KENT Razor Plus 24C User manual

The Razor®Plus family of
automatic scrubbers feature:
–Tools free, interchangeable scrub
decks
(disc and cylindrical)
–Onboard battery charger
–
ECO solution system for
enhanced productivity
–Whisper-quiet operation
–Ergonomic operator controls
Delivering Innovation,
Quality and Value
A
u
t
o
m
a
t
i
c
S
c
r
u
b
b
e
r
s
Razor®Plus
IDEAL
APPLICATIONS
INCLUDE:
–Schools and
Universities
–Retail Facilities
–Healthcare Facilities
–Municipal Facilities
–Contract Cleaners
–Industrial Settings
–Office Buildings
Simple. Clean.

The Kent Razor®Plus family
consists of five models designed
on a modular platform to allow
tools-free exchange of scrub
decks. Three disc models (24D,
26D & 28D) are available
featuring “click-off/click-on”
scrub heads. The two cylindrical
models (24C & 28C) have pre-
sweeping capabilities. All
models feature 21 gallons
solution and recovery capacity,
variable scrub pressure, the
industry’s best sound level, and
astandard onboard battery
charger. Additionally, the
Economically Calibrated Orifice
(ECO) system allows more than
afull hour of productive
scrubbing on a single refill/
dump cycle. Options include
additional scrub decks for
multiple applications, main-
tenance-free gel batteries, and
multiple scrub brushes. The
cumulative result is a level of
innovation, flexibility, safety,
performance, productivity,
reliability,and value not
previously experienced in walk-
behind automatic scrubbers.
Tools-free adjustable
splash skirt
Vacuum motor exhausts
into heavy-duty tubular
steel chassis resulting in
ultra-quiet operation
21 gallon recovery tank
provides easy access for
simple clean-out
Best combination of innovation, quality, and value in
walk-behind automatic scrubbers
Q
u
i
e
t
,
C
l
e
a
n
O
p
e
r
a
t
i
o
n
Optional onboard
solution fill hose
allows machine to
be filled at any
faucet within facility
Scrub decks are
interchangeable
with no-tools in less
than one minute

Convenient storage
platform features a
rubber strap to secure
awide variety of items
21 gallon solution tank
combined with ECO system
allows over one hour of
continuous scrub time
without refilling
Large, foam-filled tires
provide smooth operation
and high traction
S
i
m
p
l
e
C
l
e
a
n
i
n
g
S
o
l
u
t
i
o
n
s
Adjustable, ergonomic
paddle handle provides
comfort and safety.
Simple control panel design
give quick access to variable
scrub pressure, ECO solution
system, and click-off scrub
head system (disc models).
Onboard battery charger and
charger cord is located on the
rear of the machine. Access
window provides battery and
charger status.
Top cover opens for easy
access to recovery tank,
vacuum float shut-off,
and allows solution
tank to be filled from
the rear of the machine
Heavy-duty,break-away
squeegee with tools-free blade
rotation and replacement
Tip back tank design
allows full accessibility
to batteries and all
components for simple
inspection and
maintenance
Cylindrical scrub decks
feature tools-free
removable brushes.
Counter-rotating brushes
deposit loose debris into
hopper for sweep/scrub
multi-tasking.

©2006, Kent, Printed in U.S.A., Form L1559K, 5-06
TECHNICAL SPECIFICATIONS
Razor®Plus
Razor®Plus 24D Razor®Plus 26D Razor®Plus 28D Razor®Plus 24C Razor®Plus 28C
Brush Type: Disc Disc Disc Cylindrical Cylindrical Scrub Path: 24 in (61 cm) 26 in (66 cm) 28 in (71 cm) 24 in (61 cm) 28 in (71 cm) Max Productivity
33,800 ft2/hr (3,140 m2/hr) 36,600 ft2/hr (3,400 m2/hr) 39,400 ft2/hr (3,660 m2/hr) 33,800 ft2/hr (3,140 m2/hr) 39,400 ft2/hr (3,660 m2/hr)
@ 3.2 mph:
Max Productivity
15,800 ft2/hr (1,468 m2/hr) 17,200 ft2/hr (1,598 m2/hr) 18,500 ft2/hr (1,719 m2/hr) 15,800 ft2/hr (1,598 m2/hr) 18,500 ft2/hr (1,719 m2/hr)
@ 1.5 mph: Run Time: 3 – 4.5 hrs. (variable by battery size and scrubbing application) – ALL MODELS Scrub Head Size:
(2) 12 in (30.5 cm) brushes (2) 13 in (33 cm) brushes (2) 14 in (35.5 cm) brushes (2) 23 in (58 cm) brushes (2) 27 in (61 cm) brushes or pad holders or pad holders or pad holders
Voltage: 24 V 24 V 24 V 24 V 24 V Power Source: (4) 6 V batteries (wet acid and gel cell available) – ALL MODELS Onboard Battery Charger:
24 V, 25 amp Wet/Gel – ALL MODELS
Brush Speed: 220 rpm 220 rpm 220 rpm 600 rpm 600 rpm Brush Pressure: 70 lb-110 lb (32 kg-50 kg) variable by gas shock – DISC MODELS 70 lb (32 kg) 70 lb (32 kg) Brush Motors: (2) 0.54 hp (2) 0.54 hp (2) 0.54 hp (2) 0.60 hp (2) 0.60 hp Solution Control: Gravity feed, variable from 0.25gal/min-1.0gal/min with ECO (Efficiency Calibrated Orifice) which allows over one full hour of scrub time
on a single tank
Solution Tank: 21 gal (80 L) 21 gal (80 L) 21 gal (80 L) 21 gal (80 L) 21 gal (80 L) Recovery Tank: 21 gal (80 L) 21 gal (80 L) 21 gal (80 L) 21 gal (80 L) 21 gal (80 L) Vacuum Motor: 0.68 hp 3-stage 0.68 hp 3-stage 0.68 hp 3-stage 0.68 hp 3-stage 0.68 hp 3-stage Sound Level: 66 dB A at operator's position – ALL MODELS Drive System: 0.27 hp variable forward and reverse, max speed = 3.2 mph (5.2 km/hr), 10% gradeability – ALL MODELS Dimensions W = 26 in (66 cm) W = 27 in (69 cm) W = 30 in (76 cm) W = 26 in (66 cm) W = 30 in (66 cm) (w/o squeegee): L = 59 in (150 cm) L = 59 in (150 cm) L = 59 in (150 cm) L = 59 in (150 cm) L = 59 in (150 cm)
H = 42 in (107 cm) H = 42 in (107 cm) H = 42 in (107 cm) H = 42 in (107 cm) H = 42 in (107 cm)
Squeegee Width: 32 in (81 cm) 32 in (81 cm) 34 in (86 cm) 32 in (81 cm) 34 in (86 cm) Weight:
Machine Only = 265 lb (120 kg), With Max Battery = 539 lb (245 kg), Machine Shipping Weight (batteries shipped separately) = 350 lb (159 kg)
