDRENAJ E
En primer lugar, asegt_msede insertar la tubeda
de drenaje en la bandeja de la base antes de la
instalacibn.El aire acondicionado debe instaJarse
con una ligera inclinacion(1/4") hacia abajo para
el drenaje adecuado del exceso de agua condensada
a travdsde la tuberia de drenaje.
FUYAU
DRENAJE D'EVACUATION
PARTEPOSTERIOR
TUBO DE DEL RECIPIENTE
DRENAJE DE BASE
PARTE INFERIOR DEL
_ASE
Flgura 6
-19-

_J INSTALE EL ACONDICIONADOR DE AIRE
EN LA VENTANA
•Levanteconcuidadoel aireacondicionadoy desicelohasta
la ventanaabierta Aseg[_resede quela gufainferiordelaire
acondicionadopasaperlas muescasde lossoportasen L
•AIencajaren del seporteL, e]acondicionadorde aire
estar_eentradoen la aberturadela ventana,come se
rnuestraen la Figure7
•Mientrassujeta el acondicionadorde aire,baje
cuidadosarnenteel marcocorredizode la ventana
detr&sde la guia superiordelacondicionadordeaire,
comese rnuestraenla Figura8
I "-, I
Llneacentral Figura 7
BORDE DE L_ VENTANA
I/ ill ,a,,,,.
SUPPORT EN L I _Figura 8
_--_FIJE LOS PANELES CORREDIZOS
Extiendalos panelescorredizospareltenar laaberturade
la ventana,usando los 4 tomillos (TIPO B) parefijarios
oorno semuestraen la Figure9
_J INSTALEEL SELLODE VENTANACORREDIZAY
EL SEGURODEVENTANA CORREDIZA
•Cortelajuntadeespuma(TIPOE) ala anchurade la
ventanaMetala juntadeespumaentreelmarcoinferior
y superiorde laventanaparaevitarque entreairee insectos
en la sale,comese muestraen Figura9
•Coloqueel soporteen Lrestanteenuno de losdosladesde
laventanautilizandeuntornillo(TIPOA) Consulteel detalle
de Figura9 Lainstalacio'nde estesoporteevitaquela
unidadcaigaeuandoselevantalaventana
[HIJ Im7-'Ie]_e]
MARCO
Figura 9
•Retireel tornillode la parteinferiorderechadela carcasa
•Utiliceestetomillopareincorporarel soportedeapoyo
(TIPOH)ala platatcrmainteriordela ventana,
comese muestraenFigura10
I_lSl ELACONDICIONADORDEAIREESTABLOQUEADO
PORELMARCODELACONTRAVENTANA
•Silacontraventanainterfierefijeunlist6ndemaderade2' de
anchoalalfdizarinteriordelavantana,queatraviesela
anchuratotaldelalt_izarEllist6ndernaderadebeset
sufieientementegruesoparelevantarlaalturadelalf_izardela
ventanadetal mar,eraquelaunidadpuedaserinstaLadasinla
interferenciadelmarcodelacontraventanaVeala Figure11
Lapartasuperiordellist6ndernaderadebeser
aproximadamente3/4"m_saltoqueelmarcodela
centraventanaoellist6ndemadera(fueradelacase)pare
queelvaporemanadodelaunidadpuededrenar
adecuadamentehaciaelexterior
•Instaleunsegundelist6ndemadera(deaprcximadamente6'
delargoy 1"deanchoy delmismogrosordelprimerlisten)en
elcentredelalfdizarexteriorniveladoconlaparteposteriordel
alf_izarinteriorAtornillelossoportesL entrelafaja Esto
levantar_elsoporteL cornosemuestraenlaFigura11
1- MAX
FRANJA DE MADERA _3/4-PULG
MONTADA SOBRE _ _1 I DE SEPARACION
L_pARTESUPERIOR1_2J_//tL.=I
DEL DESCANSO
ANTEpECH O HQJA DOBL_
INTERIOR
ANTEpECHO
LAELIMINACI( NDE LAVENTANA
Apagueelaireacondicionadoy desenchufeel cablede
alimentaci6nRetireel soporteen Ly lostornillosinstalados
enla partesuperioreinferiorde lospaneleslateralesy
gu_rdelosparela posteriorreinstalaci6nCierrelos paneles
latarales Sujetandofirmementeel aireaccodicionado,
levanteel marcoe inclineconcuidadoel aireacondioicoado
haciaafueraparedrenartodaelaguecondensadaLevanta
el aireacondicionadodela ventanay retirelajuntade
espurcadeentre lasventanas
•Elaireacondicionadodelquasehablaaneatamanualafirmapeligro
depesoexcesivo
DosomaspersonasserequiereparamovereinstalartaunidadPare
evitarheddasoagotamlentousetecnicasapropiadasparelevntary
moverlaunidad
•AImanejarleunidad,tengacuidadopareevitarcortarseconlasalertas
met_icasafiladasqueest_onlosserpentinesfron_ypoatedor.
•Aseguresequeelaimacon_cionadonosecaigadurantelainstalacion.
- 20 -
