UHF FM TRANSCEIVER
TK-3130/3131
SERVICE MANUAL
30K : TK-3130 (K type)
31K : TK-3131 (K type)
A : TK-3131 (A type)
GENERAL .................................................. 2
REALIGNMENT ......................................... 3
CIRCUIT DESCRIPTION ............................ 5
SEMICONDUCTOR DATA ........................ 9
DESCRIPTION OF COMPONENTS ........ 10
PARTS LIST ............................................. 11
EXPLODED VIEW.................................... 17
PACKING ................................................. 18
ADJUSTMENT ........................................ 20
PC BOARD VIEWS
TX-RX UNIT (X57-6460-XX) (B/2) ...... 24
TX-RX UNIT (X57-6460-XX) (A/2)...... 27
SCHEMATIC DIAGRAM.......................... 33
BLOCK DIAGRAM ................................... 37
LEVEL DIAGRAM .................................... 39
TERMINAL FUNCTION ........................... 40
KNB-27N (Ni-MH BATTERY PACK) ........ 40
SPECIFICATIONS .................................... 41
CONTENTS
Antenna
(T90-1004-05) Knob (VOL)
(K29-9138-03)
Cap (P-jack)
(B09-0627-03)
Cabinet assy (Front)
(A02-3663-03) : 30K
(A02-3705-03) : 31K
(A02-3706-03) : A
Button knob (PTT)
(K29-9137-13)
Key top
(K29-9136-12)
Photo is TK-3130.

2
TK-3130/3131 GENERAL
INTRODUCTION
SCOPE OF THIS MANUAL
This manual is intended for use by experienced techni-
cians familiar with similar types of commercial grade com-
munications equipment. It contains all required service in-
formation for the equipment and is current as of this publica-
tion date. Changes which may occur after publication are
covered by either Service Bulletins or Manual Revisions,
which are issued as required.
ORDERING REPLACEMENT PARTS
When ordering replacement parts or equipment informa-
tion, the full part identification number should be included.
This applies to all parts : components, kits, and chassis. If
the part number is not known, include the chassis or kit
number of which it is a part and a sufficient description of
the required component, for proper identification.
PERSONNEL SAFETY
The following precautions are recommended for person-
nel safety :
• DO NOT transmit until all RF connectors are secure and
any open connectors are properly terminated.
• SHUT OFF this equipment when near electrical blasting
caps or while in an explosive atmosphere.
• This equipment should be serviced by only qualified tech-
nicians.
SERVICE
This radio is designed for easy servicing. Refer to the
schematic diagrams, printed circuit board views, and align-
ment procedures contained within.
TK-3130
Destination Number of CH Frequency No. / Frequency / Color Factory default CH setting RF power output
K 2 channel 1 464.5000MHz Brown CH1 : 464.5500MHz / QT OFF 1W / 500mW
2 464.5500MHz Yellow Color : Yellow
3 467.7625MHz J CH2 : 467.9250MHz / QT OFF
4 467.8125MHz K Color : Blue Star
5 467.8500MHz Silver Star
6 467.8750MHz Gold Star
7 467.9000MHz Red Star
8 467.9250MHz Blue Star
All channels are Narrow band width. User can select channel frequency from above.
TK-3131
Destination Number of CH Frequency No. / Frequency / Color RF power output
Bank A Bank B
RX/TX RX TX
K 15 channel CH1 : 462.5625MHz CH1 : 462.5625MHz 462.5625MHz 1W / 500mW
CH2 : 462.5875MHz CH2 : 462.5875MHz 462.5875MHz
CH3 : 462.6125MHz CH3 : 462.6125MHz 462.6125MHz
CH4 : 462.6375MHz CH4 : 462.6375MHz 462.6375MHz
CH5 : 462.6625MHz CH5 : 462.6625MHz 462.6625MHz
CH6 : 462.6875MHz CH6 : 462.6875MHz 462.6875MHz
CH7 : 462.7125MHz CH7 : 462.7125MHz 462.7125MHz
CH8 : 462.5750MHz White CH8 : 462.5750MHz 467.5750MHz White
CH9 : 462.6250MHz Black CH9 : 462.6250MHz 467.6250MHz Black
CH10 : 462.6750MHz Orange CH10 : 462.6750MHz 467.6750MHz Orange
CH11 : 462.5500MHz CH11 : 462.5500MHz 467.5500MHz
CH12 : 462.6000MHz CH12 : 462.6000MHz 467.6000MHz
CH13 : 462.6500MHz CH13 : 462.6500MHz 467.6500MHz
CH14 : 462.7000MHz CH14 : 462.7000MHz 467.7000MHz
CH15 : 462.7250MHz CH15 : 462.7250MHz 467.7250MHz
All channels are Wide band width. Factory default setting is Bank A.

3
TK-3130/3131
TK-3131
Destination Number of CH Frequency No. / Frequency / Color RF power output
A 14 channel CH1 : 467.5125MHz 1W / 500mW
CH2 : 467.5250MHz
CH3 : 467.5375MHz
CH4 : 467.5500MHz
CH5 : 467.5625MHz
CH6 : 467.5750MHz
CH7 : 467.5875MHz
CH8 : 467.6000MHz
CH9 : 467.6125MHz
CH10 : 467.6250MHz
CH11 : 467.6375MHz
CH12 : 467.6500MHz
CH13 : 467.6625MHz
CH14 : 467.6750MHz
All channels are Narrow band width.
GENERAL
GETTING ACQUAINTED
qPTT (Push to Talk) switch
Press and hold, then speak into the microphone to trans-
mit.
wMENU key
Press to perform various functions. Press and hold while
switching the power ON to enter Setting Mode.
eCAL key
Press before making a call, to alert the other party mem-
bers.
r/keys
Press to change the operating channel, to select a menu
in Setting Mode, and to perform other functions.
tPower switch/Volume control
Turn clockwise to switch the power ON and counter-
clockwise to switch the power OFF. Rotate to adjust the
volume.
yMON key
Press to monitor the current channel for activity.
uLED indicator
Indicates the transceiver status.
iSP/MIC jacks
Lift the covers and insert the accessory’s plugs here.
1
2
3
4
5
6
8
Antenna
Microphone
Speaker
7

4
TK-3130/3131
Frequency Configuration
Fig. 1 Frequency configuration
ANT
SW BPF MIX, IF DET AF
AMP
TCXO
RF
AMP
RF
AMP
MIC
AMP
PLL VCO
1st MIX
CF
450kHz
38.85MHz
MCF
38.4MHz
SP
MIC
ANT
460~470MHz
460~470MHz
421.15~
431.15MHz
RF
AMP
Tripler
X3
12.8MHz
Reception method Double super heterodyne
1st IF frequency 38.85MHz
2nd IF frequency 450kHz
Transmission method VCO direct oscillation amplification
Modulation Variable reactance phase modulation
Table 1 Basic configuration
Receiver System
■Front End
The high-frequency signal from the antenna passes
through a low-pass filter and a high-frequency switch (D12,
L25 and D13) which switches between transmission and re-
ception, and goes to the BPF (L42) to remove unwanted sig-
nals. The resulting signal is amplified by high-frequency am-
plifier (Q18) and goes to the first mixer (Q19).
■First Mixer
The signal that reaches Q19 is mixed with the first local
signal from the VCO to produce a first IF signal (38.85MHz).
(Receive frequency – First local frequency
= First IF frequency = 38.85MHz)
The first IF signal passes through MCF: XF1 (monolithic
crystal filter) to remove unwanted signals.
The first IF signal is amplified by IF amplifier (Q20) and
goes to IF IC (IC2).
CIRCUIT DESCRIPTION
Item Rating
Nominal center frequency (fo) 38.85MHz
Pass bandwidth ±5.0kHz or more at 3dB
Attenuation bandwidth ±18.5kHz or less at 35dB
Ripple 1.0dB or less
Insertion loss 4.0dB or less
Guaranteed attenuation 70dB or more at fo–900kHz
Terminating impedance 610Ω±10% / 3.0pF±0.5pF
Table 2 MCF (L71-0586-05) : TX-RX unit (B/2) XF1
Item Rating
Nominal center frequency (fo) 450kHz
6dB bandwidth ±6.0kHz or more
50dB bandwidth ±12.5kHz or less
Ripple (at 450kHz±4kHz) 2dB or less
Guaranteed attenuation 35dB or more
(at 450kHz±100kHz)
Insertion loss 6dB or less
I/O matching impedance 2.0kΩ
Table 3 Ceramic filter (L72-0958-05) : TX-RX unit (B/2) CF1
Fig. 2 Receiver section configuration
Fig. 3 Receiver circuit
ANT
LPF
3T 3R
D12
L25
D13
L42
BPF
Q18
3R
IF IC
Q20
XF1
3R
1st IF : 38.85MHz
Q19
VCO
1st local
OSC
BPF
L42 RF AMP Q18 1st MIXER Q19 MCF XF1 IF AMP Q20 IF AMP, DET IC2 AF AMP IC208 SP
1st local OSC (PLL) 2nd local OSC
ANT
38.85MHz465.0MHz
D12
D13
L25
LPF ANT
SW

5
TK-3130/3131 CIRCUIT DESCRIPTION
■IF Amplifier
The IF circuit is integrated in the FM IC (IC2). The IF IC
contains local input, mixer, limiter amplifier, FM DET, and
low-frequency amplifier.
The IF signal coming from the IF amplifier (Q20) goes to
the IF IC mixer and is mixed with the second local signal
(38.4MHz) to produce a second IF signal.
(38.85MHz – 38.4MHz = 450kHz)
The tripled PLL reference oscillation (12.8MHz x 3) is
used for the second local signal.
The second IF signal passes through ceramic filter (CF1)
to remove unwanted signals.
The second IF signal passing through the ceramic filter
passes through the limiter amplifier consisting six differen-
tial amplifiers and is detected.
The FM detection is quadrature detection method. The
phase of the output signal from the limiter amplifier is
shifted by 90 degrees by a quad coil (L36) and compared
with the original waveform to produce detection output.
■Squelch Circuit
A squelch circuit is provided to prevent no-signal noise or
weak signals from outputting to a speaker during transmis-
sion.
■AF Circuit
The FM IC output passes through the base band IC
(IC205), mute (Q213), and amplifier (IC207). After go to AF
power amplifier IC (IC208). This IC have BTL amplifier func-
tion and electrical Volume. At internal speaker, BTL ampli-
fied. At external speaker, IC switch off the 1 channel ampli-
fier by connectors information.
MIX
Amp
Amp
Amp
Amp
DET
IC2
IC205
IC208
CF1
450kHz
16
MIXIN
38.85
MHz
1st IF 9
AFOUT
38.4MHz
X3TCXO Q22
12.8MHz
PLL
X1
HPF LPF 23
RXIN
MUTE
Q213
IC207
Amp
SW VR202
AF VR
INT. SP
J200
EXT. SP
AF
Q21
Noise ampD16
DET
BUSY
19
2452 RSSI
IC204
CPU
6
AF MUTE
Q212
Q214
SW
SP AMP
Q20
IF amp
Fig. 4 IF amplifier, squelch and
AF amplifier circuits
Transmitter System
■Microphone Amplifier Circuit
The audio signal from the microphone passes through
the MIC amplifier (IC207). Then, the signal goes through the
base band IC (IC205) that has the 6dB/oct pre-emphasis cir-
cuit, band-pass filter (300 to 3kHz), amplifier, and limiter.
The distortion components outside the audio band are re-
moved by the splatter filter.
■Modulation Circuit
The MIC amplifier (IC207) output passes through VR201
for modulation adjustment and goes to the modulation input
of the VCO circuit for variable reactance phase modulation.
■Transmission Output Circuit
The VCO output is amplified by a high-frequency ampli-
fier (Q7~Q10), passes through a high-frequency antenna
switch, passes through a low-pass filter and goes to the an-
tenna.
The transmission output is about 1W with 3.8V DC sup-
ply at battery terminal.
■Low-Pass Filter Circuit
A three-stage Chebyshev type low-pass filter is located
between the antenna and transmit/receive switching circuit.
It removes harmonic components contained in the transmis-
sion output.
Fig. 5 Transmitter section configuration
Fig. 6 Microphone amplifier circuit
ANT
LPF
ANT SW
D12,13
DRIVE
AMP
Q9
PRE-DRIVE
AMP
Q8
RF AMP
Q7
VCO
Q4, Q5VR201
MIC AMP
IC207MIC
FINAL
AMP
Q10
Amp
IC205 LPFIDC
DET
D205
SW
D204
MIC
MUTE
Q210
IC207
MIC amp
MIC

6
TK-3130/3131
CIRCUIT DESCRIPTION
PLL System
■VCO Circuit
The VCO is housed in a shield case.
The VCO circuit consists of a transistor (Q4), a variable
capacity diode (D4) for frequency control, a variable capacity
diode (D8) for modulation, transmit/receive frequency shift
diode (D17), control transistor (Q2), variable capacitor (TC1)
for PLL lock voltage control, and oscillator buffer amplifier
(Q5).
■PLL Circuit
Frequency data is sent to the PLL IC (IC1) from the CPU
(IC204) as serial data when the power turns on, when the
channel is changed, or when transmission begins. It sets
the variable divider in the PLL IC.
The TCXO (X1) produce a 12.8MHz reference frequency.
It is divided to produce a 12.5kHz PLL comparison fre-
quency in the PLL IC.
The VCO input is divided by the divide ratio set by the
divider in the PLL IC to generate 12.5kHz. It is compared
with the reference comparison frequency by the phase
comparator to detect a phase difference.
The charge pump circuit in the PLL IC converts it to a
control voltage that can drive the VCO directly.
The control voltage passes through a loop filter which
passes low frequency and is applied to the VCO control pin
to control the oscillator frequency. The loop filter removes
unwanted harmonics and noise contained in the output from
the phase comparator and determines PLL response and
synchronizing characteristics by the amplitude and phase
characteristics (Fig. 8).
Fig. 7 VCO circuit
In receive mode, the shift signal T/R goes low, Q2 turns
off, and the shift diode (D17) not contact. Q4 produces the
first local frequency for reception.
(Receive channel frequency – 38.85MHz)
In transmit mode, the shift signal T/R goes high, Q2 turns
on and D17 does conducts. Q4 produces about 460~470
MHz and the VCO frequency equals the transmit channel
frequency.
The 3.0V circuit voltage is produced by ripple removing
filter circuit Q3.
■Unlock Detection Circuit
If the PLL cannot be synchronized for some reason or
other when switching the channel or changing between
transmission and reception, the PLL IC outputs a low unlock
detection signal. This signal goes to the CPU to inhibit trans-
mission when the PLL is unlocked.
Fig. 8 PLL circuit
++ +
CP1
XIN
3C
3C
PLL data
(CPU)
STB
DATA
CK
CPU (IC204)
UL
VCO
LV
Loop filter
VCO OUT
F OUT FIN1
3C,T/R,MOD
PLL IC
IC1
LD
TCXO TO
X1 12.8MHz
Vcont
R22
R23
R126
R21
R24
R26
C42
C186
C27
C38 C36
C198
C194
TC1
D8
D4
D17
C44
C46
C30C31 C29
C33 C32
D3
R15
R17 R36
L10
L9
L43
Q4
Q2
Q3
Q5
C45
C41 R25 C185
R35
R18
R10
L11
R11 L8
L44
L12
R14
R146
LV
MOD
T/R
3C
+
VCO
OUT

7
TK-3130/3131
Control System
■Reset Circuit
When a battery voltage is dropped, IC201 is detected low
voltage, and this detected signal input to IC204 for stop the
CPU function. IC200 is detected the reset voltage.
■Battery Voltage Detection Circuit
The unit detects a low battery voltage and display the
BATT indicator on the LCD. The battery voltage is divided
and applied to the analog value input pin (BATT) of the CPU,
and converted to a digital signal.
■Power Supply Circuit
The power supply voltage is maintained to 3.0V by the
series regulator (IC213). It is used as CPU power 3M. The
3C, 3R and 3T voltages are regulated by the IC209.
The B (battery voltage) is supplied to the RF final transis-
tor Q10.
The transmission power 3T is supplied to the transmis-
sion output circuit when the CPU turns Q219 on only in
transmit mode. 3T is junction to VR2 to generate PA gate
(Q10) for power alignment.
The reception power 3R is provided to the receive and IF
circuits when the CPU turns Q220 on only in receive mode.
The transmission/reception power 3C is supplied to the
VCO and PLL circuits when the CPU turns Q218 on in trans-
mit and receive modes.
If no signal is received for 10 seconds, the CPU enters
the power save mode, and turns common power 3C and
reception power 3R on for one cycle and off for three cycles
according to the signals from the CPU to save the battery
power.
CIRCUIT DESCRIPTION
Fig. 9 Reset, battery voltage detection and
power supply circuits
Fig. 10 QT/DQT circuit
IC213
AVR
IC209 Q218
Q220
Q219
AVR SW
SW
SW
3C
3M
SB
3R
3T
Power
SW
B
IC204
CPU BATT
IC204
CPU
TO
IC206 IC2
TI
40
20
LPF
TCXO
IF IC
VCO
TX AF
VR200
LPF
RX AF
Fig. 11 AK2368 (IC205) block diagram
HPF
+VR1 Com-
pressor Pre-
emphasis
Scrambler
Limiter Splatter
filter
+VR2
HPF
BPF
OSC
LPF
+VR3
–
–
+
+
Control register
and data buffer MSK
MODEM
Expander
+VR4 De- emphasis
De-
scrambler
–
+
23
22
14
15
Reception
signal
input
Transmission
signal output
6
3.6864MHz
171819
3
4
11
20
21
Microphone
input
Frame
detection
Receiver
Reception output
TX data/
RX data
Control data
■QT/DQT
•Encode (Transmit)
QT/DQT signal is generated by CPU (IC204). Output sig-
nal (IC204 pin 40 (TO)) goes to TCXO modulation and VCO
modulation (Through the VR200).
•Decode (Receive)
Detected AF signal go to IC206. Function of IC206 is LPF
for sub-audible frequency. This signal goes to IC204 pin 20
(TI). IC204 is detected the QT or DQT.

8
TK-3130/3131
SEMICONDUCTOR DATA
■Terminal function
Pin No. Port Name I/O Function
1~3 V1~V3 I LCD Voltage
4,5 NC I NC
6 AF MUTE O RXsignal AF Mute L : Mute
7 SEL I
8 SHIFT O Clock Frequency shift
9 VSS I GND
10 OSC2 O Clock oscillation out
11 OSC1 I Clock oscillation in
12 MMOD I GND
13 XI I NC
14 XO O NC
15 VDD I Power supply
16 RST I Reset L : Reset
17 VREF+ I GND
18 UL I PLL Unlock L : Unlock
19 BUSY I RX Busy Detect
20 TI I QT/DQT signal
21 BIAS I NC
22 BATT I Battery Voltage
23 VOX I VOX Level
24 RSSI I RX Carrier Level
25 VIB O Vibrator Control H : On
26 VREF– I GND
27 VDD I Power supply
28 TXD O to FPU Data
29 RXD I from FPU Data
30 TDATA O MSK TX Data
31 DIR O IC205 Control
32 SCLK O IC205 Clock
33 DI/O I/O IC205 Data
34 APC O TX Power H/L H : Low power
35 BEEP O Beep
36 PABC O Final SW
37 3CC O 3C SW L : On
38 3RC O 3R SW L : On
39 3TC O 3T SW L : On
40 TO O TX QT/DQT out
CPU : MN101C54AKA (TX-RX UNIT (A/2) IC204)
Pin No. Port Name I/O Function
41 BATT L I Battery Low
42 TCLK O MSK TX Clock
43 RDF I Detect MSK Data
44 VDD I Power Supply
45 PTT I PTT L : Press
46 MONI I MONITOR key L : Press
47 CALL I CALL key L : Press
48 UP I UP key L : Press
49 MODE I MODE key L : Press
50 DOWN I DOWN key L : Press
51 MICMUTE O MIC Mute H : Mute
52 SP AMP O AF AMP on/off H : On
53 PCLK O PLL IC Clock
54 PDATA O PLL IC Data
55 PEN O PLL IC Enable
56 ECLK O EEPROM Clock
57 EDATA I/O EEPROM Data
58 BACKLIT O LCD Lamp on/off H : On
59 RLED O Red LED on/off H : On
60 GLED O Green LED on/off H : On
61,62 NC O NC
63~76 SEG13~SEG0 O LCD
77~79 COM0~COM2 O LCD
80 NC O NC
FET : 2SK3078 (Q9)
■Absolute Maximum Ratings (Ta=25°C)
Item VDSS VGSS IDPch Tch Tstg
Rating 15V 5V 0.5A 3W 150°C –45~+150°C
Tc=25°C
FET : NE5510279A (Q10)
■Absolute Maximum Ratings (Ta=25°C)
Item VDSS VGSS IDPch Tch Tstg
Rating 8.5V 6.0V 1.0A 2.4W 125°C –55~+125°C
Tc=25°C

9
TK-3130/3131
TX-RX UNIT (X57-6460-XX)
Ref. No. Part Name Description
IC1 IC Phase locked loop system
IC2 IC IF system
IC200 IC Voltage detect
IC201 IC Reset switch
IC203 IC EEPROM
IC204 IC CPU
IC205 IC Base band
IC206 IC Active filter
IC207 IC MIC amplifier / Limiter
IC208 IC Audio power amplifier
IC209 IC Voltage regulator (3V)
IC213 IC Voltage regulator (3V)
IC214 IC Divider
Q1 Transistor RF amplifier
Q2 Transistor DC switch (T/R)
Q3 Transistor Ripple filter
Q4 Transistor VCO
Q5 Transistor RF buffer amplifier
Q6,7 Transistor RF amplifier
Q8 Transistor TX pre-drive
Q9 FET TX drive
Q10 FET TX final
Q11 Transistor Temperature protection switch
Q13 FET DC switch
Q14 Transistor DC switch (HI/LO)
Q18 FET RF amplifier
Q19 FET Mixer
Q20 Transistor IF amplifier
Q21 Transistor Noise amplifier
Q22 Transistor Tripler
Q200 Transistor DC switch (Backlight)
DESCRIPTION OF COMPONENTS
Ref. No. Part Name Description
Q201 Transistor DC switch (Busy)
Q202 Transistor DC switch (TX)
Q210 Transistor MIC mute / AGC
Q212 Transistor DC switch
Q213 FET Audio mute switch
Q214 Transistor AF amplifier power supply
Q216 FET Vibration switch
Q217 FET VOX switch
Q218 Transistor DC switch (3C)
Q219 Transistor DC switch (3T)
Q220 Transistor DC switch (3R)
Q221 Transistor Beat shift switch
D1 Diode Unlock detect
D3 Diode Current steering
D4 Variable Frequency control
capacitance diode
D8 Variable TX modulation
capacitance diode
D9,10 Diode RF switch
D12,13 Diode Antenna switch
D16 Diode Noise detect
D17 Diode Current steering
D200 LED LCD backlight
D201 LED TX / BUSY
D202 Diode AF detect
D204 Diode MIC mute / AGC switch
D205 Diode AGC detect
D208 Diode Surge absorption
D209 Diode Reverse protection
D210 Zener Diode Voltage protection

10
TK-3130/3131
PARTS LIST
2nd Word G H J K L
ppm/°C±30 ±60 ±120 ±250 ±500
Example : CC45TH = –470 ±60ppm/°C
Multiplier
2nd number
1st number
2 2 0 = 22pF
CAPACITORS CC 45 TH 1H 220 J
1234 56
1 = Type … ceramic, electrolytic, etc. 4 = Voltage rating
2 = Shape … round, square, ect. 5 = Value
3 = Temp. coefficient 6 = Tolerance
•Temperature coefficient
1st Word C L P R S T U
Color* Black Red Orange Yellow Green Blue Violet
ppm/°C 0 –80 –150 –220 –330 –470 –750
•Tolerance (More than 10pF)
Code C D G J K M X Z P No code
(%) ±0.25 ±0.5 ±2±5±10 ±20 +40 +80 +100 More than 10µF – 10 ~ +50
–20 –20 –0 Less than 4.7µF –10 ~ +75
•Voltage rating
ABCDEFGHJKV
0 1.0 1.25 1.6 2.0 2.5 3.15 4.0 5.0 6.3 8.0 –
1 10 12.5 16 20 25 31.5 40 50 63 80 35
2 100 125 160 200 250 315 400 500 630 800 –
3 1000 1250 1600 2000 2500 3150 4000 5000 6300 8000 –
•Chip capacitors
(EX) C C 7 3 F S L 1 H 0 0 0 J
1 234 5 6 7
(Chip) (CH, RH, UJ, SL)
(EX) C K 7 3 F F 1 H 0 0 0 Z
1 234 5 6 7
(Chip) (B, F)
RESISTORS
•Chip resistor (Carbon)
(EX) R D 7 3 E B 2 B 0 0 0 J
1 234 5 6 7
(Chip) (B,F)
•Carbon resistor (Normal type)
(EX) R D 1 4 B B 2 C 0 0 0 J
1 234 5 6 7
1 = Type … ceramic, electrolytic, etc. 5 = Voltage rating
2 = Shape … round, square, ect. 6 = Value
3 = Dimension 7 = Tolerance
4 = Temp. coefficient
•Capacitor value
010 = 1pF
100 = 10pF
101 = 100pF
102 = 1000pF = 0.001µF
103 = 0.01µF
(Less than 10pF)
Code B C D F G
(pF) ±0.1 ±0.25 ±0.5 ±1±2
1st word
2nd word
Refer to the table above.
Dimension (Chip capacitors)
Dimension code L W T
Empty 5.6 ±0.5 5.0 ±0.5 Less than 2.0
A 4.5 ±0.5 3.2 ±0.4 Less than 2.0
B 4.5 ±0.5 2.0 ±0.3 Less than 2.0
C 4.5 ±0.5 1.25 ±0.2 Less than 1.25
D 3.2 ±0.4 2.5 ±0.3 Less than 1.5
E 3.2 ±0.2 1.6 ±0.2 Less than 1.25
F 2.0 ±0.3 1.25 ±0.2 Less than 1.25
G 1.6 ±0.2 0.8 ±0.2 Less than 1.0
H 1.0 ±0.05 0.5 ±0.05 0.5 ±0.05
Dimension
Dimension (Chip resistor)
Dimension code L W T
E 3.2 ±0.2 1.6 ±0.2 1.0
F 2.0 ±0.3 1.25 ±0.2 1.0
G 1.6 ±0.2 0.8 ±0.2 0.5 ±0.1
H 1.0 ±0.05 0.5 ±0.05 0.35 ±0.05
Rating wattage
Code Wattage Code Wattage Code Wattage
1J 1/16W 2C 1/6W 3A 1W
2A 1/10W 2E 1/4W 3D 2W
2B 1/8W 2H 1/2W
1 = Type
2 = Shape
3 = Dimension
4 = Temp. coefficient
5 = Voltage rating
6 = Value
7 = Tolerance
CC45 Color*
T
W
L

TK-3130/3131 PARTS LIST
11
30K :TK-3130K
31K : TK-3131K
A : TK-3131A
✽New Parts. indicates safety critical components.
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
L: Scandinavia K: USA P: Canada
Y: PX (Far East, Hawaii) T: England E: Europe
Y: AAFES (Europe) X: Australia M: Other Areas
TK-3130/3131
TX-RX UNIT (X57-6460-XX)
New Desti-
parts nation
Ref. No.
Address Parts No. Description
New Desti-
parts nation
Ref. No.
Address Parts No. Description
13A✽A02-3661-13 CABINET ASSY (REAR)
21A✽A02-3663-03 CABINET ASSY (FRONT) 30K
21A✽A02-3705-03 CABINET ASSY (FRONT) 31K
21A✽A02-3706-03 CABINET ASSY (FRONT) A
53B✽B09-0627-03 CAP (P-JACK)
61B✽B11-1285-03 ILLUMINATION GUIDE (LCD)
71B✽B38-0866-05 LCD
83A✽B41-1841-04 CAUTION LABEL (FCC SAR) 30K,31K
91D✽B46-0773-10 WARRANTY CARD 30K
91D✽B46-0774-00 WARRANTY CARD 31K
10 1D ✽B62-1486-00 INSTRUCTION MANUAL 30K
10 1D ✽B62-1590-00 INSTRUCTION MANUAL 31K
11 1F ✽B62-1591-00 INSTRUCTION MANUAL A
12 3A ✽B72-1970-04 MODEL NAME PLATE 30K
12 3A ✽B72-2062-04 MODEL NAME PLATE 31K
12 3A ✽B72-2063-04 MODEL NAME PLATE A
13 1B ✽E29-1194-04 INTER CONNECTOR (LCD)
14 1A E37-0810-15 PARALLEL CORD (SP)
16 3A ✽F07-1855-02 COVER (BATT)
17 2A ✽G11-4192-04 SHEET
18 3B ✽G11-4193-04 SHEET
19 2A G13-1751-04 CUSHION
20 2A ✽G13-1934-04 CUSHION
21 3B G53-1521-04 PACKING (P-JACK)
22 2D,2F ✽H12-3110-05 PACKING FIXTURE
23 2C ✽H12-3111-03 PACKING FIXTURE 30K,31K
24 1D,1E ✽H25-2345-04 PROTECTION BAG
25 3C ✽H52-1817-02 ITEM CARTON CASE 30K
25 3C ✽H52-1897-02 ITEM CARTON CASE 31K
26 3F ✽H52-1898-02 ITEM CARTON CASE A
27 1B ✽J21-8427-14 HARDWARE FIXTURE (LCD)
28 1D,1F ✽J29-0691-04 HOOK ASSY
29 2A J30-1212-04 SPACER (MIC)
31 1A ✽K29-9136-12 KEY TOP
32 2A ✽K29-9137-13 BUTTON KNOB (PTT)
33 3B ✽K29-9138-03 KNOB (VOL)
A 3B N14-0583-04 CIRCULAR NUT (VOL)
B 2A N39-2030-46 PAN HEAD MACHINE SCREW
C 3A N80-2006-45 PAN HEAD TAPTITE SCREW
D 3B N80-2012-45 PAN HEAD TAPTITE SCREW
E 2B N82-2005-46 BINDING HEAD TAPTITE SCREW
F 2A N82-2008-45 BINDING HEAD TAPTITE SCREW
35 1A T07-0362-05 SPEAKER
36 2A ✽T42-0335-05 MOTOR
37 2B ✽T90-1004-05 ANTENNA
39 1C ✽W08-0937-05 AC ADAPTER (120V AC) 30K,31K
40 1C ✽W08-0938-15 CHARGER 30K,31K
D200 B30-2143-05 LED (YG)
D201 ✽B30-2242-05 LED (RG)
C1 CK73HB1H471K CHIP C 470PF K
C2 CC73HCH1H470J CHIP C 47PF J
C3,4 CC73HCH1H100D CHIP C 10PF D
C5 CK73HB1H102K CHIP C 1000PF K
C6 C92-0695-05 CHIP-TAN 10UF 10WV
C7 CC73HCH1H470J CHIP C 47PF J
C13 CK73HB1H102K CHIP C 1000PF K
C17 C92-0001-05 CHIP C 0.1UF 35WV
C18 C92-0501-05 CHIP-TAN 1.5UF 10WV
C19 C92-0502-05 CHIP-TAN 0.33UF 35WV
C22 CK73HB1H471K CHIP C 470PF K
C24 CC73HCH1H090D CHIP C 9.0PF D
C25 CC73HCH1H100D CHIP C 10PF D
C27 CK73HB1H471K CHIP C 470PF K
C29,30 CK73HB1H471K CHIP C 470PF K
C31 C92-0712-05 CHIP-TAN 22UF 6.3WV
C32,33 CK73HB1H471K CHIP C 470PF K
C35 CC73HCH1H120J CHIP C 12PF J
C36 CC73HCH1H070B CHIP C 7.0PF B
C38 CC73HCH1H0R5B CHIP C 0.5PF B
C41 CC73HCH1H100D CHIP C 10PF D
C42 CK73HB1H471K CHIP C 470PF K
C44 CC73HCH1H120J CHIP C 12PF J
C45 CC73HCH1H0R5B CHIP C 0.5PF B
C46 CK73HB1H471K CHIP C 470PF K
C47 CC73HCH1H080D CHIP C 8.0PF D
C48 CK73HB1H471K CHIP C 470PF K
C50,51 CK73HB1H471K CHIP C 470PF K
C52 CK73HB1H182K CHIP C 1800PF K
C53 CC73GCH1H030C CHIP C 3.0PF C
C54,55 CK73HB1H471K CHIP C 470PF K
C56 CC73HCH1H040C CHIP C 4.0PF C
C57 CK73HB1H471K CHIP C 470PF K
C59-61 CK73HB1H471K CHIP C 470PF K
C63 CK73HB1A104K CHIP C 0.10UF K
C64,65 CC73HCH1H150J CHIP C 15PF J
C67 CK73HB1H102K CHIP C 1000PF K
C69,70 CK73HB1H102K CHIP C 1000PF K
C71 CK73HB1H471K CHIP C 470PF K
C73 CK73HB1H471K CHIP C 470PF K
C76 CK73HB1H471K CHIP C 470PF K
C77 CK73HB1C103K CHIP C 0.010UF K
C78 CK73HB1A104K CHIP C 0.10UF K
C79 CK73FB1A105K CHIP C 1.0UF K
C80 CK73HB1H471K CHIP C 470PF K
C87 CC73GCH1H220J CHIP C 22PF J
C89 CK73GB1H471K CHIP C 470PF K
C91 CK73GB1H471K CHIP C 470PF K
C92 CC73GCH1H080D CHIP C 8.0PF D
C93 CC73GCH1H471J CHIP C 470PF J
C94 CC73HCH1H010C CHIP C 1.0PF C
TK-3130/3131
TX-RX UNIT (X57-6460-XX) -10 : TK-3130/3131 K -31 : TK-3131 A

TK-3130/3131
PARTS LIST
12
30K : TK-3130K
31K : TK-3131K
A : TK-3131A
Ref. No. Address Parts No. Description Ref. No. Address Parts No. Description
New Desti-
parts nation
New Desti-
parts nation
C95 CC73GCH1H070B CHIP C 7.0PF B
C97 CC73GCH1H150J CHIP C 15PF J
C99 CC73GCH1H120J CHIP C 12PF J
C100 CC73GCH1H020B CHIP C 2.0PF B
C101 CC73GCH1H060B CHIP C 6.0PF B
C103 CK73HB1H102K CHIP C 1000PF K
C106 CK73HB1H471K CHIP C 470PF K
C118 CK73HB1H471K CHIP C 470PF K
C119 CC73HCH1H070D CHIP C 7.0PF D
C120 CK73HB1H471K CHIP C 470PF K
C122,123 CK73HB1H471K CHIP C 470PF K
C128,129 CK73HB1H471K CHIP C 470PF K
C130 CK73HB1C103K CHIP C 0.010UF K
C132 CK73HB1H471K CHIP C 470PF K
C133 CK73HB1C103K CHIP C 0.010UF K
C134 CK73HB1H102K CHIP C 1000PF K
C135 CK73HB1C103K CHIP C 0.010UF K
C136 CC73HCH1H030C CHIP C 3.0PF C
C137 CC73HCH1H120J CHIP C 12PF J
C138 CC73HCH1H030C CHIP C 3.0PF C
C140 CC73HCH1H040C CHIP C 4.0PF C
C143 CK73HB1H102K CHIP C 1000PF K
C144 CK73HB1C103K CHIP C 0.010UF K
C145 CK73HB1H102K CHIP C 1000PF K
C146 CK73HB1C103K CHIP C 0.010UF K
C147 CK73HB1H182K CHIP C 1800PF K
C148 CC73HCH1H270J CHIP C 27PF J
C150 CK73HB1A104K CHIP C 0.10UF K
C151 CK73HB1H182K CHIP C 1800PF K
C153-155 CK73HB1H471K CHIP C 470PF K
C156 CK73HB1H182K CHIP C 1800PF K
C157 CK73HB1H102K CHIP C 1000PF K
C158 CK73HB1A333K CHIP C 0.033UF K
C159 CK73HB1H102K CHIP C 1000PF K
C160 CK73HB1A473K CHIP C 0.047UF K
C161 CK73FB1E224K CHIP C 0.22UF K
C162 CK73HB1H102K CHIP C 1000PF K
C163 C92-0695-05 CHIP-TAN 10UF 10WV
C164 CK73HB1H102K CHIP C 1000PF K
C165 CK73HB1H471K CHIP C 470PF K
C166 CC73HCH1H470J CHIP C 47PF J
C169 CK73HB1H331K CHIP C 330PF K
C170 CK73GB1H183K CHIP C 0.018UF K
C171 CC73HCH1H150J CHIP C 15PF J
C172 CK73HB1C103K CHIP C 0.010UF K
C173 CC73HCH1H680J CHIP C 68PF J
C174 CC73HCH1H330J CHIP C 33PF J
C175 CC73HCH1H121J CHIP C 120PF J
C176 CC73HCH1H330J CHIP C 33PF J
C177 CC73HCH1H680J CHIP C 68PF J
C178 CK73HB1H102K CHIP C 1000PF K
C179 CK73FB1A105K CHIP C 1.0UF K
C180 CK73HB1H102K CHIP C 1000PF K
C181 C92-0695-05 CHIP-TAN 10UF 10WV
C182 CK73HB1H102K CHIP C 1000PF K
C183 C92-0695-05 CHIP-TAN 10UF 10WV
C185 CC73HCH1H100B CHIP C 10PF B
C186 CK73HB1H471K CHIP C 470PF K
C187 CC73HCH1H220J CHIP C 22PF J
C189 CK73GB1H471K CHIP C 470PF K
C190 CK73HB1H471K CHIP C 470PF K
C191 CK73HB1C103K CHIP C 0.010UF K
C192 CC73HCH1H180J CHIP C 18PF J
C193 CK73HB1H471K CHIP C 470PF K
C196 CK73HB1H471K CHIP C 470PF K
C200 CK73HB1H102K CHIP C 1000PF K
C201 CK73HB1A104K CHIP C 0.10UF K
C202 C92-0695-05 CHIP-TAN 10UF 10WV
C203 CK73HB1H102K CHIP C 1000PF K
C205 CK73HB1H102K CHIP C 1000PF K
C206,207 CK73FB1A105K CHIP C 1.0UF K
C208,209 CC73HCH1H100D CHIP C 10PF D
C210 CK73FB1C105K CHIP C 1.0UF K
C211 CK73HB1H102K CHIP C 1000PF K
C212 CK73HB1C103K CHIP C 0.010UF K
C213 CK73FB1E104K CHIP C 0.10UF K
C214 CK73HB1C103K CHIP C 0.010UF K
C215 CK73HB1A473K CHIP C 0.047UF K
C219 C92-0695-05 CHIP-TAN 10UF 10WV
C220 CK73HB1A473K CHIP C 0.047UF K
C222 C92-0587-05 CHIP-TAN 2.2UF 4WV
C223 CK73HB1A104K CHIP C 0.10UF K
C224 C92-0519-05 CHIP-TAN 1.0UF 25WV
C225 CK73HB1E472K CHIP C 4700PF K
C227 C92-0519-05 CHIP-TAN 1.0UF 25WV
C228 CK73HB1A104K CHIP C 0.10UF K
C229 C92-0695-05 CHIP-TAN 10UF 10WV
C231 CK73HB1A104K CHIP C 0.10UF K
C232 CK73HB1A473K CHIP C 0.047UF K
C233 CK73HB1C223K CHIP C 0.022UF K
C234 C92-0519-05 CHIP-TAN 1.0UF 25WV
C235 CK73HB1H222K CHIP C 2200PF K
C236 CK73HB1C223K CHIP C 0.022UF K
C237 CK73HB1H561K CHIP C 560PF K
C238 CK73HB1A104K CHIP C 0.10UF K
C240 CK73HB1A104K CHIP C 0.10UF K
C241 CK73HB1H392K CHIP C 3900PF K
C242 CK73HB1A104K CHIP C 0.10UF K
C243 CK73HB1H102K CHIP C 1000PF K
C244 CK73HB1H392K CHIP C 3900PF K
C245 CK73HB1H332K CHIP C 3300PF K
C246 C92-0519-05 CHIP-TAN 1.0UF 25WV
C247 CK73HB1H222K CHIP C 2200PF K
C248 CK73HB1C103K CHIP C 0.010UF K
C249 CK73HB1C223K CHIP C 0.022UF K
C250 CK73HB1A104K CHIP C 0.10UF K
C253 CK73GB1C104K CHIP C 0.10UF K
C254,255 C92-0695-05 CHIP-TAN 10UF 10WV
C256 CK73HB1H102K CHIP C 1000PF K
C257 CK73HB1A104K CHIP C 0.10UF K
C258 CK73HB1H102K CHIP C 1000PF K
C259 C92-0695-05 CHIP-TAN 10UF 10WV
C260 CK73GB1C104K CHIP C 0.10UF K
C262 C92-0665-05 TANTAL 100UF 6.3WV
C263 CK73HB1H102K CHIP C 1000PF K
C264 C92-0695-05 CHIP-TAN 10UF 10WV
C265 CK73HB1H102K CHIP C 1000PF K
C266 CK73HB1A104K CHIP C 0.10UF K
C268 CK73HB1A104K CHIP C 0.10UF K
C269 C92-0695-05 CHIP-TAN 10UF 10WV
TX-RX UNIT (X57-6460-XX)

TK-3130/3131 PARTS LIST
13
30K :TK-3130K
31K : TK-3131K
A : TK-3131A
Ref. No. Address Parts No. Description Ref. No. Address Parts No. Description
New Desti-
parts nation
New Desti-
parts nation
TX-RX UNIT (X57-6460-XX)
C270 CK73HB1C123K CHIP C 0.012UF K
C271 CK73FB1A105K CHIP C 1.0UF K
C272,273 CK73HB1H102K CHIP C 1000PF K
C274 CK73HB1A104K CHIP C 0.10UF K
C275 CC73HCH1H470J CHIP C 47PF J
C278 CK73FB1A105K CHIP C 1.0UF K
C279 CK73HB1A104K CHIP C 0.10UF K
C280 CK73HB1A473K CHIP C 0.047UF K
C282 CK73HB1C103K CHIP C 0.010UF K
C285 CK73HB1H471K CHIP C 470PF K
C287,288 CK73FB1C105K CHIP C 1.0UF K
C289 CC73HCH1H030C CHIP C 3.0PF C
C290,291 CK73HB1H102K CHIP C 1000PF K
C292,293 CC73HCH1H101J CHIP C 100PF J
TC1 C05-0383-05 CERAMIC TRIMMER CAP (6P)
CN1 ✽E40-6213-05 PIN ASSY
CN202 ✽E40-6214-05 PIN ASSY SOCKET
J200 2B E11-0457-05 PHONE JACK (2.5D/3.5D)
F200 F53-0217-05 FUSE (3A)
CF1 L72-0958-05 CERAMIC FILTER (450KHZ)
L1 ✽L40-1001-86 SMALL FIXED INDUCTOR (10U)
L2 L92-0140-05 FERRITE CHIP
L8 L40-1085-54 SMALL FIXED INDUCTOR (100NH)
L9,10 ✽L40-1001-86 SMALL FIXED INDUCTOR (10U)
L11 L92-0140-05 FERRITE CHIP
L12 L40-1875-92 SMALL FIXED INDUCTOR (18NH)
L14-16 L40-2275-92 SMALL FIXED INDUCTOR (22NH)
L19 L40-1075-92 SMALL FIXED INDUCTOR (10NH)
L20 L92-0149-05 FERRITE CHIP
L22 L92-0149-05 FERRITE CHIP
L23 L34-4568-05 AIR-CORE COIL
L25-27 L34-4563-05 AIR-CORE COIL
L28 L34-4572-05 AIR-CORE COIL
L30 L40-4775-92 SMALL FIXED INDUCTOR (47NH)
L32 L40-2775-92 SMALL FIXED INDUCTOR (27NH)
L34 L40-3385-85 SMALL FIXED INDUCTOR (0.33U)
L35 L40-4785-85 SMALL FIXED INDUCTOR (0.47U)
L36 L34-4554-05 COIL
L38 L40-5681-86 SMALL FIXED INDUCTOR (0.56U)
L39 L40-4781-86 SMALL FIXED INDUCTOR (0.47U)
L40,41 L40-2285-92 SMALL FIXED INDUCTOR (220NH)
L42 ✽L79-1807-05 FILTER (465.0MHZ)
L43 L40-2275-54 SMALL FIXED INDUCTOR (22NH)
L44 ✽L40-1001-86 SMALL FIXED INDUCTOR (10U)
L45 ✽L40-3967-98 SMALL FIXED INDUCTOR (3.9NH)
L48 L40-1091-37 SMALL FIXED INDUCTOR (1.000UH)
L49 L40-4775-92 SMALL FIXED INDUCTOR (47NH)
L50 L40-5663-92 SMALL FIXED INDUCTOR (5.6NH)
L51 L40-1875-92 SMALL FIXED INDUCTOR (18NH)
L55 L40-6865-92 SMALL FIXED INDUCTOR (6.8NH)
L56 L40-1085-92 SMALL FIXED INDUCTOR (100NH)
L57 L92-0149-05 FERRITE CHIP
L58 ✽L79-1807-05 FILTER (465.0MHZ)
L59 L40-2285-54 SMALL FIXED INDUCTOR (220NH)
L201 L92-0140-05 FERRITE CHIP
L202,203 L92-0138-05 FERRITE CHIP
X1 L77-1792-05 TCXO (12.8MHZ)
X201 L77-1633-05 CRYSTAL RESONATOR (7.3728M)
XF1 L71-0586-05 MCF (38.85MHZ)
R1 RK73HB1J472J CHIP R 4.7K J 1/16W
R2 RK73HB1J273J CHIP R 27K J 1/16W
R3 RK73HB1J100J CHIP R 10 J 1/16W
R4 RK73HB1J563J CHIP R 56K J 1/16W
R5,6 R92-1368-05 CHIP R 0 OHM
R7 RK73HB1J101J CHIP R 100 J 1/16W
R8 RK73HB1J472J CHIP R 4.7K J 1/16W
R9 RK73HB1J101J CHIP R 100 J 1/16W
R10,11 RK73HB1J103J CHIP R 10K J 1/16W
R12 RK73HB1J470J CHIP R 47 J 1/16W
R13 RK73HB1J563J CHIP R 56K J 1/16W
R14 RK73HB1J102J CHIP R 1.0K J 1/16W
R15 RK73HB1J472J CHIP R 4.7K J 1/16W
R16 RK73HB1J100J CHIP R 10 J 1/16W
R17 RK73HB1J473J CHIP R 47K J 1/16W
R18 RK73HB1J104J CHIP R 100K J 1/16W
R20 RK73HB1J103J CHIP R 10K J 1/16W
R21 RK73HB1J473J CHIP R 47K J 1/16W
R22 RK73HB1J562J CHIP R 5.6K J 1/16W
R23 RK73HB1J682J CHIP R 6.8K J 1/16W
R24 RK73GB1J221J CHIP R 220 J 1/16W
R25 RK73HB1J683J CHIP R 68K J 1/16W
R26 RK73HB1J101J CHIP R 100 J 1/16W
R27 RK73HB1J183J CHIP R 18K J 1/16W
R28 RK73HB1J153J CHIP R 15K J 1/16W
R29 R92-1368-05 CHIP R 0 OHM
R30 RK73HB1J821J CHIP R 820 J 1/16W
R31 RK73HB1J221J CHIP R 220 J 1/16W
R32 RK73HB1J332J CHIP R 3.3K J 1/16W
R33 RK73HB1J103J CHIP R 10K J 1/16W
R34 RK73HB1J332J CHIP R 3.3K J 1/16W
R35 RK73HB1J470J CHIP R 47 J 1/16W
R36 RK73HB1J102J CHIP R 1.0K J 1/16W
R39 RK73HB1J392J CHIP R 3.9K J 1/16W
R40 RK73HB1J470J CHIP R 47 J 1/16W
R42 RK73HB1J821J CHIP R 820 J 1/16W
R45 RK73HB1J5R6J CHIP R 5.6 J 1/16W
R51 RK73HB1J104J CHIP R 100K J 1/16W
R56,57 RK73HB1J221J CHIP R 220 J 1/16W
R58 RK73HB1J391J CHIP R 390 J 1/16W
R59 RK73HB1J100J CHIP R 10 J 1/16W
R60 RK73HB1J101J CHIP R 100 J 1/16W
R61 RK73HB1J222J CHIP R 2.2K J 1/16W
R62 RK73HB1J123J CHIP R 12K J 1/16W
R63 RK73HB1J102J CHIP R 1.0K J 1/16W
R64 RK73HB1J123J CHIP R 12K J 1/16W
R82,83 RK73HB1J564J CHIP R 560K J 1/16W
R84 R92-1368-05 CHIP R 0 OHM
R86 RK73HB1J184J CHIP R 180K J 1/16W
R87 RK73HB1J104J CHIP R 100K J 1/16W
R89 RK73HB1J101J CHIP R 100 J 1/16W
R91 R92-1368-05 CHIP R 0 OHM
R92 RK73HB1J100J CHIP R 10 J 1/16W
R94 RK73HB1J472J CHIP R 4.7K J 1/16W
R95 RK73HB1J102J CHIP R 1.0K J 1/16W
R96 RK73HB1J181J CHIP R 180 J 1/16W
R98 RK73HB1J470J CHIP R 47 J 1/16W
R99,100 RK73HB1J561J CHIP R 560 J 1/16W
R103 RK73HB1J334J CHIP R 330K J 1/16W
R104 RK73HB1J101J CHIP R 100 J 1/16W

TK-3130/3131
PARTS LIST
14
30K : TK-3130K
31K : TK-3131K
A : TK-3131A
Ref. No. Address Parts No. Description Ref. No. Address Parts No. Description
New Desti-
parts nation
New Desti-
parts nation
R105 RK73HB1J153J CHIP R 15K J 1/16W
R107 RK73HB1J332J CHIP R 3.3K J 1/16W
R108 RK73HB1J472J CHIP R 4.7K J 1/16W
R109 RK73HB1J681J CHIP R 680 J 1/16W
R110 RK73HB1J122J CHIP R 1.2K J 1/16W
R111 RK73HB1J334J CHIP R 330K J 1/16W
R113 RK73HB1J274J CHIP R 270K J 1/16W
R114 RK73HB1J472J CHIP R 4.7K J 1/16W
R115 RK73HB1J151J CHIP R 150 J 1/16W
R117 RK73HB1J100J CHIP R 10 J 1/16W
R118 RK73HB1J222J CHIP R 2.2K J 1/16W
R119 RK73HB1J334J CHIP R 330K J 1/16W
R120 RK73HB1J101J CHIP R 100 J 1/16W
R126 RK73HB1J470J CHIP R 47 J 1/16W
R129 RK73HB1J393J CHIP R 39K J 1/16W
R135 RK73HB1J104J CHIP R 100K J 1/16W
R138-140 RK73HB1J101J CHIP R 100 J 1/16W
R141 RK73HB1J154J CHIP R 150K J 1/16W
R142 R92-1368-05 CHIP R 0 OHM
R143 RK73GB1J220J CHIP R 22 J 1/16W
R144 RK73GB1J221J CHIP R 220 J 1/16W
R146 RK73HB1J473J CHIP R 47K J 1/16W
R147 R92-1368-05 CHIP R 0 OHM
R148 RK73GB1J683J CHIP R 68K J 1/16W
R149 RK73GB1J473J CHIP R 47K J 1/16W
R200-202 RK73GB1J181J CHIP R 180 J 1/16W
R203,204 RK73HB1J473J CHIP R 47K J 1/16W
R206-208 RK73HB1J102J CHIP R 1.0K J 1/16W
R211 RK73HB1J473J CHIP R 47K J 1/16W
R212 RK73HB1J104J CHIP R 100K J 1/16W
R213 RK73HB1J473J CHIP R 47K J 1/16W
R214,215 RK73HB1J104J CHIP R 100K J 1/16W
R216 RK73HB1J473J CHIP R 47K J 1/16W
R217,218 RK73HB1J104J CHIP R 100K J 1/16W
R219 RK73HB1J154J CHIP R 150K J 1/16W
R220 RK73HB1J474J CHIP R 470K J 1/16W
R221,222 RK73HB1J102J CHIP R 1.0K J 1/16W
R229 RK73HB1J153J CHIP R 15K J 1/16W
R230 RK73HB1J124J CHIP R 120K J 1/16W
R231 RK73HH1J105D CHIP R 1.0M D 1/16W
R232,233 RK73HB1J103J CHIP R 10K J 1/16W
R234 RK73HB1J124J CHIP R 120K J 1/16W
R235 RK73HB1J104J CHIP R 100K J 1/16W
R237 RK73HB1J223J CHIP R 22K J 1/16W
R238 RK73HB1J562J CHIP R 5.6K J 1/16W
R239 RK73HB1J103J CHIP R 10K J 1/16W
R240 RK73HB1J473J CHIP R 47K J 1/16W
R241 RK73HB1J474J CHIP R 470K J 1/16W
R242 R92-1252-05 CHIP R 0 OHM J 1/16W 30K,31K
R243,244 RK73HB1J473J CHIP R 47K J 1/16W
R245 RK73HB1J103J CHIP R 10K J 1/16W
R246 RK73HB1J472J CHIP R 4.7K J 1/16W
R247 RK73HB1J473J CHIP R 47K J 1/16W
R248 RK73HB1J563J CHIP R 56K J 1/16W
R251 RK73HB1J274J CHIP R 270K J 1/16W
R252 RK73HB1J223J CHIP R 22K J 1/16W
R253 RK73HB1J103J CHIP R 10K J 1/16W
R254 RK73HB1J334J CHIP R 330K J 1/16W
R255 RK73HB1J333J CHIP R 33K J 1/16W
R256 RK73HB1J394J CHIP R 390K J 1/16W
TX-RX UNIT (X57-6460-XX)
R257 R92-1368-05 CHIP R 0 OHM
R259 RK73HB1J104J CHIP R 100K J 1/16W
R260,261 R92-1368-05 CHIP R 0 OHM
R262 RK73HB1J153J CHIP R 15K J 1/16W
R263 RK73HB1J392J CHIP R 3.9K J 1/16W
R264,265 RK73HB1J104J CHIP R 100K J 1/16W
R266 RK73HB1J562J CHIP R 5.6K J 1/16W
R267 RK73HB1J563J CHIP R 56K J 1/16W
R268 R92-1368-05 CHIP R 0 OHM
R269 RK73HB1J224J CHIP R 220K J 1/16W
R270 RK73HB1J473J CHIP R 47K J 1/16W
R271 RK73HB1J393J CHIP R 39K J 1/16W
R272 RK73HB1J473J CHIP R 47K J 1/16W
R273 RK73HB1J124J CHIP R 120K J 1/16W
R274 RK73HB1J103J CHIP R 10K J 1/16W
R277 RK73HB1J824J CHIP R 820K J 1/16W
R280 R92-1368-05 CHIP R 0 OHM
R281 RK73HB1J104J CHIP R 100K J 1/16W
R282 RK73HB1J473J CHIP R 47K J 1/16W
R283 RK73HB1J333J CHIP R 33K J 1/16W
R284 RK73HB1J274J CHIP R 270K J 1/16W
R285 R92-1368-05 CHIP R 0 OHM
R287,288 RK73HB1J104J CHIP R 100K J 1/16W
R289 RK73HB1J472J CHIP R 4.7K J 1/16W
R290 RK73GB1J821J CHIP R 820 J 1/16W
R291 RK73HB1J104J CHIP R 100K J 1/16W
R292 RK73HB1J103J CHIP R 10K J 1/16W
R293 RK73HB1J182J CHIP R 1.8K J 1/16W
R294 RK73HB1J471J CHIP R 470 J 1/16W
R295 RK73HB1J331J CHIP R 330 J 1/16W
R296 RK73HB1J103J CHIP R 10K J 1/16W
R298 RK73HB1J101J CHIP R 100 J 1/16W
R299 RK73HB1J151J CHIP R 150 J 1/16W
R300,301 RK73HB1J102J CHIP R 1.0K J 1/16W
R308 RK73HB1J101J CHIP R 100 J 1/16W
R309 RK73HB1J331J CHIP R 330 J 1/16W
R311,312 RK73GB1J680J CHIP R 68 J 1/16W
R316 RK73HB1J564J CHIP R 560K J 1/16W
R317 R92-1368-05 CHIP R 0 OHM
R322 RK73HB1J102J CHIP R 1.0K J 1/16W
R324-329 RK73HB1J102J CHIP R 1.0K J 1/16W
R330 RK73HB1J104J CHIP R 100K J 1/16W
R334 RK73HB1J562J CHIP R 5.6K J 1/16W
R336 RK73HB1J102J CHIP R 1.0K J 1/16W
R337 RK73HB1J124J CHIP R 120K J 1/16W
R338,339 RK73HB1J101J CHIP R 100 J 1/16W
R340 RK73GB1J152J CHIP R 1.5K J 1/16W
VR1 R12-7491-05 TRIMMING POT. (68K)
VR2 R12-7488-05 TRIMMING POT. (22K)
VR200 R12-7494-05 TRIMMING POT. (220K)
VR201 R12-7490-05 TRIMMING POT. (47K)
VR202 2B ✽R31-0640-05 VARIABLE RESISTOR
S200 S70-0434-05 TACT SWITCH
MIC200 1A ✽T91-0631-05 MIC ELEMENT
D1 MA2S111 DIODE
D3 MA2S111 DIODE
D4 MA360 VARIABLE CAPACITANCE DIODE
D8 MA360 VARIABLE CAPACITANCE DIODE

TK-3130/3131 PARTS LIST
15
30K :TK-3130K
31K : TK-3131K
A : TK-3131A
D9,10 HSC277 DIODE
D12 HVC131 DIODE
D13 HSC277 DIODE
D16 MA742 DIODE
D17 HSC277 DIODE
D202 MA742 DIODE
D204 DAN222 DIODE
D205 1SS372 DIODE
D208 ✽KDZ3.3V ZENER DIODE
D209 1SR154-400 DIODE
D210 KDZ4.7EV ZENER DIODE
IC1 TB31202FN IC (PHASE LOCKED LOOP SYSTEM)
IC2 TA31136FN IC (IF SYSTEM)
IC200 ✽XC61CN2902N IC (VOLTAGE DETECT)
IC201 ✽XC61CN2702N IC (RESET SWITCH)
IC203 24LC08BT-ISN IC (EEPROM)
IC204 ✽MN101C54AKA IC (CPU)
IC205 ✽AK2368 IC (BASE BAND)
IC206 NJM2100V IC (ACTIVE FILTER)
IC207 NJM2100V IC (MIC AMPLIFIER/LIMITER)
IC208 ✽LM4865M IC (AUDIO POWER AMP)
IC209 ✽TK71530ASCL IC (VOLTAGE REGULATOR)
IC213 ✽TK71530ASCL IC (VOLTAGE REGULATOR)
IC214 TC7W74FU IC (DIVIDER)
Q1 2SC5108(Y) TRANSISTOR
Q2 DTC114EE DIGITAL TRANSISTOR
Q3 2SC4617(S) TRANSISTOR
Q4 2SC5066(O) TRANSISTOR
Q5-7 2SC5108(Y) TRANSISTOR
Q8 2SC4226(R24) TRANSISTOR
Q9 ✽2SK3078 FET
Q10 ✽NE5510279A FET
Q11 DTC114TE DIGITAL TRANSISTOR
Q13 2SK1824 FET
Q14 DTC114TE DIGITAL TRANSISTOR
Q18 3SK274 FET
Q19 3SK320 FET
Q20 KTC4082 TRANSISTOR
Q21 2SC4738(GR) TRANSISTOR
Q22 KTC4082 TRANSISTOR
Q200-202 DTC114EE DIGITAL TRANSISTOR
Q210 2SC4919 TRANSISTOR
Q212 DTC144EE DIGITAL TRANSISTOR
Q213 2SK1824 FET
Q214 KTA1298(Y) TRANSISTOR
Q216 ✽3LN02C FET
Q217 2SK1824 FET
Q218-220 DTA123JE DIGITAL TRANSISTOR
Q221 2SK1824 FET
TH1 157-503-65001 THERMISTOR
TX-RX UNIT (X57-6460-XX)
Ref. No. Address Parts No. Description Ref. No. Address Parts No. Description
New Desti-
parts nation
New Desti-
parts nation

16
TK-3130/3131
EXPLODED VIEW
Parts with the exploded numbers larger than 700 are not supplied.
AB
1
2
3
Fold the tab on the conductive
sheet (G11-4193-04) as shown
below.
2
27
7
6
13
35
14
31
29
17
20
MIC200
B
700 Frame
701 S/No. label
36
E
37
32 19
33
18
A
21 5
Dx2
Cx2
Cx2
16
1
12
8
FVR202
J200
TX-RX UNIT (A/2)
TX-RX UNIT (B/2)
A : N14-0583-04
B M2 x 3 : N39-2030-46
C M2 x 6 BLK : N80-2006-45
D M2 x 12 BLK : N80-2012-45
E M2 x 5 : N82-2005-46
F M2 x 8 BLK : N82-2008-45

17
TK-3130/3131PACKING (TK-3130/3131 K)
CD
1
2
3
40 Charger
(W08-0938-15)
39 AC adapter
(W08-0937-05)
702 KNB-27N
(Ni-MH battery pack)
28 Hook assy
(J29-0691-04)
24 Protection bag
(H25-2345-04)
22 Packing fixture
(H12-3110-05)
23 Packing fixture
(H12-3111-03)
25 Item carton case
(H52-1817-02) : TK-3130
(H52-1897-02) : TK-3131
9 Warranty card
(B46-0773-10) : TK-3130
(B46-0774-00) : TK-3131
10 Instruction manual
(B62-1486-00) : TK-3130
(B62-1590-00) : TK-3131

18
TK-3130/3131
PACKING (TK-3131 A)
EF
1
2
3
11 Instruction manual
(B62-1591-00)
24 Protection bag
(H25-2345-04)
28 Hook assy
(J29-0691-04)
22 Packing fixture
(H12-3110-05)
26 Item carton case
(H52-1898-02)

19
TK-3130/3131
Required Test Equipment
1. Stabilized Power Supply
1) The supply voltage can be changed between 0V and 10V,
and the current is 3A or more
2) The standard voltage is 3.8V
2. DC Ammeter
1) Class 1 ammeter (17 ranges and other features).
2) The full scale can be set to either 300mA or 3A.
3) A cable of less internal loss must be used.
3. Frequency Counter (f. counter)
1) Frequencies of up to 1GHz or so can be measured.
2) The sensitivity can be changed to 500MHz or below, and
measurements are highly stable and accurate (0.2ppm or
so).
4. Power Meter
1) Measurable frequency : Up to 600MHz
2) Impedance : 50Ω, unbalanced
3) Measuring range : Full scale of 3W or so
4) A standard cable (5D2W 1m) must be used.
5. RF Voltmeter (RF V.M)
1) Measurable frequency : Up to 600MHz or so
6. Linear Detector
1) Measurable frequency : Up to 600MHz or so
2) Characteristics are flat, and CN is 60dB or more
7. Digital Voltmeter
1) Voltage range : FS=10V or so
2) Input resistance : 1MΩor more
8. Oscilloscope
1) Measuring range : DC to 30MHz
2) Provides highly accurate measurements for 5 to 25MHz.
9. AF Voltmeter (AF V.M)
1) Measurable frequency : 50Hz to 1MHz
2) Maximum sensitivity : 1mV or more
10. Standard Signal Generator (SSG)
1) Maximum frequency : 600MHz or more
2) Output : –133dBm/0.05µV to 7dBm/501mV
3) Output impedance : 50Ω
11. Dummy Load
1) 8Ω, 1W or more
12. AF Generator (AG)
1) Frequency range : 100Hz to 100kHz
2) Output : 0.5mV to 1V
13. Distortion Meter
1) Measurable frequency : 30Hz to 100kHz
2) Input level : 50mV to 10Vrms
ADJUSTMENT
Switches
qPTT (Push to Talk) switch
wMENU key
eCAL key
r/keys
tPower switch/Volume control
yMON key
uLED indicator
iSP/MIC jacks
1
2
3
4
5
6
8
Antenna
Microphone
Speaker
7

20
TK-3130/3131
ADJUSTMENT
Adjustment Points
Jigs
Use jigs for repair or adjustment.
■Extension cable (E30-3480-08)
Connecting Jigs
Connect the extension cable as shown in the illustration
below.
Solder the ANT cable to the ANT terminal on the TX-RX
unit (B/2).
VR1 : Transmit frequency
VR2 : Power (1 W)
TC1 : VCO lock voltage (TX 2.5V or less)
L36 : AF level (Adjust to the MAX)
LV : VCO lock voltage terminal
S200
PTT SW
VR202
POWER/VOL
J200
EXT. SP/MIC
VR200
VR201
TX-RX UNIT (X57-6460-XX) (A/2)
Component side
VR1
TC1 LV
VR2 L36
–
ANT
TX-RX UNIT
(X57-6460-XX) (B/2)
Component side +
VR200 : DQT/QT balance
VR201 : MAX deviation
+,–: External power supply terminal (Fasten it with an alligator clip.)
Cut
CN202
CN1
TX-RX unit
(A/2)
TX-RX unit
(B/2)
Extension cable
(E30-3480-08)
TX-RX unit (A/2) TX-RX unit (B/2)
ANT
terminal
ANT cable
Do not solder on this part.
GND
■ANT cable (E30-3418-05)
Modify the cable as shown below.
