DMX125DAB
MONITOR WITH RECEIVER
Quick Start Guide
ÉCRAN AVEC RÉCEPTEUR
Guide de démarrage rapide
MONITOR MIT EMPFÄNGER
Kurzanleitung
MONITOR MET ONTVANGER
Snelstartgids
MONITOR CON RICEVITORE
Guida rapida
MONITOR CON RECEPTOR
Guía de inicio rápido
MONITOR COM RECETOR
Guia de Iniciação Rápida
B5K-0673-00 (E)© 2019 JVC KENWOOD Corporation
Model name indication position
See “Removing the trim plate” (P.13)
Position d’indication du nom du modèle
Reportez-vous à la section « Retrait de la
plaque de garniture » (p.29)
Anzeigeposition der Modellbezeichnung
Siehe „Entfernen der Ziertafel“ (S.45)
Model naam indicatie positie
Zie “Verwijderen van de afwerkingsplaat”
(P.61)
Posizione di indicazione del nome del
modello
Fare riferimento a “Rimozione della piastra
di taglio” (P.77)
Posición de la indicación del nombre del
modelo
Consulte “Retirada del marco” (P.93)
Posição da indicação do nome do modelo
Consulte “Retirar a moldura” (P.109)
Trim plate
Plaque de garniture
Zierplatte
Afwerkingsplaat
Piastra di taglio
Marco
Moldura
_B5K-0673-00_DMX125DAB_QSG.indb 1 2019/06/10 15:21

2
Before use
Before use................................................................................. 2
How to read this manual................................................................................... 2
Precautions ................................................................................................................2
Getting Started....................................................................... 3
Clock settings........................................................................................................... 3
Basics .......................................................................................... 4
Functions of the Buttons on the Front Panel...................................... 4
Common operations........................................................................................... 4
HOME screen ............................................................................................................4
Source control screen.........................................................................................4
Digital Radio ............................................................................ 5
Digital Radio Basic Operation........................................................................5
Digital Radio Setup............................................................................................... 5
Radio........................................................................................... 6
Radio Basic Operation.........................................................................................6
Radio Setup................................................................................................................ 6
USB .............................................................................................. 7
Preparation.................................................................................................................7
Playback operations............................................................................................. 7
iPod/iPhone ............................................................................. 8
Preparation.................................................................................................................8
Playback operations............................................................................................. 8
External Components.......................................................... 9
Using external audio/video players........................................................... 9
Rear view camera................................................................................................... 9
Controlling Audio .................................................................. 9
Controlling General Audio............................................................................... 9
Bluetooth ................................................................................10
Register your smartphone to the unit ...................................................10
Receive a phone call..........................................................................................10
Make a phone call................................................................................................10
Playing Bluetooth Audio Device................................................................11
Installation.............................................................................. 11
Before Installation................................................................................................11
Installing the unit.................................................................................................12
About this Unit......................................................................16
More information.................................................................................................16
Note for specifications......................................................................................16
Copyrights................................................................................................................16
Precautions
#WARNING
Ñ To prevent injury or re, take the
following precautions:
• To prevent a short circuit, never put or leave any
metallic objects (such as coins or metal tools)
inside the unit.
• Do not watch or fix your eyes on the unit’s display
when you are driving for any extended period.
• If you experience problems during installation,
consult your KENWOOD dealer.
Ñ Precautions on using this unit
• When you purchase optional accessories, check
with your KENWOOD dealer to make sure that
they work with your model and in your area.
• The Radio Data System or Radio Broadcast Data
System feature won’t work where the service is
not supported by any broadcasting station.
Ñ Protecting the monitor
• To protect the monitor from damage, do not
operate the monitor using a ballpoint pen or
similar tool with the sharp tip.
Ñ Cleaning the Unit
If the front panel of this unit is stained, wipe it with
a dry soft cloth such as a silicon cloth. If the front
panel is stained badly, wipe the stain off with a
cloth moistened with neutral cleaner, then wipe it
again with a clean soft dry cloth.
! CAUTION
• Applaying spray cleaner directly to the unit may
affect its mechanical parts. Wiping the front panel
with a hard cloth or using a volatile liquid such as
thinner or alcohol may scratch the surface or erase
screened print.
Ñ How to reset your unit
If the unit or the connected unit fails to operate
properly, reset the unit.
Reset button
Contents
How to read this manual
• The panels shown in this guide are examples used to
provide clear explanations of the operations. For this
reason, they may be different from the actual panels.
• In operation procedures, bracket shape indicates the
key or button you should control.
< >: indicates the name of panel buttons.
[ ]: indicates the name of touch keys
• For detailed operations and
information, refer to the
INSTRUCTION MANUAL on
the following website:
<https://www.kenwood.com/cs/ce/>
_B5K-0673-00_DMX125DAB_QSG.indb 2 2019/06/10 15:21

3
English |
Continued on the next page...
Getting Started
1 Turn the ignition key of your car to ACC.
The unit is turned on.
2 Press the <8MENU> button.
3 Touch [ ].
4 Touch the corresponding key and set the value.
[System]
[Beep Tone]
Activates or deactivates the key-touch tone.
“ON” (Default), “OFF”
[Language]
Select the language used for the control screen
and setting items. Default is “English”.
[Time/Date]
Adjust the clock time. (P.3)
[Clock Mode]
Select the time display format.
[12hr] / [24hr] (Default)
[Parking Guidelines]
You can display parking guidelines to enable
easier parking when you shift the gear to the
reverse (R) position. Default is “ON”.
[Guidelines SETUP]
If you select [ON] for [Parking Guidelines], you can
adjust the parking guidelines.
[System Reset]
Touch [System Reset] and then touch [YES] to set
all the settings to the initial default settings.
[Bluetooth]
Displays the Bluetooth Settings screen.
[Screen]
[Dimmer]
Select the dimmer mode.
“High” (Default) / “Mid” / “Low”
[Demo]
Select the demonstration mode. Default is “ON”.
5 Touch [6].
Clock settings
Ñ Synchronizing the clock time with FM
RDS
Activate [RDS Clock Sync].
See Radio Setup (P.6).
Ñ Adjusting the clock manually
✎NOTE
• Deactivate [RDS Clock Sync] before adjusting the
clock.
1 Press the <8MENU> button.
2 Touch [ ].
3 Touch [System].
4 Touch [Time/Date].
Clock screen appears.
5 Touch [R] or [S] to set the clock time.
6 Touch [6].
_B5K-0673-00_DMX125DAB_QSG.indb 3 2019/06/10 15:21

4
BasicsBasics
Functions of the Buttons on the
Front Panel
1
2
3
4
5
6
1Remote Sensor
• Receives the remote control signal.
28MENU
• Displays the HOME screen. (P.4)
• Pressing for 1 second turns the power off.
• When the power off, turns the power on.
3AUD
• Displays the Audio screen.* (P.9)
* The Audio screen is not displayed during SETUP
screen or on the list screen etc,
4+ , – (Volume)
• Adjusts volume. The volume will go up until 20
when you keep pressing [ + ].
5MUTE/ DISP OFF (Display o)
• Mutes/restores the sound.
• Pressing for 1 second turns the screen off.
When the screen is off, touch the display to turn
on the screen.
6Reset
• If the unit or the connected unit fails to operate
properly, the unit returns to factory settings
when this button is pressed.
Common operations
Ñ Turning on the power
1 Press the <8MENU> button.
Ñ Turning o the power
1 Press and hold the <8MENU> button.
HOME screen
1 Press the <8MENU> button.
HOME screen appears.
2
5
3
6
4
8
7
1
1Clock display
2Switches to the digital radio broadcast. (P.5)
3Switches to the radio broadcast. (P.6)
4[USB]
Plays files on a USB device. (P.7)
[iPod]
Plays an iPod/iPhone. (P.8)
• When iPod/iPhone is connected.
[Mirroring]
Displays the Mirroring screen.
• When android device with “Mirroring OB for
KENWOOD” application installed is connected.
5Displays the Hands Free screen. (P.10)
6Plays a Bluetooth audio player. (P.11)
7Switches to an external component connected to
the AV-IN input terminal. (P.9)
8Displays the SETUP screen. (P.3)
Source control screen
1
1[ ] : Returns to previous screen.
[ ] : Displays the Audio screen. (P.9)
_B5K-0673-00_DMX125DAB_QSG.indb 4 2019/06/10 15:21

5
English |
Digital Radio
Continued on the next page...
Digital Radio
Digital Radio Basic Operation
1 Press the <8MENU> button.
2 Touch [Digital Radio].
Ñ Source control screen
2
1
3
1Displays the information of the current service:
Service name, Ensemble name, PTY Genre,
Channel
2[DAB] : Switches the Digital Radio preset band.
“DAB1”, “DAB2”, “DAB3”
[DLS] : Display the Dynamic Label Segment
screen
[E][F] : Select an ensemble, service, and
component.
[ ] : Displays the Digital Radio Setup screen.
(P.5)
3Recalls the memorized service.
When touched for 2 seconds, stores the current
receiving service in memory.
Ñ Store a services
You can store the current receiving service in
memory.
1 Tune in to a service you want to preset.
2 Touch and hold [#] (#:1-5) in which you want to
store the service.
Ñ Select a stored service
1 Touch [#] (#:1-5).
Digital Radio Setup
1 Touch [ ].
2 Set each item as follows.
[Service List]
Displays the Service List screen.
• [ ] : Touch and then touch [Yes] to find the latest
service list.
[TI]
Switches to the traffic information automatically
when the traffic bulletin starts.
“ON”, “OFF” (Default)
[PTY]
Searches for a program by program type.
[Priority]
If the same service is provided by Radio Data System
when reception of the service being provided by
Digital Radio becomes poor, automatically switches
to Radio Data System.
“ON”, “OFF” (Default)
[Announcement Select]
Switches to the set Announcement service.
[Related Service]
When you select ON, the unit switches to a related
service (if exists) when a DAB service network is not
available. Default is “OFF”.
[Antenna Power]
Sets power supply to the Digital Radio antenna. Set
to “ON” when the Digital Radio antenna in use is
equipped with a booster. Default is “ON”.
3 Touch [6].
_B5K-0673-00_DMX125DAB_QSG.indb 5 2019/06/10 15:21

6
Radio
Radio Basic Operation
1 Press the <8MENU> button.
2 Touch [Radio].
Ñ Source control screen
2
1
3
1Displays the information of the current station:
PS name, Frequency, PTY Genre, Indicator Items
2[FM] : Switches the FM band.
“FM1”, “FM2”, “FM3”
[AM] : Switches the AM band.
“AM1”, “AM2”
[E][F] : Tunes in a station with good
reception automatically.
[ ] : Displays the Radio Setup screen. (P.6)
3Recalls the memorized station.
When touched for 2 seconds, stores the current
receiving station in memory.
Ñ Auto memory
You can preset 6 stations for the current band (FM1/
FM2/FM3/AM1/AM2).
1 Touch [FM] or [AM] to select the band.
2 Touch [ ].
3 Touch [Auto Store].
The local stations with the strongest signals are
found and stored automatically.
Ñ Manual memory
You can store the current receiving station in
memory.
1 Tune in to a station you want to preset.
2 Touch and hold [#] (#:1-6) in which you want to
store the station.
Ñ Recalling the preset station
1 Touch [#] (#:1-6).
Radio Setup
1 Touch [ ].
2 Set each item as follows.
[Auto Store]
Automatically searches and stores the 6 stations with
the strongest signals for the selected band.
“Auto Store” appears.
[Local Seek]
Tunes in only to the stations with sufficient signal
strength. (LOC indicator lights up.)
“ON”, “OFF” (Default)
[RDS] *1
Displays the RDS Settings screen.
[AF]
When station reception is poor, automatically
switches to the station that is broadcasting the
same program over the same Radio Data System
network.
“ON” (Default), “OFF”
[TA]
Switches to the traffic information automatically
when the traffic bulletin starts. (TI indicator lights
up.)
“ON”, “OFF” (Default)
[RDS Clock Sync]
Synchronizing the Radio Data System station time
data and this unit’s clock.
“ON” (Default), “OFF”
[PTY]
Select a program type.
[PTY Seek]
Searches for a program by program type.
*1 FM only
3 Touch [6].
_B5K-0673-00_DMX125DAB_QSG.indb 6 2019/06/10 15:21

7
English |
Continued on the next page...
USB
Preparation
Ñ Connecting a USB device
1 Remove the cap of the USB terminal.
2 Connect the USB device with the USB cable.
The unit reads the device and playback starts.
Ñ To disconnect the USB device:
1 Press the <8MENU> button.
2 Touch a source other than [USB].
3 Detach the USB device.
Ñ Usable USB device
This unit can play MPEG1/ MPEG2/ MPEG4/ H.264/
MKV/ MP3/WMA/ AAC/ WAV/ FLAC/ OGG les stored
in a USB mass storage class device.
Playback operations
Ñ Control the music you are listening to on
the source control screen.
1
4
3
2
1The jacket of the currently playing file is displayed.
2Displays the information of the current file.
3Playing time/File number
Play time bar : For confirmation of current playing
position.
4[ ] : Selects Random playback mode.
[ ] : Selects Repeat playback mode.
[U], [H] : Plays or pauses.
[E], [F] : Searches the previous/next
content.
Touch and hold to fast forward or fast
backward.
[1] : Searches file. (P.7)
Ñ For Video playback
1 When the operation buttons are not displayed
on the screen, touch the display.
6
7
6[ ] : You can adjust image quality in video
screen.
[INITIALIZE] : To clear the adjustment.
7[U], [H] : Plays or pauses.
[E], [F] : Searches the previous/next
content.
Touch and hold to fast forward or fast
backward.
[1] : Searches file. (P.7)
[NORMAL]/[16:9]/[4:3] : Select a screen mode.
Ñ Selecting a track in a list (Searches le)
1 Touch [1].
2 Select whether you search by audio files [ ],
video files [ ].
3 Touch [ ] to moves to the upper hierarchy.
4 Touch the desired folder.
When you touch a folder its contents are displayed.
• Touch [6] to moves to the upper hierarchy.
5 Touch desired item from the content list.
Playback starts.
✎NOTE
• The source control screen appears when you touch
[6] at the top hierarchy.
_B5K-0673-00_DMX125DAB_QSG.indb 7 2019/06/10 15:21

8
iPod/iPhoneiPod/iPhone
Preparation
Ñ Connecting iPod/iPhone
• For Lightning connector models: Use USB Audio
cable for iPod/iPhone—KCA-iP103 (optional
accessory).
• For details about connecting iPod/iPhone, see
page 15 .
1 Remove the cap of the USB terminal.
2 Connect the iPod/iPhone.
The unit reads the device and playback starts.
Ñ To disconnect the iPod/iPhone
1 Press the <8MENU> button.
2 Touch a source other than [iPod].
3 Detach the iPod/iPhone.
Ñ Connectable iPod/iPhone
The following models can be connected to this unit.
Made for
• iPhone XS Max
• iPhone XS
• iPhone XR
• iPhone X
• iPhone 8 Plus
• iPhone 8
• iPhone 7 Plus
• iPhone 7
• iPhone SE
• iPhone 6s Plus
• iPhone 6s
• iPhone 6 Plus
• iPhone 6
• iPhone 5s
✎NOTE
• If you start playback after connecting the iPod, the
music that has been played by the iPod is played
first.
• Cap the USB terminal whenever not using.
Playback operations
Ñ Control the music you are listening to on
the source control screen.
1
4
3
2
1Artwork (Shown if the track contains artwork)
2Displays the information of the current file.
3Playing time/File number
Play time bar : For confirmation of current playing
position.
4[ ] : Selects Random playback mode.
[ ] : Selects Repeat playback mode.
[U], [H] : Plays or pauses.
[E], [F] : Searches the previous/next
content.
Touch and hold to fast forward or fast
backward.
[1] : Searches content. (P.8)
Ñ Selecting a content in a list
1 Touch [1].
2 Touch desired item.
When you touch a category its contents are
displayed.
3 Touch desired item from the content list.
Playback starts.
• Touch [6] to moves to the upper hierarchy.
✎NOTE
• The source control screen appears when you touch
[6] at the top hierarchy.
_B5K-0673-00_DMX125DAB_QSG.indb 8 2019/06/10 15:21

9
English |
Continued on the next page...
External Components
Using external audio/video players
Ñ Starting playback
1 Connect an external component to the AV-IN
input terminal. (P.14)
2 Press the <8MENU> button.
3 Touch [AV-IN].
4 Turn on the connected component and start
playing the source.
Ñ For Video playback
1 When the operation buttons are not displayed
on the screen, touch the display.
1
Rear view camera
To use a rear view camera, the REVERSE lead
connection is required. For connecting a rear view
camera. (P.14)
Ñ Displaying the picture from the rear
view camera
The rear view screen is displayed when you shift the
gear to the reverse (R) position.
• To erase the caution message, touch the screen.
You can adjust various settings such as audio
balance or subwoofer level.
1 Press the <AUD> button.
2 See the below for each operation method.
Controlling General Audio
1 Press the <AUD> button.
2 Touch [Fader / Balance].
3 Set each item as follows.
[Fader Balance]
Balance
[U] [T]
Adjust the left and right volume
balance.
15 (right) to 15 (left)
Fader
[R] [S]
Adjust the front and rear volume
balance.
15 (front) to 15 (rear)
[INITIALIZE] To clear the adjustment.
Controlling Audio
_B5K-0673-00_DMX125DAB_QSG.indb 9 2019/06/10 15:21

10
Bluetooth
Register your smartphone to the
unit
You can use your Bluetooth smartphone when
paired to this unit.
1 Turn on the Bluetooth function on your
smartphone/cell-phone.
2 Search the unit (“DMX125DAB”) from your
smartphone/cell-phone.
If a PIN code is required, enter the PIN code
(“0000”).
• appears when the Bluetooth smartphone is
connected.
Ñ Disconnecting the device
• Turn off the Bluetooth function from your
smartphone/cell-phone.
• Turn off the ignition switch.
Receive a phone call
1 Touch [Û].
• [Ý] : Reject an incoming call.
Ñ Operations during a call
[Ý]Ending a call
You can send tones by touching desired keys
on the screen.
• Touch [6] to close the window.
Switches the speaking voice output between
smartphone/cell-phone and speaker.
⿠Adjust the receiver volume
Press the <+> or <–> button.
Make a phone call
1 Press the <8MENU> button.
2 Touch [TEL].
3 See the table below for each operation method.
Call by entering a phone number
1) Enter a phone number with number keys.
2) Touch [Û].
Make a call
• Touch [ ] to delete the last entry.
Call using call records
1) Touch [ ].
2) Touch [ ] (Incoming Calls), [ ] (Outgoing
Calls), [ ] (Missed Calls).
3) Select the phone number from the list.
Make a call
Call using the phonebook
1) Touch [ ].
2) Select the name from the list.
Make a call
• [ ] : Updates the phonebook. Touch this
button after you have made a change
to the phonebook of your smartphone/
cell-phone.
Bluetooth
_B5K-0673-00_DMX125DAB_QSG.indb 10 2019/06/10 15:21
