KENT Razor Blade 26D User manual

Razor Blade 26D-28D
PARTS LIST
KENT MODELS:
908 7099 020 - 908 7100 020
908 7101 020
909 6458 000(3)2006-06
Razor Blade 28C

2005-12
1
909 6458 000(3)2006-06
DESCRIPTION PLAN
WHEN ORDERING PARTS
* Use the 8, 9 or 10 digit numbers from the “Ref. No.” columns in this parts list.
* Specify the model and serial number of the machine.
* Use the space below to record the model and serial number for future reference.
Model ___________________ Serial No. ___________________
GENERAL VIEW 2-3
TANKS ASSEMBLY 4-5
DIRTY WATER TANK 6-7
CHASSIS SYSTEM 8-9
FRONT WHEELASSEMBLY 10-11
STEERING SYSTEM 12-13
CONTROL PANELASSEMBLIES 14-15
PEDALASSEMBLY 16-19
FOOTBOARD ASSEMBLY 20-21
SOLUTION SYSTEM 22-23
SQUEEGEE SYSTEM 26D 24-25
SQUEEGEE SYSTEM 28D-28C 26-27
DISC BRUSHES SYSTEM 28-29
CYLINDRICAL BRUSHES SYSTEM 30-39
SEATASSEMBLY 40-41
LIFTING BRUSH DECK SYSTEM 42-43
ELECTRICAL COMPONENTS 44-45
BATTERY CHARGER ASSEMBLY 46-47
WIRING DIAGRAM 48-49
ACCESSORIES 50-53
RECOMMENDED SPARE PARTS 54-55
TABLE OF CONTENTS
RAZOR BLADE 26D - 28D - 28C
* = Optional
# = Modified item No. or New item No.
[] = Not shown
xxxxxx= Contained in a Kit

2005-12
2
909 6458 000(3)2006-06
RAZOR BLADE 26D - 28D - 28C
GENERAL VIEW
15
12
16
17
14
7
8
6
13
2
1
5
93
10
11
4
18
19

2005-12
3
909 6458 000(3)2006-06
Item No. Ref. No. Qty Description
1 145 1129 000 6 Washer 16X6
2 145 1894 000 6 Screw M6X30
3 1 Squeegee system 26D
4 909 5903 000 1 Hatch right
5 909 5904 000 1 Hatch left
6 1 Brushes system 26D
6 1 Brushes system 28D
7 1 Front wheel assembly
8 1 Solution system
9 1 Squeege support system
10 1 Squeegee system 28D-28C
11 1 Lifting brush deck system
12 1 Steering system
13 1 Cylindrical brushes system 28C
14 1 Chassis assembly
15 1 Tanks assembly
16 909 6068 000 1 Battery container
17 1 Footboard Assembly
18 909 6158 000 1 Box for battery charger cable
19 146 0765 000 2 Screw 6X10
RAZOR BLADE 26D - 28D - 28C
GENERAL VIEW

2005-12
4
909 6458 000(3)2006-06
RAZOR BLADE 26D - 28D - 28C
TANKS ASSEMLY
12
7
6
14
8
16
11
13
15
10
1
2
4
5
3
17
SEE SEAT ASSEMBLY
SEE DIRTY WATER TANK
9
8
3
18

2005-12
5
909 6458 000(3)2006-06
Item No. Ref. No. Qty Description
1 xxxxxxxx 6 Washer flat 6X18 (Tanks assembly hardware kit)
2 xxx xxxx xxx 1 Washer flat 6X12,5 SS (Tanks assembly hardware kit)
3 xxxxxxxx 4 Nut hex low M6 selflock. SS (Tanks assembly hardware kit)
4 xxx xxxx xxx 2 Washer flat 6X24 SS (Tanks assembly hardware kit)
5 xxx xxxx xxx 1 Screw M6X95 (Tanks assembly hardware kit)
6 xxx xxxx xxx 4 Washer flat 12X24 SS (Tanks assembly hardware kit)
7 xxx xxxx xxx 2 Screw M12X130 (Tanks assembly hardware kit)
8 xxx xxxx xxx 3 Screw M6X65 (Tanks assembly hardware kit)
9 xxx xxxx xxx 2 Washer flat 6X12,5 (Tanks assembly hardware kit)
10 xxx xxxx xxx 4 Washer split 6 (Tanks assembly hardware kit)
11 xxx xxxx xxx 2 Gasket (Tanks assembly hardware kit)
12 909 6245 000 1 Fresh water tank
13 xxx xxxx xxx 1 Cable guide (Tanks assembly hardware kit)
14 xxx xxxx xxx 2 Spacer (Tanks assembly hardware kit)
15 xxxxxxxx 2 Screw M6X70 (Tanks assembly hardware kit)
16 xxxxxxxx 2 Nut hex M12 selflock. (Tanks assembly hardware kit)
17 xxx xxxx xxx 2 Screw M6X45 (Tanks assembly hardware kit)
18 xxx xxxx xxx 2 Razor Blade Decal (Kit decals)
[19] 909 6470 000 1 Kit decals (Razor blade decals pos.18; KENT decal pos. 22 - pag.12; battery
decal pos. 38 - pag. 8; decal fuse 60A, decal fuse 5A, decal fuse 100A pos.
29-30-31 - pag. 38)
[20] 909 6401 000 1 Tanks assembly hardware kit (1,2,3,4,5,6,7,8,9,10, 11,13,14,15,16,17)
RAZOR BLADE 26D - 28D - 28C
TANKS ASSEMLY

2005-12
6
909 6458 000(3)2006-06
RAZOR BLADE 26D - 28D - 28C
DIRTY WATER TANK
16
5
3
4
15
13
18
19
17
14
2
22
1
8
7
11
12
6
10
21
20
9
23
25
24
26
28
29
30 31 32 33
34

2005-12
7
909 6458 000(3)2006-06
Item No. Ref. No. Qty Description
1 xxxxxxxx 2 Nut cap M6 (Float cage fitting kit)
2 xxxxxxxx 3 Nut hex low M6 selflock. (Dirty water tank hardware kit)
3 08812259 2 Cage, float
4 08812373 1 Floating ball
5 909 6199 000 1 Holder, float cage
6 08812967 1 Hose clamp (Hose clamp kit)
7 xxxxxxxx 1 Gasket (Float cage fitting kit)
8 xxx xxxx xxx 2 Washer flat 6X18 SS (Float cage fitting kit)
9 145 0543 000 1 Hose clamp 14/32-52
10 xxx xxxx xxx 1 Screw M5X12 SS (Hose clamp kit)
11 xxx xxxx xxx 2 Nut M6 SS (Float cage fitting kit)
12 xxx xxxx xxx 4 Washer flat 6X12,5 SS (Float cage fitting kit)
13 xxx xxxx xxx 2 Screw hex. hd M6X40 SS (Float cage fitting kit)
14 909 5196 000 1 Vacuum motor 24V 500W
15 909 6246 000 1 Recovery tank
16 909 6247 000 1 Tank cover
17 xxx xxxx xxx 3 Spacer hex M6 H70 (Dirty water tank hardware kit)
18 909 6094 000 3 Vibration damping
19 909 6095 000 1 Gasket
20 909 6096 000 1 Drain hose
21 909 6097 000 1 Vacuum hose
22 146 0629 000 1 Gasket
23 909 5371 000 2 Carbon brush
24 909 6380 000 1 Hose clamp kit (6,10)
25 909 6381 000 1 Float cage fitting kit (1,7,8,11,12,13)
26 909 6382 000 1 Dirty water tank hardware kit (2,17)
[27] 909 6128 000 1 Clamp
28a 909 6442 000 1 Acoustic insulation hose
29a 909 6569 000 1 Acoustic insulation
30# xxx xxxx xxx 2 Screw M3X20 ss
31# xxx xxxx xxx 1 Cover tank plate
32# xxx xxxx xxx 2 Washer flat 3X12 SS
33# xxx xxxx xxx 2 Nut hex. low selflock. M3 SS
34# 909 6811 000 1 Cover tank stopper kit (30,31,32,33,35)
[35]# 909 6813 000 1 Installation instructions for cover tank stopper kit
RAZOR BLADE 26D - 28D - 28C
DIRTY WATER TANK
a: on machines with serial number starting from 060803403

2005-12
8
909 6458 000(3)2006-06
RAZOR BLADE 26D - 28D - 28C
CHASSIS SYSTEM
2
9
85
21
8
11
18
1
26
15
1
17
30
32
10
16
22
25
24
3
28
31
23
14 7
27
6
12
4
13
29
20
10
1
3
33
34
35
36
37
19
39
40
41
42

2005-12
9
909 6458 000(3)2006-06
RAZOR BLADE 26D - 28D - 28C
CHASSIS SYSTEM
Item No. Ref. No. Qty Description
1 xxx xxxx xxx 8 Washer flat 6X12,5 SS (Bar protection fitting kit -Actuator’s pin fitting kit -
Chassis hardware kit)
2 xxxxxxxx 2 Screw hex hd M8x35 SS (Chassis hardware kit)
3 xxxxxxxx 3 Nut hex. low self lock. M6 SS (Bar protection fitting kit -Kit tank cable)
4 08603688 2 Nut hex. low self lock. M5 SS
5 xxxxxxxx 2 Bushing ø 8X12X12.5 (Chassis hardware kit)
6 xxxxxxxx 2 Bushing (Rear wheels fitting kit)
7 xxx xxxx xxx 1 Washer flat 6X24 SS (Kit tank cable)
8 xxxxxxxx 4 Washer flat 8x17 SS (Chassis hardware kit)
9 xxx xxxx xxx 2 Washer split 8 SS (Chassis hardware kit)
10 145 4772 000 8 Insert hex. M6
11 145 4773 000 3 Insert hex. M8
12 xxx xxxx xxx 2 Screw M8X20 (Rear wheels fitting kit)
13 145 8282 000 2 Screw hex hd M5x12 SS
14 xxx xxxx xxx 1 Screw (Kit tank cable)
15 xxx xxxx xxx 4 Washer split 6 SS (Chassis hardware kit)
16 xxx xxxx xxx 2 Retaining ring (Actuator’s pin fitting kit)
17 145 9828 000 1 Screw M8X35
18 xxx xxxx xxx 4 Screw hex hd M6X16 SS (Chassis hardware kit)
19 xxx xxxx xxx 1 Squeegee lifting calble
20 909 6240 000 1 Plate
21 145 2612 000 2 Pulley
22 146 0987 000 4 Clamp
23 xxx xxxx xxx 1 Spacer (Kit tank cable)
24 xxx xxxx xxx 2 Screw hex hd M6x20 SS (Bar protection fitting kit)
25 909 6065 000 1 Chassis BR601-BR651-BR751
26 909 6066 000 1 Actuator protection
27 909 6067 000 2 Rear wheel ø 300x70
28 909 6069 000 1 Bar protection cable
29 909 6070 000 1 Drain hose bracket
30 909 6715 000 1 Jack motor 24V
31 909 6151 000 1 Tank cable
32 xxx xxxx xxx 1 Pin (Actuator’s pin fitting kit)
33 909 6364 000 1 Rear wheels fitting kit (6,12)
34 909 6365 000 1 Kit tank cable (3,7,14,23)
35 909 6366 000 1 Bar protection fitting kit (1,3,24)
36 909 6367 000 1 Actuator’s pin fitting kit (1,16,32)
37 xxx xxxx xxx 1 Battery decal (Kit decals)
[38] 909 6368 000 1 Chassis hardware kit (1,2,5,8,9,15,18)
39 xxx xxxx xxx 1 Nut hex low selflock M6
40 xxx xxxx xxx 1 Squeegee cable adapter
41 xxx xxxx xxx 2 Nut hex. M6 SS
42 909 6757 000 1 Squeegee cable kit (19,39,40,41)
[46] 909 6758 000 1 Installation Instructions
for squeegee cable kit

2005-12
10
909 6458 000(3)2006-06
RAZOR BLADE 26D - 28D - 28C
FRONT WHEEL ASSEMBLY
29
23
22 33
5
20
6
21
30
18
35
25
32
26
2
17
24
15
11
14
10
7
12
13
36
8
28
31
37
4 34
27
19
9
1
16
3
38
40
39
41
15
42
43
44
45
47
46

2005-12
11
909 6458 000(3)2006-06
RAZOR BLADE 26D - 28D - 28C
FRONT WHEEL ASSEMBLY
Item No. Ref. No. Qty Description
1 xxxxxxxx 2 Cable clamp (Cable clamps fitting kit)
2 08600669 2 Pin 4X20
3 xxxxxxxx 2 Nut hex. low self lock. M5 (Cable clamps fitting kit)
4 145 9774 000 1 Key 5X5X20
5 xxx xxxx xxx 2 Screw hex hd M5x10 (Clamp kit)
6 xxx xxxx xxx 4 Bushing (Front wheel assy hardware kit)
7 xxx xxxx xxx 6 Washer split 8 (Fitting plate kit)
8 145 5065 000 2 Screw M5X14
9 145 5919 000 2 Dowel M10X25
10 xxx xxxx xxx 6 Washer flat 8X17 (Fitting plate kit)
11 xxx xxxx xxx 1 Ring nut (Ring nut kit)
12 xxx xxxx xxx 6 Screw hex hd M8X20 (Fitting plate kit)
13 145 9191 000 1 Retaining ring
14 145 9309 000 6 Screw M6X20
15 xxx xxxx xxx 2 Washer flat 16X30 (Ring nut kit)
16 xxx xxxx xxx 5 Washer flat 5X10 (Cable clamps fitting kit)
17 xxx xxxx xxx 2 Screw M5X25 (Cable clamps fitting kit)
18 xxx xxxx xxx 4 Screw M10X35 (Front wheel assy hardware kit)
19 146 1533 000 1 Dowel M5X10
20 xxx xxxx xxx 2 Clamp (Clamp kit)
21 909 5937 000 1 Steering support
22 909 5938 000 1 Vibration damping
23 909 5939 000 1 Drive wheel 600W 24V
24 909 5940 000 1 Steering support plate
25 909 5941 000 1 Ball bearing support
26 909 5942 000 1 Ball bearing
27 909 5943 000 1 Steering pinion
28 xxx xxxx xxx 1 Crown (Crown kit)
29 909 5945 000 1 Steering shaft
30 909 5946 000 1 Support
31 xxx xxxx xxx 1 Steering crown spacer (Crown kit)
32 909 6317 000 1 Sensor kit
33 909 6221 000 1 Bracket wire protection
34 145 2330 000 1 Greaser
35 145 4691 000 1 Ball bearing
36 145 9505 000 1 Bushing
37 146 2873 000 1 Washer flat 16X30 nylon
38 909 6324 000 1 Carbon brush kit (4pcs)
39 909 6323 000 1 Tyre wheel
40 909 6326 000 1 Electromagnetic brake
41 909 6325 000 1 Motor 600W 24V
42 909 6370 000 1 Fitting plate kit (7,10,12)
43 909 6371 000 1 Crown kit (28,31)
44 909 6372 000 1 Cable clamps fitting kit (1,3,16,17)
45 909 6373 000 1 Ring nut kit (11,15)
46 909 6374 000 1 Clamp kit (5,20)
47 909 6375 000 1 Front wheel assy hardware kit (6,18)

2005-12
12
909 6458 000(3)2006-06
RAZOR BLADE 26D - 28D - 28C
STEERING SYSTEM
SEE CONTROL PANEL SYSTEM
18
22
6
2
5
17
13
16
9
15
14
3
8
19
21
4
1
12
11
7
10
20
24
23
25
Name Plate
26

2005-12
13
909 6458 000(3)2006-06
RAZOR BLADE 26D - 28D - 28C
STEERING SYSTEM
Item No. Ref. No. Qty Description
1 xxx xxxx xxx 2 Nut hex. M5 (Kit rod tension)
2 xxx xxxx xxx 8 Washer split 8 (Steering system hardware kit)
3 145 4773 000 4 Insert hex. M8
4 xxx xxxx xxx 2 Nut hex. self lock. M12X1,25 (Support fitting kit)
5 xxx xxxx xxx 8 Screw hex hd M8X25 (Steering system hardware kit)
6 xxx xxxx xxx 8 Washer flat 8X17 (Steering system hardware kit)
7 909 6074 000 1 Cable
8 xxx xxxx xxx 2 Screw M12X30 (Support fitting kit)
9 146 2445 000 1 Steering column
10 146 2446 000 1 Support
11 146 2449 000 1 Plunger indexing
12 xxx xxxx xxx 1 Rod tension M5X52 (Kit rod tension)
13 146 2457 000 1 Bellow rubber
14 146 2458 000 1 Lever
15 909 5011 000 3 Screw oval hd M6X20 SS
16 909 6071 000 1 Steering column
17 909 6072 000 1 Wheel steering
18 909 6248 000 1 Front cover
19 xxx xxxx xxx 2 Bushing (Support fitting kit)
20 145 9619 000 1 Joint
21 xxx xxxx xxx 2 Washer flat 12X36 (Support fitting kit)
22 xxx xxxx xxx 1 KENT decal (Kit decals)
23 909 6398 000 1 Support fitting kit (4,8,19,21)
24 909 6399 000 1 Kit rod tension (1,12)
25 909 6400 000 1 Steering system hardware kit (2,5,6)
26 145 9290 000 1 Spring

2005-12
14
909 6458 000(3)2006-06
RAZOR BLADE 26D - 28D - 28C
CONTROL PANEL ASSEMBLIES 2006-04
9
10
1
7
4
11
6
13
12
8
3
2
5
14

2005-12
15
909 6458 000(3)2006-06
RAZOR BLADE 26D - 28D - 28C
CONTROL PANEL ASSEMBLIES
Item No. Ref. No. Qty Description
1 145 9124 000 3 Nut hex selflock M3
2 146 2888 000 1 Key switch
3 145 4719 000 1 Knob for potentiometer
4 909 6605 000 3 Spacer
5 146 1727 000 1 Emergency switch
6 146 1728 000 1 Contact
7 909 6608 000 1 Electronic board support
8 146 1710 000 5 Screw M 5X10
9 xxx xxxx xxx 1 Control panel
10 909 6076 000 1 Potentiomenter
11 909 6077 000 1 Electronic board
12 909 6078 000 1 Decal control panel
13 xxx xxxx xxx 1 Control panel gasket
14 146 2887 000 1 Key
[15] 909 6647 000 1 Control panel kit (1-4-7-9-13)
2006-04

2005-12
16
909 6458 000(3)2006-06
RAZOR BLADE 26D - 28D - 28C (before serial number 061808339)
PEDAL ASSEMBLY
1
11
19 20 21 4
13
25
18
10
35
7
8
23
22
9
6
17
16
15
14
12
2
24
24

2005-12
17
909 6458 000(3)2006-06
RAZOR BLADE 26D - 28D - 28C (before serial number 061808339)
PEDAL ASSEMBLY
Item No. Ref. No. Qty Description
1 08053500 1 Nut M4
2 08812095 4 Screw M6X16
3 145 4510 000 2 Washer split 4
4 145 1147 000 2 Spring washer
5 145 6015 000 1 Screw hex hd M4X20
6 145 1241 000 1 Clamp
7 145 2473 000 1 Rod tension M6x32
8 145 4527 000 2 Nut hex low M6
9 145 5867 000 2 Screw hex hd 3,9X13
10 145 9144 000 1 Washer flat 4X9
11 145 9141 000 2 Screw hex hd M4X16
12 146 1938 000 1 Speed contr. pedal bracket
13 146 1939 000 1 Speed contr. pedal support
14 146 2910 000 1 Speed control pedal
15 146 2062 000 1 Gasket
16 146 2315 000 1 Pedal gasket
17 146 2480 000 1 Harness drive pedal
18 145 9228 000 3 Washer split 6
19 146 2882 000 1 Lever
20 146 2883 000 1 Spring
21 146 2884 000 1 Spacer
22 145 4086 000 1 Pedal cover
23 145 8479 000 1 Dowel M6
24 08361400 7 Nut hex selflock low M6
25 145 9227 000 3 Screw hex hd M6X20
[26] 146 2881 000 1 Speed control pedal complete kit (1,2,3,4,5,6,7,8,9,10,11, 12,13,14,15,16,17,
18,19,20,21,22,23,24,25,)

2005-12
18
909 6458 000(3)2006-06
RAZOR BLADE 26D - 28D - 28C (after serial number 061808339)
PEDAL ASSEMBLY
25
18
10
35
7
8
23
22
9
6
16
15
14
12
2
24 17
1
11
19 20 21 4
13
24
2006-06
