Kenwood LZH-100W - DVD Player With LCD Monitor User manual

LZH-100W
Instruction Manual
Kenwood Corporation
KEN
~ DO I DOLBY I illJ~ffil [Q]D~~
v IDE 00 I G I TAL DIGITAL AUOKl [DIGITAl VIDEO I
Take the time to read through this instruction manual.
Familiarity
with installation and operation procedures will help you obtain the
best performance from the new DVD player.
Record the serial number, found on the back of the unit, in the spaces designated on the warranty card,
and in
the space provided below. Refer to the model and serial numbers whenever you call upon your
Kenwood dealer
for information or service on the product.
Model LZH-l
OOW Serial number _
CD75-K00005-2 Designed in Japan

Contents
~ JV~r!,i!,g }
~~e~p~~~~~ ~
Before use
About the remote
Box contents
About discs
5
6
6
7
Name and function of each part 8
----------------------------------
Unit
Remote Controller
FM transmitter for audio
How to playa DVD
Releasing the Monitor
POWER and SOURCE select
On Screen Display control
OSD
SETUP
DVD setup
LANGUAGE
DISPLAY
AUDIO
LOCK
OTHERS
DVD movie setup
Music
mode
Photo mode
11
12
13
16
21
22
24
Installation (Professional installation recommended) 27
fo!,~efti2'! dla9r~~ 2~
!r<!upl~s~o2~n9 39
~p~clfi~a!i~n~ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ __ _ _ _ _ _ _ _ _ _3 j
t2 English

.A. Warning
A CAUTION
Use of controls, adjustments or performance of
procedures other than those specified herein may
result in hazardous
radiation exposure.
AWarning
Kenwood Corporation
2967-3, ISHIKAWA-MACHI
HACHIOJI-SHI, TOKYO, JAPAN
Kenwood Corp. CERTIFIES THIS EQUIPMENT
CONFORMS TO DHHS REGULATIONS NO.21 CFR.
1040.10. CHAPTER 1, SUBCHAPTER J.
Location: Bottom Panel
-To minimize the risk of improper installation, Kenwood recommends that the installation of this product be
performed by
an MECP-Certified professional installer.
Improper installation may
cause damage to the vehicle or injury to the driver and occupants.
-Installation must
be performed according to this product installation manual. Kenwood is not responsible for
damages or injuries resulting from installation not performed strictly in accordance with the procedures described
in this manual.
-Proper installation
of this product may require the use of mounting hardware not included with this product.
-
Use only new, unused and properly-sized fasteners to install this product. Do not use previously-installed or worn
fasteners.
-
No modifications to the product or mounting hardware are permitted.
-This product
is designed to be used and viewed by rear seat passengers only. The monitor screen must not be
visible
to the driver. Viewing by the driver while operating the vehicle will create an unsafe condition.
-Kenwood does
not recommend connecting hanging wires or cables to auxiliary connectors while the vehicle is
in motion.
-This product must
not obstruct the driver's rear view when installed or used.
-It is the responsibility of the purchaser and installer to comply with all applicable laws and regulations governing
the installation and use of this product.
-Kenwood disclaims all liability
for any property damage or personal injury that may result from improper or
unintended installation or use of this product.
FCC WARNING
This equipment may generate or use radio frequency energy. Changes or modifications to this equipment may
cause harmful interference unless the modifications are expressly approved in the instruction manual. The user
could lose
the authority to operate this equipment if an unauthorized change or modification is made.
NOTE
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in aresidential installation.
This equipment may
cause harmful interference to radio communications if it is not installed and used in accordance
with the instructions. However, there is no guarantee that interference will not occur in aparticular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
-Reorient
or relocate the receiving antenna.
-Increase
the separation between the equipment and receiver.
-Connect
the equipment into an outlet on acircuit different from that to which the receiver is connected.
-Consult
the dealer or an experienced radiofTV technician for help.
English 3t

Safety precautions
AWARNING
To prevent injury or fire, take the following precautions:
•Insert the unit all the way in until it is fully locked in place. Otherwise, it may fall out of place when jolted.
•
To prevent ashort circuit, never put or leave any metallic objects (such as coins or metal tools) inside the unit.
•If the
unit starts to emit smoke or strange smells, turn off the power immediately and consult your Kenwood dealer.
•
Do not connect the unit to the front monitor. This unit is for rear seat entertainment.
•
Do not attempt to pull down or hang from the unit after proper installation.
Doing
so may cause damage to the unit or cause personal injury.
ACAUTION
To prevent damage to the unit, take the following precautions:
•Make sure to ground the unit to anegative 12V DC power supply.
•
Do not open the top or bottom covers of the unit.
•
Do not install the unit in aspot exposed to direct sunlight or excessive heat or humidity. Also avoid places with too much
dust or
the possibility of water splashing.
•
Do not use your own screws. Use only the screws provided. If you use the worng screws, you could damage the unit.
When replacing afuse, only
use a new one with the prescribed rating. Using afuse with the wrong
rating may
cause your unit to malfunction.
NOTE
• If you experience problems during installation, consult your Kenwood dealer.
•
The illustrations of the display and the panel appearing in this manual are examples used to explain more clearly how
the controls are used.
Therefore, what appears on the display in the illustrations may differ from what appears on the actual display
some
of the illustrations on the display may represent something impossible in actual operation.
Lens Fogging
Right after you turn on the car heater in cold weather, dew or condensation may form on the lens in the
DVD player of the unit. Called lens fogging, DVD may not be played in such condensation.
Ifthe
unit still does not operate normally after while, consult your Kenwood dealer.
Cleaning the Unit
Ifthe faceplate of this unit is stained, wipe it with adry soft cloth such as asilicon cloth.
Ifthe faceplate
is stained badly, wipe the stain off with acloth moistened with neutral cleaner, then wipe neutral cleaner off.
Lt
•Applying spray cleaner directly to the unit may affect its mechanical parts. Wiping the faceplate with ahard cloth or using
avolatile liquid
such as thinner or alcohol may scratch the surface or erase characters.
This product incorporates copyright protection technology that is protected by U.S.patents and other intellectual property
rights.
Use of this copyright protection technology must be authorized by Macrovision. Reverse engineering or disassembly is
prohibited.
NOTE
This Class Bdigital apparatus complies with Canadian ICES-003.
_4 English

Before use
Icons on the DVD discs
Description
""""""","""." ..
Indicates the region code where the disc can be played.
Number
of angles provided by the angle function. The number in the icon indicates the
number of angles. (Max. 9angles)
Icon
(IJ
- ."~,,-",~-~ ... _,- --
@
""NumberofvoicelangUageSrecordedwiththeaudio function. The number in the icon
U.J indicates the number of voice languages.(Max. 8languages)
______ ' '_ •. dw.__ __ •• __ ~ _.~_ • ~ •• y ••• ~~._w __ ._~ __ ~ ~. ~ __ · __ ., . .w ~_. __ T_._ .. '._T~
r32\ Number of subtitle languages recorded with the subtitle function. The number in the icon
~ indicates the number of subtitle languages. (Max. 32 languages)
ffiJ
.~- ~---".- . ....,_ ........ _--_ ... -..---_ ... _ .. , .......... y .......... _- .... ~,",~ •• ~
~
;
Aspect ratios that can be selected. " LB "stands for letter Box and" PS " for Pan/Scan. In
the example on the left, the 16:9 video can be converted into letter box video.
Region codes in the world
The DVD players are given aregion code according to the
country or area it is marketed, as shown in the following map.
Playable discs
• CD-R
•DVD-R
•DVD-RW
•CD-RW
•DVD+R
•DVD+RW
Playable media format
• MPEG 1 • MPEG2
•DVD-AC3 •DVD-Video
•Video
CD Ver.1.0 •Video CD Ver.1.1
•Video
CD Ver.2.0 •CD-DA
•MP3 •
JPG
*The Region Code of the unit is labeled on the gift box.
Unplayable discs
This player cannot play back any of the following discs.
•DVD-ROM/DVD-RAM discs •HQ-VCD discs
• CDV discs (Only the audio part can be reproduced) •Photo CD discs
•CD-G/CD-EG/CD-EXTRA discs(Only the audio can be reproduced) • SACD/HYBRID SACD discs
Also, you cannot play back the DVD-R/RW and DVD+R/RW discs if not recorded in the DVD-Video
format.
Restrictions due to difference between discs
Some DVD and VCD discs can be played only in certain playback modes according to the intentions of
the software producers. As this player plays discs according to their
intentions. some functions may not work as intended by you. [0 ]
Please be sure to read the instructions provided with each disc, . '.""
When an inhibition icon is displayed on the monitor, it indicates ,. .
that the disc being played is under the restriction as described above.
English 5t

About the remote
Loading the battery
1. Use two" AAA"- size batteries.
Open the cover while pressing downwards
to remove
it as illustrated.
2. Insert the batteries with the +and -poles aligned properly,
following the illustration inside the case.
AWARNING
•Store unused batteries out of the reach of children. Contact adoctor immediately if the battery is accidentally swallowed.
Do not put the remote in aplace where it moves when you drive. If it falls under the brake pedal, etc., it will hinder your
driving, and
cause danger.
~ • Do not set the remote in hot places such as on the dashboard.
~
~
•The provided batteries are intended for use in operation checking, and their service life may be short.
•When the remote controllable distance becomes short, replace both of the batteries with new ones.
Box contents
After purchasing this product, open the packaging and see if any of the components listed below are damaged or missing.
If there is an abnormality, make an inquiry with your place of purchase. As these images are to facilitate the understanding
of the consumer, they may differ from the actual conditions.
•
Remote Control 1 EA
Unit 1 EA :&Batteries 2EA : AN Input Cable(6m) 1EA :Bracket 1EA &Screw 8EA
................................................................... ~ .
Power &Dome Lamp
Connector1EA
AN Input/Output
Cable 1EA
Digital Audio Cable 1EA
&Cable Tie 2EA
FM TX Antenna Cable 1 EA
lamp Cover 2EA
Manual1EA&
Warranty card 1EA
Screw
•
Trim Ring 1 EA
\..
. . .
......................... .. .... ,. ".
r.1 4EA for Bracket (Short) •
I4EA for Bracket (long)
14EA for Unit
_6 English

About discs
Handling discs
·Don't touch the recording surface of the disc.
•
CD-R and CD-RW are easier to damage than a
normal music
CD. Use a CD-R/RW, DVD-R/RW or
DVD+R/RW after reading the caution items on
the package etc.
•
Don't stick tape etc. on the disc.
Also,
Don't use adisc with tape stuck on it.
When using anew disc
If the disc center hole or outside rim has burrs,
use it after removing them with aball point
pen etc.
iI~ ,,,"
Burrs
Disc accessories
Don't use disc type accessories.
Disc cleaning
Clean from the center of the disc and move outward.
Removing discs
When removing discs from this unit, pull
them out horizonta Ily.
Discs that can1t be used
• Discs that aren't round can't be used.
•
Discs with coloring on the recording surface
or discs that are dirty can't be used.
•This
unit can only play the CDs with
r.!lCOMPACT ([]D~@ ([]i@
L!!JO~(lli DlGrTALAUOIO DIGITAL AUDIO
D'GlTAl. AUDID ~ IReWritiliel
It may not correctly play discs which do not
have the logo.
• A
CD-R or CD-RW that hasn't been finalized
can't be played.(For the finalization process,
refer
to your CD-R/CD-RW writing software
and recorder instruction manual.)
Disc storage
·Don't place them in direct sunlight (on the
seat or dashboard etc.) and where the
temperature is high .
•Store
discs in their cases.
English 7t

Name and function of each part
UNIT
80'
IR Transmitter Angle
I-~~iii-:
I
::------------
I I
J
DVD MENU
Display the title
menu of the loaded
DVD disc
NEXT
DOOR LIGHT SWITCH
SOURCE
(DVD, AV1, AV2)
PLAY/PAUSE
STOP POWER
PWR
>~
S:
SRC STOP PLAY /
~
OFF· DOOR • ON
'-----------------1-------1-- -- - --1---"
FF~
SELECT
PREV
MENU
(MONITOR SETUP)
MONITOR OPEN REW ~
BUTTON
c:u.
OFF DOOR ON
OFF : Light is off
DOOR : Light goes on when car doors are opened and
goes off when car doors are closed.
ON : Light is on and stays on until switch is moved to
"DOOR" or "OFF" position.
ts Eng!ish

Disc Slot ----------...,
EJECT Button ------.........,
Eject adisc
'0_
Opening
Angle
POWER ---------------------------.
Hard Reset Key -------------------------......,
If all buttons on the Unit or Remote Control are
in malfunction, a
User can reset the Unit by
pushing this
button. Then, the unit will be
automatically
power off.
SPC(Smart Parental Control) -------~
While a DVD is being used or playing, the driver
or
front seat passenger can gain the attention from
the rear seat passenger by pushing the SPC button.
The audio
will be muted and video paused with
II ATIENTION ! Press SPC to resume II warning displayed
on
the screen. Pressing this button again will resume
the movie from the point it was paused, un-mute
the audio, and turn off the warning message.
o
.. ~~r=====~-e::::J)
,,' -/
.. ,/ ~
IR Wireless transmitter module IR Wireless Headphone
This module sends the audio signal to wireless IR headphones.
The audio signal
is converted to an infrared light transmitted to your headphones
by line
of sight.
English 9_

Remote Controller
Shift Key
Shift the Modes between
Music, Photo &Movie
Mode
if it is amulti-media disc.
l-HI-I+--- PLAY I PAUSE
Play/Pause disc play
....----- DM(DVD MENU)
Display the title menu of
the loaded DVD disc
PBC On/Off
Display or skip a title menu of
the loaded Video CD disc
KENWOOD
RC-100
0~
1
1
(]) I. 0-- (!J-o-li ~-- ~~~~iSC play
1
1
o0<0 :4-ll-I~- NUMERIC buttons
1 Use for the selection on the
o CD 0imenu screen
............................ -I
II l(
POWER
Power On/OFF
M (Menu)
Monitor Setup
VOl/.
Increase volume
VOl/T
Decrease volume
PREV I ..... ~
Move to the previous
chapter
or track
~ Notice
These volume keys are
not available in auxiliary
mode.
\\
\~
NEXT I ~~
Move to the next
SETUP ---.:.;..:.:-_~~ chapter or track
DVD setup
~~
(During no playing)
DVD movie s~~~ ~ SOURCE
(During playing DVD or VCD) ~r----------"" DVD, AV1, AV2
ENT
Enter
*Special Tip
These
arrow keys are useful for moving acursor up/down or leftiright
while aUser is changing the value &level on DVD Monitor Menu(M),
DVD Setup(SETUP), DVD Title Menu(DM), DVD Movie Setup(OSD),
Music
Mode & Photo Mode.
_10 English

FM transmitter for audio
In order to listen to the audio portion of the disc through the vehicle speakers, setup the settings once the
unit has been installed.
NEXT,
@) ~@j :.i', -t()a
MENU : ~
T:. DVD
PREV......J MENU
Press this button
1. Press the •(dot) button for 1.5 sec to bring out the control menu for FM transmitter
on the screen of the unit.
2. Press the up Aor down ...arrow buttons to turn the FM transmitter on or off.
3. Press the left ... or right ~ arrow buttons on the Unit to tune FM transmit frequency.
When the unit's
FM frequency matches with vehicle audio head unit's FM frequency,
the Audio will come
out through vehicle speakers.
•Open
FM frequency are FM 88.0MHz -89.5MHz (Tuning By interval of 100KHz)
FM 88.0MHz
POWER ON
<Example>
English 11t

How to playa DVD
Releasing the Monitor
Push the open button (located at the front of your screen) and open the monitor to the desired level.
You can also adjust the swivel angle.
90·
225·
~
J{
......"
"-0
0-
~
()
,....,
1"\
..
:.
Push to open
PWR(Power) and SRC(Source) select
1. Press the PWR(Power) button on either the remote control or the unit once to turn the power on.
Press the same PWR(Power) button to turn your power off.
PWR
~
SRC
Unit
Remote Controller
2. Press the SRC(Source) button on the remote controller or on the unit to select adesired auxiliary
mode(AV1, AV2)
or DVD mode. To change the source, press the SRC(Source) button repeatedly.
c··.·~~t)z --~AV1 c. --~ .. AV1.'.,
t -------JI
3. Insert a DVD Disc
Load adisc in the disc loading slot with the label
side up, and
it will be played automatically.
¢J Insert
t12 English

On Screen Display control
When the M(Menu) button on the Unit or the remote controller is pressed, the OSD will display
the setting menu as follows:
-. ~,
". SFi!GHTNESS
CONTRAST
COLOR
TINT
SHARPNESS
61%
Adjust for Brightness, Contrast, Color, Tint &Sharpness
~ OSD
~ Adjust for OSD Horizontal/Vertical position
I)#}JI SETUP
•. .• Select for auto-application of Reset(Auto-setting for Screen)
Press the up"/ down T arrow buttons on the the unit or remote controller to move the highlight
cursor up / down in the menu list, and press the left <IIIl or right ~ arrow buttons to change the
value /level while the menu OSD is still displayed on the screen.
English 13t

aR.i'~BtNi:ss ,'.
CONTRAST
COLOR
TINT
SHARPNESS
..::::~ ~="=' ::' :::'====:::;.::.J! j 61 %
OSD
I
I
I C'iOsCrrl-·pdstTION
IOSD V-POSITION
I
i
1. Use this menu to achieve the desired settings for
Brightness, Contrast, Color, Tint &Sharpness.
•
Brightness: Dim +-+ Bright
• Contrast : Contrast between light and shade
•
Color : Brilliance & Hue of color
• Tint : Tint of color
•Sharpness :Sharpness of view
2. Change the values with the left/right arrow buttons
after highlighting the function to control.
1. Use this menu to achieve the desired settings for
OSD H-Position &OSD V-Position.
• OSD H-Position : Moving OSD menu horizontally
• OSD V-Position : Moving OSD menu vertically
2. Change the values with the left/right arrow buttons
after highlighting the function to control.
t14 English
55%

SETUP
fU:SET
1. Use this menu to setup the enable/disable of auto
application for Reset.
•Reset :Brings its factory defaults always
automatically for Brightness, Contrast,
Color,
Tint &Sharpness whenever
the system power goes on.
2. Select ON/OFF with the left/right arrow buttons after
highlighting the function to enable/disable.
I
I
!
I
i(.
OFF
rON
English 1St

DVDSETUP
When the SETUP button on the remote controller is pressed, the DVD OSD will display the DVD
setup
as follows:
Language
Select Language in OSD Menu, Disc Audio, Subtitle &Disc Menu
Display
Select Display mode(Screen frame) &TV Output(AUTO/PAUNTSC)
Audio
Select Audio format(Dolby Digital), Sample frequency &
Digital output On/Off
Lock
Input Rating &Password
Others
Select Load Default &Screen Saver
Press the up'" / down ~ arrow buttons on the remote controller to move the highlight cursor
up/down in the menu list, and press the left ..... or right ~ arrow buttons to change the value /
level
while the menu OSD is still displayed on the screen.
t'6 English

LANGUAGE
1. Use to setup Language Settings for Menu, Disc Audio,
Subtitle &
Disc Menu
•Menu Language: Language for OSD menu
•
Disc Audio :Language for DVD movie
•
Disc Subtitle :Select for Showing/Hiding of subtitle
• Disc Menu :Language for DVD movie menu
2. Select Language/values with the left/right arrow buttons
after highlighting the menu to change.
* Notice
There are two types of Chinese in the menu languages.
The upper is the Simplified Chinese, and the lower is the
Traditional
Chinese.
* Special Tip
• Original; The original language of the disc.
• Other If there is not auser's desired language in Disc Audio, Disc Subtitle & Disc Menu, a
user may choose one from the
below other language code list.
~ Inputting Method; After selecting 'Other', input 4 digit numbers referring to the below
language code list.
For example,
if auser prefer to Abkhazian as awish language, auser input '6566' by aremote
controller,
and press 'ENT'.
Input 4 digit numbers here.
English 17_

~ Other Language Code List
language Code
Country language C()de Country
6566
Abkhazian 7678
Lingala
6565 Afar 7684 Lithuanian
6570 Afrikaans
7775
Macedonian
8381 Albanian 7771
Malaqasy
6577
Ameharic 7783
Malay
6582
Arabic 7776
Malayalam
7289 Armenian
7784 Maltese
6583 Assamese
7773
Maori
6588
Aymara 7782
Marathi
6590 Azerbaiiani 7779 Moldavian
6665 Bashkir
7778
Mongolian
6985
Basgue
7865 Nauru
6678
Bengali; Bangia
7869 Nepali
6890
Bhutani 7879
Norwegian
6672
Bihari
7982
Oriya
6682
Breton 8065 Paniabi
6671 Bulgarian
8083 Pashto. Pushto
7789 Burmese
7065
Persian
6669
Byelorussian 8076 Polish
7577 Cambodian 8084 Portuguese
6765
Catalan 8185 Ouechua
9072
Chinese 8277
Rhaeto-Romance
6779
Corsican 8279 Rumanian
7282
Croatian 8285 Russian
6783
Czech 8377 Samoan
6865
Danish
8365
Sanskrit
7876 Dutch 7168 Scots Gaelic
6978
Enalish 8382 Serbian
6979 Esperanto
8372 Serbo-Croatian
6984
Estonian 8378 Shona
7079
Faroese
8368
Sindhi
7074
Fiii 8373
Singhalese
7073
Finnish 8375 Slovak
7082 French 8376 Siovenian
7089 Frisian
8379 Somali
7176
Galician
6983
Spanish
7565 Georgian
8385 Sudanese
6869 German 8387 Swahili
6976
Greek
8386
:Swedish
7576
Greenlandic 8476 Tagalog
7178
Guarani 8471 Taiik
7185
Guiarati 8465 Tamil
7265
Hausa 8484 Tatar
7387
Hebrew 8469 Teluau
7273
Hindi 8472
:Thai
7285
Hungarian 6679 Tibetan
7383
Icelandic 8473 Tiarinva
7378
Indonesian
--
8479 Tonaa
7365 Interlinaua
8482
Turkish
7165
Irish 8475 Turkmen
7384
Italian 8487 Twi
7465
IJaoanese 8576 Ukrainian
7487
!Javanese
8582 Urdu
7578
Kannada 8590 Uzbek
7583 Kashmiri
8673 Vietnamese
7575
:Kazakh
8679
Volapuk
7589
!Kirghiz
6789 Welsh
7579
Korean 8779
Wolof
--
7585
:Kurdish
8872
iXhosa
Laothian
--
7679
7473
IYiddish
7665 Latin Yoruba
--
8979
7686 Latvian Lettish
9085 Zulu

DISPLAY
*Special Tip: SCREEN DISPLA Y
1. Use to achieve the desired settings for Display &
TV Output .
•Display
Mode :Selecting 4:3 Letterbox, 4:3 Panscan
or 16:9 Widescreen.
•TV
Output :Selecting Auto, PAL or NTSC.
2. Select values with the left/right arrow buttons
after highlighting the menu to change.
AUDIO
16:9 Widescreen
1. Use to achieve the desired settings for Audio
Format(Dolby Digital), Sample Frequency &
Digital Output
•Dolby Digital :Selecting Bitstream or PCM
•Sample Frequency: Selecting 48KHz or 96KHz
•
Digital Output :Selecting On / Off
2. Select values with the left/right arrow buttons after
highlighting the menu to change.
English 19t

LOCK
*Special Tip: Rating &Parental Lock
OTHERS
1. Use to achieve the desired settings for Rating &Password.
•Rating :Selecting Lock/Unlock
for Parental
mode.
Determining how the unit
re-acts to amovie disc according to
rating .
•Password: No factory default is registered at the
initial mode. It only displays 'New'.
Auser can register apassword
with
4 digit numbers on the remote controller.
2. Select values with the left/right arrow buttons after
highlighting the menu to change.
The
parental lock is a rating limit system for
DVD movies. It works with DVD discs that have
been assigned a
rating.
Auser can decide which ratings can be played
without blocking.(The factory default is Unlock.}
1. Use to achieve the desired settings for Load Default &
Screen Saver.
•Load
Default: Loading the factory default
for re-setting system.
•Screen Saver :Selecting Enable/Disable
of Screen
saver.
If it is on, Screen saver activates
when the system is inactive
for 5minutes
2. Select values with the left/right arrow buttons after
highlighting the menu to change.
