Kenwood TK-3160 User manual

UHF FM TRANSCEIVER
TK-3160
©2004-1 PRINTED IN JAPAN
B51-8674-00 (S) 559
SERVICEMANUAL
GENERAL .............................................................2
SYSTEM SET-UP .................................................2
REALIGNMENT....................................................3
DISASSEMBLY FOR REPAIR ..............................4
CIRCUIT DESCRIPTION .......................................6
INSTALLATION..................................................10
TERMINAL FUNCTION......................................11
SEMICONDUCTOR DATA .................................12
COMPONENTS DESCRIPTION .........................13
PARTS LIST........................................................14
EXPLODED VIEW...............................................21
PACKING ............................................................22
ADJUSTMENT ...................................................23
PC BOARD
TX-RX UNIT (X57-673X-XX) ........................28
SCHEMATIC DIAGRAM.....................................32
BLOCK DIAGRAM..............................................36
LEVEL DIAGRAM...............................................38
KSC-30................................................................39
SPECIFICATIONS............................BACK COVER
CONTENTS
Does not come with antenna.
Antenna is available as an option.
E ·X2 versions
Knob (CH-SELECTOR)
(K29-9280-13)
Knob (VOLUME)
(K29-9278-13)
Cabinet assy
(A02-3826-43)
Knob (PTT)
(K29-9332-03)
Antenna
(KRA-23: Option)

TK-3160
2
Merchandise received
Choose the type of transceiver
Transceiver programming A personal computer (IBM PC or compatible), programming
interface (KPG-22), and programming software (KPG-82D)
are required for programming.
(The frequency, TX power HI/LOW, and signalling data are programmed
for the transceiver.)
TX/RX 440~470 4.0W TK-3160 (E)
TX/RX 470~512 4.0W TK-3160 (X2)
Frequency range (MHz) RF power Type
Delivery
Are you using the speaker microphone? YES
NO
KMC-17 or KMC-21
Speaker microphone
(Option)
Are you using the optional antenna? YES
NO
KRA-23 or KRA-27
Optional antenna
GENERAL / SYSTEM SET-UP
INTRODUCTION
SCOPE OF THIS MANUAL
This manual is intended for use by experienced technicians
familiar with similar types of commercial grade
communications equipment. It contains all required service
information for the equipment and is current as of the
publication date. Changes which may occur after publication
are covered by either Service Bulletins or Manual Revisions.
These are issued as required.
ORDERING REPLACEMENT PARTS
When ordering replacement parts or equipment information,
the full part identification number should be included. This
applies to all parts, components, kits, or chassis. If the part
number is not known, include the chassis or kit number of
which it is a part, and a sufficient description of the required
component for proper identification.
PERSONAL SAFETY
The following precautions are recommended for personal
safety:
●DO NOT transmit until all RF connectors are verified secure
and any open connectors are properly terminated.
●SHUT OFF and DO NOT operate this equipment near
electrical blasting caps or in an explosive atmosphere.
●This equipment should be serviced by a qualified technician only.
SERVICE
This radio is designed for easy servicing. Refer to the
schematic diagrams, printed circuit board views, and alignment
procedures contained within.
SYSTEM SET-UP
Unit
Model TX-RX Unit Frequency range Remarks
& destination
TK-3160 E X57-6732-71 440~470MHz IF1 : 49.95MHz
LOC : 50.4MHz
TK-3160 X2 X57-6730-72 470~512MHz IF1 : 49.95MHz
LOC : 50.4MHz

TK-3160
3
REALIGNMENT
2. How to Enter Each Mode
Mode Operation
User mode Power ON
PC mode ReceivedcommandsfromPC
1. Modes
Mode Function
User mode For normal use.
PC mode Used for communication between the
radio and PC (IBM compatible).
Data programming Used to read and write frequency data
mode and other features to and from the radio.
PC test mode Used to check the radio using the PC.
This feature is included in the KPG-
82D.
User mode
PC mode
PC test mode
Data programming
mode
PC tuning mode
REALIGNMENT
3.PC Mode
3-1. Preface
The TK-3160 transceiver is programmed using a personal
computer, a programming interface (KPG-22) and programming
software (KPG-82D).
The programming software can be used with an IBM PC
or compatible. Figure 1 shows the setup of an IBM PC for
programming.
3-2. Connection procedure
1. Connect the TK-3160 to the personal computer with the
interface cable.
2. When the POWER is switched on, user mode can be
entered immediately. When the PC sends a command,
the radio enters PC mode.
When data is transmitting from the transceiver, the red
LED lights.
When data is received by the transceiver, the green LED
lights.
Notes:
• The data stored in the personal computer must match the
model type when it is written into the EEPROM.
• Change the TK-3160 to PC mode, then attach the interface
cable.
3-3. KPG-22 description
(PC programming interface cable: Option)
The KPG-22 is required to interface the TK-3160 with the
computer. It has a circuit in its D-subconnector (25-pin) case
that converts the RS-232C logic level to the TTL level.
The KPG-22 connects the SP/MIC connector of the TK-3160
to the computer’s RS-232C serial port.
3-4. Programming software description
KPG-82D is the programming software for TK-3160
supplied on a CD-ROM. This software runs under Windows
98, ME, Windows 2000 or XP on an IBM-PC or compatible
machine.
The data can be input to or read from TK-3160 and edited
on the screen. The programmed or edited data can be printed
out. It is also possible to tune the transceiver.
Fig. 1
Tuning cable
(E30-3216-05)
RF Power meter
or SSG
Gray +
Gray/Black –
1.5D-XV Lead wire +
1.5D-XV Shield wire –
}
}SP
MIC
KPG-22
KPG-82D
IBM-PC

TK-3160
4
DISASSEMBLY FOR REPAIR
1. Separating the case assembly from the chassis.
1. Remove the volume knob z.
2. Remove the two screws x.
3. Lift the chassis c, and remove it from the case assembly.
Note: After separating the case assembly from the chassis,
remove the channel knob.
2. Separating the chassis from the TX/RX unit.
1. Remove the two screws v fixing the TX/RX unit B/2.
2. Remove the twelve screws band two screws nfixing
the TX/RX unit A/2.
3. Remove the solder from the antenna terminal using a
soldering iron m, then lift the unit off.
3. How to remove the battery terminal block.
1. Remove the two screws /, then pull out the back cover Ω.
2. Remove the screw ≈.
Note: The two screws nof TX/RX unit A/2 are fixing the
battery terminal block ,.

TK-3160
5
Assembling
• Installation of battery terminal block and
packing
Install them so that no distortion or deformation occurs.
• Installation of speakers and cushion, and wire
styling of speakers
Install the speakers so that they do not protrude from the
cushion. Perform the wire styling of speakers as shown in a
photograph.
• Attaching the cushion
Attach the cushion as shown in Fig. 1.
Note: Cushion must not cover the screws A,Band C.
DISASSEMBLY FOR REPAIR
Install the cushion
according to the
guide.
• Installation of chassis and cabinet assy
Wire Styling
B
A
C
Fig. 1
Take screw Band
MIC edge as reference
line when sticking.
G13-2018-04
Stick between screw
Aand B.
G13-2017-04
G13-2020-04
Do not press this area, top
packing easily deform.
Second, press down the Chassis to the
cabinet assy as shown in the diagram.
Good Condition NG Condition
After mount, packing
should be in this
condition.
Packing deform.
Packing protruded out.
Note:
• Take care that the packing does not protrude from the
chassis or case.
• Replace the protruded or deformed packing with a new one.
First, mount the set to the cabinet assy.

TK-3160
6
Fig. 3 Wide/Narrow switching circuit
CIRCUIT DESCRIPTION
1. Frequency Configuration
The receiver utilizes double conversion. The first IF is 49.95
MHz and the second IF is 450 kHz. The first local oscillator
signal is supplied from the PLL circuit.
The PLL circuit in the transmitter generates the necessary
frequencies. Fig. 1 shows the frequencies.
1) Front End (RF AMP)
The signal coming from the antenna passes through the
transmit/receive switching diode circuit, (D204,D206,D208
and D212) passes through a BPF (L413 and L414), and is
amplified by the RF amplifier (Q404).
The resulting signal passes through a BPF (L409,L408 and
407) and goes to the mixer. These BPFs are adjusted by
variable capacitors (D402,D403,D404,D405 and D406). The
input voltage to the variable capacitor is regulated by
voltage output from the microprocessor (IC805).
2) First Mixer
The signal from the front end is mixed with the first local
oscillator signal generated in the PLL circuit by Q403 to
produce a first IF frequency of 49.95 MHz.
The resulting signal passes through the XF401 MCF to cut
the adjacent spurious and provide the opitimun
characteristics, such as adjacent frequency selectivity.
Fig. 2 Receiver section
2. Receiver
The frequency configuration of the receiver is shown in Fig. 2.
3) IF Amplifier Circuit
The first IF signal is passed through a four-pole monolithic
crystal filter (XF401) to remove the adjacent channel signal.
The filtered first IF signal is amplified by the first IF amplifier
(Q202) and then applied to the lF system IC (IC401). The IF
system IC provides a second mixer, second local oscillator,
limiting amplifier, quadrature detector and RSSI (Received
Signal Strength Indicator). The second mixer mixes the first
IF signal with the 50.4MHz of the second local oscillator
output (TCXO X1) and produces the second IF signal of
450kHz.
The second IF signal is passed through the ceramic filter
(CF401) to remove the adjacent channel signal. The filtered
second IF signal is amplified by the limiting amplifier and
demodulated by the quadrature detector with the ceramic
discriminator (CD401). The demodulated signal is routed to
the audio circuit.
4) Wide/Narrow Switching Circuit
Narrow and Wide settings can be made for each channel
by switching the demodulation level.
The WIDE (low level) and NARROW (high level) data is
output from IC805, pin 54.
When a WIDE (low level) data is received, Q401 turn on.
When a NARROW (high level) data is received, Q401 turn
off.
Q401 turns off/on with the Wide/Narrow data and the IC401
detector output level is switched to maintain a constant
output level during wide or narrow signals.
SP
BPF
IC602
AF Amp IC601 IC605
AF PA
IC401
IF,MIX,DET
ANT
AQUA
CF401
TCXO
TUNE
Q4
X3 multiply
TUNE
ANT SW
BPF MCF
1st Local
RF AMP
Q404 MIXER
Q403 XF401 IF AMP
Q402
AF VOL
X1
16.8MHz
2nd Local
Q401
C409
W/N
R408
R409 CD401
IFO
QUAD
IC401
FM IF SYSTEM
5R
AFOUT
Q402
L : Wide
H : Narrow
5) Audio Amplifier Circuit
The demodulated signal from IC401 is amplified by IC602,
and goes to AF amplifier through IC601.
The signal then goes through an AF volume control (VR801),
and is routed to an audio power amplifier (IC605) where it is
amplified and output to the speaker.
Fig. 1 Frequency configuration
SP
TX: 440 ~ 470MHz (E)
470 ~ 512MHz (X2) PLL
VCO
IF SYSTEM
ANT
TCXO
X3 multiply
49.95MHz
MCF AF
AMP
MIC
MIC
AMP
TX
AMP RF
AMP
50.4MHz
CF
450kHz
RX:390.05 ~ 420.05MHz (E)
420.05 ~ 462.05MHz (X2)
TX/RX: 440 ~ 470MHz (E)
470 ~ 512MHz (X2)
16.8MHz
RF
AMP
ANT SW

TK-3160
7
CIRCUIT DESCRIPTION
6) Tone Volume Fixed Circuit
This function generates a TONE signal sound even if the
AF volume of the transceiver is the minimum.
A TONE signal is sent through Q602 to the AF amplifier
when, in the FPU, “TONE Volume Fixed” is set to ON.
7) Squelch
Part of the AF signal from the IC enters the FM IC (IC401)
again, and the noise component is amplified and rectified
by a filter and an amplifier to produce a DC voltage
corresponding to the noise level.
The DC signal from the FM IC goes to the analog port of
the microprocessor (IC805). IC805 determines whether to
output sounds from the speaker by checking whether the
input voltage is higher or lower than the preset value.
To output sounds from the speaker, IC805 sends a high
signal to the SP MUTE line and turns IC605 on through
Q603,Q604,Q607 and Q608. (See Fig. 5)
8) Receive Signalling
(1) QT/DQT
The output signal from IF IC (IC401) enters the
microprocessor (IC805) through IC601. IC805 determines
whether the QT or DQT matches the preset value, and
controls the SP MUTE and the speaker output sounds
according to the squelch results.
(2) 5-TONE
Part of the received AF signal output from the AF amplifier
IC602, and then pass through an audio processor (IC601),
goes to the other AF amplifier IC603, is compared, and then
goes to IC805. IC805 checks whether 2-TONE data is
necessary. If it matches, IC805 carries out a specified
operation, such as turning the speaker on. (See Fig. 5)
(3) MSK (Fleet Sync)
Fleet Sync utilizes 1200bps and 2400bps MSK signal is
output from pin 6 of IC601. And is routed to the VCO.
When encoding MSK, the microphone input signal is muted.
(4) DTMF
The DTMF input signal from the IF IC (IC401) is amplified
by IC602 and goes to IC601, the DTMF decoder. The
decoded information is then processed by the CPU.
3. PLL Frequency Synthesizer
The PLL circuit generates the first local oscillator signal for
reception and the RF signal for transmission.
1) PLL
The frequency step of the PLL circuit is 5 or 6.25kHz.
A 16.8MHz reference an oscillator signal is divided at IC1
by a fixed counter to produce oscillator (VCO) output signal
which is buffer amplified by Q9 then divided in IC1 by a
dual-module programmable counter. The divided signal is
compared in phase with the 5 or 6.25kHz reference signal
from the phase comparator in IC1. The output signal from
the phase comparator is filtered through a low-pass filter
and passed to the VCO to control the oscillator
frequency.(See Fig. 6)
2) VCO
The operating frequency is generated by Q6 in transmit
mode and Q5 in receive mode. The oscillator frequency is
controlled by applying the VCO control voltage, obtained
from the phase comparator, to the varactor diodes (D4 and
D7 in transmit mode and D3 and D9 in receive mode). The
RX pin is set high in receive mode causing Q8 and Q12 to
turn Q6 off and turn Q5 on.
The TX pin is set high in transmit mode. The outputs from
Q5 and Q6 are amplified by Q9 and sent to the RF amplifiers.
Fig. 4 Tone volume fixed circuit
IC805
CPU BEEP
BEEPSW
TONE VOL FIXED
IC601
AQUA VOL
IC605
TA7368F
Q602 Hi: ON
LOW: OFF
+
SP
SP-J
[VOL Position vs Output Level]
Output Level (mV)
Min
ON OFF
25
500
Center Max
Fig. 5 AF amplifier and squelch
RECEIVE SIGNALING
RECEIVE SIGNALING
SP
Q608
SW
IF Amp
FM IF IC401 IC602
IF Amp
IC601
IC605
AF PA
IC805
IC603
BPF & COMPALATER
Q603,604,607
SW
QT/DQT
5-TONE
DTMF
CLK,DATA,
STD,LOADN
SIGNAL
SP MUTE
HSDI
LSDI
AN SQL
CPU
AQUA

TK-3160
8
CIRCUIT DESCRIPTION
Fig. 8 Microphone amplifier
Fig. 9 Drive and final amplifier and APC circuit
4. Transmitter System
1) Microphone Amplifier
The signal from the microphone passes through IC601.
When encoding DTMF, it is turned OFF for muting the
microphone input signal by IC601.
The signal passes through the Audio processor (IC601) for
the maximum deviation adjustment, and goes to the VCXO
modulation input.
2) Drive and Final Amplifier
The signal from the T/R switch (D201 is on) is amplified by
the pre-drive (Q206) and drive amplifier (Q207) to 50mW.
Theoutputofthedrive amplifier is amplified by the RF power
amplifier (Q211) to 4.0W (1W when the power is low). The
RF power amplifier consists of two MOS FET stages. The
output of the RF power amplifier is then passed through
the harmonic filter (LPF) and antenna switch (D204 and
D206) and applied to the antenna terminal.
From
T/R SW
(D201) DRIVE
AMP RF
POWER AMP LPF
ANT
SW
D204
D206
AN
T
VGVG
Q207 Q211
Pre-DRIVE
AMP
Q206
VDD
RF
AMP
Q205
VG
R256
R257
R261
+B
IC201
(1/2) IC201 (2/2)
PCTV
(IC805)
IC601
IC805
LPF
DTMF/5 TONE
LSDTCXO
LSDVCO
CPU
AGC
VCO
MIC
X1
TCXO
LPF
LPF
AQUA
3) APC Circuit
The APC circuit always monitors the current flowing through
the RF power amplifier (Q211) and keeps a constant current.
The voltage drop at R256, R257 and R261 is caused by the
current flowing through the RF power amplifier and this
voltage is applied to the differential amplifier IC201(1/2).
IC201(2/2) compares the output voltage of IC201(1/2) with
the reference voltage from IC805. The output of IC201(2/2)
controls the VG of the RF power amplifier, Drive amplifier
and Pre-Drive amplifier to make both voltages the same.
The change of power high/low is carried out by the change
of the reference voltage.
4) Encode Signalling
(1) QT/DQT
QT,DQT data of the LSDTCXO Line is output from pin 22 of
the CPU. The signal passes through a low-pass CR filter
and goes to the TCXO(X1).
The QT,DQT data of the LSDVCO Line is output from pin
3) Unlock Detector
If a pulse signal appears at the LD pin of IC1, an unlock
condition occurs, and the DC voltage obtained from C19,
R6, and Q1 causes the voltage applied to the microprocessor
to go high. When the microprocessor detects this condition,
the transmitter is disabled, ignoring the push-to-talk switch
input signal.(See Fig. 7)
Fig. 7 Unlock detector circuit
Fig. 6 PLL circuit
PLL DATA
X1
16.8MHz
REF OSC
1/M
1/N
PLL IC IC1
PHASE
COMPARATOR CHARGE
PUMP
LPF
5kHz/6.25kHz
D4,7
D3,9
Q6
TX VCO
Q5
RX VCO
Q9
BUFF AMP Q11
RF AMP
RX
TX
Q7
RF AMP
Q8, 12
T/R SW
5kHz/6.25kHz
LPF
5C
R6
Q1
C19
R7 IC805
IC1
LD
UL
PLL IC
CPU
R16

TK-3160
9
2) Memory Circuit
Memory circuit consists of the CPU (IC805) and an EEPROM
(IC804). An EEPROM has a capacity of 64k bits that contains
the transceiver control program for the CPU and data such
as transceiver channels and operating features.
3) Low Battery Warning
The battery voltage is checked using by the microprocessor.
Thetransceivergeneratesa warning tone when it falls below
the warning voltage shown in the table.
(1)The red LED blinks when the battery voltage falls below
the voltage (1) shown in the table during transmission.
(2)The red LED blinks when the battery voltage falls below
the voltage (2) shown in the table during transmission.
Note:
The transceiver checks the battery voltage during reception
even when, in the FPU, the Battery Warning status function
is set to “On TX” (default setting).
However, the LED does not blink during reception. During
transmission, the LED blinks to generate the warning tone
of a low battery voltage.
(3)The transceiver immediately stops transmission when
the battery voltage falls below the voltage (3) shown in
the table. A message tone beeps while the PTT switch
is released.
CIRCUIT DESCRIPTION
20 of the CPU. The signal passes through a low pass CR
filter, mixes with the audio signal, and goes to the VCO
modulation input. TX deviation is adjusted by the CPU.
(2) DTMF/5 TONE
High-speed data is output from pin 2 of the CPU. The signal
passes through a low-pass CR filter, and provides a TX and
SP out tone, and is then applied to the audio processor
(IC601). The signal is mixed with the audio signal and goes
to the VCO.
TX deviation is adjusted by the CPU.
(3) MSK (Fleet Sync)
The MSK input signal from the IF IC is amplified by IC602
(1/2) and goes to pin 31 of IC 601. The signal is demodulated
by MSK demodulator in IC 601. The demodulated data goes
to the CPU for processing.
5. Power Supply
There are 3.5V power supply for PLL circuit and five 5V
power supplies for the microprocessor: 5M,5MS,5C,5R, and
5T. 5M for microprocessor is always output while the power
is on. 5M is always output, but turns off when the power is
turned off to prevent malfunction of the microprocessor.
5C is a common 5V and is output when SAVE is not set to
OFF.
5R is 5V for reception and output during reception.
5T is 5V for transmission and output during transmission.
6. Control Circuit
The control circuit consists of a microprocessor (IC805) and
its peripheral circuits. It controls the TX-RX unit. IC805 mainly
performs the following:
(1) Switching between transmission and reception by the
PTT signal input.
(2) Reading system, group, frequency, and program data
from the memory circuit.
(3) Sending frequency program data to the PLL.
(4) Controlling squelch on/off by the DC voltage from the
squelch circuit.
(5) Controlling the audio mute circuit by the decode data
input.
(6) Transmitting tone and encode data.
1) Frequency Shift Circuit
The microprocessor (IC805) operates at a clock of
7.3728MHz. This oscillator has a circuit that shifts the
frequency by BEAT SHIFT SW (Q810).
A beat sound may be able to be evaded from generation if
“Beat Shift” is set to ON when it is generated in the internal
spurious transmission modulated sound of a transceiver.
IC805
CPU
IC804
EEPROM
Fig. 11 Memory circuit
X801C834 XOUT
IC805
Q810
Hi: OFF
LOW: ON BSHIFT
Fig. 10 Frequency shift circuit
Battery Case Li-ion Battery Ni-Cd Battery Ni-MH Battery
(1) 6.2[V] 6.5[V] 6.2[V] 6.2[V]
(2) 7.5[V] 7.1[V] 6.8[V] 7.0[V]
(3) 5.9[V] 6.2[V] 5.9[V] 5.9[V]
SB R833
R834
88
IC805
CPU
Fig. 12 Low battery warning

TK-3160
10
4) Battery Type Detection
The transceiver automatically detects teh battery type,
measuring the resistance between the S-terminal and +
terminal on the battery pack and changes the supplied
voltage to the S-tarminal as below. The microprocessor then
detects the battery type.
Channel selector
CPU
IC805
SIDE 2
EN4
EN3
EN2
EN1
67
68
69
70
PTT PTT
SW
SIDE 1
34
74
75
76
AUXSW AUX SW
SW1
SW2
Fig. 13 Control system
7. Control System
Keys and channel selector circuit.
The signal from keys and channel selector input to
microprocessor directly as shown in fig. 13.
CIRCUIT DESCRIPTION / INSTALLATION
Resistor value Battery type Input voltage of S-terminal
1.8MΩLi-ion 0.3~1.3V
560kΩNi-Cd 1.3~2.6V
220kΩNi-MH 2.6~5.0V
OPEN Battery case 0~0.3V
INSTALLATION
1. Optional Board
Remove the TX/RX unit from the radio before installing the
optional board in the radio.
The procedure for removing the TX/RX unit is described in
the DISASSEMBLY FOR REPAIR section in the Service
Manual.
Install the optional board on the back of the TX/RX unit.
For details on installation of the optional board, refer to
Installation Information supplied with the optional board.
When installing the optional board, also refer to the chart in
TERMINAL FUNCTION section (page 11) given in the Service
Manual.
Note: To install and use the Scrambler Board, remove “R601”
and “R647” from the front of the TX/RX unit.
R647 R601
R601
R607
R608
R609
R610
R613
R615
R616
617
R618
R621 R622
R623
R624
R625
R626
R627
R628
R629
R631
R632
R633
R634
R636
R640
R835
R641
R836
R642
C607
R643
C608
R839 C609
R647
C610
R840
C613
C614
C
616
C618
C619
C621
C622
R855
C625
R856
C627 C628
C630
C631
C1
C632
C633
C3
C4
C634
C635
C636
C637
C640
C641
C642
C643
C645
C646
C648
C846
C847
R695
R696
IC601
CP803
4
CP808
CP809
CP810
CP812
CP813
CP814
R1
R2
R3
L804
L806
75
76
++ +
19
10
16
1725
26
32
+VCC
51
50
CE
TX-RX UNIT (X57-673X-XX)
Component side view

TK-3160
11
TERMINAL FUNCTION
■Solder point connection
MIC_I Mic input Input sensitivity/Impedance (1kHz std. dev.) 7±3mVrms @22kΩLoad
MIC_O Mic o utput Output voltage/Impedance (1kHz 15mVrms mic input) 2.6±1.0mVrms @2.2kΩLoad
Output voltage/Impedance (1kHz 100mVrms mic input) 90±20mVrms @100kΩLoad
RA_I Receiver AF input Input sensitivity/Impedance (1kHz rated AF power/Vol. MAX) 75±20mVrms @22kΩLoad
RA_O Receiver AF output Output voltage/Impedance (1kHz std. mod.) 150±50mVrms @2.2kΩLoad
Output voltage/Impedance (1kHz system mod.) 290±50mVrms @100kΩLoad
A1 AUX1 Load >100kΩ(Low) Vss ~ 0.4V (High) Vdd-0.8V ~ Vdd
A2 AUX2 Load >100kΩ(Low) Vss ~ 0.4V (High) Vdd-0.8V ~ Vdd
A3 AUX3 Load >100kΩ(Low) Vss ~ 0.4V (High) Vdd-0.8V ~ Vdd
A4 AUX4 Load >100kΩ(Low) Vss ~ 0.4V (High) Vdd-0.8V ~ Vdd
A5 AUX5 Load >100kΩ(Low) Vss ~ 0.4V (High) Vdd-0.8V ~ Vdd
A6 AUX6 Load >100kΩ(Low) Vss ~ 0.4V (High) Vdd-0.8V ~ Vdd
SB Switched B Output Voltage/7mA load DC (Battery terminal) ±0.5V
GND GND Vss
5C DC 5V Output Voltage/10mA load 5.0±0.5V
TXAFI Transmit AF input Input sensitivity/Impedance (1kHz std. dev.) 280±50mVrms @22kΩLoad
DEO Discriminator signal output Output voltage/Impedance (1kHz std. mod.) 280±50mVrms @2.2kΩLoad
LSDFO Received sub-tone output Output voltage/Impedance (150Hz 15% mod.) 180±50mVrms @2.2kΩLoad
ALT Sidetone input Input sensitivity/Impedance (1kHz rated AF power/Vol. MAX) 7±3mVrms @22kΩLoad
Designation Function Condition Value

TK-3160
12
Microprocessor : M30622MCA8C1GP (TX-RX UNIT : IC805)
■Pin function
1 PCTV O APC/BPF control data output.
2 DTMF O DTMF,5TONE.
3 HSDI I High speed data input.(5TONE)
4 EEPDAT I/O EEPROM data input/output.
5 EEPCLK O EEPROM Clock
6 BYTE I GND.
7 CNVSS I GND.
8 AUX5 O Option Board 5
9 AUX6 O Option Board 6
10 RESET I CPU reset.
11 XOUT O CPU clock.
12 VSS - GND.
13 XIN I CPU clock.
14 VCC - +5V.
15 NC I NC
16 INT I Battery voltage monitor input Low battery : L
17 RDF/FD I Base Band IC Data input
18 TCLK/ I Base Band IC Data input
DTRDI
19 NC - NC
20 LSDVCO O Low speed data output. (VCO)
21 NC I NC
22 LSDTCXO O Low speed data output. (TCXO)
23 NC I NC
24 BEEP O Beep output.
25 OPTDET I Option detect input
26 NC - NC
27 NC - NC
28 NC - NC
29 AUX4 O Option board port 4
30 AUX2 I/O Option board port 2
31 NC - NC
32 NC - NC
33 TXD I/O Serial data.
34 PTT/RXD I PTT on : L/Serial data.
35 STD I Base Band IC Data input
36 BBDIR O Base Band IC Data output
37 BBCLK O Base Band IC clock output
38 BBDI/O I/O Base Band IC Data input/output
39 NC - NC
40 TDATA/ O Base Band IC Data output
DTRCLK
41 DTRLOADN O Base Band IC Data output
42 AUX3 O Option board port 3
43 AUX1 O Option board port 1
44 NC - NC
45 NC - NC
46 DSW O APC voltage discharge Switch
47 BEEPSW O Beep switch.
48 AFCOUT O AF amp power supply control
49 AFMUTE O RX audio mute
50 NC - NC
51 TX O TX VCO power supply switch TX:L
52 RX O RX VCO power supply switch RX:L
Pin Port I/O Function
No. Name Pin Port I/O Function
No. Name
53 BSHIFT O Beet shift switch.
54 W/N O W/N switch Wide:L
55 NC - NC
56 APCSW O APC switch output.
57 SAVE O Battery save output.
58 5TC O 5T control output.
59 5RC O 5R control output.
60 VCC - +5V.
61 5MSC O 5M control output.
62 VSS - GND.
63 NC - NC
64 NC - NC
65 NC - NC
66 NC - NC
67 EN4 I CH selector input 4.
68 EN3 I CH selector input 3.
69 EN2 I CH selector input 2.
70 EN1 I CH selector input 1.
71 NC - NC
72 LEDTX O RED LED lights control output
73 LEDRX O GREEN LED lights control output
74 AUXSW I Key input.(Emergency)
75 SIDE1 I Side key 1 input.
76 SIDE2 I Side key 2 input.
77 NC - NC
78 NC - NC
79 SIM1 I Destination select 1.
80 SIM2 I Destination select 2.
81 NC - NC
82 PLLUL I PLL unlock detect input. unlock : L
83 RFCLK O PLL clock output. Latch : L
84 RFDAT O PLL data output.
85 PS O PLL power save output.
86 PLLSTB O PLL strobe output.
87 BATTSEL I Battery distinction input.
88 BATT I Battery voltage input.
89 VOX I VOX input.
90 RSSQL I Received signal strength indicator input.
91 ANSQL I Squelch level input.
92 LSDI I Low speed data input (QT/DQT).
93 THM I Thermistor input.
94 AVSS - GND.
95 NC - NC
96 VREF - +5V.
97 AVCC - +5V.
98 NC - NC
99 NC - NC
100 NC - NC
SEMICONDUCTOR DATA

TK-3160
13
COMPONENTS DESCRIPTION
IC1 IC PLL system
IC201 IC Comparator (APC)
IC401 IC FM IF system
IC601 IC Audio processor
IC602 IC AF AMP
IC603(1/2) IC HSD AMP
IC603(2/2) IC HSD AMP
IC604 IC VOX AMP
IC605 IC AF power AMP
IC801 IC Voltage regulator / 5V
IC802 IC Voltage detector / Reset
IC803 IC Voltage detector / INT
IC804 IC EEPROM
IC805 IC Microprocessor
IC806 IC Flip Flop
Q1 Transistor Level shift
Q2 Transistor Level shift
Q3 Transistor Level shift
Q4 Transistor Tripler
Q5 FET VCO / RX
Q6 FET VCO / TX
Q7 Transistor PLL IC f_in AMP
Q8 FET DC switch / TX VCO
Q9 Transistor RF Buffer AMP
Q10 Transistor Ripple filter
Q11 Transistor RF AMP
Q12 FET DC switch / RX VCO
Q205 Transistor Pre-drive AMP
Q206 FET Pre-drive AMP
Q207 FET TX Drive AMP
Q208 Transistor APC switch
Q209 FET APC switch
Q210 Transistor APC switch
Q211 FET TX Final AMP
Q212 FET APC switch
Q213 Transistor APC switch
Q401 Transistor W/N switch
Q402 Transistor IF AMP
Q403 FET Mixer
Q404 FET RF AMP
Q407 FET DC switch
Q601 FET AF Mute
Q602 FET Beep switch
Q603 Transistor DC switch / SP Mute
Q604 Transistor DC switch
Q605 Transistor MIC AGC
Q606 Transistor MIC AGC
Q607 Transistor DC switch / SP Mute
Q608 FET SP Mute switch
Q801 Transistor 5T switch
Q802(1/2) FET 5TC switch
Q802(2/2) FET SAVE switch
Q803(1/2) Transistor AVR / 5C
Q803(2/2) Transistor AVR / 5T
Q804 Transistor 5C switch
Q805(1/2) Transistor LED switch / Green
Q805(2/2) Transistor LED switch / Red
Q806 Transistor AVR / PLLB
Q807 Transistor PLLB switch
Q808 Transistor 5MS switch
Q809 Transistor 5R switch
Q810 FET Beet shift switch
D3
Variable
Frequency control / RX VCO
capacitance diode
D4
Variable
Frequency control / TX VCO
capacitance diode
D7
Variable
Frequency control / TX VCO
capacitance diode
D9
Variable
Frequency control / RX VCO
capacitance diode
D10
Variable
Modulation
capacitance diode
D11 Diode Current steering
D201 Diode TX/RX RF switch
D203 Zener diode APC protect
D204 Diode ANT switch
D206 Diode ANT switch
D208 Diode ANT switch
D212 Diode ANT switch
D401 Diode TX/RX RF switch
D402
Variable
RF BPF tuning
capacitance diode
D403
Variable
RF BPF tuning
capacitance diode
D404
Variable
RF BPF tuning
capacitance diode
D405
Variable
RF BPF tuning
capacitance diode
D406
Variable
RF BPF tuning
capacitance diode
D407 Diode Rectifier
D603 Diode Limitter
D604 Diode Detector
D605 Diode Detector
D606 Diode Detector
D801 Diode 5M protect
D802 LED LED / Red
D803 LED LED / Green
D805 Diode Reverse protection
Ref. No. Use/Function Operation/Condition
TX-RX UNIT (X57-673X-XX) Ref. No.
Use/Function Operation/Condition

TK-3160 PARTS LIST
14
∗New Parts. indicates safety critical components.
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
L: Scandinavia K: USA P: Canada
Y: PX (Far East, Hawaii) T: England E: Europe
Y: AAFES (Europe) X: Australia M: Other Areas
Parts No. Description Address New
parts
Destination Destination
TK-3160
Ref. No. Parts No. Description
Address New
parts
TK-3160 (Y50-579X-XX)
TX-RX UNIT (X57-673X-XX)
Ref. No.
F 2D N35-3004-45 BINDING HEAD MACHINE SCREW
G 3A,3B ∗N78-2040-46 PAN HEAD TAPTITE SCREW
H 2A,2B N83-2005-46 PAN HEAD TAPTITE SCREW
45 2A ∗R31-0650-05 VARIABLE RESISTOR
46 2A S60-0420-05 ROTARY SWITCH
47 1B T07-0369-05 SPEAKER
D802 B30-2156-05 LED(RED)
D803 B30-2157-05 LED(YELLOW)
C1 CK73GB1H392K CHIP C 3900PF K
C2 CK73GB1H471K CHIP C 470PF K
C3 CK73GB1H103K CHIP C 0.010UF K
C5 CK73GB1H471K CHIP C 470PF K
C6 CK73GB1H103K CHIP C 0.010UF K
C7 CK73GB1H471K CHIP C 470PF K
C8 CC73GCH1H100D CHIP C 10PF D
C9 CK73GB1H103K CHIP C 0.010UF K
C10 CC73GCH1H100D CHIP C 10PF D
C11-13 CC73GCH1H101J CHIP C 100PF J
C14 C92-0713-05 CHIP-TAN 10UF 6.3WV
C15 CK73GB1H102K CHIP C 1000PF K
C16 CC73GCH1H470J CHIP C 47PF J
C18,19 CK73GB1C104K CHIP C 0.10UF K
C20 CC73GCH1H060B CHIP C 6.0PF B X2
C22 CK73GB1C104K CHIP C 0.10UF K
C24 C92-0713-05 CHIP-TAN 10UF 6.3WV
C25 CK73GB1H471K CHIP C 470PF K
C27 CK73GB1H103K CHIP C 0.010UF K
C28 CC73GCH1H560J CHIP C 56PF J
C29 CK73GB1H471K CHIP C 470PF K
C30 CC73GCH1H220J CHIP C 22PF J
C31 CC73GCH1H560J CHIP C 56PF J
C32 C92-0002-05 CHIP-TAN 0.22UF 35WV
C33 CC73GCH1H470J CHIP C 47PF J
C34 CK73GB1H471K CHIP C 470PF K
C35 CC73GCH1H680J CHIP C 68PF J
C36 C92-0585-05 CHIP-TAN 4.7UF 16WV
C37 CK73GB1H103K CHIP C 0.010UF K
C38,39 C92-0002-05 CHIP-TAN 0.22UF 35WV
C40 CK73GB1H183K CHIP C 0.018UF K
C41,42 CK73GB1A105K CHIP C 1.0UF K
C43,44 CC73HCH1H101J CHIP C 100PF J
C45 CC73HCH1H020B CHIP C 2.0PF B E
C45 CC73HCH1H040B CHIP C 4.0PF B X2
C46 CC73HCH1H220J CHIP C 22PF J E
C46 CC73HCH1H390J CHIP C 39PF J X2
C47 CK73GB1H471K CHIP C 470PF K
C48 CC73HCH1H150J CHIP C 15PF J
C49 CC73HCH1H330J CHIP C 33PF J E
C49 CC73HCH1H470J CHIP C 47PF J X2
C50 CC73HCH1H020C CHIP C 2.0PF C X2
TX-RX UNIT (X57-673X-XX) 0-71:X2 2-71:E
1 1B A02-3826-43 CABINET ASSY
2 2B A10-4068-31 CHASSIS
3 3A A82-0054-02 REAR PANEL
4 3A B01-0694-03 ESCUTCHEON
5 2D B09-0676-13 CAP ACCESSORY
61C∗B62-1788-00 INSTRUCTION MANUAL E
61C∗B62-1798-00 INSTRUCTION MANUAL X2
73B∗B72-2255-04 MODEL NAME PLATE E
73B∗B72-2256-04 MODEL NAME PLATE X2
83A∗E04-0446-05 RF COAXIAL RECEPTACLE(SMA)
10 2A ∗E37-1101-05 SPEAKER WIRE(RED)
11 2A ∗E37-1102-05 SPEAKER WIRE(BLACK)
12 3A ∗E72-0416-23 BATT TERMINAL BLOCK
13 2B ∗G11-4090-04 SHEET(FINAL FET)
14 3B ∗G11-4254-04 SHEET(PTT)
15 3A ∗G11-4287-04 SHEET(BATT TERMINAL BLOCK)
16 3A ∗G11-4289-04 SHEET(CHASSIS)
17 3B ∗G11-4293-04 SHEET
18 2A ∗G11-4294-04 SHEET
19 3B ∗G11-4295-04 SHEET
20 1A ∗G11-4306-04 SHEET
21 2A ∗G11-4312-04 SHEET
22 2B ∗G13-2001-04 CUSHION(CHASSIS)
23 2B ∗G13-2014-04 CUSHION(CHASSIS BOTTOM)
24 2B ∗G13-2017-04 CUSHION
25 2B ∗G13-2018-04 CUSHION
26 3A ∗G13-2019-04 CUSHION
27 2B ∗G13-2020-04 CUSHION
28 3A ∗G13-2026-04 CUSHION
29 ∗G13-2027-04 CUSHION
30 2B ∗G53-1580-03 PACKING(CHASSIS)
31 1B ∗G53-1581-12 PACKING(SPEAKER)
32 3B ∗G53-1582-03 PACKING(BATT TERMINAL BLOCK)
33 3A ∗G53-1641-02 PACKING
34 3C ∗H12-3150-02 PACKING FIXTURE
35 ∗H25-2345-04 PROTECTION BAG
36 1D ∗H52-2000-02 ITEM CARTON CASE
37 ∗H62-1738-03 OUTER PACKING CASE
38 2A ∗J19-5454-03 HOLDER
39 2D ∗J21-8464-04 HARDWARE FIXTURE ACCESSORY
40 2C J29-0701-05 HOOK ACCESSORY
41 3A ∗J30-1275-04 SPACER(CH KNOB)
42 1A ∗K29-9278-13 KNOB(VOLUME)
43 3A ∗K29-9280-13 KNOB(CH SELECTOR)
44 1B ∗K29-9332-03 KNOB(PTT)
A 3A N14-0583-04 CIRCULAR NUT(CH)
B3A∗N14-0805-04 CIRCULAR NUT(VOLUME)
C 3A N30-2604-46 PAN HEAD MACHINE SCREW
D 3B N30-2612-46 PAN HEAD MACHINE SCREW
E 3A,3B N30-3006-45 PAN HEAD MACHINE SCREW

TK-3160
PARTS LIST
15
TX-RX UNIT (X57-673X-XX)
Destination
Ref. No. Parts No. Description
Address New
parts Destination
Ref. No. Parts No. Description
Address New
parts
C50 CC73HCH1H070D CHIP C 7.0PF D E
C51 CC73HCH1H180J CHIP C 18PF J E
C51 CC73HCH1H220J CHIP C 22PF J X2
C52 CC73GCH1H050C CHIP C 5.0PF C
C53 CC73HCH1H030B CHIP C 3.0PF B X2
C53 CC73HCH1H040B CHIP C 4.0PF B E
C54 CC73HCH1H030C CHIP C 3.0PF C
C55,56 CC73HCH1H010B CHIP C 1.0PF B
C57 CC73GCH1H030C CHIP C 3.0PF C
C58 CC73HCH1H040B CHIP C 4.0PF B X2
C58 CC73HCH1H050B CHIP C 5.0PF B E
C59 CC73GCH1H050C CHIP C 5.0PF C
C60 CC73HCH1H040B CHIP C 4.0PF B
C61 CK73HB1H471K CHIP C 470PF K
C62 CC73HCH1H070B CHIP C 7.0PF B E
C62 CC73HCH1H090B CHIP C 9.0PF B X2
C63 CC73GCH1H100D CHIP C 10PF D
C64 CC73HCH1H050B CHIP C 5.0PF B
C65 CC73HCH1H101J CHIP C 100PF J
C66 CC73HCH1H090B CHIP C 9.0PF B X2
C66 CC73HCH1H120J CHIP C 12PF J E
C67 CK73HB1H471K CHIP C 470PF K
C68 CK73GB1H471K CHIP C 470PF K
C69 CC73HCH1H050B CHIP C 5.0PF B X2
C69 CC73HCH1H070B CHIP C 7.0PF B E
C70 CK73HB1H471K CHIP C 470PF K
C71 CC73GCH1H0R5B CHIP C 0.5PF B
C72 CC73HCH1H0R5B CHIP C 0.5PF B
C73 CK73GB1H471K CHIP C 470PF K
C74 CC73HCH1H100D CHIP C 10PF D
C75,76 CK73HB1H471K CHIP C 470PF K
C77 C92-0713-05 CHIP-TAN 10UF 6.3WV
C78 CK73HB1H471K CHIP C 470PF K
C80 CC73HCH1H070D CHIP C 7.0PF D
C82 CC73HCH1H330J CHIP C 33PF J
C83-85 CK73HB1H471K CHIP C 470PF K
C86 CC73HCH1H070D CHIP C 7.0PF D
C92 CK73GB1H471K CHIP C 470PF K
C94,95 CK73HB1A104K CHIP C 0.10UF K
C201,202 CK73GB1H471K CHIP C 470PF K
C205 CK73GB1A224K CHIP C 0.22UF K
C223 CK73GB1H471K CHIP C 470PF K
C224 CC73GCH1H040C CHIP C 4.0PF C X2
C224 CC73GCH1H070D CHIP C 7.0PF D E
C226 CK73GB1H471K CHIP C 470PF K
C233 CK73GB1H471K CHIP C 470PF K
C241 CK73GB1H471K CHIP C 470PF K
C242 CC73GCH1H060D CHIP C 6.0PF D
C243 CK73GB1C104K CHIP C 0.10UF K
C248 CC73GCH1H050C CHIP C 5.0PF C E
C249 CC73GCH1H130J CHIP C 13PF J
C255 CK73GB1H471K CHIP C 470PF K
C258 CK73GB1C104K CHIP C 0.10UF K
C280 CC73GCH1H100D CHIP C 10PF D X2
C280 CC73GCH1H330J CHIP C 33PF J E
C282 CC73GCH1H220J CHIP C 22PF J E
C282 CC73GCH1H680J CHIP C 68PF J X2
C283 CC73GCH1H100D CHIP C 10PF D
C284 CC73GCH1H200J CHIP C 20PF J
C286 C92-0565-05 CHIP-TAN 6.8UF 10WV
C288 CK73GB1A105K CHIP C 1.0UF K
C290-293 CK73GB1H471K CHIP C 470PF K
C294 CC73GCH1H101J CHIP C 100PF J
C295 CC73GCH1H270J CHIP C 27PF J X2
C295 CC73GCH1H330J CHIP C 33PF J E
C296 CK73GB1H471K CHIP C 470PF K
C297 CK73GB1H103K CHIP C 0.010UF K
C298 CK73GB1C104K CHIP C 0.10UF K
C299 CK73GB1A105K CHIP C 1.0UF K
C300 CC73GCH1H180J CHIP C 18PF J X2
C300 CC73GCH1H220J CHIP C 22PF J E
C301 CK73GB1H103K CHIP C 0.010UF K
C308 CC73GCH1H120J CHIP C 12PF J X2
C308 CC73GCH1H270J CHIP C 27PF J E
C309 CK73GB1H471K CHIP C 470PF K
C317 CC73GCH1H150J CHIP C 15PF J X2
C326 CK73GB1H471K CHIP C 470PF K
C341 CC73GCH1H3R5B CHIP C 3.5PF B E
C349 CC73GCH1H060B CHIP C 6.0PF B X2
C349 CC73GCH1H070B CHIP C 7.0PF B E
C351 CC73GCH1H150J CHIP C 15PF J X2
C351 CC73GCH1H270J CHIP C 27PF J E
C352 CK73GB1H471K CHIP C 470PF K
C353 CC73GCH1H040B CHIP C 4.0PF B
C355 CC73GCH1H050B CHIP C 5.0PF B
C356 CC73GCH1H101J CHIP C 100PF J E
C356 CK73GB1H471K CHIP C 470PF K X2
C358 CC73GCH1H030B CHIP C 3.0PF B
C359 CC73GCH1H1R5B CHIP C 1.5PF B
C360 CC73GCH1H060B CHIP C 6.0PF B X2
C360 CC73GCH1H3R5B CHIP C 3.5PF B E
C361 CC73GCH1H020B CHIP C 2.0PF B X2
C361 CC73GCH1H2R5B CHIP C 2.5PF B E
C363 CC73GCH1H060B CHIP C 6.0PF B X2
C363 CC73GCH1H4R5B CHIP C 4.5PF B E
C364 CC73GCH1H0R5B CHIP C 0.5PF B X2
C364 CC73GCH1H020B CHIP C 2.0PF B E
C365 CC73GCH1H020B CHIP C 2.0PF B X2
C368 CC73GCH1H050B CHIP C 5.0PF B X2
C368 CC73GCH1H100D CHIP C 10PF D E
C371 CC73GCH1H010B CHIP C 1.0PF B
C372 CK73GB1H471K CHIP C 470PF K
C401 CK73GB1H182K CHIP C 1800PF K
C402,403 CC73GCH1H331J CHIP C 330PF J
C405 CC73GCH1H390J CHIP C 39PF J
C406 C92-0713-05 CHIP-TAN 10UF 6.3WV
C407 CK73GB1H103K CHIP C 0.010UF K
C408 CK73GB1C104K CHIP C 0.10UF K
C409 CC73GCH1H680J CHIP C 68PF J
C410 CK73GB1H471K CHIP C 470PF K
C411-413 CK73GB1C104K CHIP C 0.10UF K
C414 CC73GCH1H100D CHIP C 10PF D
C415 CK73GB1H471K CHIP C 470PF K
C416,417 CK73GB1H103K CHIP C 0.010UF K
C418 CK73GB1H471K CHIP C 470PF K
C419 CC73GCH1H010B CHIP C 1.0PF B
C420 CK73GB1C104K CHIP C 0.10UF K
C421 CC73GCH1H080B CHIP C 8.0PF B
C422 CK73GB1H103K CHIP C 0.010UF K
C424 CK73GB1H103K CHIP C 0.010UF K

TK-3160 PARTS LIST
16
TX-RX UNIT (X57-673X-XX)
Destination
Ref. No. Parts No. Description
Address New
parts Destination
Ref. No. Parts No. Description
Address New
parts
C425 CC73GCH1H060D CHIP C 6.0PF D
C426 CC73GCH1H020B CHIP C 2.0PF B
C427 CC73GCH1H100D CHIP C 10PF D X2
C427 CC73GCH1H120J CHIP C 12PF J E
C428 CK73GB1H471K CHIP C 470PF K
C429 CC73GCH1H120J CHIP C 12PF J E
C429 CC73GCH1H150J CHIP C 15PF J X2
C430 CK73GB1H471K CHIP C 470PF K
C431 CK73GB1H103K CHIP C 0.010UF K
C432 CK73GB1H471K CHIP C 470PF K
C434 CC73GCH1H050B CHIP C 5.0PF B
C435 CK73GB1H471K CHIP C 470PF K
C439 CK73GB1H471K CHIP C 470PF K
C445 CC73GCH1H040B CHIP C 4.0PF B E
C445 CC73GCH1H4R5B CHIP C 4.5PF B X2
C447 CC73GCH1H150J CHIP C 15PF J X2
C447 CC73GCH1H330J CHIP C 33PF J E
C448 CC73GCH1H030B CHIP C 3.0PF B E
C448 CC73GCH1H1R5B CHIP C 1.5PF B X2
C456 CK73HB1H471K CHIP C 470PF K
C464 CC73GCH1H1R5B CHIP C 1.5PF B X2
C464 CC73GCH1H2R5B CHIP C 2.5PF B E
C465 CC73GCH1H010B CHIP C 1.0PF B E
C465 CC73GCH1H060B CHIP C 6.0PF B X2
C466 CC73GCH1H150J CHIP C 15PF J X2
C466 CC73GCH1H330J CHIP C 33PF J E
C467 CK73HB1H471K CHIP C 470PF K
C468 CC73GCH1H020B CHIP C 2.0PF B
C469 CC73GCH1H030B CHIP C 3.0PF B E
C469 CC73GCH1H1R5B CHIP C 1.5PF B X2
C470 CK73HB1H471K CHIP C 470PF K
C471 CC73GCH1H150J CHIP C 15PF J X2
C471 CC73GCH1H330J CHIP C 33PF J E
C472 C92-0714-05 CHIP-TAN 4.7UF 6.3WV
C473 CC73HCH1H050B CHIP C 5.0PF B X2
C473 CC73HCH1H060B CHIP C 6.0PF B E
C474,475 CK73GB1H471K CHIP C 470PF K
C478,479 CK73HB1H471K CHIP C 470PF K
C481 CK73GB1H471K CHIP C 470PF K E
C481,482 CK73GB1H471K CHIP C 470PF K X2
C482 CC73GCH1H120G CHIP C 12PF G E
C483 CC73GCH1H040B CHIP C 4.0PF B E
C483 CC73GCH1H050B CHIP C 5.0PF B X2
C484 CC73GCH1H150J CHIP C 15PF J X2
C484 CC73GCH1H330J CHIP C 33PF J E
C485 CC73GCH1H030B CHIP C 3.0PF B
C487 CK73GB1H471K CHIP C 470PF K
C488 CC73GCH1H030B CHIP C 3.0PF B E
C488 CC73GCH1H2R5B CHIP C 2.5PF B X2
C489 CC73GCH1H150J CHIP C 15PF J X2
C489 CC73GCH1H330J CHIP C 33PF J E
C490 CC73GCH1H080B CHIP C 8.0PF B X2
C491 CC73GCH1H100D CHIP C 10PF D E
C491 CC73GCH1H330J CHIP C 33PF J X2
C492 CC73GCH1H3R5B CHIP C 3.5PF B
C493 CK73GB1H471K CHIP C 470PF K
C494 CK73GB1H103K CHIP C 0.010UF K
C495 CC73GCH1H010C CHIP C 1.0PF C
C501 CK73GB1H471K CHIP C 470PF K
C503 CC73HCH1H1R5B CHIP C 1.5PF B X2
C504 CK73HB1H471K CHIP C 470PF K
C506 CK73GB1A105K CHIP C 1.0UF K
C507 CK73GB0J225K CHIP C 2.2UF K
C508 CK73GB1H471K CHIP C 470PF K
C601 CK73GB1A224K CHIP C 0.22UF K
C605 C92-0632-05 CHIP-TAN 6.8UF 6.3WV
C607 CK73GB1H103K CHIP C 0.010UF K
C608 CK73GB1H392K CHIP C 3900PF K
C609 CK73GB1H103K CHIP C 0.010UF K
C610 C92-0714-05 CHIP-TAN 4.7UF 6.3WV
C611 CK73GB1A105K CHIP C 1.0UF K
C613-615 CK73GB1C104K CHIP C 0.10UF K
C616 CK73GB1H332K CHIP C 3300PF K
C618 CK73GB1C104K CHIP C 0.10UF K
C619 CK73GB1H392K CHIP C 3900PF K
C621,622 C92-0714-05 CHIP-TAN 4.7UF 6.3WV
C624 CK73GB1C104K CHIP C 0.10UF K
C625 CC73GCH1H680J CHIP C 68PF J
C627 CK73GB1E123K CHIP C 0.012UF K
C628 CK73GB1H222K CHIP C 2200PF K
C629 CK73GB1C104K CHIP C 0.10UF K
C630 CC73GCH1H101J CHIP C 100PF J
C631 CK73GB1E123K CHIP C 0.012UF K
C632 CK73GB1C104K CHIP C 0.10UF K
C633 CC73GCH1H020B CHIP C 2.0PF B
C634 CK73GB1H102K CHIP C 1000PF K
C635 CK73GB1C104K CHIP C 0.10UF K
C636 CK73GB1C683K CHIP C 0.068UF K
C637 CC73GCH1H101J CHIP C 100PF J
C638 CK73GB1H471K CHIP C 470PF K
C639 CC73GCH1H470J CHIP C 47PF J
C640 CC73GCH1H101J CHIP C 100PF J
C641,642 CK73GB1C104K CHIP C 0.10UF K
C643 CC73GCH1H680J CHIP C 68PF J
C645 CK73GB0J225K CHIP C 2.2UF K
C646 CK73GB1H821K CHIP C 820PF K
C647 CK73GB1H471K CHIP C 470PF K
C648,649 CK73GB1C104K CHIP C 0.10UF K
C650 C92-0713-05 CHIP-TAN 10UF 6.3WV
C652 CK73GB1H471K CHIP C 470PF K
C653 CK73GB1A224K CHIP C 0.22UF K
C654 CK73GB1H103K CHIP C 0.010UF K
C655 CK73GB1C223K CHIP C 0.022UF K
C656 CK73GB1C104K CHIP C 0.10UF K
C657 CC73GCH1H470J CHIP C 47PF J
C658 CK73GB1C104K CHIP C 0.10UF K
C659 CK73GB1H103K CHIP C 0.010UF K
C660 CK73GB1A105K CHIP C 1.0UF K
C662,663 CK73GB1C104K CHIP C 0.10UF K
C664 CK73GB1H102K CHIP C 1000PF K
C665 CK73GB1H471K CHIP C 470PF K
C667 CK73GB1H471K CHIP C 470PF K
C668 CK73GB1H103K CHIP C 0.010UF K
C669 CK73GB1H471K CHIP C 470PF K
C671 CK73GB1C104K CHIP C 0.10UF K
C672,673 CK73GB1H392K CHIP C 3900PF K
C674 CC73GCH1H221J CHIP C 220PF J
C675,676 C92-0804-05 CHIP-TAN 1.5UF 15WV
C677 CK73GB1H332K CHIP C 3300PF K
C678 CK73FB1C474K CHIP C 0.47UF K

TK-3160
PARTS LIST
17
TX-RX UNIT (X57-673X-XX)
Destination
Ref. No. Parts No. Description
Address New
parts Destination
Ref. No. Parts No. Description
Address New
parts
C679 CC73GCH1H101J CHIP C 100PF J
C680 C92-0560-05 CHIP-TAN 10UF 6.3WV
C681 CK73GB1C223K CHIP C 0.022UF K
C684 CK73GB1C104K CHIP C 0.10UF K
C686 CK73GB1C473K CHIP C 0.047UF K
C687 C92-0560-05 CHIP-TAN 10UF 6.3WV
C688 CC73GCH1H221J CHIP C 220PF J
C689 CK73GB1C223K CHIP C 0.022UF K
C690 CK73GB1H102K CHIP C 1000PF K
C691 C92-0665-05 TANTAL 100UF 6.3WV
C692 CC73GCH1H221J CHIP C 220PF J
C693 CK73GB1H471K CHIP C 470PF K
C695 CK73GB1H471K CHIP C 470PF K
C696 CK73GB1A224K CHIP C 0.22UF K
C801 CK73GB1A105K CHIP C 1.0UF K
C802 CK73GB1H103K CHIP C 0.010UF K
C803,804 CK73GB1A105K CHIP C 1.0UF K
C805 CK73GB1H471K CHIP C 470PF K
C807 CK73GB1H471K CHIP C 470PF K
C809 CK73GB1A105K CHIP C 1.0UF K
C811 CK73GB1C104K CHIP C 0.10UF K
C812 CK73GB1H103K CHIP C 0.010UF K
C814 CK73GB1H103K CHIP C 0.010UF K
C816,817 CK73GB1H471K CHIP C 470PF K
C818 CK73GB1H103K CHIP C 0.010UF K
C819 CK73GB1H471K CHIP C 470PF K
C820,821 CK73GB1A105K CHIP C 1.0UF K
C822 CK73GB1H471K CHIP C 470PF K
C823 CK73GB1H103K CHIP C 0.010UF K
C825 C92-0713-05 CHIP-TAN 10UF 6.3WV
C828 CK73GB1H471K CHIP C 470PF K
C830 CK73GB1C104K CHIP C 0.10UF K
C833 CK73GB1A105K CHIP C 1.0UF K
C834 CK73GB1C104K CHIP C 0.10UF K
C835,836 CK73GB1A105K CHIP C 1.0UF K
C837 CK73GB1H471K CHIP C 470PF K
C840 CK73GB1H471K CHIP C 470PF K
C841 CK73GB1H103K CHIP C 0.010UF K
C842 CC73GCH1H150J CHIP C 15PF J
C843 CC73GCH1H030C CHIP C 3.0PF C
C845 CC73GCH1H150J CHIP C 15PF J
C846 CK73GB1H103K CHIP C 0.010UF K
C847 C92-0712-05 CHIP-TAN 22UF 6.3WV
C849 CK73GB1H471K CHIP C 470PF K
C850 CK73GB1H103K CHIP C 0.010UF K
C852,853 CK73GB1H471K CHIP C 470PF K
C854 CK73GB1H103K CHIP C 0.010UF K
C861 CK73FB1A475K CHIP C 4.7UF K
CTC1,2 C05-0384-05 CERAMIC TRIMMER CAP(10PF)
93B∗E37-1085-05 FLAT CABLE
J601 E11-0457-05 PHONE JACK (2.5/3.5)
∗F20-3352-04 INSULATING SHEET
F801 F53-0190-05 FUSE
G11-4300-04 RUBBER CUSHION
∗J99-0374-04 ADHESIVE TAPE
CD401 L79-1582-05 TUNING COIL
CF401 ∗L72-1015-05 CERAMIC FILTER
L1 L40-4795-85 SMALL FIXED INDUCTOR(4.7UH)
L2 L40-1875-92 SMALL FIXED INDUCTOR(18NH)
L3 L40-1581-86 SMALL FIXED INDUCTOR(0.15UH)
L5 L92-0138-05 FERRITE CHIP
L6 L40-1085-92 SMALL FIXED INDUCTOR(100NH)
L7 L92-0138-05 FERRITE CHIP
L8 L40-1885-92 SMALL FIXED INDUCTOR(180NH)
L9 L40-2785-92 SMALL FIXED INDUCTOR(270NH)
L10 L92-0163-05 BEADS CORE
L11 L40-1885-92 SMALL FIXED INDUCTOR(180NH)
L12 L40-2785-92 SMALL FIXED INDUCTOR(270NH)
L14 L41-1278-14 SMALL FIXED INDUCTOR X2
L14 L41-1578-14 SMALL FIXED INDUCTOR E
L15 L41-1578-14 SMALL FIXED INDUCTOR X2
L15 L41-1878-14 SMALL FIXED INDUCTOR E
L16 L40-1275-92 SMALL FIXED INDUCTOR(12NH)
L17,18 L41-2285-03 SMALL FIXED INDUCTOR
L19 L40-1875-92 SMALL FIXED INDUCTOR(18NH)
L20,21 L40-3391-86 SMALL FIXED INDUCTOR(3.3UH)
L22 L92-0163-05 BEADS CORE
L23 L40-1875-92 SMALL FIXED INDUCTOR(18NH) X2
L23 L40-2275-92 SMALL FIXED INDUCTOR(22NH) E
L25 L40-2275-92 SMALL FIXED INDUCTOR(22NH)
L205 L40-1875-92 SMALL FIXED INDUCTOR(18NH)
L207 L40-1875-92 SMALL FIXED INDUCTOR(18NH)
L208 L92-0138-05 FERRITE CHIP
L209 L40-8265-92 SMALL FIXED INDUCTOR(8.2NH)
L213 L40-8265-92 SMALL FIXED INDUCTOR(8.2NH)
L216 L40-1575-54 SMALL FIXED INDUCTOR(15NH)
L217 L92-0149-05 FERRITE CHIP
L218 L40-1263-92 SMALL FIXED INDUCTOR(1.2NH) E
L220 L34-4602-05 AIR-CORE COIL
L221 L92-0149-05 FERRITE CHIP
L222 L40-2285-54 SMALL FIXED INDUCTOR(220NH)
L223 L34-4572-05 AIR-CORE COIL
L224-226 L34-4564-05 AIR-CORE COIL
L227 L40-1092-81 SMALL FIXED INDUCTOR
L401 L92-0138-05 FERRITE CHIP
L402 L40-1875-92 SMALL FIXED INDUCTOR(18NH)
L403 L40-5685-85 SMALL FIXED INDUCTOR(0.56UH)
L404 L40-1585-92 SMALL FIXED INDUCTOR(150NH) X2
L404 L40-2785-92 SMALL FIXED INDUCTOR(270NH) E
L405 L40-2275-92 SMALL FIXED INDUCTOR(22NH) X2
L405 L40-2775-92 SMALL FIXED INDUCTOR(27NH) E
L407-409 L41-6868-14 SMALL FIXED INDUCTOR X2
L407-409 L41-8268-14 SMALL FIXED INDUCTOR E
L410 L92-0138-05 FERRITE CHIP
L411 L41-2285-03 SMALL FIXED INDUCTOR
L413,414 L41-6868-14 SMALL FIXED INDUCTOR X2
L413,414 L41-8268-14 SMALL FIXED INDUCTOR E
L415 L41-3978-03 SMALL FIXED INDUCTOR X2
L415 L41-4778-03 SMALL FIXED INDUCTOR E
L416 L40-5681-86 SMALL FIXED INDUCTOR(0.56UH)
L601 L92-0140-05 FERRITE CHIP
L602 L92-0149-05 FERRITE CHIP
L801 L92-0149-05 FERRITE CHIP
L802 L92-0140-05 FERRITE CHIP
L803-807 L92-0138-05 FERRITE CHIP

TK-3160 PARTS LIST
18
TX-RX UNIT (X57-673X-XX)
Destination
Ref. No. Parts No. Description
Address New
parts Destination
Ref. No. Parts No. Description
Address New
parts
X1 L77-1932-05 TCXO (16.8MHZ)
X801 L77-1933-05 CRYSTAL RESONATOR(7.3728MHZ)
XF401 L71-0617-15 MCF (49.95MHZ)
CP1,2 RK75HA1J473J CHIP-COM 47K J 1/16W
CP3,4 RK75HA1J102J CHIP-COM 1.0K J 1/16W
CP801,802 RK75HA1J473J CHIP-COM 47K J 1/16W
CP803-805 RK75HA1J102J CHIP-COM 1.0K J 1/16W
CP806 RK75HA1J473J CHIP-COM 47K J 1/16W
CP807 RK75HA1J102J CHIP-COM 1.0K J 1/16W
CP808 RK75HA1J472J CHIP-COM 4.7K J 1/16W
CP809-818 RK75HA1J102J CHIP-COM 1.0K J 1/16W
R1 RK73GB1J223J CHIP R 22K J 1/16W
R2 RK73GB1J103J CHIP R 10K J 1/16W
R3 RK73GB1J474J CHIP R 470K J 1/16W
R4 R92-1252-05 CHIP R 0 OHM J 1/16W
R5 RK73GB1J224J CHIP R 220K J 1/16W
R6 RK73GB1J473J CHIP R 47K J 1/16W
R7,8 R92-1252-05 CHIP R 0 OHM J 1/16W
R9 RK73GB1J393J CHIP R 39K J 1/16W
R12 RK73GB1J101J CHIP R 100 J 1/16W
R13 R92-1252-05 CHIP R 0 OHM J 1/16W
R14 RK73GB1J222J CHIP R 2.2K J 1/16W
R15 R92-1252-05 CHIP R 0 OHM J 1/16W
R16 RK73GB1J102J CHIP R 1.0K J 1/16W
R17 RK73GB1J101J CHIP R 100 J 1/16W
R18 RK73GB1J474J CHIP R 470K J 1/16W
R19 RK73GB1J100J CHIP R 10 J 1/16W
R20,21 R92-1252-05 CHIP R 0 OHM J 1/16W
R22 RK73GB1J122J CHIP R 1.2K J 1/16W
R23,24 RK73GB1J681J CHIP R 680 J 1/16W
R25 RK73GB1J103J CHIP R 10K J 1/16W
R26 RK73GB1J223J CHIP R 22K J 1/16W
R27 RK73GB1J103J CHIP R 10K J 1/16W
R28 RK73GB1J393J CHIP R 39K J 1/16W
R29 RK73GB1J104J CHIP R 100K J 1/16W E
R29 RK73GB1J154J CHIP R 150K J 1/16W X2
R30 RK73HB1J333J CHIP R 33K J 1/16W
R31 RK73GB1J560J CHIP R 56 J 1/16W
R32 RK73HB1J153J CHIP R 15K J 1/16W
R33 RK73HB1J473J CHIP R 47K J 1/16W
R34 RK73GB1J473J CHIP R 47K J 1/16W
R35 RK73GB1J220J CHIP R 22 J 1/16W
R36 RK73HB1J100J CHIP R 10 J 1/16W
R37 RK73HB1J181J CHIP R 180 J 1/16W
R38 RK73HB1J100J CHIP R 10 J 1/16W
R39 RK73HB1J151J CHIP R 150 J 1/16W
R40 RK73GB1J102J CHIP R 1.0K J 1/16W
R41 RK73GB1J154J CHIP R 150K J 1/16W
R43 RK73HB1J154J CHIP R 150K J 1/16W
R44 RK73HB1J472J CHIP R 4.7K J 1/16W
R46 RK73HB1J101J CHIP R 100 J 1/16W
R47 RK73HB1J682J CHIP R 6.8K J 1/16W
R48 RK73HB1J103J CHIP R 10K J 1/16W
R49 RK73GJ1J333D CHIP R 33K D 1/16W
R50 RK73HB1J331J CHIP R 330 J 1/16W
R51 RK73GJ1J104D CHIP R 100K D 1/16W
R55 RK73HB1J222J CHIP R 2.2K J 1/16W
R56 RK73HB1J470J CHIP R 47 J 1/16W
R57 R92-1368-05 CHIP R 0 OHM
R58 RK73GB1J472J CHIP R 4.7K J 1/16W
R202 RK73GB1J472J CHIP R 4.7K J 1/16W
R203 R92-1252-05 CHIP R 0 OHM J 1/16W
R204 RK73GB1J153J CHIP R 15K J 1/16W
R207 RK73GB1J333J CHIP R 33K J 1/16W
R215 R92-1252-05 CHIP R 0 OHM J 1/16W
R222 RK73GB1J331J CHIP R 330 J 1/16W
R224 RK73GB1J220J CHIP R 22 J 1/16W
R229 RK73GB1J331J CHIP R 330 J 1/16W
R230 RK73GB1J180J CHIP R 18 J 1/16W
R231,232 RK73GB1J331J CHIP R 330 J 1/16W
R234 RK73GB1J103J CHIP R 10K J 1/16W
R235 RK73GB1J101J CHIP R 100 J 1/16W
R237 RK73GB1J223J CHIP R 22K J 1/16W
R242 RK73GB1J124J CHIP R 120K J 1/16W
R247 RK73GB1J473J CHIP R 47K J 1/16W E
R247 RK73GB1J683J CHIP R 68K J 1/16W X2
R251 R92-1252-05 CHIP R 0 OHM J 1/16W
R252 RK73GB1J220J CHIP R 22 J 1/16W
R253 R92-1252-05 CHIP R 0 OHM J 1/16W
R255 R92-1252-05 CHIP R 0 OHM J 1/16W
R256,257 RK73EB2ER39K CHIP R 0.39 K 1/4W
R258 R92-1252-05 CHIP R 0 OHM J 1/16W X2
R259 RK73GB1J473J CHIP R 47K J 1/16W X2
R259,260 RK73GB1J473J CHIP R 47K J 1/16W E
R260 RK73GB1J823J CHIP R 82K J 1/16W X2
R261 RK73EB2ER39K CHIP R 0.39 K 1/4W
R262 R92-0670-05 CHIP R 0 OHM
R263 RK73GB1J101J CHIP R 100 J 1/16W
R264,265 RK73GH1J154D CHIP R 150K D 1/16W
R267-270 RK73GH1J154D CHIP R 150K D 1/16W
R271 RK73GB1J103J CHIP R 10K J 1/16W
R272 RK73GB1J473J CHIP R 47K J 1/16W
R273 R92-1252-05 CHIP R 0 OHM J 1/16W
R274 RK73GB1J105J CHIP R 1.0M J 1/16W
R275 RK73GB1J222J CHIP R 2.2K J 1/16W
R276,277 RK73GB1J104J CHIP R 100K J 1/16W
R278 R92-0670-05 CHIP R 0 OHM
R279,280 RK73GB1J271J CHIP R 270 J 1/16W
R281,282 R92-1252-05 CHIP R 0 OHM J 1/16W
R401 RK73GB1J100J CHIP R 10 J 1/16W
R403 RK73GB1J102J CHIP R 1.0K J 1/16W
R404 RK73GB1J334J CHIP R 330K J 1/16W E
R404 RK73GB1J684J CHIP R 680K J 1/16W X2
R406 RK73GB1J332J CHIP R 3.3K J 1/16W
R407 RK73GB1J474J CHIP R 470K J 1/16W
R408 RK73GB1J332J CHIP R 3.3K J 1/16W
R409 RK73GB1J392J CHIP R 3.9K J 1/16W
R412 RK73GB1J122J CHIP R 1.2K J 1/16W E
R412 RK73GB1J331J CHIP R 330 J 1/16W X2
R413 RK73GB1J124J CHIP R 120K J 1/16W
R414 RK73GB1J681J CHIP R 680 J 1/16W
R415 RK73GB1J472J CHIP R 4.7K J 1/16W
R416 RK73GB1J101J CHIP R 100 J 1/16W
R417 RK73GB1J470J CHIP R 47 J 1/16W
R419 RK73GB1J102J CHIP R 1.0K J 1/16W X2
R419 RK73GB1J222J CHIP R 2.2K J 1/16W E
R420 RK73GB1J151J CHIP R 150 J 1/16W
R422 RK73GB1J104J CHIP R 100K J 1/16W
R423 RK73GB1J563J CHIP R 56K J 1/16W E

TK-3160
PARTS LIST
19
TX-RX UNIT (X57-673X-XX)
Destination
Ref. No. Parts No. Description
Address New
parts Destination
Ref. No. Parts No. Description
Address New
parts
R423 RK73GB1J683J CHIP R 68K J 1/16W X2
R424 RK73HB1J104J CHIP R 100K J 1/16W
R425 RK73GB1J563J CHIP R 56K J 1/16W E
R425 RK73GB1J683J CHIP R 68K J 1/16W X2
R427 R92-1252-05 CHIP R 0 OHM J 1/16W
R430,431 RK73HB1J105J CHIP R 1.0M J 1/16W
R438 RK73HB1J105J CHIP R 1.0M J 1/16W
R440 RK73HB1J221J CHIP R 220 J 1/16W
R441 RK73HB1J151J CHIP R 150 J 1/16W E
R441 RK73HB1J220J CHIP R 22 J 1/16W X2
R457 RK73HB1J104J CHIP R 100K J 1/16W
R459 RK73GB1J104J CHIP R 100K J 1/16W
R460 RK73GB1J563J CHIP R 56K J 1/16W X2
R460 RK73GB1J683J CHIP R 68K J 1/16W E
R461 R92-1252-05 CHIP R 0 OHM J 1/16W
R462,463 RK73GB1J105J CHIP R 1.0M J 1/16W
R464 R92-0670-05 CHIP R 0 OHM
R465 RK73GB1J332J CHIP R 3.3K J 1/16W
R469 RK73GB1J221J CHIP R 220 J 1/16W
R471 RK73GB1J104J CHIP R 100K J 1/16W
R474 RK73GB1J103J CHIP R 10K J 1/16W E
R474 RK73GB1J223J CHIP R 22K J 1/16W X2
R475 RK73GB1J104J CHIP R 100K J 1/16W X2
R475 RK73GB1J683J CHIP R 68K J 1/16W E
R476 RK73GB1J103J CHIP R 10K J 1/16W
R601 R92-1252-05 CHIP R 0 OHM J 1/16W
R602 RK73GB1J124J CHIP R 120K J 1/16W X2
R602 RK73GB1J184J CHIP R 180K J 1/16W E
R603 R92-1252-05 CHIP R 0 OHM J 1/16W
R604 RK73GB1J184J CHIP R 180K J 1/16W
R607-609 RK73GB1J103J CHIP R 10K J 1/16W
R610 RK73GB1J472J CHIP R 4.7K J 1/16W
R612 RK73GB1J273J CHIP R 27K J 1/16W
R613 RK73GB1J824J CHIP R 820K J 1/16W
R615 RK73GB1J334J CHIP R 330K J 1/16W
R616 R92-1252-05 CHIP R 0 OHM J 1/16W
R617 RK73GB1J473J CHIP R 47K J 1/16W
R618 RK73GJ1J364D CHIP R 360K D 1/16W
R621 RK73GB1J473J CHIP R 47K J 1/16W
R622 RK73GB1J684J CHIP R 680K J 1/16W
R623 RK73GB1J274G CHIP R 270K G 1/16W
R624 RK73GB1J562J CHIP R 5.6K J 1/16W
R625 RK73GB1J563J CHIP R 56K J 1/16W
R626,627 RK73GB1J184J CHIP R 180K J 1/16W
R628 RK73GB1J224J CHIP R 220K J 1/16W
R629 RK73GB1J394J CHIP R 390K J 1/16W
R630 RK73GB1J684J CHIP R 680K J 1/16W
R631 RK73GB1J394J CHIP R 390K J 1/16W
R632 RK73GB1J823J CHIP R 82K J 1/16W
R633 RK73GB1J223J CHIP R 22K J 1/16W
R634 RK73GB1J153J CHIP R 15K J 1/16W
R636 RK73GB1J474J CHIP R 470K J 1/16W
R637 RK73GB1J394J CHIP R 390K J 1/16W
R639 RK73GB1J393J CHIP R 39K J 1/16W
R640 RK73GB1J184J CHIP R 180K J 1/16W
R641,642 RK73GB1J124J CHIP R 120K J 1/16W
R643 RK73GB1J184J CHIP R 180K J 1/16W
R644,645 RK73GB1J472J CHIP R 4.7K J 1/16W
R646 RK73GB1J223J CHIP R 22K J 1/16W
R647 R92-1252-05 CHIP R 0 OHM J 1/16W
R648 RK73GB1J103J CHIP R 10K J 1/16W
R649 RK73GB1J104J CHIP R 100K J 1/16W
R650 RK73GB1J102J CHIP R 1.0K J 1/16W
R651 R92-1252-05 CHIP R 0 OHM J 1/16W
R652 RK73GB1J273J CHIP R 27K J 1/16W
R653 RK73GB1J392J CHIP R 3.9K J 1/16W
R654 RK73GB1J103J CHIP R 10K J 1/16W
R655,656 RK73GB1J105J CHIP R 1.0M J 1/16W
R657 RK73GB1J332J CHIP R 3.3K J 1/16W
R658 RK73GB1J103J CHIP R 10K J 1/16W
R660 RK73GB1J154J CHIP R 150K J 1/16W
R661 RK73GB1J684J CHIP R 680K J 1/16W
R665 R92-1252-05 CHIP R 0 OHM J 1/16W
R666 RK73GB1J822J CHIP R 8.2K J 1/16W
R667 RK73GB1J104J CHIP R 100K J 1/16W
R668 RK73GB1J473J CHIP R 47K J 1/16W
R669 RK73GB1J222J CHIP R 2.2K J 1/16W
R670 RK73GB1J102J CHIP R 1.0K J 1/16W
R671 RK73GB1J683J CHIP R 68K J 1/16W
R672 RK73GB1J102J CHIP R 1.0K J 1/16W
R673 RK73GB1J272J CHIP R 2.7K J 1/16W
R674 R92-1252-05 CHIP R 0 OHM J 1/16W
R675 RK73GB1J822J CHIP R 8.2K J 1/16W
R676 RK73GB1J151J CHIP R 150 J 1/16W
R677-679 R92-1252-05 CHIP R 0 OHM J 1/16W
R681 RK73GB1J222J CHIP R 2.2K J 1/16W
R682 RK73GB1J100J CHIP R 10 J 1/16W
R683 RK73GB1J474J CHIP R 470K J 1/16W
R684 RK73GB1J182J CHIP R 1.8K J 1/16W
R686 RK73GB1J471J CHIP R 470 J 1/16W
R687 RK73GB1J102J CHIP R 1.0K J 1/16W
R688,689 RK73GB1J101J CHIP R 100 J 1/16W
R691 RK73GB1J333J CHIP R 33K J 1/16W
R692 R92-1252-05 CHIP R 0 OHM J 1/16W
R693 RK73GB1J273J CHIP R 27K J 1/16W
R694,695 R92-1252-05 CHIP R 0 OHM J 1/16W
R696 RK73GB1J103J CHIP R 10K J 1/16W
R697 R92-1252-05 CHIP R 0 OHM J 1/16W
R698 RK73GB1J152J CHIP R 1.5K J 1/16W
R802 RK73GB1J101J CHIP R 100 J 1/16W
R803,804 R92-1252-05 CHIP R 0 OHM J 1/16W
R805 RK73GB1J153J CHIP R 15K J 1/16W
R807 RK73GB1J103J CHIP R 10K J 1/16W
R808 RK73GB1J102J CHIP R 1.0K J 1/16W
R809 RK73GB1J272J CHIP R 2.7K J 1/16W
R810 RK73GB1J334J CHIP R 330K J 1/16W
R811 RK73GB1J332J CHIP R 3.3K J 1/16W
R812 RK73GB1J334J CHIP R 330K J 1/16W
R813 RK73GB1J332J CHIP R 3.3K J 1/16W
R814 RK73GB1J153J CHIP R 15K J 1/16W
R815 R92-1252-05 CHIP R 0 OHM J 1/16W
R816 RK73GB1J224J CHIP R 220K J 1/16W
R817 RK73GB1J272J CHIP R 2.7K J 1/16W
R818 RK73GB1J821J CHIP R 820 J 1/16W
R819 RK73GB1J103J CHIP R 10K J 1/16W
R820 RK73GB1J561J CHIP R 560 J 1/16W
R821 RK73GB1J331J CHIP R 330 J 1/16W
R823 RK73GB1J102J CHIP R 1.0K J 1/16W
R824 RK73GB1J183J CHIP R 18K J 1/16W
R825 RK73GB1J473J CHIP R 47K J 1/16W

TK-3160 PARTS LIST
20
TX-RX UNIT (X57-673X-XX)
Destination
Ref. No. Parts No. Description
Address New
parts Destination
Ref. No. Parts No. Description
Address New
parts
R827 RK73GB1J102J CHIP R 1.0K J 1/16W
R828 RK73GB1J332J CHIP R 3.3K J 1/16W
R829 RK73GB1J272J CHIP R 2.7K J 1/16W
R830 RK73GB1J821J CHIP R 820 J 1/16W
R833,834 RK73GH1J474D CHIP R 470K D 1/16W
R835,836 RK73HB1J102J CHIP R 1.0K J 1/16W
R839,840 RK73GB1J473J CHIP R 47K J 1/16W
R841 R92-1252-05 CHIP R 0 OHM J 1/16W
R842 R92-1368-05 CHIP R 0 OHM
R844 RK73GB1J473J CHIP R 47K J 1/16W
R845 R92-1368-05 CHIP R 0 OHM
R847,848 RK73GB1J102J CHIP R 1.0K J 1/16W
R849 R92-1252-05 CHIP R 0 OHM J 1/16W
R851 R92-1368-05 CHIP R 0 OHM
R852 RK73HB1J473J CHIP R 47K J 1/16W
R854 RK73GB1J680J CHIP R 68 J 1/16W
R855-857 RK73HB1J102J CHIP R 1.0K J 1/16W
R858 R92-1368-05 CHIP R 0 OHM
R859 RK73GB1J104J CHIP R 100K J 1/16W
VR1 R12-7491-05 TRIMMING POT.(68K)
S802-805 S70-0457-05 TACT SWITCH
MIC60 T91-0543-05 MIC ELEMENT
D3,4 1SV325 VARIABLE CAPACITANCE DIODE
D7 1SV325 VARIABLE CAPACITANCE DIODE
D9 1SV325 VARIABLE CAPACITANCE DIODE
D10 1SV278 VARIABLE CAPACITANCE DIODE
D11 HSC277 DIODE
D201 HSC277 DIODE
D203 HZU5CLL ZENER DIODE
D204 HVC131 DIODE
D206 HVC131 DIODE
D208 HVC131 DIODE
D212 HVC131 DIODE
D401 HSC277 DIODE
D402-406 HVC369B VARIABLE CAPACITANCE DIODE
D407 RB521S-30 DIODE
D603-606 RB706F-40 DIODE
D801 RB521S-30 DIODE
D805 1SR154-400 DIODE
IC1 MB15E03SL MOS IC
IC201 TA75W01FU MOS IC
IC401 TA31136FN MOS IC
IC601 ∗AQUA MOS IC
IC602 TC75S51FE MOS IC
IC603 TC75W51FU MOS IC
IC604 TC75S51FE MOS IC
IC605 TA7368F MOS IC
IC801 XC6204B502MR MOS IC
IC802 ∗PST9134NR MOS IC
IC803 XC61CN5002NR MOS IC
IC804 ∗CAT24WC64JI ROM IC
IC805 ∗30622MCA-8C1GP MPU
IC806 TC7W74FU MOS IC
Q1 DTC144EE DIGITAL TRANSISTOR
Q2,3 UMG9N TRANSISTOR
Q4 KTC4082 TRANSISTOR
Q5,6 2SK508NV(K52) FET
Q7 2SC5108(Y) TRANSISTOR
Q8 2SJ347 FET
Q9 2SC5108(Y) TRANSISTOR
Q10 2SC4617(S) TRANSISTOR
Q11 2SC5108(Y) TRANSISTOR
Q12 2SJ347 FET
Q205 2SC5108(Y) TRANSISTOR
Q206 ∗2SK3077 FET
Q207 2SK2596 FET
Q208 DTC114EE DIGITAL TRANSISTOR
Q209 2SK879(GR) FET
Q210 DTC114EE DIGITAL TRANSISTOR
Q211 2SK3476 FET
Q212 2SK1824 FET
Q213 DTA144EE DIGITAL TRANSISTOR
Q401 DTA144EE DIGITAL TRANSISTOR
Q402 2SC4649(N,P) TRANSISTOR
Q403 3SK318 FET X2
Q403,404 3SK318 FET E
Q404 3SK293 FET X2
Q407,408 2SK1824 FET
Q601,602 2SK1824 FET
Q603 DTC144EE DIGITAL TRANSISTOR
Q604 2SA1362(GR) TRANSISTOR
Q605 2SC4116(Y) TRANSISTOR
Q606 2SA1586(Y,GR) TRANSISTOR
Q607 DTC144EE DIGITAL TRANSISTOR
Q608 2SK1588 FET
Q801 UMG3N TRANSISTOR
Q802 UPA672T FET
Q803 FP210 TRANSISTOR
Q804 UMG3N TRANSISTOR
Q805 UMG9N TRANSISTOR
Q806 KTA1298(Y) TRANSISTOR
Q807 UMG3N TRANSISTOR
Q808,809 DTA123JE DIGITAL TRANSISTOR
Q810 2SK1824 FET
TH1 B57331V2104J THERMISTOR
TH600 B57331V2104J THERMISTOR
