Kenmore 580.75180500 Manual

REPAIR
PARTS
LIST
Model No.
580.75180500
◆Product Type ◆Part Number
◆Model Number ◆Part Description
Sears, Reobuck and Co., Hoffman Estates, IL 60179 U.S.A.
To Call
Toll Free
For Parts:
1-800-366-PART
(1-800-366-7278)
1-800-4-MY-HOME
(1-800-469-4663)
For Service:
The model number of your Air Conditioner can be found
on the right side of the cabinet.
All repair parts listed are available for immediate
purchase or special order when you visit your nearest
Sears Service Center, or the Service Department at most
Sears stores. To order parts by phone, call the toll free
parts number listed to the left.
When requesting service or ordering parts, always
provide the following information:
¤
ROOM AIR CONDITIONER

01/04 - 2 -
Room Air Conditioner To order Parts call Toll Free
Model No. 580.75180500 1-800-4-MY-HOME®(1-800-469-4663)
CAUTION: Use the Kenmore part number on all orders, not the illustration number.
CABINET & FRONT GRILLE ASSEMBLY
2-A
1-A
3-A
5-A 6-A
8-A
7-A
9-A
4-A
REPAIR PARTS

- 3 - 01/04
580.75180500
CAUTION: Use the Kenmore part number on all orders, not the illustration number.
CABINET & FRONT GRILLE ASSEMBLY
# = Functional Parts
* = Non-illustrated Parts
1 - A
2 - A
3 - A
4 - A
5 - A
6 - A
7 - A
8 - A
9 - A
*
PART NUMBER
3530A20045A
3530A10231A
5231A20008A
4758A30022A
4758A20042A
4758A20042B
3091AR6057R
2H00858D
3850A27114F
3828A21007F
DESCRIPTION
FRONT GRILLE
INLET GRILLE
AIR FILTER ASSEMBLY
VANE
LOUVER
LOUVER
CABINET ASSEMBLY
UPPER GUIDE
LABEL, ENERGY
MANUAL OWNER'S
ILLUSTRATION
NUMBER

01/04 - 4 -
580.75180500
CAUTION: Use the Kenmore part number on all orders, not the illustration number.
CONTROL BOX ASSEMBLY
9-B 3-B
1-B
5-B
13-B
6-B
11-B
12-B
7-B
2-B
10-B
8-B
4-B

- 5 - 01/04
580.75180500
CAUTION: Use the Kenmore part number on all orders, not the illustration number.
CONTROL BOX ASSEMBLY
# = Functional Parts
* = Non-illustrated Parts
1 - B #
2 - B
3 - B
4 - B
5 - B #
6 - B
7 - B
8 - B
9 - B
10 - B
11 - B
12 - B
13 - B
PART NUMBER
4994A20045A
3720A20267A
3550A30122A
6871A20617M
6871A20619A
0CZZA20001L
6411A20048J
6323A20012C
6631AR3843V
6850A90001G
6631A30003A
6711A20089C
3831A20097C
DESCRIPTION
CONTROL BOX
PANEL, CONTROL
COVER, CONTROL BOX
PWB ASSEMBLY, MAIN
PWB ASSEMBLY, DISPLAY
CAPACITOR
POWER CORD ASSEMBLY
THERMISTOR ASSEMBLY
CONNECTOR ASSEMBLY
CABLE FLAT
CONNECTOR ASSEMBLY
REMOTE CONTROL
ESCUTCHEON
ILLUSTRATION
NUMBER

01/04 - 6 -
580.75180500
CAUTION: Use the Kenmore part number on all orders, not the illustration number.
AIR HANDLING & CYCLE PARTS
5-C
6-C
9-C
12-C
14-C
10-C
11-C
2-C
1-C
4-C
15-C
20-C
13-C
8-C
3-C 7-C
11-C
21-C
16-C 19-C
18-C
17-C

- 7 - 01/04
580.75180500
CAUTION: Use the Kenmore part number on all orders, not the illustration number.
AIR HANDLING & CYCLE PARTS
# = Functional Parts
* = Non-illustrated Parts
1 - C
2 - C
3 - C
4 - C
5 - C
6 - C
7 - C #
8 - C
9 - C #
10 - C #
11 - C
12 - C
13 - C
14 - C #
15 - C #
16 - C
17 - C
18 - C
19 - C
20 - C
21 - C
PART NUMBER
3041A20067B
5238A10008A
3072A20005A
4790A20031A
4900A20004A
4960AR1596A
4681A23010A
4790A30018A
5901A20009A
5900AR1508A
3H02932C
4998A10013A
4800A20001A
5421A20091G
5403A20112B
4948A30008A
4H01029F
4H01010A
4H02023A
3530A20042D
5238A20014A
DESCRIPTION
BASE PAN WELD ASSEMBLY
AIR GUIDE
SCROLL
BARRIER
DAMPER
MOTOR MOUNT
MOTOR ASSEMBLY
BARRIER, BLOCK
TURBO FAN
AXIAL FAN
CLAMP SPRING
SHROUD
BRACE
EVAPORATOR ASSEMBLY
CONDENSER ASSEMBLY
ORIFICE
WASHER RUBBER
PIPE ELBOW
HOLE RUBBER
GRILLE, REAR
AIR GUIDE UPPER
ILLUSTRATION
NUMBER

01/04 - 8 -
580.75180500
CAUTION: Use the Kenmore part number on all orders, not the illustration number.
COMPRESSOR PARTS
3-D
4-D
2-D
5-D
8-D
9-D
11-D
7-D
6-D
1-D
10-D
13-D
12-D

- 9 - 01/04
580.75180500
CAUTION: Use the Kenmore part number on all orders, not the illustration number.
COMPRESSOR PARTS
# = Functional Parts
* = Non-illustrated Parts
1 - D
2 - D #
3 - D
4 - D
5 - D
6 - D
7 - D
8 - D
9 - D
10 - D
11 - D
12 - D
13 - D
PART NUMBER
4H00982C
2520UCBJ002
4810AR4155B
1NHA0801206
4986U-L001D
3550U-L002C
4H01058A
4H00947A
5211A30066N
5211A20441L
5210A21099E
5210A21099F
5211A30275Z
DESCRIPTION
ISOLATOR, COMP
COMPRESSOR
BRACKET, WASHER
HEXAGON NUTS
GASKET
TERMINAL COVER
GASKET NUT
TERMINAL COVER NUT
TUBE ASSEMBLY DISCHARGE
TUBE ASSEMBLY SUCTION
TUBE, FORMED
TUBE, FORMED
TUBE ASSEMBLY CAPILLARY
ILLUSTRATION
NUMBER

01/04 - 10 -
580.75180500
CAUTION: Use the Kenmore part number on all orders, not the illustration number.
INSTALLATION KIT ASSEMBLY
1-E
4-E
6-E
2-E
7-E 5-E
3-E
8-E

- 11 - 01/04
580.75180500
CAUTION: Use the Kenmore part number on all orders, not the illustration number.
INSTALLATION KIT ASSEMBLY
# = Functional Parts
* = Non-illustrated Parts
1 - E
2 - E
3 - E
4 - E
5 - E
6 - E
7 - E
8 - E
PART NUMBER
4H01785B
4959AR3402E
4959AR3402F
3H01479D
3H01395C
4H01516A
4H01483A
4H01482A
DESCRIPTION
LBRACKET
CURTAIN ASSEMBLY
CURTAIN ASSEMBLY
SUPPORT BRACKET
SILL BRACKET
LOCK NUT
CARRIAGE BOLT
M-SCREW
ILLUSTRATION
NUMBER
