KEYKING FPC2001 User manual

User Manual
Thank you for purchasing Keyking products. Please read this manual thoroughly before using.
FPC2001 Biometric Reader (Standalone, Narrow)
KEYKING GROUP

KEYKING GROUP FPC2001 Biometric Reader User Manual（V1.00）
Page 2 of 20
Index
Chapter 1 Introduction ...................................................................................................................................... 3
1.1 Summary ................................................................................................................................................ 3
1.2 Model Definition.................................................................................................................................... 4
1.3 Model List.............................................................................................................................................. 5
1.3.1 FPC1000 Series List:................................................................................................................... 5
1.3.2 FPC2000 Series List:................................................................................................................... 6
1.4 Features .................................................................................................................................................. 6
1.5 Application Mode................................................................................................................................... 8
1.5.1 Works as a reader......................................................................................................................... 8
1.5.2 Works as a standalone.................................................................................................................. 8
Chapter 2 Wiring Diagram................................................................................................................................. 10
2.1 FPC2001 Appearance........................................................................................................................... 10
2.2 Connector..............................................................................................................................................11
2.3 Wiring Diagram.................................................................................................................................... 13
2.4 Lock Wiring Diagram........................................................................................................................... 14
2.5 TCP/IP Network................................................................................................................................... 15
Chapter 3 Mounting ........................................................................................................................................ 17
3.1 Install FPC2001 on the Door Frame..................................................................................................... 17
Chapter 4 Operation in Sphinx........................................................................................................................ 18
4.1 Select FPC2000 Series ......................................................................................................................... 18
4.2 Search & Config FPC2001................................................................................................................... 18
4.3 Enrolling finger for user....................................................................................................................... 18
4.4 Transfer to FPC2001 terminal.............................................................................................................. 18
4.5 FPC2001 setting................................................................................................................................... 18
Chapter 5 FAQ ................................................................................................................................................ 20

KEYKING GROUP FPC2001 Biometric Reader User Manual（V1.00）
Page 3 of 20
Chapter 1 Introduction
1.1 Summary
FPC2001 is a new outstanding biometric standalone controller developed by KEYKING.
When FPC2001 works as T&A controller, employees need to press their finger on the
reader(which has to be authorized) to complete attendance. The TFT screen of FPC2000 will
display time and staff ID info. This system greatly improved the T&A simplicity and offered cost
saving on traditional tags. When FPC2000 works as an access controller, the traditional key is no
longer needed, employees can enter their special space by flashing authorized cards. FPC2000
can by itself control a door, both in and out, at least one reader is needed for one side, and the
other side can be controlled either by a reader or a Rex Button. This system provides a more
convenient and secured access environment, it also makes it possible for managers to verify the
attendance in time. FPC2000 is compatible with a big range of applications including, building
management, enterprise management, government, military and prison.
FPC2001 Appearance FPC2001 Diagram

KEYKING GROUP FPC2001 Biometric Reader User Manual（V1.00）
Page 4 of 20
FPC2001 installed on the wall
1.2 Model Definition
Model Definition:
FPC 200 1- P
P: Proximity; 125KHz;Awid, EM, HID, Keyking
U: CPU, Mifare, Mifare Sector; 13.56MHz
1: Model 0, 1, 2
200: 2000 Series, Identify fake Finger; 1000 Series, Optical senso
r
FPC: Finger Print Controller;

KEYKING GROUP FPC2001 Biometric Reader User Manual（V1.00）
Page 5 of 20
FPC2000-P------PROX: Awid, EM, HID, Keyking;
FPC2000-U------CPU: CPU, Mifare SN & Mifare Sector;
Compatible with these types card:
P: Proximity; Such as EM4100, TK4100, HID1326, 1386, AWID, KK234\250T;
U: KK1208 M1, Philips S50, Mifare-1 Compatible
Supports Multi Wiegand Output:
AWID: Follow card, up to 58bits
EM, 2308: Option-W26/34
HID, 1326, 1386: Follow card, W26/27/34/35/37 and so on
KK, KK243\250T: Follow card, W34/50 bits
1.3 Model List
1.3.1 FPC1000 Series List:

KEYKING GROUP FPC2001 Biometric Reader User Manual（V1.00）
Page 6 of 20
1.3.2 FPC2000 Series List:
1.4 Features
Standard Wiegand 26/34 output, compatible with Wiegand format access controller
Dust and water resistant, suitable for wide kinds of installations.
Quick responding, anti-interference, low power consumption and stable.
WDT circuit, self-checking function.
High speed of fingerprint matching, in 1 second.
Multithreaded code has taken full advantage of multi-core CPU
500dpi optical biometric sensor, scratch resistant.
World leading fingerprint algorithm, resistant fake fingerprint.

KEYKING GROUP FPC2001 Biometric Reader User Manual（V1.00）
Page 7 of 20
Support Chinese/English interface.
Background picture and company name can be changed base on customer’s requirement.
Specification:
CPU: ARM, 32Bits, Cortex-M4, 400MHz DSP
Memory: 4MB Flash memory+8MB RAM
Fingerprint Template: 480 pcs
Biometric sensor: 500 dpi optical biometric sensor
Verify mode: FP, FP / Card, Card + FP
Communication interfaces: Wiegand output, TCP/IP communicate
Operating voltage: 12VDC
Operating current: ≤300mA
Standby current: ≤150mA
Temperature: -20°C to 65°C
Humidity: 0--95%
Dimension: 135mm L x58mm W x 45mm
Weight: 400g

KEYKING GROUP FPC2001 Biometric Reader User Manual（V1.00）
Page 8 of 20
1.5 Application Mode
1.5.1 Works as a reader
Note:
Separated wire for FPC2001. Please do not use the wires of CAT-5 as power supply wire for FPC2001,
because FPC2001 asks big current.
1.5.2 Works as a standalone
3 Application Modes:
Standalone, no external reader
Separated wire
for power supply

KEYKING GROUP FPC2001 Biometric Reader User Manual（V1.00）
Page 9 of 20
Outdoor external reader, indoor FPC2001
Indoor external reader, outdoor FPC2001

Indoor
FPC2000
Outdoor
reade
r
Outdoor
FPC2000
Indoor
Reade
r

KEYKING GROUP FPC2001 Biometric Reader User Manual（V1.00）
Page 10 of 20
Chapter 2 Wiring Diagram
2.1 FPC2001 Appearance
Figure 2-1
LED:
Blue LED: Power indicator
Green LED: Sensor indicator（Relay on indicator）
Mounting panel
Card Area
Optical Sensor
LED(Blue&Green)
Mounting
Screw
Mounting
Screw
Mounting
Screw
Cable Hole
86mm

KEYKING GROUP FPC2001 Biometric Reader User Manual（V1.00）
Page 11 of 20
2.2 Connector
Figure 2-2 FPC2001 Back
Connector No. Symbol Description Connector No. Symbol Description
J1
1 NC
Relay, Lock J2
4 BUT Exit Button
2 COM 5 SEN Door Sensor
3 NO 6 GND Ground
J3
7 D1_Out
Wiegand_Out J4
11 D1_In
Wiegand_In
8 D0_ Out 12 D0_ In
9 GND 13 GND
10 +12V 14 +12V
J5 TCP/IP, POE J6 RS232, Reserved
Sheet 2-1
J1: Relay
J5: TCP/IP, POE
J4: Wiegand_In
J2: Exit Button,
Door sensor
J3: Wiegand_Out

KEYKING GROUP FPC2001 Biometric Reader User Manual（V1.00）
Page 12 of 20
J1: Relay output
NC: Normal Closed
COM: Common
NC: Normal Closed
Choose matched terminal for different electronic lock.
J2: Rex Button, Door Sensor input
BUT: Rex Button,
SEN: Door contact
GND: Ground
J2: Relay output
Based on customized lock model and power requirement.
J3: Wiegand Output
D1_Out : Data 1 of Wiegand Output
D0_ Out : Data 1 of Wiegand Output
GND: Ground
+12V: 12Vdc
J4: Wiegand Input
D1_In : Data 1 of Wiegand Input
D0_ In : Data 1 of Wiegand Input
GND: Ground
+12V: 12Vdc
J5: TCP/IP interface
Customer can set all configurations when it’s connected to host PC. Moreover user
authorization and exporting card events can also be done via manage software.

KEYKING GROUP FPC2001 Biometric Reader User Manual（V1.00）
Page 13 of 20
To use a switch HUB or directly connect to host PC via Ethernet port.
POE available, Power Over Ethernet
DIP Switch:
DIP 1: ON---Disconnect(will not be connected to the software), OFF---Connect
DIP 2: ON---Enable WDT(Watch Dog), OFF--- Disable WDT(Watch Dog)
Default Setting (Right picture):
DIP 1: OFF---Connect, will be connected to the software
DIP 2: ON---Enable WDT(Watch Dog), More stable
2.3 Wiring Diagram
Figure 2-2 FPC2001 work as a fingerprint reader only.
Note:
1. Separated Power for FPC2001: Use a separated RVV2*1.0 wire as the power cable from controller or a
separated power supply. And connect the GND together once you use a separated power for panel and

KEYKING GROUP FPC2001 Biometric Reader User Manual（V1.00）
Page 14 of 20
FPC2001. Do not use the UTP_CAT5 as the power cable for FPC2001, do not get the power from reader
socket of panel directly.
2. Reader Fuse - 135mA only: If you get the power from panel, please connect to the power input
connector directly, do not connect to the reader socket directly. Otherwise the current will exceed the fuse
limitation, and the FPC2001 will not work.
2.4 Lock Wiring Diagram
J1: Relay Output（Lock Control）
As shown below.
Figure 2-5 Electronic Strike Lock
Figure 2-6 Magnetic Lock（Fail safe）
Figure 2-7 Cathode lock（Fail secure）

KEYKING GROUP FPC2001 Biometric Reader User Manual（V1.00）
Page 15 of 20
2.5 TCP/IP Network
FPC2000 TCP/IP network
Figure 2-8
TCP/IP crystal head
Figure 2-9
Figure 2-2
Normal net cable（to switch）
RJ45 NO. Definition
1 TX+
2 TX-
3 RX+
6 RX-
8←1 8←1

KEYKING GROUP FPC2001 Biometric Reader User Manual（V1.00）
Page 16 of 20
Figure 2-10
Crossed cable（to PC）
Figure 2-11
8←1 8←1

KEYKING GROUP FPC2001 Biometric Reader User Manual（V1.00）
Page 17 of 20
Chapter 3 Mounting
3.1 Install FPC2001 on the Door Frame
1. Hole for cable: Drill a hole on the door frame for cable out (size:28x26mm) where you want to install your
reader.
2. Mounting "Mounting Panel" on frame with 2 screws.
3. Wiring: Design the wiring between reader and controller, then process wiring.
4. Connection: Please refer to chapter 2 of the connections.
5. Mounting FPC2001.
Mounting panel
Mounting
Screw
Mounting
Screw
Mounting
Screw
Cable Hole
86mm

KEYKING GROUP FPC2001 Biometric Reader User Manual（V1.00）
Page 18 of 20
Chapter 4 Operation in Sphinx
4.1 Select FPC2000 Series
1. Select "FPC2000 Series" in "Setup / Communication / Fingerprint" of Sphinx.
4.2 Search & Config FPC2001
1. Click "NT" to search FPC2001.
2. Save it when you see it in the controller list.
4.3 Enrolling finger for user
1. Enrolling fingerprint through the FPC2001 in "personnel information / Fingerprint".
2. Admin User: Setup at least one user as a "Admin", then somebody else can not access the menu to manage
it. If you did not setup any "Admin User", everybody can manage FPC2000 to add user or something else.
4.4 Transfer to FPC2001 terminal
1. Select these FPC2001 you would like to download.
4.5 FPC2001 setting
Select these FPC2001 you would like to setup. While you setup FPC2001, please make sure it is online.

KEYKING GROUP FPC2001 Biometric Reader User Manual（V1.00）
Page 19 of 20
Here you can change the Company name and everything.
When you click Apply, then done.
No display
Tamper Alarm
Separated Transaction
of Finger Identify

KEYKING GROUP FPC2001 Biometric Reader User Manual（V1.00）
Page 20 of 20
Chapter 5 FAQ
NO Descriptions Solution
1 No response for flashing（indicator off, buzzer
no beeping）
Power problem（check power supply）
Invalid card type（use supported card）
2 Door stays opened Set short relay responding time in manage
menu
3 FP or card information missing Register FP/Card in PC.(Connect to PC first)
4 Can not open door by flashing card or FP.
Device not power up（FPC2001, Lock）
Invalid card/FP（register your card/FP）
Door open mode (Set to Card or Card / FP)
5 Can not open the door when it’s Card+FP mode
Invalid card（register your card）
Invalid FP（register your FP）
Over interval time between flash card and
verify FP.
6 Door bell not working
No connected door bells
Cable problem
Faulty door bells
7 Wrong Time/Date Set Time/Date in manage menu.
