Kenwood BLP40 User manual

English 2 - 9
Nederlands 10 - 18
Français 19 - 27
Deutsch 28 - 35
Italiano 36 - 43
Português 44 - 52
Español 53 - 61
Dansk 62 - 69
Svenska 70 - 77
Norsk 78 - 85
Suomi 86 - 93
Türkçe 94 - 101
Ïesky 102 - 109
Magyar 110 - 118
Polski 119 - 128
Ekkgmij 129 - 138
Slovenčina 139 - 147
Українська 148 - 157
´¸∂w
851 - 561
TYPE BLP40
Kenwood Ltd
New Lane
Havant
Hampshire
PO9 2NH
kenwoodworld.com
© Kenwood Ltd 2018 127611/3
instructions
istruzioni
instrucciones
Bedienungsanleitungen
gebruiksaanwijzing
Instrukcja obsługi
instruções

safety
lRead these instructions carefully and retain
for future reference.
lRemove all packaging and any labels.
lIf the cord is damaged it must, for safety
reasons, be replaced by KENWOOD or an
authorised KENWOOD repairer.
l
DO NOT process hot ingredients.
l SCALD RISK: Hot ingredients must
be allowed to cool to room temperature
before placing in the goblet or before
blending.
lDo not operate your appliance for
longer than the times specified
below without a rest period.
Processing continuously for
longer periods can damage your
appliance.
Function/
Attachment
Maximum
Operation
Time
Rest Period
Between
Operations
Blender 60 secs Unplug the
appliance
and allow to
cool down for
15 minutes
Multi Mill 60 secs
Grinding Mill 60 secs
Grating Mill 60 secs
lSwitch off and unplug:
before fitting or removing parts;
when not in use;
before cleaning.
lNever fit the blade unit to the power
unit without the blender goblet or mill
jar fitted.
lAlways unplug the appliance before putting
your hands or utensils in the goblet.
2
c
f
1
2
j
k
l
3
4
b
a
d
e
h
i
g
om
pn
5 7
6

3
lAlways take care when handling the blade
assembly and avoid touching the cutting
edge of the blades when cleaning.
lOnly operate the blender with the lid in
place.
lOnly use the goblet with the blade
assembly supplied.
lNever let the power unit, cord or plug get
wet.
lNever use a damaged appliance. Get it
checked or repaired: see ‘service and
customer care’.
lNever use an unauthorised attachment.
lNever leave the appliance unattended
when it is operating.
lWhen removing the blender or mill from the
power unit:
wait until the blades have completely
stopped;
do not accidentally unscrew the goblet
or mill jar/lid from the blade assembly.
lNever run the blender empty.
lNever blend more than the maximum
capacity stated in the recommended
usage chart.
lSmoothie recipes - never blend frozen
ingredients that have formed a solid mass
during freezing, break it up before adding
to the goblet.
lDo not process hard spices such as
Nutmeg or Turmeric root as they may
damage the blade.
lDo not use the blender as a storage
container. Keep it empty before and after
use.
lAlways use the blender on a secure, dry
level surface.

before plugging in
lMake sure your electricity supply is
the same as the one shown on the
underside of the appliance.
l This appliance conforms to EC
Regulation 1935/2004 on materials
and articles intended to come into
contact with food.
before using for the first
time
l Wash the parts: see ‘care and
cleaning’.
key
blender
a filler cap
b locking lid
c goblet
d blender sealing ring
e blender blade unit
f power unit
g cord storage
h speed + pulse control
i ice crushing button
multi mill (if supplied)
j multi mill jar
k multi mill sealing ring
l multi mill blade unit
grinding mill (if supplied)
mmill lid
ngrinding mill blade assembly
grating mill (if supplied)
o mill lid
p grating mill blade assembly
4
lNever place this appliance on or near a
hot gas or electric burner or where it could
touch a heated appliance.
lMisuse of your appliance can result in
injury.
lThis appliance shall not be used by
children. Keep the appliance and its cord
out of reach of children.
lAppliances can be used by persons with
reduced physical, sensory or mental
capabilities or lack of experience and
knowledge if they have been given
supervision or instruction concerning use
of the appliance in a safe way and if they
understand the hazards involved.
lOnly use the appliance for its intended
domestic use. Kenwood will not accept
any liability if the appliance is subject to
improper use, or failure to comply with
these instructions.

5
to use your blender
Use your blender for soups, drinks,
pâtés, mayonnaise, breadcrumbs,
biscuit crumbs, chopping nuts and
crushing ice.
1 Fit the blender sealing ring dinto
the blender blade unit e - ensuring
the seal is located correctly in the
grooved area.
lLeaking will occur if the seal
is damaged or incorrectly
fitted.
2 Screw the blade assembly onto
the goblet – ensuring the blade
assembly is fully tightened 1.
Refer to the graphics on the
underside of the blade unit as
follows:
- unlocked position
- locked position
3 Put your ingredients into the
goblet.
4 Put the filler cap in the lid.
5 Fit the lid to the goblet and turn
clockwise to lock.
6 Place the blender onto the power
unit with the handle situated to the
right hand side and lock by turning
clockwise until you hear a “click”
2.
lThe appliance will not work
if the blender is incorrectly
fitted.
7 Select a speed (refer to the
recommended usage chart).
blender hints
lTo blend dry ingredients - cut into
pieces, remove the filler cap, then
with the appliance running, drop
the pieces down one by one. Keep
your hand over the opening. For
best results empty regularly.
lThe processing of spices is not
recommended as they may
damage the plastic parts.
lWhen making mayonnaise, put all
the ingredients, except the oil, into
the blender. Remove the filler cap.
Then, with the appliance running,
add the oil slowly through the hole
in the lid.
lThick mixtures, e.g. pâtés and dips,
may need scraping down. If the
mixture is difficult to process, add
more liquid.

6
to use your multi mill
(if supplied)
Use your multi mill for milling herbs,
nuts, coffee beans and purees.
1 Put your ingredients into the jar j.
Fill it no more than half full.
2 Fit the multi mill sealing ring
kinto the multi mill blade unit
l - ensuring the seal is located
correctly in the grooved area.
lEnsure that the seal is fitted
correctly.
3 Turn the blade unit lupside
down. Lower it into the jar, blades
down 3. Turn anti-clockwise to
lock.
4 Place the mill onto the power unit
and lock by turning clockwise until
you hear a “click” 4.
5 Select a speed or use the pulse
control.
to use your grinding
mill (if supplied)
Suitable for grinding spices, coffee
beans and processing ginger,
garlic and chillies.
1 Place your ingredients into the
blade assembly n.
2 Fit the lid m and turn anti-
clockwise to lock 5.
3 Place the mill onto the power unit
and lock by turning clockwise until
you hear a “click” 6.
4 Select a speed or use the pulse
(P) control.
to use your grating mill
(if supplied)
Suitable for grating parmesan
cheese, nutmeg, coconut and
dried fruit.
1 Place your ingredients into the
blade assembly p.
2 Fit the lid o and turn anti-
clockwise to lock 7.
3 Place the mill onto the power unit
and lock by turning clockwise until
you hear a “click” 6.
4 Select a speed or use the pulse
(P) control.
blender recommended usage chart
Do not operate your appliance for longer than the
times specified below without a rest period. Processing
continuously for longer periods can damage your appliance.
speed usage/food items max. quantity
1Frothing milk 1 litre
Light mixes e.g. batters, milkshakes,
scrambled egg 1 litre
2 - 3 Soups & drinks 1.6 litres
Thicker mixes e.g. pâtés
Mayonnaise 3 eggs +
450ml oil
Smoothie drinks
Place the fresh fruit and liquid ingredients in 800ml
first (includes yoghurt, milk and fruit juices) liquid
Then add ice or frozen ingredients (includes
frozen fruit, ice or ice cream)
Ice crushing - operate in short bursts until 6 cubes
crushed to the desired consistency. (125g)
(P) Operates the motor in a start/stop action.
pulse The pulse will operate for as long as it is held in –
position.

7
hints
lFor optimum performance when
processing spices we recommend
that you do not process more than
50g at a time in the mill.
lWhole spices retain their flavour
for a much longer time than
ground spices so it is best to grind
a small quantity fresh at a time to
retain the flavour.
lTo release the maximum flavour
and essential oils whole spices are
best roasted prior to milling.
lBaby food/purees - allow cooked
food to cool to room temperature
before processing in the mill.
care and cleaning
lAlways switch off, unplug and
dismantle before cleaning.
lEmpty the goblet before
unscrewing it from the blade unit.
lDo not immerse the blade unit in
water.
power unit
lWipe with a damp cloth, then dry.
lDo not immerse the power unit in
water.
lStore excess cord in the storage
area at the back of the power
unit g.
blade assemblies
blender and multi mill
lRemove the blade unit from the
goblet or mill by turning to the
unlock position to release.
grinding and grating mills
lRemove the lid from the blade
assembly by turning in a clockwise
direction.
1 blender/multi mill: remove and
wash the sealing ring.
2 Do not touch the sharp blades –
brush them clean using hot soapy
water, then rinse thoroughly under
the tap. Do not immerse the
blade unit in water.
3 Leave to dry upside down.
mill recommended usage chart
Do not operate your appliance for longer than the
times specified below without a rest period. Processing
continuously for longer periods can damage your appliance.
ingredients mill max qty speed operating
time
Herbs - best chopped Multi 15g 3 5 – 10 secs
when clean and dry
Nuts Multi or Grinding 50g 3 10 – 15 secs
Coffee Beans Multi or Grinding 50g 3 30 secs
Baby Foods & Purees Multi 50g 3 30 secs
Spices – such as black Grinding 50g 3 30 – 60 secs
peppercorns, cardamom
seeds, cumin seeds,
coriander seeds, fennel
seeds, whole cloves etc.
Chillies Grinding 30g 3 10 secs
Fresh Root Ginger Grinding 30g 3 10 secs
Garlic Grinding 4 cloves 3 10 secs
Parmesan Cheese – cut Grating 60g 3 10secs
into 1cm cubes
Dried Fruit Grating 50g 3 10 secs
Coconut Grating 50g 3 20 secs
Nutmeg Grating 2 3 40 secs

8
other parts
Wash by hand, then dry.
Item Suitable for
dishwashing
Filler cap 4
Locking lid 4
Goblet 4
Blender sealing
ring
4
Multi mill
sealing ring
4
Blade unit 8
Multi mill jar 4
Mill lid 4
Grinding mill
blade assembly
8
Grating mill
blade assembly
8
service and customer
care
l If you experience any
problems with the operation
of your appliance, before
requesting assistance refer to
the “troubleshooting guide”
section in the manual or visit
www.kenwoodworld.com.
l Please note that your product
is covered by a warranty, which
complies with all legal provisions
concerning any existing warranty
and consumer rights in the
country where the product was
purchased.
l If your Kenwood product
malfunctions or you find any
defects, please send it or bring
it to an authorised KENWOOD
Service Centre. To find up to date
details of your nearest authorised
KENWOOD Service centre visit
www.kenwoodworld.com or the
website specific to your Country.
lDesigned and engineered by
Kenwood in the UK.
lMade in China.
IMPORTANT INFORMATION
FOR CORRECT DISPOSAL
OF THE PRODUCT IN
ACCORDANCE WITH THE
EUROPEAN DIRECTIVE ON
WASTE ELECTRICAL AND
ELECTRONIC EQUIPMENT
(WEEE)
At the end of its working life, the
product must not be disposed of as
urban waste.
It must be taken to a special local
authority differentiated waste
collection centre or to a dealer
providing this service.
Disposing of a household appliance
separately avoids possible negative
consequences for the environment
and health deriving from inappropriate
disposal and enables the constituent
materials to be recovered to obtain
significant savings in energy and
resources. As a reminder of the need
to dispose of household appliances
separately, the product is marked
with a crossed-out wheeled dustbin.

9 10
troubleshooting guide
Problem Cause Solution
The Blender will not No Power Check blender
operate. plugged in.
Blender not assembled Check blade unit is
correctly. fully tightened to
the goblet.
Blender leaking from blade Seal missing. Check seal is fitted
assembly. Seal incorrectly fitted. correctly and not
Seal damaged. damaged. To obtain
a replacement seal
see “service &
customer care”.
Blender seal missing from The seal is packed Unscrew goblet and
blade unit when removed pre-fitted to the blade check that seal is
from packaging. unit. fitted to blade unit.
To obtain a
replacement seal
see “service &
customer care”.
If none of the above solve the problem see “Service & Customer Care”.

9 10
veiligheid
lLees deze instructies zorgvuldig door en
bewaar ze voor toekomstig gebruik.
lVerwijder de verpakking en alle labels.
lAls het snoer beschadigd is, moet het
om veiligheidsredenen door Kenwood
of een door Kenwood geautoriseerd
reparatiebedrijf vervangen worden.
lVerwerk NOOIT hete
ingrediënten.
lKANS OP BRANDWONDEN: Laat hete
ingrediënten altijd tot kamertemperatuur
afkoelen voordat u ze in de beker plaatst
of verwerkt.
lGebruik uw apparaat nooit langer
dan hieronder staat aangegeven
zonder een pauze. Als u het
apparaat langere tijd zonder
pauze gebruikt, kan dat schade
veroorzaken.
Functie /
hulpstuk
Maximale
inschakeltijd
Pauze
tussen twee
inschakelingen
Blender 60 sec. Haal de
stekker uit het
stopcontact en
laat het apparaat
15 minuten
afkoelen
Multimole 60 sec.
Maalmolen 60 sec.
Raspmolen 60 sec.
lSchakel het apparaat uit en haal de
stekker uit het stopcontact:
voordat u onderdelen aanbrengt of
verwijdert;
Nederlands
Vouw de voorpagina a.u.b. uit voordat u begint te lezen.
Op deze manier zijn de afbeeldingen zichtbaar
