Keysight 11667C Power Splitter
Operating and Service Manual
11
1 General Information
Specifications 12
Instrument Covered by Manual 13
Description 14
Equipment Available 15
This manual contains operating and service information for the Keysight 11667C power splitter. The
microfiche part number of the power splitter is 11667-90045. Use this number to order microfilm
transparencies of this manual. The microfiche package includes the latest manual changes
supplement and relevant service notes.

1 General Information
12 Keysight 11667C Operating and Service Manual
Specifications
Table 1-1 lists performance specifications. The instrument is tested against these performance
standards. Table 1-2 provides supplemental (non-warranted) characteristics of the Keysight
11667C.These are also denoted as typical, nominal, or approximate.
Table 1-1 General specifications
Description Value
Frequency range DC to 50 GHz
Maximum power +27 dBm
Connectors 2.4 mm female on all ports
Table 1-2 Electrical specifications
Description Frequency
DC to 18 GHz DC to 26.5 GHz DC to 40 GHz DC to 50 GHz
Input return loss (SWR) 20 dB (1.22) 16 dB (1.38) 14 dB (1.50) 12 dB (1.65)
Equivalent output SWR
(leveling or ratio measurements) 1.29 1.29 1.50 1.65
Output tracking
(between output arms) 0.30 dB 0.35 dB 0.40 dB 0.40 dB
Table 1-3 Mechanical specifications
Description Value
Pin depth 0.000 to 0.076 mm (0.000 to 0.003 in)[a]
[a] Allowable recession of the end of the female center pin behind the outer conductor mating plane.
Dimensions 35.2 mm H x 35.2 mm W x 10 mm D (1.4 x 1.4 x 0.4 in)
Weight Net 0.06 kg (0.13 lb)
Shipping 0.14 kg (0.3 lb)
Table 1-4 Supplemental characteristics
Description Frequency
DC to 18 GHz DC to 26.5 GHz DC to 40 GHz DC to 50 GHz
Phase tracking (between output arms) 2.0° 2.5° 3.0° 3.0°
Insertion loss 6.0 dB 7.0 dB 8.0 dB 8.5 dB

General Information 1
Keysight 11667C Operating and Service Manual 13
Instrument Covered by Manual
Each Keysight 11667C has a unique serial number. The content of this manual applies directly to
power splitters with serial number 00101 and above.
An Keysight 11667C manufactured after the printing of this manual may be different from those
documented in this manual. The manual for that instrument is supplied with a manual changes
supplement that documents the differences.
In addition to change information, the supplement may contain information that applies to all
instruments, regardless of serial number. To keep this manual as current as possible, periodically
request the latest manual changes supplement. The supplement for this manual is keyed to it's
print date and part number. Copies of the supplement are available from Keysight.

1 General Information
14 Keysight 11667C Operating and Service Manual
Description
The Keysight 11667C is a two-resistor power splitter used in network analysis where one output
arm is used for leveling or to supply a reference signal for ratio measurements.
In a network analyzer system, the node at the fork of the power splitter is held constant by the
leveling action of the network analyzer reference channel (see Figure 1-1). Because a virtual
ground is present at the node, the resistance in each output arm is 50 ohms, giving a 50 ohm
matched output impedance.
The ratio between the two power splitter arms is not affected by source power level variation.
Variations in power level appear in both arms equally and simultaneously.
Figure 1-1 Keysight 11667C schematic and dimensions

General Information 1
Keysight 11667C Operating and Service Manual 15
Equipment Available
The power splitter’s 2.4 mm connectors are compatible with all other 2.4 mm connectors. Keysight
also produces adapters from 2.4 mm to other coaxial connector types. Refer to 2.4 mm ADAPTERS
and CALIBRATION ACCESSORIES, part number 11900-90003, for a list of these products and their
specifications.

1 General Information
16 Keysight 11667C Operating and Service Manual
THIS PAGE HAS BEEN INTENTIONALLY LEFT BLANK.

Keysight 11667C Power Splitter
Operating and Service Manual
17
2 Installation
Initial Inspection 18
Preparation for Use 19

2Installation
18 Keysight 11667C Operating and Service Manual
Initial Inspection
If the shipping container or cushioning material is damaged, do not discard them until the power
splitter has been checked mechanically and electrically.
Inspect the power splitter for mechanical damage.
Electrically test the power splitter. Refer to Performance Tests.
Notify your nearest Keysight office if there is mechanical damage or defect, or if the power splitter
does not pass electrical tests. Notify the carrier if the shipping container is damaged or the
cushioning material shows signs of stress. Keep all shipping materials for the carrier's inspection.
Keysight will arrange for repair or replacement without waiting for a claim settlement.

Installation 2
Keysight 11667C Operating and Service Manual 19
Preparation for Use
Mating connectors
The accuracy and repeatability of each measurement depends on the proper care and use of the
2.4 mm connectors. Visually inspect and clean connectors before every connection. Measure
mechanical tolerances (pin depth) with a precision gage prior to the connector's first use, and
periodically thereafter. Torque connections to 8 in-lb (90 N-cm). Information concerning the
proper maintenance, inspection, and gaging of connectors is provided in the Keysight Microwave
Connector Care manual, part number 08510-90064.
Environment
Operate the power splitter only in environments within the limits listed. Storage and shipment
environments must meet the conditions shown.
Returning the power splitter for service
If you return the instrument to Keysight, follow the Packaging instructions. Attach a tag to the
instrument indicating the model and serial number, type of service required, return address, and
technical contact person with complete phone number.
CAUTION
Maximum input power to the Keysight 11667C is +27 dBm. Exceeding this limit will damage the
resistor network and void the warranty.
Table 2-1 Environmental requirements
Parameter Required values/ranges
Temperature
–Operating
– Storage and shipment
0 to +55 °C (+32 to +131 °F)
-40 to +75 °C (-40 to +167 °F)
Humidity
–Operating
– Storage and shipment
Up to 95% relative
Up to 95% relative
Altitude
–Operating
– Storage and shipment
Up to 4,572 metres (15,000 feet)
Up to 7,620 metres (25,000 feet)

2Installation
20 Keysight 11667C Operating and Service Manual
Packaging
Containers and materials identical to those used in factory packaging are available through
Keysight offices. If you choose to package the instrument with commercially available materials,
follow these instructions:
1Place the power splitter completely inside an anti-static bag.
2Use a strong shipping container. A double-wall carton made of 350-pound test material is
adequate.
3Use a 7 to 10 cm (3 to 4 in) layer of shock-absorbing material around all sides of the instrument
to provide a firm cushion and prevent movement inside the container.
4Seal the shipping container securely.
5Mark the shipping container FRAGILE.
