Kentix AlarmManager-BASIC User manual

!
kentix.com
User-Manual
Kentix AlarmManager
MultiSensors
KeyPad and Accessories
Kentix DoorLock
Kentix360 Cloud and SIM


!
Page (06-2017, subject to change) kentix.com2
Kentix360 - Cloud and SIM
DoorLock
KeyPad-Touch & Accessories
MultiSensors
Kentix-Systems - basic infos
The AlarmManager


1. Introduction and summary 7
1.1. Features 7
1.2. Applications 7
1.3. Safety note 7
2. Connection examples and installation notes 8
2.1. StarterSet-BASIC/PRO-1 8
2.2. StarterSet-PRO-2 8
2.3. StarterSet with optional equipment 9
2.4. Alarm-inputs 10
2.5. Relay contacts 10
2.6. Power supply 10
3. Overview KENTIX System Topology 11
4. AlarmManager-BASIC/PRO 12
4.1. Login to the AlarmManager 12
4.2. Changing IP-Settings 12
4.3. Communication- / Network ports 13
4.4. Default settings / Factory defaults 13
4.5. Configuration in 8 steps 14
4.6. Visual and acoustic signaling 15
4.7. Alarm zones 16
4.8. Quitting Alarms 16
4.9. User accounts 17
4.10. SMS commands for remote control of AlarmManager 18
4.11. Settings - AlarmManager-BASIC and -PRO 19
4.12. Settings - AlarmManager-PRO only 21
4.13. SMS gateway function 22
4.14. SMS Limit 22
4.15. MIB for SNMP-Systems 23
4.16. Execution of Firmware Updates 24
4.17. License management and upgrade 24
4.18. Connections - AlarmManager-BASIC/PRO 25
5. MultiSensors 26
5.1. Mounting instructions for MultiSensor-RF / -LAN / -LAN-RF 26
5.2. Coverage of the integrated PIR movement detector 26
5.3. Calibration of the temperature / humidity sensor 27
5.4. Kentix system jack at MultiSensor-RF / -LAN / -LAN-RF 27
5.5. MultiSensor-RF 28
5.5.1. Adding a MultiSensor-RF 28
5.6. MultiSensor-LAN 29
5.6.1. Default settings / Factory defaults 29
5.6.2. Software function MultiSensor-LAN 29
5.6.3. Configuration - Basic configuration 31
5.6.4. Configuration - MultiSensor (Sensor- and alarm settings) 32
5.6.5. Users 33
5.6.6. System 34
5.6.7. Switch alarm output 2 34
5.7. MultiSensor-Door / MultiSensor-RACK-MINI 35
5.7.1. Mounting instructions 36
5.7.2. Usage of the reed contact 37
5.7.3. Opening of the casing / replacement of battery 38
Page (06-2017, subject to change) kentix.com3


5.7.4. Adding a MultiSensor-Door / -RACK-MINI 38
5.7.5. Settings 38
5.7.6. Test of the settings 39
5.8. MultiSensor-Rack 40
5.8.1. Safety note and installation 40
5.8.2. Default settings 40
5.8.3. Overview connections 41
5.8.4. Kentix system jack at MultiSensor-RACK 42
5.8.5. Recommended installation 42
5.8.6. ConfigurationConfiguration 43
5.8.7. EnergySensor - Energy 43
5.8.8. Control 46
5.8.9. Configuration - EnergySensor 47
5.8.10. Users 48
5.8.11. System 48
5.8.12. Configuration of the vibration sensor 48
5.9. Control a network camera with MultiSensor-LAN/RACK 49
5.10.Communication Interfaces MultiSensor-LAN/RACK 49
5.11.Perform software update on MultiSensor-LAN / -RACK 50
6. How to open the AlarmManager chassis for inserting a SIM card 51
7. KeyPad-Touch (KKPT) 52
7.1. Adding a KeyPad 52
7.2.Operation KeyPad 53
8. Enhancements 55
8.1. Leakage sensor (KLS03) 55
8.2. Leakage sensor rope (KLS03-ROPE) 57
8.3. Kentix Power-Adapter (KIO1) with digital input clips 58
8.4. Kentix Power-Adapter (KIO2) for powering a MultiSensor 59
8.5. Kentix Power-Adapter (KIO3) with digital I/O clips 60
8.6. Overview and application examples for Power-Adapters (KIO1-3) 61
8.7. Kentix Alarm sirene (KFLASH1) 62
8.7.1. Configuration 63
8.8. Kentix IO-Modules 64
8.9. MultiSensor-LAN-RF (LAN-ZigBee Repeater) 65
9. Kentix DoorLock 66
9.1. Components 66
9.1.1. Online knob (DoorLock-DC) and profile cylinder 67
9.1.2. Online door lever (DoorLock-LE) 67
9.1.3. Online wall reader (DoorLock-WA) 67
9.1.4. Online cabinet lock (DoorLock-RA) 67
9.1.5. Master card set 68
9.1.6. AccessPoint 68
9.1.7. Accessories 68
9.2. Installation & Programming (Inbetriebnahme) 69
9.2.1. Online knob 69
9.2.2. Online door lever 70
9.2.3. Online wall reader 73
9.2.4. Online cabinet lock 77
9.2.5. AccessPoint 80
9.3. Configuration and operation modes 81
9.3.1. DoorLock-device without AccessPoint (offline-mode) 81
Page (06-2017, subject to change) kentix.com4


9.3.1.1. Initial setup - insert / activate batteries 81
9.3.1.2. Initial setup - Master card set 82
9.3.2. DoorLock-devices with AccessPoint (online-mode) 84
9.3.2.1. Default settings / factory defaults 84
9.3.2.2. Communication ports 84
9.3.2.3. Dashboard - Access logbook 85
9.3.2.4. Dashboard - DoorLock control 85
9.3.2.5. Access - Users 86
9.3.2.6. Teach-in of RFID-media in the online-mode 87
9.3.2.7. Access - Access profiles 88
9.3.2.8. Access - Time profiles 88
9.3.2.9. Access - DoorLocks 88
9.3.2.10. Access - DoorLocks - Switching of alarm zones 90
9.3.2.11. Configuration - General 90
9.3.2.12. Configuration - Network 91
9.3.2.13. Configuration - Communication 91
9.3.2.14. Configuration - Master/Slave Mode 92
9.3.2.15. Configuration - Network cameras 92
9.3.2.16. Kentix360 93
9.3.2.17. System - Logbook 93
9.3.2.18. System - SD card 93
9.3.2.19. System - System settings 93
9.3.2.20. System - Help 94
9.3.3. Master-Slave-mode (Compound operation with multiple AccessPoints) 94
9.3.4. Reset of components 94
9.3.5. Battery replacement 95
9.3.6. Emergency opening 96
9.3.7. Dismantling 96
10.Kentix AlarmManager Smartphone-App 97
10.1. The Profile menu 97
10.2. AlarmManager 98
10.2.1. SMS Control 98
10.3. MultiSensor-LAN / -LAN-RF / -RACK 98
10.4. AccessPoint 99
11. Kentix360 Cloud 100
11.1. Setup 100
11.2. Administration 101
11.3. Manage AccessPoint 102
12. Kentix SIM card 103
12.1. Setup 103
12.2. Telephone number and PIN 103
12.3. SMS alarming 103
13. Data sheets 104
13.1. Data sheet AlarmManager-BASIC/PRO (KAM-BASIC/PRO) 104
13.2. Data sheet MultiSensor-RF (KMS-RF) 105
13.3. Data sheet MultiSensor-LAN (KMS-LAN) 106
13.4. Data sheet MultiSensor-LAN-RF (KMS-LAN-RF) 107
13.5. Data sheet MultiSensor-RACK (KMS-RACK) 108
13.6. Data sheet MultiSensor-Door (KMS-Door) 109
13.7. Data sheet MultiSensor-RACK-MINI (KMS-RACK-MINI) 110
13.8. Data sheet KeyPad (KKPT) 111
Page (06-2017, subject to change) kentix.com5


13.9. Data sheet AccessPoint (KXP-16) 112
13.10. Data sheet Online Door knob DoorLock-DC (KXC-KN1/2) 113
13.11. Data sheet DoorLock-LE (KXC-LE) 114
13.12. Data sheet DoorLock-WA (KXC-WA) 115
13.13. Data sheet DoorLock-RA1 (KXC-RA1) 116
13.14. Data sheet digital I/O expansion-module (KIO7052) 117
13.15. Data sheet digital I/O expansion-module (KIO7053) 118
13.16. Data sheet leakage sensor (KLS03) 119
14.Checklist - Acceptance report 120
15. Support 123
Page (06-2017, subject to change) kentix.com6


1. Introduction and summary
Thank you for your decision to buy a KENTIX monitoring solution based on the KENTIX MultiSensor technology.
1.1. Features
The KENTIX AlarmManager-BASIC/PRO is the central system unit, where all the information of the
MultiSensors are collected. The AlarmManager is installed in the server room or rack. It controls and forwards
all alarm and fault messages to the responsible persons. The configuration is done with a comfortable PC client,
the Kentix ControlCenter. The connection and installation of the devices is done plug&play with external power
supplies and RJ45 cabling.
1.2. Applications
•Industry and Trade
•Banks
•Authorities and hospitals
•Telecommunications
•Law firms and medical practices
•Energy and water utility
1.3. Safety note
The installation of the AlarmManager must be run by a competent person.
The sole responsibility for protection against misuse of the SIM card is the card owner. The device allows the
use of a PIN number.
In a power failure, the settings of the AlarmManager are not lost. Energized relays drop out and go back when
the power returns in the unswitched output state.
The device sends power outages directly via SMS. The internal energy supply can protect short-term power
failures for 3-5 minutes. To bridge a longer downtimes, use a suitable UPS system.
Installation
To ensure the security and integrity of the operator and the correct operation of the KENTIX AlarmManager, the
execution of the installation only has to be done by an expert. There must also be ensured, that the relevant
requirements are met.
Environment
The installation must be such that the KENTIX AlarmManager and all associated cables are not affected by the
environmental conditions listed here: dust, humidity, excessive heat, direct sunlight, heat sources, devices that
build strong electromagnetic fields, liquids or corrosive chemicals.
See the technical data sheet for more technical data and environment conditions.
Protection
During the installation of the AlarmManager, certain degrees of protection must be guaranteed. Observe the
relevant regulations for installation in certain environments such as industrial or residential and commercial
buildings.!
Page (06-2017, subject to change) kentix.com7
Kentix-Systems - basic infos


2. Connection examples and installation notes
2.1. StarterSet-BASIC/PRO-1
2.2. StarterSet-PRO-2
Page (06-2017, subject to change) kentix.com8
CompleteSet-PRO 2:
1. Connect the MultiSensor-RF with the AlarmManager or the KIO-Power-Adapter.#
Connect the MultiSensor-LAN with a PoE-Switch.#
Follow steps 2 to 8 described for „StarterSet-BASIC/PRO-1“.
2. The KeyPad is added to the configuration like a Radio Sensor.#
For the configuration please follow the steps as described on p.52 in this manual.
3. Save the Configuration to transfer it into the AlarmManager.
Kentix-Systems - basic infos
1. Connect AlarmManager and MultiSensor via
patchcable.
2. Connect power supply to AlarmManager and
current.
3. Download, install and start Kentix ControlCenter.#
(Software-Download on www.kentix.com)
4. Enter Kentix-Default-IP-Address
(192.168.100.222) and the default user data
(admin/password) and press „Login“.#
(check your own network-settings).
5. Setup IP-Address of AlarmManager in the settings.
6. Add Radio Sensor in „Sensor-Devices“.
7. Make individual setup.
8. Save the Configuration to transfer it into the
AlarmManager.


2.3. StarterSet with optional equipment
1. MultiSensor-LAN:#
Establish network connection and external power supply, if needed.#
Connect to the sensor via browser by entering the Default-IP (192.168.100.223).#
Press „Login“ to reach configurations menu (Username: „admin“, Password: „password“).#
Activate AlarmManager communication in the network-section.#
After saving the settings and a restart, the sensor can be configured with the Kentix ControlCenter.
2. Leakage-Sensor:!
The connection of a Leakage-Sensor is realized either by a direct connection to an AlarmManager,
MultiSensor-LAN or MultiSensor-Rack or with a KIO1-Power-Adapter (required for a connection to a
MultiSensor-RF). The configuration is then done on the device to which the leakage sensor is connected.#
Enter a name in the field „System input 1“ and switch the alarming of the input to „Alarm when open“ and
„Always-Active“.
3. MultiSensor-Door / -Rack-Mini:!
Please follow the the instructions for adding new sensors as described in this manual. Also note that there
are differences in procedure depending on the type of MultiSensor.
Page (06-2017, subject to change) kentix.com9
Kentix-Systems - basic infos


2.4. Alarm-inputs
When installing the device follow the instructions in this manual. Please note polarity and technical data of the
inputs.
2.5. Relay contacts
When installing the device follow the instructions listed in this manual.
Connected devices must installed properly following the specifications in this manual. Pay particular attention to
the allowed supply voltages and services for the various consumers in the technical data-sheet.
2.6. Power supply
The devices are supplied with a DC voltage between 10-32VDC. Use only recommended power supplies or
listed power supplies in this document. The polarity of the cable must not be interchanged. According to the two
operation types "Plug'n Play" and "fixed installation", you can power devices from the plug power supply or via a
fixed connection.
Example 1: Power supply of one MultiSensor via the system jack of the AlarmManager
Example 2: Power supply of two MultiSensors via Power Adapter (KIO1) and plug power supply
Electronic equipment is not domestic waste - in accordance with directive 2002/96/EC OF THE
EUROPEAN PARLIAMENT AND THE COUNCIL dated 27th January 2003 concerning used electrical
and electronic appliances, it must be disposed of properly. At the end of its service life, take this unit for
disposal at a designated public collection point.
Spent batteries are special waste!
Do not throw spent batteries into your domestic waste; take them to a collection point for spent batteries.
The products complies with applicable European standards and directives and is confirmed by the CE
mark.
The CE conformity declaration is available on request.



Page (06-2017, subject to change) kentix.com10
Kentix-Systems - basic infos


3. Overview KENTIX System Topology
Page (06-2017, subject to change) kentix.com11
Kentix-Systems - basic infos
✓The AlarmManager is the central unit.#
With the BASIC-Ausführung up to 10 MultiSensors (only MultiSensor-RF) and 3 KeyPads can be
connected. The PRO-Version supports up to 100 devices (MultiSensor-RF/-LAN/-RACK/-LAN-RF/-
Door or KeyPads).
✓The Kentix RF-components are communication via (ZigBee®) radio in the 2.4GHz ISM Band.#
The MultiSensors and KeyPads work in a mesh network and communicate via each other.
✓Always start each new project with a CompleteSet. The Sets include everything you need for a
Plug’n’Play installation. Select the set according to your project size.
✓You can expand the CompleteSets with the extension parts and accessories at any time.
Mobile phone


4. AlarmManager-BASIC/PRO
4.1. Login to the AlarmManager
The PC-Client Kentix ControlCenter displays a Login-screen after starting the Application.
To log in, enter IP-Address and user data for your AlarmManager.
With the first commissioning, use the default IP-Address 192.168.100.222#
and the user data admin/password to log in.
4.2. Changing IP-Settings
Connection with PC: Connect the LAN interface of the AlarmManager via the supplied LAN cable to your
PC. Note that a direct connection needs the supplied crossover adapter. Set the IP
address of your PC for example to "192.168.100.123".
Note that changes in the IP-Settings get active directly after applying.
A wrong configuration can set the AlarmManager to a state where it is only accessible via direct connection.!
Page (06-2017, subject to change) kentix.com12
NOTE
Only users with the permission „Administrator“ are allowed to make changes to the AlarmManager.#
For users without the admin permission, only the tab pages „Dashboard - Logbook - Chart“ are available for
viewing purposes.
The AlarmManager
IMPORTANT!
If you forgot the IP-address of the AlarmManager connect it with the crossover cable directly to the LAN port of
your PC. Open the Network settings in the ControlCenter to show the current IP address. You may have to
disable the firewall and also additional network cards of the PC.


4.3. Communication- / Network ports
For the configuration and firmware updates and also the communication between#
MultiSensors (-LAN / -LAN-RF / -RACK) the following ports are used. These ports eventually have to be taken
into account for the configuration of your network.
In combination with the Kentix360 Cloud additional ports for configuration and connection to the Cloud are
required.
4.4. Default settings / Factory defaults
Default IP-address: 192.168.100.222
Subnet mask: 255.255.255.0
User: admin
Password: password
Setup IP-Address: Change IP settings in the Kentix Control center opening#
„System“ -> „Settings“ -> „Network...“ in the menu.
No
Description
Port number
1
Configuration AlarmManager via ControlCenter, firmwareupdate
TCP 21, 80, 2101#
from PC to AlarmManager
2
Access to web-interface of AlarmManager / MultiSensors
TCP 80, 443
from PC to AlarmManager / MultiSensors
3
Data transfer between MultiSensors and AlarmManager
TCP 80
4
Request of measurement values via SNMP (network monitoring) from
AlarmManager / MultiSensors
TCP 161 (from SNMP-Tool to AlarmManager or
MultiSensor)
No
Description
Port number
1
Configuration of the Kentix360 Cloud via ControlCenter
TCP 80, 443#
from PC to Internet („mykentix.com“)
2
Communication between AlarmManager/AccessPoint or mobile app to
cloud
TCP 5222 to the Internet#
(„mykentix.com“)
Page (06-2017, subject to change) kentix.com13
Reset to factory defaults
To reset the AlarmManager to factory defaults, press the RESET Button on the back of the board and hold it
down for 5 seconds. The device will be set to factory defaults and restarts. After about 30 seconds the
AlarmManager can be accessed again via the default settings.
(NOTE: This function is valid for all AlarmManager-BASIC/PRO from 01/2014 on)
The AlarmManager


4.5. Configuration in 8 steps
No
Step
Comment
Startup
1
Connect the AlarmManager via LAN cable to the PC. The yellow LED on the
LAN connector indicates a connection. Start the Kentix ControlCenter and
connect with the default IP-address 192.168.100.222 to the AlarmManager.
With 1:1 LAN connection via network cable
use crossover-adapter. Make sure that
your PC is in the same network.
Menu item „System - Settings“
2
To change the network configuration open the menu item „Network“.
3
To configure the different notification ways, use the menu item „E-Mail, SNMP &
GSM“.
Enter the mobile data according to the used SIM card. When a PIN is used for
the SIM card, first „Save“ your configuration with the correct PIN before inserting
the SIM card into the AlarmManager to avoid a lock of the card.
You can disable the PIN of your SIM card
with a mobile phone. The entries in the
software will then be ignored.
Register tab „User accounts“
4
In the first user account enter your name, e-mail-address and mobile number in
international notation (+49 ...).
Assign an user password and a 4-digit Operator-PIN. The first user account is
always the "Administrator Account" and can not be deleted.#
You can test the e-mail and mobile settings
by pressing one of the test-buttons.
5
Using a KeyPad the PIN also applies to the operation via a KeyPad. Note that
the KeyPad allows only 4-digit passwords. To use the internal RFID card inside a
KeyPad also enter the RFID card number.
When controlling the AlarmManager via
your mobile phone the transmitted phone
number will be checked in addition to the
password.
Register tab „Sensor-Devices“
6
Press the "+" key to teach-in new devices such as MultiSensor or KeyPad.
BASIC: A new window opens and all accessible devices appear as soon as you
press the „learn button“ at the device. After all devices are available in the list
press the "Save" button.#
PRO: A windows opens where you can select RF- or LAN-components.
Selecting RF starts the scanning process as described in the BASIC-Version.
LAN-components have to be configured by entering the correct IP-address in
the „device address“-field.
When you run the teach-in process for RF-
devices a closed wireless network is
created, similar to an encrypted wireless
PC network. Make sure that the devices
are located in radio range close to the
AlarmManager / MultiSensor-LAN-RF.
7
In the list of devices you can already test functionality of the device. With a "right
click" you get a choice of test functions. Let the selected MultiSensor LED flash
and give the device a name.
Via the test functions you can switch also
the external outputs on or off.
8
Finally change the alarm settings and alarm assignments (Armed-Active /
Always-Active) according to your needs.
Armed-Active: Alarms are only triggered,
when the system is in armed state.
Always-Active: Alarms are always
triggered, independent of the armed/
disarmed state of the system
Saving the configuration
IMPORTANT!
Changes made in the ControlCenter only become active when being saved into the AlarmManager.

Page (06-2017, subject to change) kentix.com14
The AlarmManager


4.6. Visual and acoustic signaling
AlarmManager
LED-POWER: Lights after connection to the power supply
LED-GSM: Flashes: Booked into GSM network, ready for communication.
Constant: No GSM network connection, no communication possible
LED-ARMED: Lights if AlarmManager is armed
LED-ALARM: Lights if an alarm is triggered
MultiSensor-RF / -LAN / -LAN-RF
LED-GREEN: Lights if MultiSensor is powered and function is OK (not in stealth mode)
Lights after power lost for around 3 minutes.
LED-RED: Constant: MultiSensor is armed
Flashes: An alarm was triggered
MultiSensor-RF / -LAN / -LAN-RF and AlarmManager
BUZZER: Alternating: Arm delay is running.#
Delay is depending on configured time in the ControlCenter.
Constant of 1 Second: System has been disarmed.
Constant of 3 Seconds: Arming was not executed - alarms are existing. Please check
external alarm inputs on AlarmManager or MultiSensor.#
#
MultiSensor-Door / -Rack-Mini
Normal operation mode:
LED-RED: blinking 1x per routine message in case of alarm
LED-GREEN: OFF
BUZZER: 1x short in case of alarm (if acoustic signalization is active)
Teach-In process:
LED-RED: OFF
LED-GRÜN: long blinking: Teach-In process started
ON: Teach-In process completed
BUZZER: 1x long when pressing and holding down the teach-in button
for approx. 3 seconds (start of teach-in process)
Page (06-2017, subject to change) kentix.com15
The AlarmManager


4.7. Alarm zones
MultiSensors connected to the AlarmManager and also the inputs of Kentix IO-modules can be assigned to
different alarm zones. With this option a separation into different areas can be realized. Every zone can be
switched to armed or disarmed state and send alarms independent from the other alarm zones.
For the configuration, add the desired number of zones in the alarm zones section of the base settings and
enter a name for every zone. After this assign the sensors to the desired zone.#
4.8. Quitting Alarms
When an Armed-Active or Always-Active alarm is triggered at the AlarmManager, it has to be quit after the
cause has been fixed. This can be done by the Web-Interface, the ControlCenter, via SMS or with the App.
The last triggered alarm will be resent every time the set up time for the alarm repetition runs up. With a value of
0 this repetition can be suppressed.
If an existing alarm is quit without the cause being fixed, the AlarmManager stops the alarm repetition. The
alarm state stays active.
Additionally the AlarmManager tries for every 6 hours to quit existing alarms. When the cause has been fixed or
is no longer present, alarming can be stopped this way, but gives the possibility to be re-triggered again.
Page (06-2017, subject to change) kentix.com16
IMPORTANT!
Only when an alarm has been quit, it can be triggered again.
Other following alarms with a different cause from the sensors are still reported without acknowledgement.
IMPORTANT!
Also with multiple sensors in one zone an alarm of the type „Armed-Active“ can only be reported once for
every zone. After alarming the alarm repetition is activated. If a continuous alarming is desired, the automatic
quitting of alarms can be activated in the advanced settings.
The Quitting (by Software/Web-Interface/SMS/App) of alarms always considers all alarms regardless of the
assigned alarm zone.
The AlarmManager


4.9. User accounts
In the user accounts the setup of the permissions and the alarming is done.
Only if the required user data is entered, a user can control the AlarmManager or request information.
The list describes the user data required for AlarmManager interaction:
Kentix360 cloud access
A mobile access to the AlarmManager via the Kentix360 cloud service can be activated for each user account.
The option „Kentix360 cloud access“ activates a button „Setup app access“ where the users individual cloud ID
is displayed.#
After the first login with the smartphone alarms are also reported to the user as push notification.
Additionally messages are also send via e-mail and SMS, if the corresponding contact information is stored.
Input field
Description
User Password
Login to the ControlCenter, the Web-Interface and the Kentix App
PIN-Code
Remote control by SMS and switching via KeyPad
E-Mail Address
Destination address for the alarming
Phone number
Destination phone number for the alarming. Also used as authentication for the SMS controlling.
Assigned alarm zones
The user can only switch zones assigned to his account. To switch all zones together, every zone has to
be assigned to the user.
Permissions
Assign single permissions for the user by activating the according option.
Page (06-2017, subject to change) kentix.com17
IMPORTANT!
Only users with the permission „Administrator“ are allowed to make changes to the AlarmManager.#
For users without the admin permission, only the tab pages „Dashboard - Logbook - Chart“ are available for
viewing purposes.
Power failures and connection interrupts to the sensors are also only reported to users marked as
„Administrator“.
The AlarmManager
NOTE!
When the AlarmManager is registered for the cloud service, the SMS alarming can be deactivated if
desired. For this the options „Messages always via SMS“ and „Message network monitoring via SMS“ are
available.


4.10. SMS commands for remote control of AlarmManager
The AlarmManager reports not only all the alarms via SMS, it can be also remotely controlled via simple SMS
commands from a mobile phone. This brings the big advantage of having the central alarm system in your
pocket and remotely setting the system to the desired states.
The AlarmManager can be armed or disarmed and alarms can be acknowledged remotely. So you can decide if
it is necessary to intervene on the ground at any time by using the SMS information and status inquiry.
Important notes for remote control of the AlarmManagers via SMS
•Upper- and lower-case can be used.
•Between „Operator-PIN“ and „COMMAND“ is always a space.
•The „Operator-PIN“ can have 4-8 alphanumerical characters. Setup the PIN with the ControlCenter.
•The AlarmManager is confirming each command SMS with an SMS back to the sender.
•Command SMS with the wrong phone number or password will not be confirmed for security reasons.
SMS control commands
Example: Arm-disarming of the AlarmManager via SMS command"
SMS command
Description
Example
Confirmation
{PIN} ON
Arming of the AlarmManagers. All zones will be
armed.
1234 on
OK! ARM All Zones
{PIN} ON{ZONE}
Arming of the selected zone.
1234 on1
OK! ARM ZONE 1
{PIN} OFF
Disarming of all zones.
1234 off
OK! DISARM All Zones
{PIN} QUIT
Acknowledge of all pending alarms. The alarm
repetition is terminated.
The AlarmManager can be set to arm state again.
1234 quit
OK! ALARM QUIT
{PIN} STATE
The AlarmManager sends the actual system state.
1234 state
OK! ARMED/DISARMED/
ALARM
{PIN} MSTATE1-n
The AlarmManager sends the actual system state
and values of a MultiSensor.
Enter the number of the MultiSensor (1-100)
directly after the command „MSTATE“."
The response contains the name of the
MultiSensor.
1234 mstate1
OK! SENSORNAME:
TEMP=20C
REL-HUM=25%
DEW-POINT=3C
MOTION=15%
EXT-IN=0
SABOTAGE=0
POWER=OK
Page (06-2017, subject to change) kentix.com18
NOTE!
When a sensor sends an alarm, the SMS contains the number of the sensor to send a mstate request.
The AlarmManager
OK! ARM ZONE 123
1234 on
SMS command
SMS answer


4.11. Settings - AlarmManager-BASIC and -PRO
General Settings
System name
Enter the name of the system and choose the active state.
Regional settings
This settings allow to choose the timezone and the temperature unit.
Security - Webinterface always requires authentication!
This prevents the system state to be accessed by unauthorized users.
Security - Communication Key (AccessPoint)!
Using the Access System „Kentix DoorLock“ single alarmzones can be armed or disarmed.
The control for this is realized with a Kentix AccessPoint. To encrypt to connection between the devices a
communication key has to be entered here. This key must be identical in all connected devices.
When no access system is used, this field can be left empty.
Backup folder
The path to the backup files of the AlarmManager‘s configuration is set here.
Network
Here the network settings if the AlarmManager can be defined. For the use of the Kentix360-Cloud or an email-
configuration with DNS servername a valid gateway and DNS Server has to be defined here.
Alarm behavior
Alarm functions
Set the behavior of the AlarmManager for pending alarms here. The arming delay makes it possible to set a
timespan between arming and alarm triggering.
Signaling
The acoustic feedback (buzzers of AlarmManager and MultiSensors) and the feedback of the LEDs can be
activated or deactivated as needed, except the CO-alarming. A CO-alarm always triggers all buzzers for the
specified buzzer time.
Kentix360 Cloud
Please read the chapters „Kentix360 Cloud“ and „Kentix SIM“.
Page (06-2017, subject to change) kentix.com19
The AlarmManager


E-Mail, SNMP & GSM
E-Mail
For e-mail notifications an account can be configured with optional user credentials. Depending on the e-mail
server, setting an encryption method might be necessary. When choosing the encryption mode (STARTTLS /
SSL) the required port will be set to the according default port. The port can be changed if required.
The e-mail notification can be testet directly in the settings using the orange checkbox.#
SNMP - Monitoring
The AlarmManager supports full SNMP-functionality, therefore alarms can be sent as traps. Additionally the
AlarmManager can be configured for requests via network monitoring systems. For this purpose you can
download a MIB (Management Information Base) for the SNMP host.
GSM settings
Enter the mobile number and PIN of the SIM card.
Network monitoring
Configure up to 50 network devices (BASIC: 3 devices). For each device network services can be defined to be
monitored (ICMP Ping or TCP portcheck).
The AlarmManager periodically checks, if the specified services on the servers are available or if there is an
answer on a sent PING. The request interval can be set between 60 and 999 seconds. Note that the alarm will
be triggered after 3 failed attempts.
By pressing the Kentix-Check-Button the connection to the selected service can be tested.
In addition to the server monitoring function, the AlarmManager (PRO only) can receive incoming SNMP-Traps
as alarms. These will be sent to the users which are configured to be notified of always-active alarms. The
retrigger time of this service specifies the period of time after which the alarm can be sent again.
Page (06-2017, subject to change) kentix.com20
NOTE!
The test e-mail is sent to the e-mail-address of the first user. In case of an error please check, whether an e-
mail-address has already been configured for this user. Also take care of possible restrictions (routing/firewalls)
in your network and synchronize data like encryption and communication port with the responsible persons.
NOTE!
When the AlarmManager is registered for the Kentix360 cloud, all e-mails will be sent by the cloud-service. In
this case no e-mail-server is required, but recommended as a fallback option for additional redundancy.#
When the AlarmManager is not able to sent messages via the cloud-service it will automatically send e-mails
via the configured SMTP server.
The AlarmManager
