Keysight Technologies E5053A User manual

User’s Guide
Keysight E5053A
Microwave Downconverter

Notices
© Keysight Technologies
2005-2019
No part of this manual may be
reproduced in any form or by any
means (including electronic storage
and retrieval or translation into a
foreign language) without prior
agreement and written consent from
Keysight Technologies, Inc. as
governed by United States and
international copyright laws.
Trademark Acknowledgments
Manual Part Number
E5053-90020
Edition
Edition 4, April 2019
Printed in Malaysia
Published by:
Keysight Technologies International
Japan G.K,
1-3-3 Higashikawasaki-cho
Chuo-ku
Kobe-shi, Hyogo, Japan
Warranty
THE MATERIAL CONTAINED IN THIS
DOCUMENT IS PROVIDED “AS IS,”
AND IS SUBJECT TO BEING
CHANGED, WITHOUT NOTICE, IN
FUTURE EDITIONS. FURTHER, TO
THE MAXIMUM EXTENT PERMITTED
BY APPLICABLE LAW, KEYSIGHT
DISCLAIMS ALL WARRANTIES,
EITHER EXPRESS OR IMPLIED WITH
REGARD TO THIS MANUAL AND
ANY INFORMATION CONTAINED
HEREIN, INCLUDING BUT NOT
LIMITED TO THE IMPLIED
WARRANTIES OF
MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE.
KEYSIGHT SHALL NOT BE LIABLE
FOR ERRORS OR FOR INCIDENTAL
OR CONSEQUENTIAL DAMAGES IN
CONNECTION WITH THE
FURNISHING, USE, OR
PERFORMANCE OF THIS
DOCUMENT OR ANY INFORMATION
CONTAINED HEREIN. SHOULD
KEYSIGHT AND THE USER HAVE A
SEPARATE WRITTEN AGREEMENT
WITH WARRANTY TERMS
COVERING THE MATERIAL IN THIS
DOCUMENT THAT CONFLICT WITH
THESE TERMS, THE WARRANTY
TERMS IN THE SEPARATE
AGREEMENT WILL CONTROL.
Technology Licenses
The hardware and/or software
described in this document are
furnished under a license and may be
used or copied only in accordance
with the terms of such license.
Declaration of Conformity
Declarations of Conformity for this
product and for other Keysight
products may be downloaded from
the Web. Go to
http://www.keysight.com/go/confor
mity. You can then search by product
number to find the latest Declaration
of Conformity.
U.S. Government Rights
The Software is “commercial
computer software,” as defined by
Federal Acquisition Regulation
(“FAR”) 2.101. Pursuant to FAR
12.212 and 27.405-3 and
Department of Defense FAR
Supplement (“DFARS”) 227.7202, the
U.S. government acquires
commercial computer software
under the same terms by which the
software is customarily provided to
the public. Accordingly, Keysight
provides the Software to U.S.
government customers under its
standard commercial license, which
is embodied in its End User License
Agreement (EULA), a copy of which
can be found at
http://www.keysight.com/find/sweu
laThe license set forth in the EULA
represents the exclusive authority by
which the U.S. government may use,
modify, distribute, or disclose the
Software. The EULA and the license
set forth therein, does not require or
permit, among other things, that
Keysight: (1) Furnish technical
information related to commercial
computer software or commercial
computer software documentation
that is not customarily provided to
the public; or (2) Relinquish to, or
otherwise provide, the government
rights in excess of these rights
customarily provided to the public to
use, modify, reproduce, release,
perform, display, or disclose
commercial computer software or
commercial computer software
documentation. No additional
government requirements beyond
those set forth in the EULA shall
apply, except to the extent that those
terms, rights, or licenses are
explicitly required from all providers
of commercial computer software
pursuant to the FAR and the DFARS
and are set forth specifically in
writing elsewhere in the EULA.
Keysight shall be under no obligation
to update, revise or otherwise modify
the Software. With respect to any
technical data as defined by FAR
2.101, pursuant to FAR 12.211 and
27.404.2 and DFARS 227.7102, the
U.S. government acquires no greater
than Limited Rights as defined in FAR
27.401 or DFAR 227.7103-5 (c), as
applicable in any technical data.
Safety Notices
A CAUTION notice denotes a hazard. It
calls attention to an operating
procedure, practice, or the like that,
if not correctly performed or adhered
to, could result in damage to the
product or loss of important data. Do
not proceed beyond a CAUTION
notice until the indicated conditions
are fully understood and met.
A WARNING notice denotes a hazard.
It calls attention to an operating
procedure, practice, or the like that,
if not correctly performed or adhered
to, could result in personal injury or
death. Do not proceed beyond a
WARNING notice until the indicated
conditions are fully understood and
met.

3
Keysight E5053A Microwave Downconverter
User’s Guide
Caution
Safety Summary
The following general safety precautions must be observed during all phases of
operation, service, and repair of this instrument. Failure to comply with these
precautions or with specific WARNINGS elsewhere in this manual may impair
the protection provided by the equipment. Such noncompliance would also
violate safety standards of design, manufacture, and intended use of the
instrument. Keysight Technologies assumes no liability for the customer’s
failure to comply with these precautions.
Do not exceed the operating input power, voltage, and current level and signal
type appropriate for the instrument being used, refer to your instrument’s
Function Reference.
Electrostatic discharge (ESD) can damage the highly sensitive microcircuits in
your instrument. ESD damage is most likely to occur as the test fixtures are
being connected or disconnected. Protect them from ESD damage by wearing
a grounding strap that provides a high resistance path to ground. Alternatively,
ground yourself to discharge any static charge built-up by touching the outer
shell of any grounded instrument chassis before touching the test port
connectors.
The E5053A complies with INSTALLATION CATEGORY II as well as
POLLUTION DEGREE 2 in IEC61010-1. The E5053A is an INDOOR USE
product.
The LEDs in the E5053A are Class 1 in accordance with IEC60825-1,
CLASS 1 LED PRODUCT
This equipment is MEASUREMENT CATEGORY I (CAT I). Do not use for CAT
II, III, or IV.

4 Keysight E5053A Microwave Downconverter
Caution
Safety Summary
-
• Ground the Instrument
To avoid electric shock, the instrument chassis and cabinet must be
grounded with the supplied power cable’s grounding prong.
• Do NOT Operate in an Explosive Atmosphere
Do not operate the instrument in the presence of inflammable gases or
fumes. Operation of any electrical instrument in such an environment
clearly constitutes a safety hazard.
• Keep Away from Live Circuits
Operators must not remove instrument covers. Component replacement
and internal adjustments must be made by qualified maintenance
personnel. Do not replace components with the power cable connected.
Under certain conditions, dangerous voltage levels may remain even after
the power cable has been disconnected. To avoid injuries, always
disconnect the power and discharge circuits before touching them.
• DO NOT Service or Adjust the Instrument Alone
Do not attempt internal service or adjustment unless another person,
capable of rendering first aid and resuscitation, is present.
• Do NOT Substitute Parts or Modify the Instrument
To avoid the danger of introducing additional hazards, do not install
substitute parts or perform unauthorized modifications to the instrument.
Return the instrument to a Keysight Technologies Sales and Service Office
for service and repair to ensure that safety features are maintained in
operational condition.
• Dangerous Procedure Warnings
Warnings, such as the example below, precede potentially dangerous
procedures throughout this manual. Instructions contained in the warnings
must be followed.
This equipment is tested with stand-alone condition or with the
combination with the accessories supplied by Keysight Technologies
against the requirement of the standards described in the Declaration of
Conformity. If it is used as a system component, compliance of related
regulations and safety requirements are to be confirmed by the builder of
the system.
Dangerous voltage levels, capable of causing death, are present in this
instrument. Use extreme caution when handling, testing, and adjusting
this instrument.

Keysight E5053A Microwave Downconverter 5
Caution
Safety Symbols
Safety Symbols
General definitions of safety symbols used on the instrument or in manuals are
listed below.
Certification
Keysight Technologies certifies that this product met its published
specifications at the time of shipment from the factory. Keysight Technologies
further certifies that its calibration measurements are traceable to the United
States National Institute of Standards and Technology, to the extent allowed
by the Institution’s calibration facility or by the calibration facilities of other
International Standards Organization members.
Exclusive Remedies
The remedies provided herein are Buyer’s sole and exclusive remedies.
Keysight Technologies shall not be liable for any direct, indirect, special,
incidental, or consequential damages, whether based on contract, tort, or any
other legal theory.
Assistance
Product maintenance agreements and other customer assistance agreements
are available for Keysight Technologies products.
Instruction Manual symbol: the product is marked with this
symbol when it is necessary for the user to refer to the instrument
manual.
Alternating current.
Direct current.
On (Supply).
Off (Supply).
A chassis terminal; a connection to the instrument’s chassis,
which includes all exposed metal structure.
Standby.

6 Keysight E5053A Microwave Downconverter
Caution
Safety Symbols
-
For any assistance, contact your nearest Keysight Technologies Sales and
Service Office. Addresses are provided at the back of this manual.

Contents
Keysight E5053A User’s Guide 7
Table of Contents
Caution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Safety Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Safety Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Certification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Exclusive Remedies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Assistance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1. Installation
Incoming inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Requirements for installation environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Operating environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Heat dissipation clearance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Antistatic measures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Providing space to disconnect the power cable’s plug. . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Mounting front handles/flanges for rackmount. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Mounting handle kit (Option 1CN). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Mounting rackmount kit (Option 1CM) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Mounting rackmount/handle kit (Option 1CP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Power supply and fuse . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Checking the power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Setting up the fuse . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Checking and connecting the power cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Starting up E5053A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Turning ON/OFF the power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Cutting power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
2. Overview of Product
About This Product . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Names and Functions of Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
3. Connecting Devices to E5052B for Operation
Connecting E5052B and E5053A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Required Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Connection on Front Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Connection on Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Turning on Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Basic Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

8 Keysight E5053A User’s Guide
Contents
4. Information on Maintenance
Cleaning this Instrument . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Maintenance of Interconnection Ports and Test Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Cleaning a Display Other than Interconnection Ports and Test Ports . . . . . . . . . . . . . . . .31
Cautions Applicable to Requesting Repair, Replacement, Regular Calibration, etc. . . . . . . .32
Devices to be Sent Back for Repair or Regular Calibration . . . . . . . . . . . . . . . . . . . . . . . .32
Recommended Calibration Period . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
A. Manual Changes
Manual Changes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33

9
Keysight E5053A Microwave Downconverter
User’s Guide
1 Installation
This chapter provides information on how to set up the Keysight E5053A
microwave downconverter.
Incoming inspection
When you receive the product, follow the steps below to perform the incoming
inspection.
Step 1. Check the shipping container and cushioning material for damage.
Step 2. Check the contents of the package for mechanical damage or defects.
Step 3. Check the contents of the shipment using Table 1-1 and Figure 1-1 to see if
all your specified options are complete.
Step 4. If you detect any of the following in the inspection, contact you nearest
Keysight Technologies sales office.
1. If the shipping container or cushioning material is damaged or the
cushioning material shows signs of unusual stress.
2. If you find any mechanical damage or defect to the contents.
3. If the contents of the shipment are not complete.
4. If you find any fault with the product during operational checks described
below.
If there are signs of shipping damage to any portion of the outer enclosure
when opening the package (for example, the cover, front/rear panel, power
switch, and port connectors), do not turn on the power. You may get an
electrical shock.
If the shipping container or cushioning material is damaged, it should be
kept until all the other inspections have been done.

10 Keysight E5053A Microwave Downconverter
Installation
Incoming inspection
1-
In the case of 1, notify the carrier as well as your nearest Keysight
Technologies sales office. Keep the shipping container, cushioning material,
and the contents of the shipment for the carrier's inspection.
Table 1-1 Contents of the E5053A package
Name Keysight
product/part number
Qty
Standard contents
oE5053A E5053A 1
oPower cable18120-4753 1
oUSB cable 8121-0770 1
oRF SMA cable E5053-61621 2
oRF SMA cable E5053-61622 2
oBNC(m)-BNC(m) cable, 61 cm 8120-1839 1
o3.5(f)-3.5(f) adapter25061-5311 1
oBNC adapter 1250-1859 1
Option
oManual (Option ABA)3
•User’sGuide E5053-900x0 1
oHandle kit (Option 1CN)45063-9227 1
oRackmount kit (Option 1CM)55063-9214 1
E5053-61623 2
E5053-61624 2
oRackmount/handle kit (Option 1CP)55063-9221 1
E5053-61623 2
E5053-61624 2
1. This accessory varies from country to country. For the power cable option, see
http://www.keysight.com/find/powercords.
2. The contents of these accessories are not shown in Figure 1-1.
3. The number of “x” in the part number of the manual, 0 for the first edition, is
incremented by 1 each time a revision is made. The latest edition comes with the
product. The PDF version of user manual is available at
http://www.keysight.com/manuals/e5053a.
4. The contents of these accessories are not shown in Figure 1-1. For more informa-
tion on them, refer to Antistatic Measurement table.

Keysight E5053A Microwave Downconverter 11
Installation
Incoming inspection
Figure 1-1 Accessories

12 Keysight E5053A Microwave Downconverter
Installation
Requirements for installation environment
1-
Requirements for installation environment
Install the E5053A under an environment that satisfies the following
conditions.
Operating environment
Use the E5053A under the following environmental conditions.
Temperature 10 ˚C to 40 ˚C
Temperature range for
error-correction
23 ˚C 5 ˚C (< 1 ˚C deviation from the temperature
when performing the error-correction)
Humidity 20 % to 80 % at wet bulb temperature < +28 ˚C (non-
condensation)
Altitude 0 m to 2,000 m (0 to 6,561 feet)
Vibration 0.21 G maximum, 5 Hz to 500 Hz
The above environmental requirements are not intended for the
specifications and measurement accuracy of the analyzer but for the
operating environment of the analyzer.

Keysight E5053A Microwave Downconverter 13
Installation
Requirements for installation environment
Heat dissipation clearance
To satisfy the safety, specifications, and measurement accuracy of the product,
you need to keep the temperature around the product within a specific range
by providing proper heat dissipation clearance around the product or by
forcefully air-cooling the inside of the rack. For information on ambient
temperature to satisfy the specifications and measurement accuracy of the
product, refer to the “Specifications and supplemental performance
characteristics” Chapter in the User’s Guide.
When the temperature around the product is kept within the specified
temperature range, the product will comply with the safety standards.
Furthermore, the product will also comply with the safety standards when the
product is installed with clearance for heat dissipation according to Figure 1-2
below.
Figure 1-2 Providing heat dissipation clearance
Condition
Rear 180 mm
Sides 60 mm (both right and left)

14 Keysight E5053A Microwave Downconverter
Installation
Requirements for installation environment
1-
Antistatic measures
To protect electronic components from static damage, take antistatic measures
as shown in Figure 1-3. Table below shows antistatic accessories that Keysight
Technologies provides.
Figure 1-3 Example of antistatic measures
Providing space to disconnect the power cable’s plug
As described in “Cutting power supply” on page 20, the disconnecting device
(the device to cut the supply of power) of the E5053A is the plug of the power
cable. When installing the E5053A, provide sufficient clearance not to hinder
the operation of disconnecting the plug of the power cable (on the power
outlet side or the E5053A side) in an emergency to cut the supply of power.
Name Keysight part
number
Antistatic table mat 9300-0797
Wrist strap code 9300-0980
Wrist strap 9300-1383
Heel strap 9300-1169

Keysight E5053A Microwave Downconverter 15
Installation
Mounting front handles/flanges for rackmount
Mounting front handles/flanges for rackmount
You can use the E5053A on a workbench or mounted in a rack. This section
describes how to mount the front handles used to move/transport it (Option
1CN) and how to mount it into a rack as part of a measurement system (Option
1CM: without handles/Option 1CP: with handles).
Option Name Keysight part
number
1CN Handle kit 5063-9227
1CM Rackmount kit 5063-9214
1CP Rackmount/handle kit 5063-9221
Option Contents Quantity
1CN Front handle 2
Screw 6
Trim strip 2
1CM Flange for rackmount (side plate for securing) 2
Screw 6
1CP Flange for rackmount (side plate for securing) 2
Front handle 2
Screw 6

16 Keysight E5053A Microwave Downconverter
Installation
Mounting front handles/flanges for rackmount
1-
Figure 1-4 Mounting the handle/rackmount kit
Mounting handle kit (Option 1CN)
The handle kit is a kit that contains a pair of front handles used to
move/transport the E5053A. Follow these steps to mount it, referring to the
Figure 1-4.
Step 1. Remove the trim strips (1) stuck to both the sides of the front panel (stuck to
the frame).
Step 2. Mount the front handles (3) to both the sides of the front panel of the E5053A
with the attached screws.
If a front handle you mounted is damaged, replace it with new one
immediately. If you use a damaged front handle to move/transport the
instrument, the handle may break, which may injure the operator or break
the instrument.

Keysight E5053A Microwave Downconverter 17
Installation
Mounting front handles/flanges for rackmount
Mounting rackmount kit (Option 1CM)
The rackmount kit is a kit that contains 2 flanges (side plates for securing) to
mount the E5053A into the standard rack (width: 482.6 mm) of the EIA
standard. Follow these steps to mount it, referring to the Figure 1-4.
Step 1. Remove the trim strips (1) stuck to both the sides of the front panel (stuck to
the frame).
Step 2. Mount the flanges for rackmount (2) to both the sides of the front panel of the
E5053A with the attached screws.
Step 3. Remove the four legs on the bottom of the E5053A (pull up the part with the
(TAB indication and slide it to the arrow direction).
Step 4. Mount the E5053A into the rack.
Mounting rackmount/handle kit (Option 1CP)
The rackmount/handle kit is a kit that contains both the flanges for rackmount
and the front handles for the E5053A. Follow these steps to mount it, referring
to the Figure 1-4.
Step 1. Remove the trim strips (1) stuck to both the sides of the front panel (stuck to
the frame).
Step 2. Mount the front handles (3) and the flanges for rackmount (4) to both the
sides of the front panel of the E5053A with the attached screws.
Step 3. Remove the 4 legs on the bottom of the E5053A (pull up the part with the
(TAB indication and slide it to the arrow direction).
Step 4. Mount the E5053A into the rack.
Be sure to use both the front handles and the rack-mounting flanges at the
same time. Do not attempt to install flanges or handles separately with the
hardware provided, since this risks serious electrical damage to the
instrument.

18 Keysight E5053A Microwave Downconverter
Installation
Power supply and fuse
1-
Power supply and fuse
Before turning ON the E5053A, check the following.
Checking the power supply
Check that the power supplied to the E5053A satisfies the following
conditions.
Setting up the fuse
Use the fuse that meets the following specifications.
UL/CSA type, Slo-Blo, 5x20 mm miniature fuse, 3A 250V (Keysight part
number: 2110-1017)
Spare fuses are available from Keysight Technologies sales offices. To check or
replace the fuse, disconnect the power cable and pull out the fuse holder.
Figure 1-5 Fuse holder and power cable inlet
Condition
Voltage 90 to 132 Vac or 198 to 264 Vac1
1. The E5053A automatically switches between them depending on the voltage.
Frequency 47 to 63 Hz
Power consumption Max. 250 VA

Keysight E5053A Microwave Downconverter 19
Installation
Power supply and fuse
Checking and connecting the power cable
The power cable that comes with the E5053A has a three-wire structure and
one of them is the grounding wire. This power cable grounds the E5053A
through an outlet, protecting the operator from shock hazards.
Step 1. Check the power cable you use for damage.
Step 2. Connect the attached power cable between the power cable receptacle on
the rear panel of the E5053A (see Figure 1-5 on page 18) and a three-pole
outlet whose grounding terminal is grounded securely.
For power cable options, refer to http://www.keysight.com/find/powercords.
Never use a power cable that may be damaged. You may get an electrical
shock.
Securely ground the E5053A with the attached 3-wire power cable with
the grounding wire.

20 Keysight E5053A Microwave Downconverter
Installation
Starting up E5053A
1-
Starting up E5053A
This section describes how to turn ON/OFF the E5053A and how to cut the
power supply in an emergency.
Turning ON/OFF the power
Turning ON the power
Step 1. Check that the line switch in the lower left part of the front panel is pulled up
( ). If it is pushed in ( ), which means the power is OFF, push the
standby switch to pull it up ( ).
Step 2. Push the line switch to push it in ( ).
Turning OFF the power
To turn OFF the E5053A, do the following.
•Push the line switch in the lower left part of the front panel so that the
switch pushed in ( ) is pulled up ( ).
Cutting power supply
For the E5053A, the disconnecting device (the device to cut the power supply)
is the power cable’s plug (on the power outlet side or the E5053A side).
If you need to cut the power supply to avoid danger of electric shocks,
disconnect the power cable’s plug (on the power outlet side or the E5053A
side).
To turn OFF the E5053A under normal conditions, press the line switch.
Under normal conditions, never disconnect the power cable to cut the
power supply to the power cable receptacle on the rear panel.
Follow the description in “Providing space to disconnect the power cable’s
plug” on page 14 so that you can perform this operation reliably.
To turn OFF the power under normal conditions, be sure to follow the
procedure in “Turning OFF the power”.
