KENTMASTER HSC-650 Operating and maintenance manual

HSC-650, HSC-800 REV B: 08/13
HSC-650, HSC-800
INCLUDING: OPERATION, INSTRUCTION, INSTALLATION, MAINTENANCE AND PARTSBOOK
IMPORTANT: READ THIS MANUAL CAREFULLY BEFORE INSTALLING, OPERATING OR SERVICING
THIS TOOL.
MULTI PURPOSE BONE SAW
TOOL DATA
MODEL: HSC-650
ASSEMBY NO. 6220100
TYPE: HYDRAULICALLY / AIR OPERATED
NET WEIGHT: 6.5 LB (3.0 G)
HYDRAULIC PRESSURE: 2400 P.S.I. MAX
MODEL: HSC-800
ASSEMBLY NO. 6222000
TYPE: HADRAULICALLY / AIR OPERATED
NET WEIGHT: 8.8 LB (4.0 G)
HYDRAULIC PRESSURE: 2400 P.S.I. MAX
KENTMASTER MFG. CO., INC. 1801 SOUTH MOUNTAIN AVE., MONROVIA, CALIFORNIA 91016 UNITED STATES OF AMERICA
 TELEPHONE: [phone] FAX: [phone]
1 OF 21
HSC-650
HSC-800

HSC-650, HSC-800 REV B: 08/13
OPERATING AND SAFETY INSTRUCTIONS
DO NOT OPERATE THIS TOOL UNTIL YOU HAVE READ AND UNDERSTOOD THE SAFETY
INSTRUCTIONS AND OPERATING MANUALS.
DO NOT OPERATE THIS TOOL UNTIL YOU HAVE RECEIVED TRAINING IN THE HANDLING,
OPERATION AND USE OF THIS TOOL.
STOP USING A MALFUNCTIONING OR DEFECTIVE TOOL IMMEDIATELY. REPORT ANY
PROBLEMS OR DEFECTS TO YOUR SUPERVISOR FOR REMOVAL OF THE TOOL FROM
SERVICE.
DO NOT ATTEMPT TO REPAIR THE TOOL YOURSELF.
DO NOT ALLOW UNAUTHORIZED PERSONS TO USE TOOL.
REMOVE AND DISCONNECT POWER FROM THE TOOL WHEN TOOL IS LEFT UNATTENDED OR
IS NOT IN USE.
NEVER TIE DOWN, BYPASS, ALTER OR MODIFY THE ACTIVATING SWITCHES OR TRIGGERS OF
THIS TOOL.
NEVER MA E ALTERATIONS OR MODIFICATIONS TO THIS TOOL.
BE CONSTANTLY AWARE AND ALERT FOR UNSAFE CONDITIONS AND REPORT THEM
IMMEDIATELY TO YOUR SUPERVISOR.
NEVER PLACE YOUR HAND OR ANY PART OF YOUR BODY IN THE CUTTING PATH OF THE
TOOL.
NEVER ALLOW ANYONE ELSE TO PLACE THEIR HANDS OR ANY PART OF THEIR BODY IN THE
CUTTING PATH OF THE TOOL.
DO NOT ACTIVATE CONTROL SWITCHES OR TRIGGERS OF THIS TOOL UNLESS YOU INTEND
TO TEST OR OPERATE THIS TOOL.
DO NOT USE THIS TOOL FOR ANY PURPOSE OTHER THAN IT’S INTENDED PURPOSE.
WHEN OPERATING THIS TOOL WEAR THE PROTECTIVE GEAR AND SAFETY EQUIPMENT
SUPPLIED TO YOU.
THE NOISE EMISSION (SOUND PRESSURE LEVEL) AT THE WOR STATION MAY EXCEED 80 dB
(A). EAR AND SOUND PROTECTION GEAR IS REQUIRED.
KENTMASTER MFG. CO., INC. 1801 SOUTH MOUNTAIN AVE., MONROVIA, CALIFORNIA 91016 UNITED STATES OF AMERICA
 TELEPHONE: [phone] FAX: [phone]
2 OF 21
Hazards or unsafe practices which could result in severe personal injury,
death or substantial property damage.
Hazards or unsafe practices which could result in minor personal injury,
product or property damage.
Important installation, operation or maintenance information.
! WARNING
! WARNING
! WARNING
! WARNING
! WARNING
! WARNING
! WARNING
! WARNING
! WARNING
! WARNING
! WARNING
! WARNING
! WARNING
! WARNING
! CAUTION

HSC-650, HSC-800 REV B: 08/13
OPERATING INSTRUCTIONS
ONLY TRAINED PERSONNEL ARE TO OPERATE THIS TOOL.
1. TO ENSURE TOOL IS OPERATING PROPERLY, PERFORM FOLLOWING STEPS AT START OF EACH SHIFT:
•MA E SURE TOOL MOVES UP AND DOWN FREELY WHILE HANGING FROM BALANCER OVERHEAD.
•WITH POWER TO TOOL TURNED ON, TEST TRIGGER FOR PROPER OPERATION.
•DEPRESS EACH TRIGGER SEPARATELY. TOOL SHOULD NOT ACTIVATE. DEPRESS BOTH TRIGGERS. TOOL
SHOULD ACTIVATE.
•IF TOOL HAS "ANTI-TIE DOWN" OPTION, BOTH TRIGGERS MUST BE DEPRESSED SIMULTANEOUSLY FOR TOOL
TO ACTIVATE.
2. TO PERFORM WOR , HOLD TOOL FIRMLY AT BOTH HANDLES. SQUEEZE TRIGGERS TO ACTIVATE TOOL.
3. DO NOT EXERT EXCESSIVE PRESSURE. ALLOW TIME FOR THE TOOL TO CUT.
4. TOOL REQUIRES 40 S.C.F.M. OF AIR @ 90 P.S.I. AIR PRESSURE.
MAINTENANCE
ONLY TRAINED AND QUALIFIED PERSONNEL ARE TO PERFORM MAINTENANCE
AND SERVICE TO THIS TOOL.
1. FILL LUBRICATOR WITH ENTMASTER AIR MIST OIL (PART NO. 7903050). SET DRIP RATE ACCORDING TO
INSTRUCTIONS SUPPLIED.
2. TOOL REQUIRES GREASING AFTER 40 HOURS OF OPERATION. GREASE USING ENTMASTER GREASE (PART NO.
7903070).
BLADE REMOVAL AND CLEANING .
ALWAYS DISCONNECT POWER SUPPLY FROM TOOL BEFORE INSTALLING OR
REMOVING BLADE FROM TOOL.
ALWAYS WEAR WIRE MESH GLOVES WHEN INSTALLING OR REMOVING BLADE FROM TOOL.
1. TO REMOVE BLADE, LOOSEN (2) SCREWS, FIGURE 1, ITEM 1 AND GUARD, ITEM 2.
2. REMOVE SCREW, ITEM 3, BLADE HOLDER, ITEM 4 AND BLADE, ITEM 5.
3. CLEAN ALL PARTS REMOVED WITH SOAP AND WATER.
4. SHARPEN OR REPLACE BLADE WHEN NECESSARY AND LUBRICATE ALL PARTS.
5. REASSEMBLE ALL PARTS IN REVERSE ORDER.
AT END OF EACH SHIFT:
1. REMOVE SAW BLADE.
2. IF USING BLADE AGAIN, WASH BLADE WITH HOT WATER TO REMOVE FAT, MEAT AND BONE PARTICLES.
3. DRY AND APPLY A COAT OF MINERAL OIL TO ENTIRE SURFACE OF BLADE TO AVOID OXIDATION.
KENTMASTER MFG. CO., INC. 1801 SOUTH MOUNTAIN AVE., MONROVIA, CALIFORNIA 91016 UNITED STATES OF AMERICA
 TELEPHONE: [phone] FAX: [phone]
3 OF 21
! WARNING
! WARNING
! WARNING
! WARNING

HSC-650, HSC-800 REV B: 08/13
Figure 1 HSC-
SERVICE
1. EEP GOOD RECORDS OF ALL SERVICE ACTIVITY AND INCLUDE TOOL IN PREVENTIVE MAINTENANCE PROGRAM.
2. USE ONLY GENUINE ENTMASTER REPLACEMENT PARTS TO ASSURE PROPER PERFORMANCE OF TOOL.
3. CONTACT THE ENTMASTER SUPPLIER NEAREST YOU FOR PARTS AND CUSTOMER SERVICE INFORMATION.
PARTS BOO
KENTMASTER MFG. CO., INC. 1801 SOUTH MOUNTAIN AVE., MONROVIA, CALIFORNIA 91016 UNITED STATES OF AMERICA
 TELEPHONE: [phone] FAX: [phone]
4 OF 21

HSC-650, HSC-800 REV B: 08/13
MODEL HSC-650, MULTI PURPOSE BONE SAW
Figure 2 MODEL HSC-650
KENTMASTER MFG. CO., INC. 1801 SOUTH MOUNTAIN AVE., MONROVIA, CALIFORNIA 91016 UNITED STATES OF AMERICA
 TELEPHONE: [phone] FAX: [phone]
5 OF 21

HSC-650, HSC-800 REV B: 08/13
6220100: HSC-650, MULTI PURPOSE BONE SAW
ITEM PART # DESCRIPTION QTY
14000050 6.5" SAW BLADE, 140 TOOTH 1
4000620 6.5" SAW BLADE, S IP TOOTH, 70 TOOTH 1
2 6201640 FRONT HANDLE/ OPTIONAL 1
3 6201120 HOLDER, BLADE 1
4 6211670 LEVER 1
5 6211690 NAME PLATE 1
6 6220220 GUARD AND DEPTH GAUGE 1
7 6221100 GUARD 1
8 6221120 BODY, VALVE 1
9 6221130 COUPLING 1
10 6221140 FITTING 2
11 6221150 ALIGNMENT RING 1
12 6221160 GEAR HOUSING ASSEMBLY 1
13 6300770 VALVE PLUG 1
14 6600350 BUSHING 1
15 6600360 VALVE STEM 1
16 7012130 CONNECTOR 2
17 7036030 FITTING 2
18 7300710 RED AIR TUBE 1
19 7300720 GREEN AIR TUBE 1
20 7303670 HYDRAULIC HOSE 2
21 7680080 O-RING 1
22 7680120 O-RING 2
23 7680140 O-RING 1
24 7805060 HYDRAULIC MOTOR 1
25 8030030 SCREW 1
26 8208320 SCREW 4
27 8211080 SCREW 2
28 8241050 SCREW 1
29 8602050 EY 1
30 8620080 PIN 1
31 8640030 DRIVE SCREW 4
32 8890010 SPRING 1
Figure 3 BOM FOR MODELS HSC-650
KENTMASTER MFG. CO., INC. 1801 SOUTH MOUNTAIN AVE., MONROVIA, CALIFORNIA 91016 UNITED STATES OF AMERICA
 TELEPHONE: [phone] FAX: [phone]
6 OF 21

HSC-650, HSC-800 REV B: 08/13
GEARS AND GEAR HOUSING ASSEMBLY
Figure 4 6221160: GEAR HOUSING ASSEMBLY, HSC-650
Figure 5 6200230: DRIVEN CARTRIDGE ASSEMBLY
KENTMASTER MFG. CO., INC. 1801 SOUTH MOUNTAIN AVE., MONROVIA, CALIFORNIA 91016 UNITED STATES OF AMERICA
 TELEPHONE: [phone] FAX: [phone]
7 OF 21
6200230: DRIVEN CARTRIDGE ASSEMBLY
ITEM PART # DESCRIPTION QTY
1 3050060 BEARING 2
2 5000870 RETAINING RING 1
3 6201070 GEAR, BEVEL 1
4 6201090 SPACER 1
5 6201100 MANDREL, SAW 1
6 6201200 WASHER 1
7 6201220 SPACER 1
8 6201230 RETAINER NUT 1
9 6201240 SLEEVE 1
10 8236020 SCREW 4
11 8255460 SCREW 1
6221160: GEAR HOUSING ASSEMBLY, HSC-650
ITEM PART # DESCRIPTION QTY
1 6200230 DRIVEN CARTRIDGE ASSEMBLY 1
2 6201110 HOLDER, SLEEVE 1
3 6220201 DRIVE CARTRIDGE 1
4 6221110 HOUSING, GEAR 1
5 7014060 LUBE FITTING 1
6 8612050 ROLL PIN 1

HSC-650, HSC-800 REV B: 08/13
Figure 6 6220201: DRIVE CARTRIDGE ASSEMBLY, HSC-650
SPECIAL TOOLS (OPTIONAL)
Figure 7 HSC-650, SPECIAL TOOLS (OPTIONAL)
KENTMASTER MFG. CO., INC. 1801 SOUTH MOUNTAIN AVE., MONROVIA, CALIFORNIA 91016 UNITED STATES OF AMERICA
 TELEPHONE: [phone] FAX: [phone]
8 OF 21
4501470 GREASE GUN
4501460 WRENCH, DRIVE SHAFT SLEEVE
4501430 WRENCH, LOC NUT
ITEM DESCRIPTION
SPECIAL TOOLS (OPTIONAL)
6220201: DRIVE CARTRIDGE, HSC-650
ITEM PART # DESCRIPTION QTY
1 3050040 BEARING 2
2 5630620 RETAINING RING 1
3 6201030 SPACER 1
4 6201040 SPACER 1
5 6201050 DRIVE SHAFT 1
6 6201060 PINION GEAR 1
7 6201210 SHIM WASHER 1
8 6221021 SLEEVE 1
9 8503120 NUT 1
10 8600420 EY 1

HSC-650, HSC-800 REV B: 08/13
HSC-650, BLADE GUARD AND DEPTH GAUGE, 6.5”
6220220: GUARD AND DEPTH GAUGE, 6.5"
ITEM PART # DESCRIPTION QTY
1 6201180 SPACER, BRIDGE 2
2 6201200 WASHER 1
3 6211030 HANDLE 1
4 6221030 GUARD 1
5 6221040 BRIDGE 1
6 6221050 DEPTH GAUGE, 6.5" BLADE 1
7 6221070 PLATE, FRICTION 1
8 8010060 SCREW 1
9 8010100 SCREW 1
10 8031060 SCREW 1
11 8241050 SCREW 2
12 8413080 SCREW 1
13 8505100 WASHER 1
14 8507150 WASHER 1
Figure 8 6220220: GUARD AND DEPTH GAUGE, 6.5”
KENTMASTER MFG. CO., INC. 1801 SOUTH MOUNTAIN AVE., MONROVIA, CALIFORNIA 91016 UNITED STATES OF AMERICA
 TELEPHONE: [phone] FAX: [phone]
9 OF 21

HSC-650, HSC-800 REV B: 08/13
FRONT HANDLE (OPTIONAL)
6201640: FRONT HANDLE (OPTIONAL)
ITEM PART # DESCRIPTION QTY
1 6201620 FRONT HANDLE 1
2 6201630 NUT 1
3 8245080 SCREW 1
Figure 9 6201640: FRONT HANDLE (OPTIONAL)
KENTMASTER MFG. CO., INC. 1801 SOUTH MOUNTAIN AVE., MONROVIA, CALIFORNIA 91016 UNITED STATES OF AMERICA
 TELEPHONE: [phone] FAX: [phone]
10 OF 21

HSC-650, HSC-800 REV B: 08/13
MODEL HSC-800, MULTI PURPOSE BONE SAW
Figure 10 MODEL HSC-800
KENTMASTER MFG. CO., INC. 1801 SOUTH MOUNTAIN AVE., MONROVIA, CALIFORNIA 91016 UNITED STATES OF AMERICA
 TELEPHONE: [phone] FAX: [phone]
11 OF 21

HSC-650, HSC-800 REV B: 08/13
6222000: HSC-800, MULTI PURPOSE BONE SAW
ITEM PART # DESCRIPTION QTY
1
4000230 8" SAW BLADE, 150 TEETH, STANDARD 1
4000140 8" SAW BLADE, 100 TEETH 1
4000310 8" SAW BLADE, 74 TEETH, S IP TOOTH 1
2 6201640 FRONT HANDLE / OPTIONAL 1
3 6201120 HOLDER, BLADE 1
4 6211670 LEVER 1
5 6211690 NAME PLATE 1
6 6221100 GUARD 1
7 6221120 BODY, VALVE 1
8 6221130 COUPLING 1
9 6221140 FITTING 2
10 6221150 ALIGNMENT RING 1
11 6222100 GEAR HOUSING ASSEMBLY 1
12 6222200 GUARD AND DEPTH GAUGE 1
13 6300770 VALVE PLUG 1
14 6600350 BUSHING 1
15 6600360 VALVE STEM 1
16 7012130 CONNECTOR 2
17 7036030 FITTING 2
18 7300710 RED AIR TUBE 1
19 7300720 GREEN AIR TUBE 1
20 7303670 HYDRAULIC HOSE 2
21 7680080 O-RING 1
22 7680120 O-RING 2
23 7680140 O-RING 1
24 7805060 HYDRAULIC MOTOR 1
25 8030030 SCREW 1
26 8208320 SCREW 4
27 8211080 SCREW 2
28 8241050 SCREW 1
29 8602050 EY 1
30 8620080 PIN 1
31 8640030 DRIVE SCREW 4
32 8890010 SPRING 1
Figure 11 BOM FOR MODEL HSC-800
KENTMASTER MFG. CO., INC. 1801 SOUTH MOUNTAIN AVE., MONROVIA, CALIFORNIA 91016 UNITED STATES OF AMERICA
 TELEPHONE: [phone] FAX: [phone]
12 OF 21

HSC-650, HSC-800 REV B: 08/13
GEARS AND GEAR HOUSING ASSSEMBLY
Figure 12 6222100: GEAR HOUSING ASSEMBLY, HSC-800
Figure 13 6200230: DRIVEN CARTRIDGE ASSEMBLY
KENTMASTER MFG. CO., INC. 1801 SOUTH MOUNTAIN AVE., MONROVIA, CALIFORNIA 91016 UNITED STATES OF AMERICA
 TELEPHONE: [phone] FAX: [phone]
13 OF 21
6222100: GEAR HOUSING ASSEMBLY, HSC-800
ITEM PART # DESCRIPTION QTY
1 6200230 DRIVEN CARTRIDGE ASSEMBLY 1
2 6201110 HOLDER, SLEEVE 1
3 6222110 HOUSING, GEAR 1
4 6222121 DRIVE CARTRIDGE 1
5 7014060 LUBE FITTING 1
6 8612050 ROLL PIN 1
6200230: DRIVEN CARTRIDGE ASSEMBLY
ITEM PART # DESCRIPTION QTY
1 3050060 BEARING 2
2 5000870 RETAINING RING 1
3 6201070 GEAR, BEVEL 1
4 6201090 SPACER 1
5 6201100 MANDREL, SAW 1
6 6201200 WASHER 1
7 6201220 SPACER 1
8 6201230 RETAINER NUT 1
9 6201240 SLEEVE 1
10 8236020 SCREW 4
11 8255460 SCREW 1

HSC-650, HSC-800 REV B: 08/13
Figure 14 6222121: DRIVE CARTRIDGE ASSEMBLY, HSC-800
SPECIAL TOOLS (OPTIONAL)
Figure 15 HSC-800, SPECIAL TOOLS (OPTIONAL)
KENTMASTER MFG. CO., INC. 1801 SOUTH MOUNTAIN AVE., MONROVIA, CALIFORNIA 91016 UNITED STATES OF AMERICA
 TELEPHONE: [phone] FAX: [phone]
14 OF 21
4501470 GREASE GUN
4501460 WRENCH, DRIVE SHAFT SLEEVE
4501430 WRENCH, LOC NUT
ITEM DESCRIPTION
SPECIAL TOOLS (OPTIONAL)
6222121: DRIVE CARTRIDGE ASSEMBLY
ITEM PART # DESCRIPTION QTY
1 3050040 BEARING 2
2 5630620 RETAINING RING 1
3 6201060 GEAR, PINION 1
4 6201210 SHIM WASHER 1
5 6222130 SPACER, OUTER 1
6 6222140 SPACER 1
7 6222151 SLEEVE 1
8 6222160 DRIVE SHAFT 1
9 8503120 NUT 1
10 8600420 EY 1

HSC-650, HSC-800 REV B: 08/13
HSC-800, BLADE GUARD AND DEPTH GAUGE, 8.0”
6222200: GUARD AND DEPTH GAUGE, 8.0"
ITEM PART # DESCRIPTION QTY
1 6201180 SPACER, BRIDGE 2
2 6201200 WASHER 1
3 6211030 HANDLE 1
4 6222240 BRIDGE 1
5 6222250 PLATE, FRICTION 1
6 6222210 GUARD 1
7 6222220 DEPTH GAUGE, 8" BLADE 1
8 8010060 SCREW 1
9 8010100 SCREW 1
10 8031060 SCREW 1
11 8241050 SCREW 2
12 8413080 SCREW 1
13 8505100 WASHER 1
14 8507150 WASHER 1
Figure 16 6222200: GUARD AND DEPTH GAUGE, 8.0”
KENTMASTER MFG. CO., INC. 1801 SOUTH MOUNTAIN AVE., MONROVIA, CALIFORNIA 91016 UNITED STATES OF AMERICA
 TELEPHONE: [phone] FAX: [phone]
15 OF 21

HSC-650, HSC-800 REV B: 08/13
FRONT HANDLE (OPTIONAL)
6201640: FRONT HANDLE (OPTIONAL)
ITEM PART # DESCRIPTION QTY
1 6201620 FRONT HANDLE 1
2 6201630 NUT 1
3 8245080 SCREW 1
Figure 17 6201640: FRONT HANDLE (OPTIONAL)
KENTMASTER MFG. CO., INC. 1801 SOUTH MOUNTAIN AVE., MONROVIA, CALIFORNIA 91016 UNITED STATES OF AMERICA
 TELEPHONE: [phone] FAX: [phone]
16 OF 21

HSC-650, HSC-800 REV B: 08/13
HSC- TUBING DIAGRAM AND POWER SUPPLY
Figure 18 HSC- TUBING DIAGRAM AND POWER SUPPLY
KENTMASTER MFG. CO., INC. 1801 SOUTH MOUNTAIN AVE., MONROVIA, CALIFORNIA 91016 UNITED STATES OF AMERICA
 TELEPHONE: [phone] FAX: [phone]
17 OF 21

HSC-650, HSC-800 REV B: 08/13
KENTMASTER MFG. CO., INC. 1801 SOUTH MOUNTAIN AVE., MONROVIA, CALIFORNIA 91016 UNITED STATES OF AMERICA
 TELEPHONE: [phone] FAX: [phone]
18 OF 21
[ENGLISH]
GENERAL INFORMATION
MODELS
HSC-650 MULTI PURPOSE BONE SAW (6220100)
HSC-800 MULTI PURPOSE BONE SAW (6222000)
________________________________________________________________________________
SERVICE CENTERS
KENTMASTER LTD. (U.K) KENTMASTER MFG. CO., INC.
16 AVONBAN INDUSTRIAL CENTRE 1801 SOUTH MOUNTAIN AVE.
WEST TOWN ROAD MONROVIA, CALIFORNIA 91016
AVONMOUTH - BRISTOL BS11 9DE UNITED STATES OF AMERICA
UNITED INGDOM
TELEPHONE: ++ 44- (0) 117- 9235035  TELEPHONE: [phone]
FAX: ++ 44- (0) 117- 9829010 FAX: [phone]

KENTMASTER MFG. CO., INC. 1801 SOUTH MOUNTAIN AVE., MONROVIA, CALIFORNIA 91016 UNITED STATES OF AMERICA
 TELEPHONE: [phone] FAX: [phone]
Page 19 of 21
NOTICE TO EMPLOYER AND PURCHASER OF TOOL
NOTICE TO SAFETY DIRECTOR
You have purchased a powerful tool that, if misused, can cause severe
injury and harm to your employees. You must instruct your employees in
the safe and proper use of this tool and to follow the safety procedures
and instructions that have been supplied by the manufacturer of this tool.
Please follow the following instructions.
1. Instruct tool operators to test the tool each day before using it to be sure it does not malfunction.
Remove and repair any tool that malfunctions.
2. Instruct tool operators to immediately stop using a tool that malfunctions or is defective.
3. Instruct personnel to immediately remove all tools that malfunction. Be sure to disconnect tool from
power supply.
4. Instruct all personnel to stay clear of tool, and not to stand or walk in front of, or next to tool when in use.
5. Point out to all personnel the dangers related to the misuse of tool and the importance of following
safety procedures and instructions.
6. Do not make, or allow others to make, alterations or modifications to this tool.
Replace all lost or illegible labels.
7. Follow all safety, installation and maintenance instructions provided with this tool. Establish proper
safety procedures in accordance with local and national requirements to prevent accidental energizing
of tool that can cause injuries.
8. If this tool is sold or change in ownership takes place, you must provide the new owner all safety
instructions, notices and maintenance instructions you were originally provided. You can obtain
additional copies of the instructions from entmaster, free of charge upon request.
9. Give copies of instructions to: (A) Tool Operators
(B) Maintenance Supervisor
(C) Clean-up Supervisor

entmaster Worldwide Location
Kentmaster Equipment (Aust) PTY.LTD.
Unit 2,24 Central Court
Bro ns Plains Qld. 4118
Australia
Telephone: [phone]
Fax: [phone]
[email protected]m
Kentmaster do Brasil, Ltda.
Av. Dr. Joao Teodoro No. 805
Bairro De Vila Rezende
13405-240 Piracicaba, SP,
Brazil
Telephone #1: (019) 3 413 3113
Telephone #2: [phone]
Fax: [phone]
[e-mail]
Kentmaster (IRL) LTD.
Benamore, Dublin Road.
Roscrea,
CO, Tipperary,
Ireland
Telephone: [phone]
Fax: [phone]
[email protected]m
Kentmaster Equipment (NZ) LTD.
5 Cooper Street
Havelock North
Ne Zealand
Telephone #1: (64) 6 8777 857
Telephone #2: 0800 KENTMASTER
Fax: [phone]
Ne [email protected]
Kentmaster South Africa (PTY) LTD.
Johannesburg - S. Africa
Unit 54 Sunnyrock Park
Sunrock Close, Germiston
South Africa
Telephone: [phone]
Fax: [phone]
[e-mail]
Kentmaster (UK ) LTD.
Unit 16 Avonbank Ind. Centre
West To n Rd, Avonmouth-Bristol,
BS11 9DE
England
Telephone: [phone]
Fax: [phone]
[email protected]m
Kentmaster Mfg. Co., Inc.
1801 South Mountain Ave.
Monrovia, CA, 91016
USA
Telephone #1: [phone]
Telephone #2: [phone]
Fax: [phone]
[e-mail]
Kentmaster Omaha
4417 South 139th Street
Omaha, NE, 68137
USA
Telephone #1: [phone]
Telephone #2: [phone]
Fax: [phone]
[e-mail]
KENTMASTER MFG. CO., INC. 1801 SOUTH MOUNTAIN AVE., MONROVIA, CALIFORNIA 91016 UNITED STATES OF AMERICA
 TELEPHONE: [phone] FAX: [phone]
Page 20 of 21
