Kensington Presentair Manual

Presentair™
Bluetooth®Presenter,
Laser & Stylus
INSTRUCTION GUIDE
Register Now!
register.kensington.com
INSTRUCTION GUIDE

2
INSTRUCTION GUIDE
APresentair™ Bluetooth®
Presenter Remote
BCarrying Pouch
CUSB Charging Cable*
DInstruction Guide
* Charging function only, no USB data
function
Contents
AB
C
D

2 3
EFront LED/Low Battery
Indicator Light
FUp Button
GLeft Button
HDown Button
IRight Button
JReset Button
KMicroUSB Charging Connector
LStylus Tip
MRear LED/Charging Indicator
Light
NOn/Off Switch/Bluetooth
Connection Button
OLaser Warning Statement
Components
E
G
F
I
M
O
N
H
K
J
L

4
Getting Started
1 Charge your Presentair Bluetooth
Presenter Remote on any USB port
or charging adapter for 2 hours
before initial use or when the front
LED blinks yellow, indicating the
battery is low.
a
b
NOTE: This device has USB
charging function only, and will
not appear on your system as a
data device when plugged into a
USB port.
2The Rear LED blinks orange during
charghing. When the Presenter
Remote is fully charged, the Rear
LED glows solid orange.

4 5
Pairing for Your Bluetooth
Enabled Computer
Examples for pairing are included for
reference below. If your system differs
from these examples, use the your
systems specific device pairing
instructions.
WidcommMicrosoft
1Press and hold power button on
Presentair 3-6 seconds from Off
to enter pairing mode. Rear Blue
LED will blink until paired.
2Double-click located at the
bottom of the screen.
3Select Add Bluetooth Device.

6
4Select My device is set up and
ready to be found and click Next.
5The indicator light blinks blue.
Select the Kensington Device
(Appears as a mouse) on your
computer screen, and then click
Next.
6Select the mouse on your
computer screen, and then click
Next.

6 7
7Select Don’t use a passkey and
click Next.
8Click Finish.

8
Mac
1Press and hold power button on
Presentair 3-6 seconds from Off
to enter pairing mode. Rear Blue
LED will blink until paired.
2Click located in the top-left
corner of the screen.
3Click System Preferences, then
click .
4Click Set Up New Devices.
5Click Continue.

8 9
6Select Mouse from the device list,
and click Continue.
7The indicator light on the mouse
blinks blue. Kensington Device
(Appears as a mouse) appears
on your computer screen. Click
Continue.

10
8On the Conclusion screen, click
Quit.
30' (10m) max.

10 11
Power Button and Rear LED
Functions
Action Explanation
LED Color
and Behavior
Press, hold,
and release
Power
Button from
Off
Turns on
power
LED glows
blue
Press and
hold Power
Button 3–6
seconds
from Off
Turns on
power
and enters
pairing mode
LED blinks
blue until
paired to a
device
Press, hold,
and release
Power
Button from
On
Turns off
power.
The Mode
Settings are
retained
Blue LED
fades off
Press, hold,
and release
Power
Button from
Pairing Mode
Turns off
power.
The Mode
Settings are
retained
Blue LED
fades off
Mode Functions
To switch between Presenter mode
and Media mode, press and hold the
Down Button. The Front LED will glow
for 4 seconds in yellow for Presenter
mode, blue for Media mode.
Button
Presenter
Mode Media Mode
Up Button Turns laser
on as long
as button is
pressed.
Play/Pause
Down
Button
Black screen Stop

12
Left Button Page up Previous
song/video
Right Button Page down Next song/
video
Note: When there is no activity for 1
hour, the Presenter Remote will enter
sleep mode.
Technical Support
Technical support is available to all
registered users of Kensington
products. Technical Support contact
information can be found on the back
page of this manual.
Web Support
You may find the answer to your
problem in the Frequently Asked
Questions (FAQ) section of the Support
area on the Kensington Website:
www.support.kensington.com.
Telephone Support
There is no charge for technical support
except long-distance charges where
applicable. Please visit www.
kensington.com for telephone support
hours.
U.S. 800-535-4242 or 650-572-2700
Canada 800-268-3447
Please note the following when calling
support:
• Callfromaphonewhereyouhave
access to your device.
• Bepreparedtoprovidethefollowing
information:

12 13
– Name, address, and telephone
number
– Name of the Kensington product
– Make and model of your computer
– System software and version
– Symptoms of the problem and
what led to them
FEDERAL COMMUNICATIONS COMMISSION RADIO
FREQUENCY INTERFERENCE STATEMENT
This device has been tested and found to comply
with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates, uses. and can radiate
radio frequency energy and, if not installed and
used in accordance with the instructions, may
cause harmful interference to radio
communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment causes harmful interference to radio or
television reception, which can be determined by
turning the equipment off and on, the user is
encouraged to try to correct the interference by
one or more of the following measures:
• Reorientorrelocatethereceivingantenna.
• Increasetheseparationbetweentheequipment
and receiver.
• Connecttheequipmentintoanoutletona
circuit different from that to which the receiver
is connected.
• Consultthedealeroranexperiencedradio/TV
technician for help.
MODIFICATIONS: Modifications not expressly
approved by Kensington may void the user’s
authority to operate the device under FCC
regulations and must not be made.
SHIELDED CABLES: In order to meet FCC
requirements, all connections to equipment using
a Kensington input device should be made using
only the shielded cables.
FCC DECLARATION OF CONFORMITY COMPLIANCE
STATEMENT
This product complies with Part 15 of the FCC
rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful

14
interference, and (2) This device must accept any
interference received, including interference that
may cause undesired operation. As defined in
Section 2.909 of the FCC Rules, the responsible
party for this device is Kensington Computer
Product Group, 333 Twin Dolphin Drive, Redwood
Shores, CA 94065,USA.
CLASS 2 LASER SAFETY STATEMENT
This laser device
complies with
International Standard
IEC/EN 60825-1: ED 2.
2007, Class 2 Laser
Product and also
complies with 21 CFR
1040.10 and 1040.11,
except for deviations
pursuant to laser
Notice No. 50, dated
June 24, 2007:
1. Emission of a parallel beam of visible light;
2. Maximum Power of 1 milliwatt CW, wavelength
range 650±20 nanometers;
3. Operating temp between 0 ° C (32° F) to 40° C
(104° F).
• Donotdisassemblethedevice
• Donotusethedeviceoutsideofitsspecified
operating temperature range. If the device is
exposed to an environment outside of its
prescribed operation, turn off the device and
allow the temperature to stabilize within the
specified operating range before using the
device.
CAUTION!
This device has no serviceable parts. Use of
controls or adjustments or performance of
procedures other than those specified herein may
result in hazardous radiation exposure.
DISPOSING OF YOUR PRESENTAIR
• DonotincinerateordisposeofyourPresentair
in a fire or microwave.
• DonotdisposeofyourPresentairasordinary
refuse, as it contains a lithium-polymer battery.
Consult your local municipal or civil authority for
instructions on correctly disposing of a lithium-
polymer battery.
• IntheUSAandCanada:Thismark indicates
your Presentair can be recycled by the
Rechargeable Battery Recovery Corporation

14 15
(“RBRC”). When you are ready to dispose of the
Presentair, please contact the RBRC at
1-800-8-BATTERY or www.rbrc.org.
INDUSTRY CANADA CONFORMITY
This device has been tested and found to comply
with the limits specified in RSS-210. Operation is
subject to the following two conditions: (1) This
device may not cause interference, and (2) This
device must accept any interference, including
interference that may cause undesired operation
of the device.
This Class [B] digital apparatus complies with
Canadian ICES-003.
CE DECLARATION OF CONFORMITY
Kensington declares that this product is in
compliance with the essential requirements and
other relevant provisions of applicable EC
directives. For Europe, a copy of the Declaration of
Conformity for this product may be obtained by
clicking on the Compliance Documentation link at
www.support.kensington.com.
INFORMATION FOR EU MEMBER-STATES ONLY
The use of the symbol indicates that this
product may not be treated as household
waste. By ensuring this product is
disposed of correctly, you will help prevent
potential negative consequences for the
environment and human health, which
could otherwise be caused by inappropriate waste
handling of this product. For more detailed
information about recycling of this product, please
contact your local city office, your household waste
disposal service, or the shop where you purchased
the product.
Kensington and the ACCO name and design are
registered trademarks of ACCO Brands. The
Kensington Promise is a service mark of ACCO
Brands. Presentair is a trademark of ACCO Brands.
All other registered and unregistered trademarks
are the property of their respective owners.
© 2012 Kensington Computer Products Group, a
division of ACCO Brands USA LLC. Any unauthorized
copying, duplicating, or other reproduction of the
contents hereof is prohibited without written
consent from Kensington Computer Products
Group. All rights reserved. 03/12

901-2601-00
KL
Kensington Computer Products Group
A Division of ACCO Brands
333 Twin Dolphin Drive, Sixth floor
Redwood Shores, CA 94065
ACCO Brands Europe
Oxford Road
Aylesbury
Bucks, HP21 8SZ
United Kingdom
www.kensington.com
ACCO Australia
Level 2, 8 Lord St
Botany NSW 2019
Australia
Patents Pending
Designed in California, U.S.A.
by Kensington
Made in China
Complete warranty terms are available at:
www.warranty.kensington.com
