Kenwood KAH740PL User manual

English 2 - 9
Nederlands 10 - 18
Français 19 - 27
Deutsch 28 - 36
Italiano 37 - 45
Português 46 - 54
Español 55 - 63
Dansk 64 - 71
Svenska 72 - 79
Norsk 80 - 87
Suomi 88 - 95
Türkçe 96 - 103
Česky 104 - 112
Magyar 113 - 121
Polski 122 - 131
Русский 132 - 142
Қазақша 143 - 151
Ελληνικά 152 - 162
Slovenčina 163 - 171
Українська 172 - 181
Eesti 182 - 189
Lietuvių 190 - 197
Latviešu 198 - 206
1
2
3
4
5
instructions
istruzioni
instrucciones
Bedienungsanleitungen
gebruiksaanwijzing
Instrukcja obsługi
KAH740PL
Kenwood Ltd
New Lane
Havant
Hampshire
PO9 2NH
kenwoodworld.com
© Kenwood Ltd 2018 138058/1
´¸∂w
702 - 312

MAX
60s
MAX
600ml
3x
MAX 60g
or
A B
C D
E F
G H
I
MAX
60s
MAX
600ml
3x
MAX 60g
or
A B
C D
E F
G H
I
2
safety
lRead these instructions carefully and
retain for future reference.
lRemove all packaging and any labels.
lSwitch off and unplug the kitchen
machine:
before fitting and removing parts;
after use;
before cleaning.
lNever use a damaged attachment.
Get it checked or repaired : see
‘service and customer care’.
lNever use an unauthorised
attachment.
lNever leave the appliance on
unattended.
lAlways wait until the blades have
completely stopped before removing
the bottle from the High Speed
Outlet.
lThe bottle is only suitable for
use with cold ingredients. Do not
process hot ingredients.
lSCALD RISK: The unit may also
be used for making soups. Liquids
should be allowed to cool to room
temperature before placing in the
bottle or blending.
lNever drink any hot liquids from the
bottle.
lWhen drinking through the lid, take
care that the drink is smooth. Some
experimentation may be necessary to
achieve the desired result, particularly
English

3 4
when processing firm or unripened
foods as you may find that some
ingredients remain unprocessed.
lDo not touch the sharp blades. Keep
the blade unit away from children.
lAlways take care when handling the
blade assembly and avoid touching
the cutting edge of the blades when
cleaning.
lDo not blend frozen ingredients or
ice cubes without liquid.
lNever blend dry ingredients (e.g.
spices, nuts) or run the Blender
empty.
lDo not use the Blender as a storage
container.
lSome liquids increase in volume and
froth during blending e.g. milk, so
do not overfill and ensure the blade
assembly is correctly fitted.
lTo ensure long life of your Blender,
never run it continuously for longer
than 60 seconds.
lNever blend food that has formed a
solid mass during freezing, break it
up before adding to the bottle.
lNever blend more than the maximum
capacity (600ml) marked on the
bottle.
lOnly use the Blender with the blade
assembly supplied.
lNever fit the blade unit to the High
Speed Outlet without the Blender
bottle fitted.

3 4
l This appliance conforms to
EC Regulation 1935/2004 on
materials and articles intended
to come into contact with
food.
You can use your Blender
for making delicious and
nutritious cold drinks. The
dispensing lid means that it
can easily be converted into a
sports bottle.
A selection of recipes can
be found at the back of the
instructions. Combinations of
fruit and yoghurt (both fresh
and frozen), ice cream, ice
cubes, juice and milk can be
used.
before using for the first time
l Wash the parts: see ‘care &
cleaning’.
key
1dispensing lid ×2
2sports bottle ×2
3sealing ring
4blade unit
5blade holder
to assemble your
blender attachment
(AèC)
1 Add ingredients to the bottle
up to the 600ml level mark.
l For best blending
performance always add ice/
frozen ingredients to the
bottle first.
l When adding frozen
ingredients (i.e. frozen fruit,
yoghurt, ice cream or ice) do
not blend more than 60g or 3
ice cubes.
l Do not blend frozen
ingredients without liquid.
2 Fit the sealing ring 3to the
blade unit 4, ensuring the
seal is located correctly in the
grooved area.
l Leaking will occur if the seal is
damaged or incorrectly fitted.
3 Hold the underside of the
blade unit 4and lower it
onto the bottle, blades down.
4 Screw the blade holder
5onto the bottle - turn
clockwise to lock.
l Shake to disperse the
ingredients.
lWhen removing the Blender from the
power unit:
wait until the blades have
completely stopped;
do not accidentally unscrew the
Blender bottle from the blade unit.
lMisuse of your Blender can result in
injury.
Refer to your main Kitchen Machine
instruction book for additional safety
warnings.

5
to use your blender
attachment (DèE)
1 Remove the high speed outlet
cover.
2 Place the blender over the
high speed outlet with the
line up graphic▼on the blade
holder facing forward. Turn
clockwise and at the same
time push down until the unit
engages. Then turn further
clockwise until the attachment
locks into position.
Speed Max operating time
Max 60 secs
l Allow the ingredients to blend
until smooth.
after blending (F)
1 When the desired consistency
is reached, turn the speed
control to the ‘O’ off position.
2 Hold the blade holder and
turn anti-clockwise to release
the blender. Then remove the
blender supporting it with
both hands.
3 Turn the bottle the other way
up and unscrew the blade
assembly.
using the drinking
lid (G)
1 Fit and lock the lid by turning
clockwise.
2 When you want to drink,
simply flip open the lid cover.
The drink can be consumed
straight from the bottle.
hints & tips
l Note that when the
bottle is filled to max
capacity (600ml), this is
approximately two servings.
l If you do not intend
to consume your drink
immediately, keep it
refrigerated.
l Ensure your drink is thin
enough to be able to drink
from the dispensing lid. To
make a thinner drink add
more liquid.
l Once your drink has
reached the desired
consistency, you can use
the pulse ‘P’ to ensure all
ingredients are thoroughly
blended. Use the pulse ‘P’
to operate in a start stop
action to control the texture
of your drink.
l After blending, some drinks
may not be completely
smooth due to seeds
or the fibrous nature of
ingredients.
l Some drinks may separate
on standing, therefore it is
best to drink them straight
away. Separated drinks
should be stirred before
drinking.
l When the dispensing lid
is fitted always keep the
bottle upright.

6
care & cleaning
l Always switch off, unplug and
dismantle before cleaning.
l Always wash immediately
after use.
l Do not let food dry onto the
blade assembly as this will
make cleaning difficult.
blade assembly (I)
l Unscrew the blade assembly
from the bottle. Then lift out
the blade unit.
l Care should be taken when
removing the blade unit from
the blade assembly.
1 Remove and wash the sealing
ring.
2 Do not touch the sharp blades
- brush them clean using
hot soapy water, then rinse
thoroughly under the tap.
Do not immerse the blade
assembly in water.
3 Leave to dry upside down
away from children.
other parts
Wash by hand, rinse with
clean water and dry.
(H) The following table
shows which items can be
washed in the dishwasher.
Item Suitable for
dishwashing
4
8
8
4
4
service and
customer care
UK only
If you need help with:
lusing your attachment
lservicing or repairs (in or out
of guarantee)
Zcall Kenwood customer care
on 023 9239 2333.
lspares and attachments
Z call 0844 557 3653.
other countries
lIf you experience any
problems with the operation
of your attachment, before
requesting assistance refer to
the “troubleshooting guide”
section in the manual or visit
www.kenwoodworld.com.
lPlease note that your product
is covered by a warranty,
which complies with all
legal provisions concerning
any existing warranty and
consumer rights in the country
where the product was
purchased.
lIf your Kenwood product
malfunctions or you find
any defects, please send it
or bring it to an authorised
KENWOOD Service Centre.
To find up to date details
of your nearest authorised
KENWOOD Service centre
visit www.kenwoodworld.com
or the website specific to your
Country.
lDesigned and engineered by
Kenwood in the UK.
lMade in China.

7
Problem Cause Solution
The Blender will
not operate.
No power. Check kitchen machine
plugged in.
Can not fit
blender to high
speed outlet.
The▼graphicto
assist alignment is
not facing forward.
Place the blender
over the high speed
outlet with the line up
graphic▼on the blade
holder facing forward.
Turn clockwise and at
the same time push
down to engage.
Poor blending
performance.
Insufficient liquid
added.
Bottle overfilled.
Insufficient
processing time.
Add more liquid and
follow recipes supplied.
Do not fill above
600ml level mark.
Process for 60
seconds.
Poor processing
of frozen
ingredients.
Ice/frozen
ingredients
added to bottle last.
Too much frozen
ingredients added.
For best blending
performance always
add ice/ frozen
ingredients to bottle
first.
Do not process more
than 60g frozen
ingredients or more
than 3 ice cubes.
Pouring action
from lid spout
poor.
Drink consistency
too thick.
Process for longer or
add more liquid.
Blender leaking
from blade
assembly.
Seal missing.
Seal incorrectly
fitted.
Seal damaged.
Bottle not tightened
sufficiently to blade
holder.
Check seal is fitted
correctly and not
damaged.
To obtain a
replacement seal see
“service and customer
care”.
Check bottle fitted
correctly to blade
holder.
If none of the above solve the problem see “Service and Customer
Care”.
troubleshooting guide

8
IMPORTANT INFORMATION
FOR CORRECT DISPOSAL
OF THE PRODUCT IN
ACCORDANCE WITH THE
EUROPEAN DIRECTIVE ON
WASTE ELECTRICAL AND
ELECTRONIC EQUIPMENT
(WEEE)
At the end of its working life, the
product must not be disposed of
as urban waste.
It must be taken to a special local
authority differentiated waste
collection centre or to a dealer
providing this service.
Disposing of a household
appliance separately avoids
possible negative consequences
for the environment and health
deriving from inappropriate
disposal and enables the
constituent materials to be
recovered to obtain significant
savings in energy and resources.
As a reminder of the need to
dispose of household appliances
separately, the product is
marked with a crossed-out
wheeled dustbin.
recipes
Breakfast
Smoothies
breakfast 2GO
1 serving (300ml)
2 ice cubes (40g)
60ml skimmed milk
50g low fat yoghurt
50g banana cut into 2cm
slices
75g apple, chopped into 2cm
chunks
5ml wheatgerm
5ml runny clear honey
1 Add ingredients to bottle
in order stated. Shake well
before blending.
2 Switch to MAX for 60
seconds. Check the sweetness
and add the Honey if required.
nutty banana boost
1 serving (250ml)
75ml semi-skimmed milk
115g low fat hazelnut yoghurt
50g banana cut into 2cm
slices
3 ready to eat dried apricot,
chopped into 1cm pieces
1 Add ingredients to bottle
in order stated. Shake well
before blending.
2 Switch to MAX for 45
seconds.

9
Fruity Smoothies
iced strawberry
sensation
1 serving (250ml)
2 ice cubes (40g)
70ml apple juice
60g strawberries, hulled and
halved
80g cantaloupe melon, seeded
and cut into 2cm chunks
5ml runny clear honey
1 Add ingredients to bottle in
order stated.
2 Pulse 5 times, then switch to
MAX for 45 seconds. Check
the sweetness and add the
Honey if required.
summer fruit
smoothie
1 serving (250ml)
50g frozen summer fruit mix
200ml semi-skimmed milk
1 Add ingredients to bottle in
order stated.
2 Switch to MAX for 30
seconds.
mix smoothie
1 serving (250ml)
120g carrot
70g apple
75g orange (peeled)
50ml yoghurt
50ml semi skimmed milk
1 Cut the apple, orange and
carrot into 2 cm chunks.
2 Add ingredients to bottle in
order stated.
3 Pulse 5 times, then switch to
Max for 45 seconds.
Vegetable
Smoothies
green smoothie
1 serving
180g orange juice
15g kale
2tbsp (30ml) parsley
1tbsp (15ml) coriander
10 -12 mint leaves
110g banana cut into 2cm
slices
1 Add ingredients to bottle in
order stated.
2 Switch to MAX for 30
seconds.
emerald smoothie
1 serving
3 ice cubes (60g)
135g orange juice
45g yoghurt
25g spinach leaves
115g pineapple cut into 2cm
pieces
1 Add ingredients to bottle in
order stated.
2 Switch to MAX for 45
seconds.
Protein Shake
blueberry
supergreens shake
1 serving
60g frozen blueberries
275ml skimmed milk
10g protein powder
60g banana cut into 2cm
slices
40g spinach
1 Add ingredients to bottle in
order stated.
2 Switch to MAX for 30
seconds.

10
veiligheid
lLees deze instructies zorgvuldig
door en bewaar ze voor toekomstig
gebruik.
lVerwijder de verpakking en alle
labels.
lSchakel de keukenmachine uit en haal
de stekker uit het stopcontact:
voordat u onderdelen aanbrengt of
verwijdert
na gebruik
vóór u het apparaat reinigt.
lGebruik nooit een beschadigd
hulpstuk. Laat het nakijken of
repareren: zie ‘onderhoud en
klantenservice’.
lGebruik nooit een ongeautoriseerd
hulpstuk.
lLaat het apparaat nooit onbeheerd
aanstaan.
lWacht altijd totdat de messen
volledig tot stilstand zijn gekomen
voordat u de beker van het
hogesnelheidscontact af haalt.
lDe beker is alleen geschikt voor
gebruik met koude ingrediënten.
Gebruik hem niet voor hete
ingrediënten.
lVERBRANDINGSGEVAAR: De
machine kan ook worden gebruikt
voor de bereiding van soep.
Vloeistoffen moeten afgekoeld zijn
tot kamertemperatuur voordat ze in
de beker worden gegoten of worden
gemengd.
Vouw de voorpagina a.u.b. uit voordat u begint te lezen. Op deze
manier zijn de afbeeldingen zichtbaar
Nederlands
