Keysight Technologies 53150A User manual

Keysight 53150A/151A/152A
Microwave Frequency
Counter
This guide describes how to use the Keysight 53150A, 53151A, and
53152A Microwave Frequency Counters. The information in this guide
applies to instruments having the number prefix listed below, unless
accompanied by a “Manual Updating Changes” package indicating
otherwise.
SERIAL PREFIX NUMBER: 3735A, US3925, and US4050 (53150A)
3736A, US3926, and US4051 (53151A)
3737A, US3927, and US4052 (53152A)
Operating
Guide

2 Keysight 53150A/151A/152A Operating Guide
Notices
Copyright Notice
© Keysight Technologies 1999 - 2017
No part of this manual may be repro-
duced in any form or by any means
(including electronic storage and
retrieval or translation into a foreign
language) without prior agreement and
written consent from Keysight Technol-
ogies as governed by United States and
international copyright laws.
Manual Part Number
53150-90013
Edition
Edition 3, August 1, 2017
Printed in:
Printed in Malaysia
Published by:
Keysight Technologies
Bayan Lepas Free Industrial Zone,
11900 Penang, Malaysia
Technology Licenses
The hardware and/or software
described in this document are fur-
nished under a license and may be
used or copied only in accordance with
the terms of such license.
Declaration of Conformity
Declarations of Conformity for this
product and for other Keysight prod-
ucts may be downloaded from the
Web. Go to http://www.keysight.com/
go/conformity. You can then search by
product number to find the latest Dec-
laration of Conformity.
U.S. Government Rights
The Software is “commercial computer
software,” as defined by Federal Acqui-
sition Regulation (“FAR”) 2.101. Pursu-
ant to FAR 12.212 and 27.405-3 and
Department of Defense FAR Supple-
ment (“DFARS”) 227.7202, the U.S.
government acquires commercial com-
puter software under the same terms
by which the software is customarily
provided to the public. Accordingly,
Keysight provides the Software to U.S.
government customers under its stan-
dard commercial license, which is
embodied in its End User License
Agreement (EULA), a copy of which can
be found at http://www.keysight.com/
find/sweula. The license set forth in the
EULA represents the exclusive authority
by which the U.S. government may use,
modify, distribute, or disclose the Soft-
ware. The EULA and the license set
forth therein, does not require or per-
mit, among other things, that Keysight:
(1) Furnish technical information
related to commercial computer soft-
ware or commercial computer software
documentation that is not customarily
provided to the public; or (2) Relinquish
to, or otherwise provide, the govern-
ment rights in excess of these rights
customarily provided to the public to
use, modify, reproduce, release, per-
form, display, or disclose commercial
computer software or commercial com-
puter software documentation. No
additional government requirements
beyond those set forth in the EULA
shall apply, except to the extent that
those terms, rights, or licenses are
explicitly required from all providers of
commercial computer software pursu-
ant to the FAR and the DFARS and are
set forth specifically in writing else-
where in the EULA. Keysight shall be
under no obligation to update, revise or
otherwise modify the Software. With
respect to any technical data as
defined by FAR 2.101, pursuant to FAR
12.211 and 27.404.2 and DFARS
227.7102, the U.S. government
acquires no greater than Limited Rights
as defined in FAR 27.401 or DFAR
227.7103-5 (c), as applicable in any
technical data.
Warranty
THE MATERIAL CONTAINED IN THIS
DOCUMENT IS PROVIDED “AS IS,”
AND IS SUBJECT TO BEING
CHANGED, WITHOUT NOTICE, IN
FUTURE EDITIONS. FURTHER, TO THE
MAXIMUM EXTENT PERMITTED BY
APPLICABLE LAW, KEYSIGHT DIS-
CLAIMS ALL WARRANTIES, EITHER
EXPRESS OR IMPLIED, WITH REGARD
TO THIS MANUAL AND ANY INFORMA-
TION CONTAINED HEREIN, INCLUD-
ING BUT NOT LIMITED TO THE
IMPLIED WARRANTIES OF MER-
CHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE. KEYSIGHT
SHALL NOT BE LIABLE FOR ERRORS
OR FOR INCIDENTAL OR CONSE-
QUENTIAL DAMAGES IN CONNECTION
WITH THE FURNISHING, USE, OR
PERFORMANCE OF THIS DOCUMENT
OR OF ANY INFORMATION CON-
TAINED HEREIN. SHOULD KEYSIGHT
AND THE USER HAVE A SEPARATE
WRITTEN AGREEMENT WITH WAR-
RANTY TERMS COVERING THE MATE-
RIAL IN THIS DOCUMENT THAT
CONFLICT WITH THESE TERMS, THE
WARRANTY TERMS IN THE SEPARATE
AGREEMENT SHALL CONTROL.
Safety Information
CAUTION
A CAUTION notice denotes a hazard. It
calls attention to an operating proce-
dure, practice, or the like that, if not
correctly performed or adhered to,
could result in damage to the product
or loss of important data. Do not pro-
ceed beyond a CAUTION notice until
the indicated conditions are fully
understood and met.
WARNING
A WARNING notice denotes a hazard. It
calls attention to an operating proce-
dure, practice, or the like that, if not
correctly performed or adhered to,
could result in personal injury or death.
Do not proceed beyond a WARNING
notice until the indicated conditions are
fully understood and met.

Keysight 53150A/151A/152A Operating Guide 3
Safety Symbols
The following symbols on the instrument and in the documentation indicate
precautions which must be taken to maintain safe operation of the instrument.
Caution, risk of danger (refer to this
manual for specific Warning or Caution
information)
Caution, risk of electric shock
Earth (ground) terminal Frame or chassis (ground) terminal
Alternating current (AC) Direct current (DC)

4 Keysight 53150A/151A/152A Operating Guide
Detailed Warranty Information
Keysight does not warrant that the operation of Keysight products will be
uninterrupted or error free. If Keysight is unable, within a reasonable time, to
repair or replace any product to a condition as warranted, customer will be
entitled to a refund of the purchase price upon prompt return of the product.
Keysight products may contain remanufactured parts equivalent to new in
performance or may have been subjected to incidental use.
The warranty period begins on the date of delivery or on the date of installation if
installed by Keysight. If customer schedules or delays Keysight installation more
than 30 days after delivery, warranty begins on the 31st day from delivery.
Warranty does not apply to defects resulting from (a) improper or inadequate
maintenance or calibration, (b) software, interfacing, parts or supplies not
supplied by Keysight, (c) unauthorized modification or misuse, (d) operation
outside of the published environmental specifications for the product, or
(e) improper site preparation or maintenance.
TO THE EXTENT ALLOWED BY LOCAL LAW, THE ABOVE WARRANTIES ARE
EXCLUSIVE AND NO OTHER WARRANTY OR CONDITION, WHETHER WRITTEN
OR ORAL, IS EXPRESSED OR IMPLIED AND KEYSIGHT SPECIFICALLY DISCLAIMS
ANY IMPLIED WARRANTIES OR CONDITIONS OF MERCHANTABILITY,
SATISFACTORY QUALITY, AND FITNESS FOR A PARTICULAR PURPOSE.
Keysight will be liable for damage to tangible property per incident up to the
greater of $300,000 or the actual amount paid for the product that is the subject
of the claim, and for damages for bodily injury or death, to the extent that all such
damages are determined by a court of competent jurisdiction to have been
directly caused by a defective Keysight product.
TO THE EXTENT ALLOWED BY LOCAL LAW, THE REMEDIES IN THIS WARRANTY
STATEMENT ARE CUSTOMER’S SOLE AND EXCLUSIVE REMEDIES. EXCEPT AS
INDICATED ABOVE, IN NO EVENT WILL KEYSIGHT OR ITS SUPPLIERS BE LIABLE
FOR LOSS OF DATA OR FOR DIRECT, SPECIAL, INCIDENTAL, CONSEQUENTIAL
(INCLUDING LOST PROFIT OR DATA), OR OTHER DAMAGE, WHETHER BASED IN
CONTRACT, TORT, OR OTHERWISE.
For consumer transactions in Australia and New Zealand: the warranty terms
contained in this statement, except to the extent lawfully permitted, do not
exclude, restrict or modify and are in addition to the mandatory statutory rights
applicable to the sale of this product to you.

Keysight 53150A/151A/152A Operating Guide 5
Safety Considerations
Read the information below before using this instrument.
The following general safety precautions must be observed during all phases of
operation, service, and repair of this instrument. Failure to comply with these
precautions or with specific warnings elsewhere in this manual violates safety
standards for design, manufacture, and intended use of the instrument. Keysight
Technologies assumes no liability for the customer’s failure to comply with these
requirements.
Whenever it is likely that the protection has been impaired, the instrument must
be made inoperative and be secured against any unintended operation.
If this instrument is to be energized via an autotransformer (for voltage reduction),
make sure the common terminal is connected to the earthed pole terminal
(neutral) of the power source.
Instructions for adjustments while covers are removed and for servicing are for use
by trained personnel only. To avoid dangerous electric shock, do not perform such
adjustments or servicing unless qualified to do so.
For continued protection against fire, replace the line fuse(s) with fuses of the
same current rating and type (for example, normal blow, time delay). Do not use
repaired fuses or short-circuited fuseholders.
WARNING Instructions for adjustments while covers are removed and for servicing are
for use by service-trained personnel only. To avoid dangerous electric shock,
do not perform such adjustments or servicing unless qualified to do so.
WARNING Any interruption of the protective grounding conductor (inside or outside the
product's circuitry) or disconnecting the protective earth terminal will cause
a potential shock hazard that could result in personal injury (grounding one
conductor of a two conductor outlet is not sufficient protection).

6 Keysight 53150A/151A/152A Operating Guide
Safety Earth Ground
An uninterruptible safety earth ground must be maintained from the mains power
source to the product’s ground circuitry.
Acoustic Noise Emissions
LpA<47 dB at operator position, at normal operation, tested per EN 27779. All
data are the results from type test.
Geräuschemission
LpA<47 dB am Arbeits platz, normaler Betrieb, geprüft nach EN 27779. Die
Angagen beruhen auf Ergebnissen von Typenprüfungen.
Electrostatic Discharge Immunity Testing
When the product is tested with 8kV AD, 4kV CD and 4kV ID according to
IEC801-2, a system error may occur that may affect measurement data made
during these disturbances. After these occurrences, the system self-recovers
without user intervention.
WARNING When measuring power line signals, be extremely careful and always use a
step-down isolation transformer which output is compatible with the input
measurement capabilities of this product. This product’s front and rear
panels are typically at earth ground. Thus, never try to measure ac power
line signals without an isolation transformer.

Keysight 53150A/151A/152A Operating Guide 7
Waste Electrical and Electronic Equipment (WEEE) Directive
This instrument complies with the WEEE Directive marking requirement. This
affixed product label indicates that you must not discard this electrical or
electronic product in domestic household waste.
Product category:
With reference to the equipment types in the WEEE directive Annex 1, this
instrument is classified as a “Monitoring and Control Instrument” product.
The affixed product label is as shown below.
Do not dispose in domestic household waste.
To return this unwanted instrument, contact your nearest Keysight Service Center,
or visit http://about.keysight.com/en/companyinfo/environment/takeback.shtml
for more information.
Sales and Technical Support
To contact Keysight for sales and technical support, refer to the support links on
the following Keysight websites:
–www.keysight.com/find/53150A
(product-specific information and support, software and
documentation updates)
–www.keysight.com/find/assist
(worldwide contact information for repair and service)

8 Keysight 53150A/151A/152A Operating Guide
THIS PAGE HAS BEEN INTENTIONALLY LEFT BLANK.

Keysight 53150A/151A/152A Operating Guide 9
Table of Contents
Safety Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Detailed Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Safety Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Safety Earth Ground . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Acoustic Noise Emissions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Geräuschemission . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Electrostatic Discharge Immunity Testing . . . . . . . . . . . . . . . . . . . . . . . .6
Waste Electrical and Electronic Equipment (WEEE) Directive . . . . . . . .7
Product category: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Sales and Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
List of Figures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
List of Tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
1 In This Guide
Contents and Organization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Related Documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Types of Service Available if Instrument Fails . . . . . . . . . . . . . . . . . . . .20
Standard Repair Services (Worldwide) . . . . . . . . . . . . . . . . . . . . . . .20
Express Repair/Performance Calibration Service (USA Only) . . . . .20
Repair Instrument Yourself . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Repackaging for Shipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Description of the Microwave Frequency Counter . . . . . . . . . . . . . . . .22
Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Retrofit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Accessories Supplied and Available . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Accessories Supplied . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Accessories Available . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

10 Keysight 53150A/151A/152A Operating Guide
Manuals Supplied . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Keysight 53150A/151A/152A Quick Reference Guide . . . . . . . . . . . . . 25
1 Getting Started
The Front Panel at a Glance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
The Front Panel Indicators at a Glance . . . . . . . . . . . . . . . . . . . . . . . . . 29
The Front Panel Menus at a Glance . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
The Display Annunciators at a Glance . . . . . . . . . . . . . . . . . . . . . . . . . . 31
The Display Special Characters at a Glance . . . . . . . . . . . . . . . . . . . . . 33
The Rear Panel at a Glance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Operating the Counter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Turning the Counter On . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Turning the Display Backlight Off or On . . . . . . . . . . . . . . . . . . . . . . 38
Using the Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Selecting the Input Channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Measuring Frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Measuring Relative Frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Offsetting a Frequency Measurement . . . . . . . . . . . . . . . . . . . . . . . 47
Measuring Power (Channel 2 Only) . . . . . . . . . . . . . . . . . . . . . . . . . 49
Selecting the Unit of Measurement for Power . . . . . . . . . . . . . . . . . 50
Measuring Relative Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Offsetting a Power Measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Using Power Correction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Setting the Measurement Rate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Setting the Number of Averages . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Setting the Resolution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
2 Operating Your Frequency Counter
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Chapter Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
How this Counter Works for You . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Summary of the Measurement Sequence . . . . . . . . . . . . . . . . . . . . . . . 66
Using the Selection Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Sequencing Through the Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Keysight 53150A/151A/152A Operating Guide 11
Numeric Entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .68
Changing States . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .69
Using the Clear and Reset/Local Keys . . . . . . . . . . . . . . . . . . . . . . . . .71
Acknowledging Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .71
Other Function Selection Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .72
Measuring Frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .74
Setting the Resolution and Measurement Rate . . . . . . . . . . . . . . . . . . .76
Setting the Resolution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .76
Setting the Measurement Rate . . . . . . . . . . . . . . . . . . . . . . . . . . . . .78
Setting the Number of Averages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .80
Measuring Relative Frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .83
Offsetting a Frequency Measurement . . . . . . . . . . . . . . . . . . . . . . . . . .84
Measuring Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .87
Measuring Relative Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .89
Offsetting a Power Measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .90
Using Power Correction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .92
Power Correction Theory of Operation . . . . . . . . . . . . . . . . . . . . . . .93
Increasing Profile Accuracy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .94
Power Correction Examples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .94
Using the Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .101
3 Specifications
A Rack Mounting the Counter
Rack Mounting the Counter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .114
B Messages
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .118
Status Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .119
Self-Test Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .120
Error Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .121
C Using the Battery Option

12 Keysight 53150A/151A/152A Operating Guide
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
Operating the Counter from the Batteries . . . . . . . . . . . . . . . . . . . . . . 125
Operating the Counter from a DC Power Source . . . . . . . . . . . . . . . . 127
Replacing the Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
Removing the Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
Installing Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
Charging the Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133

Keysight 53150A/151A/152A Operating Guide 13
List of Figures
Figure C-1 Battery Charge Level Indicator . . . . . . . . . . . . . . . . .125
Figure C-2 External DC Power Socket . . . . . . . . . . . . . . . . . . . . .127
Figure C-3 Removing and Installing Batteries . . . . . . . . . . . . . . .129

14 Keysight 53150A/151A/152A Operating Guide
THIS PAGE HAS BEEN INTENTIONALLY LEFT BLANK.

Keysight 53150A/151A/152A Operating Guide 15
List of Tables
Table 2-1 Factory Default Function Settings . . . . . . . . . . . . . . .107
Table B-1 Status Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . .119
Table B-2 Self-Test Messages . . . . . . . . . . . . . . . . . . . . . . . . . .120
Table B-3 Error Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .121

16 Keysight 53150A/151A/152A Operating Guide
THIS PAGE HAS BEEN INTENTIONALLY LEFT BLANK.

Keysight 53150A/151A/152A Microwave Frequency Counter
Operating Guide
17
In This Guide
This book is the operating guide for the Keysight 53150A (20 GHz), 53151A
(26.5 GHz), and 53152A (46 GHz) Frequency Counters. It consists of a table of
contents, this preface, a quick reference guide, three chapters, three appendices,
and an index.
This preface contains the following information:
–Contents and Organization pg. 18
–Related Documents pg. 19
–Types of Service Available if Instrument Fails pg. 20
–Repackaging for Shipment pg. 21
–Description of the Microwave Frequency Counter pg. 22
–Options pg. 23
–Accessories Supplied and Available pg. 24
–Manuals Supplied pg. 24

In This Guide
18 Keysight 53150A/151A/152A Operating Guide
Contents and Organization
The Quick Reference Guide consists of a Menu Tree (tear-out sheet) that serves
as a tool to trigger your memory or get you quickly reacquainted with the
instrument.
Chapter 1 Getting Started is a quick-start guide that gives you a brief overview of
the Counter's keys, indicators, menus, display, and connectors. A graphical
procedure for performing a measurement is
also provided.
Chapter 2 Operating Your Instrument is an operator's reference.
You are given an overview of each group of front-panel keys, operating functions,
and menus followed by a series of exercises that guide you through the operation
of the Counter.
Chapter 3 Specifications lists the specifications and characteristics of the
Counter.
Appendix A Rack Mounting the Counter provides rack-mounting procedures for
the Counter.
Appendix B Messages lists and explains all of the messages that are displayed on
the Counter’s front panel and/or sent over the RS-232
serial interface.
Appendix C Using the Battery Option explains how to use the Counter with the
Battery option.
Index

In This Guide
Keysight 53150A/151A/152A Operating Guide 19
Related Documents
For more information on frequency counters refer to the following Series 200
Application Notes:
–Fundamentals of Electronic Frequency Counters,
Application Note 200—Keysight part number 02-5952-7506.
–Understanding Frequency Counter Specifications,
Application Note 200-4—Keysight part number 02-5952-7522.
–Fundamentals of Time and Frequency Standards,
Application Note 52-1—Keysight part number 02-5952-7870.

In This Guide
20 Keysight 53150A/151A/152A Operating Guide
Types of Service Available if Instrument Fails
If your Counter fails within one year of original purchase, Keysight will repair it free
of charge. If your instrument fails after your one-year warranty expires, Keysight
will repair it, or you can repair it yourself.
There are three types of repair services:
– Standard repair service—if downtime is not critical.
– Express Repair/Performance Calibration Service—if downtime is critical.
– Owner repair—repair the unit yourself using the Assembly-Level Service Guide.
Standard Repair Services (Worldwide)
Contact your nearest Keysight Service Center to arrange to have your Counter
repaired.
Express Repair/Performance Calibration Service (USA Only)
If downtime is critical, you can receive your repaired Counter via overnight
shipment. Just call 1-800-403-0801 and ask for Express Repair/Performance
Calibration Service. When your Counter is repaired, it will be returned via
overnight shipment.
Repair Instrument Yourself
If you choose to repair the instrument yourself or would like more details on self
test and calibration, use the procedures in the Assembly-Level Service Guide.
