Kenwood HG230 User manual

For packing purposes the handle is not fitted to the lid. To fit the
handle:-
1. Undo the screw.
2. Place handle centrally over the hole in the top of the lid.
3. Invert the lid and handle and fix together by means of the screw
assembly. DO NOT OVERTIGHTEN.
Prior to using this appliance for the first time, wash the grill plate, base,
lid and drip tray in accordance with the instructions given under the
Cleaning section. Dry thoroughly and then lightly brush the surface of
the grill plate with cooking oil.
Place the drip tray into the base, then place the grill plate onto the drip
tray. Never use the grill plate directly on the work surface, always use
with the drip tray and base.
Insert the power supply connector into the grill plate, then connect to
the power supply and switch on. Turn the temperature control to the
desired setting: the higher the number the hotter the temperature. When
the Health Grill reaches this temperature, the light will go out and
cooking can commence. (During cooking, the light will go on and off
indicating that the selected temperature is being maintained).
This appliance should only be used on a heat resistant and easy to
wipe clean surface.
The following temperature settings and times are a guide only and will
vary according to individual preferences and the size/thickness of the
food being cooked. With use you will become familiar with the time and
setting needed to cook the food to your own requirements. Some
thicker items of food in particular pork and chicken, which should be
thoroughly cooked, may benefit from being pre-cooked in an oven or
microwave before being placed on the grill.
The Health Grill has two cooking areas. The flat plate is most suitable
for cooking fried eggs, tomatoes, mushrooms whereas the grills are
suitable for cooking meat such as beefburgers, chops and steaks.
Food Temperature Approximate
Setting Time
Whole fish 12 15-20 minutes
Fish steaks 12 15 minutes
Prawns 12 6-10 minutes
Chicken - Drumstick 12 35-40 minutes
Boneless chicken breast 12 25-30 minutes
Steak MAX 3-5 minutes (rare)
15-20 minutes (well done)
Chops 12 30-35 minutes
Sausages 14 20-25 minutes
Bacon 10 6 minutes
Burgers Frozen 55g 14 10-12 minutes
Burgers Fresh 175g 14 10 minutes
Kebabs 14 10-15 minutes
Cooking Guide
Operation
Your new Kenwood Health Grill will enable you to cook a range of
healthy and flavoursome foods including meat, fish, poultry and
vegetables. During cooking the fat drains away from the food and
collects in the drip tray thus reducing the fat content of the food.
When using electrical appliances basic safety precautions should
always be followed including the following:-
1. Read all instructions.
2. Do not touch hot surfaces, use the handles.
3. Do not immerse the power supply connector in water or other
liquids and do not allow it to become wet.
4. This appliance is for domestic use only.
5. The appliance is not intended for use by young children or infirm
persons without supervision.
6. Young children should be supervised to ensure that they do not
play with the appliance.
7. Do not leave the appliance unattended when in use.
8. Never use a damaged appliance. Get it checked or repaired: see
‘service’
9. The use of accessories not recommended by the appliance
manufacturer may cause injury.
10. Take care when removing the temperature control - the probe may
be hot.
11. Do not let the power supply cord hang over the edge of the table or
worktop or touch hot surfaces. (This also applies to an extension
lead if used)
12. Do not use the appliance for other than its intended use.
13. Do not use the Health Grill outdoors.
14. Do not place any part of this appliance on or near a naked flame or
hot plate or in a heated oven.
15. Always attach the power supply connector to the appliance first,
then plug into the power supply. To disconnect, switch off, remove
plug from the power supply first and then the power supply
connector from the appliance.
16. The connector must be removed before the appliance is cleaned and
the appliance inlet must be dried before the appliance is used again.
17. Unplug the appliance from the power supply when not in use.
18. If this appliance is used with an extension lead, ensure that it is
suitable for the rating of the Health Grill and that the extension lead
is reliably earthed, If unsure check with a qualified electrician.
19. The supply cord should be regularly examined for signs of damage
and the appliance must not be used if the cord is damaged.
20. With some foods large quantities of smoke are emitted - ensure
there is adequate ventilation.
21. The appliance must be connected to a socket-outlet having an
earthing contact.
22. WARNING: Charcoal or similar combustible fuels must not be used
with this appliance.
23. Only the appropriate connector must be used with this appliance.
SAVE THESE INSTRUCTIONS
IMPORTANT SAFEGUARDS
Know Your Kenwood Health Grill
Connecting to Power
Before switching on make sure that the voltage of your electricity supply is the
same as that indicated on the rating plate.
IMPORTANT (UK ONLY): The wires in the mains lead are coloured in
accordance with the following code:
GREEN and YELLOW EARTH
BLUE NEUTRAL
BROWN LIVE
NOTE:
This appliance complies with European Economic Community Directive
89/336/EEC.
1. Handles 5. Base
2. Glass lid 6. Detachable power supply
3. Non stick grill plate connector
4. Drip tray 7. Temperature control
Key







●Tender cuts of meat are more suitable for grilling and are therefore
best used on the Health Grill. It is best to avoid cooking tough cuts
of meat.
●Best results are obtained by cooking foods of a uniform thickness.
Thinner items of food are preferable to thick items as thick items
may take a long time to cook through to the centre which may result
in the outside overcooking.
●During cooking the food should be turned frequently to ensure even
cooking. Take care as some spitting may occur during cooking.
●Food placed directly above the element may brown and cook more
quickly than food elsewhere on the grill. Therefore moving the
position of the food on the grill will help to ensure even cooking.
●Always turn and remove food from the Health Grill using utensils
that will not scratch the non stick surface. Items made of wood and
heat resistant plastic are ideal.
●The drip tray has been coated with a reflective silver coating to
direct heat upwards and make cooking more efficient. To make
cleaning a little easier the base of the drip tray may be lined with
aluminium foil. Aluminium foil will collect the fat and make disposal
easier. Also with foil, heat is reflected upwards making cooking
more energy efficient.
Note:- When lining the drip tray it is important not to overhang the sides
with foil, as this will stop air circulation.
Switch off the appliance and remove the plug from the power supply.
Allow the appliance to cool slightly then remove the power supply
connector from the appliance, by gripping the protrusions on either side.
Do not immerse the connector in water, instead wipe over if necessary
with a piece of absorbent paper or wipe with a barely damp cloth.
If used, dispose of any aluminium foil from the base/drip tray. Wash the
grill plate, base, glass lid and drip tray in hot soapy water and then dry
thoroughly. Do not use harsh abrasives or harsh scouring pads as they
may damage the non stick surface. If necessary use a soft nylon
bristled brush or a plastic scouring pad to remove stubborn marks.
These parts can also be placed in a dishwasher. Cleaning the Health
Grill after every use will help to maintain it in a good clean working
condition.
Note
After cleaning ensure that the power supply connector is thoroughly
dried before re-inserting into the appliance.
Cleaning
Hints On Use
LIMITED
New Lane • Havant • Hants • PO9 2NH • U.K.
www.kenwood.co.uk 2598/2
HG230
If the supply cord of this appliance is damaged, it must, for safety
reasons be replaced by Kenwood or an authorised Kenwood repairer.
UK
For any repairs in or out of guarantee, servicing or selected spare parts,
contact your Kenwood Authorised Repairer in the Yellow Pages under
Electrical Appliance Repairs or telephone [phone] and ask for
Customer Care.
All Other Markets
Contact the dealer from whom you purchased your appliance.
Service
