KGuard Security KG-SH330 User manual

KG-SH330/SH-530
User’s Manual
Default account & Password for KG-SH330/530
- User Account:「
「「
「aa」
」」
」
- Password:「
「「
「11」
」」
」
(Version 1.0)

KGUARD Standalone (KG-SH330&SH-530) User Manual
www.kguardsecurity.com
2
Table of Contents
1Package Content.............................................................................................................4
2Feature..............................................................................................................................5
3Specification....................................................................................................................5
4Hardware Introduction...................................................................................................7
4.1 SH330 Front view / Back view.......................................................................7
4.2 SH530 Front view / Back view.......................................................................9
4.3 Remote controller .........................................................................................11
4.4 HDD Installation.............................................................................................13
5Text Input........................................................................................................................18
6Main Screen ...................................................................................................................19
7Menu................................................................................................................................20
7.1 Login / Logout................................................................................................21
7.2 Status...............................................................................................................22
7.3 Volume.............................................................................................................23
7.4 Video Adjustment..........................................................................................24
7.5 VGA Display ...................................................................................................25
7.6 Backup Device ...............................................................................................26
7.6.1 Backup Setting.........................................................................................27
7.7 Setup................................................................................................................28
7.7.1 Pre-Camera ...................................................................................................29
7.7.2 Camera...........................................................................................................30
7.7.3 Alarm...............................................................................................................34
7.7.4 SEQ Display Setup........................................................................................36
7.7.5 Scheduled Record.........................................................................................37
7.7.6 HDD ................................................................................................................38
7.7.7 Password........................................................................................................42
7.7.8 System Setup ................................................................................................43
7.7.9 RS-232 / 422 / 485 ........................................................................................44
7.7.10 Network ........................................................................................................46
8PTZ Control....................................................................................................................50
9Software Upgrade.........................................................................................................55
10 Search & Playback................................................................................................56
10.1 Search By Time..............................................................................................57
10.2 Search By Event / Log Display ...................................................................58
10.3 Smart Search..................................................................................................59

KGUARD Standalone (KG-SH330&SH-530) User Manual
www.kguardsecurity.com
3
10.4 Search Archived Files ..................................................................................61
10.5 POS Search ....................................................................................................62
10.6 Playback/Archive For Search By Time ...........................................................63
10.7 Playback/Archive For Search By Event....................................................66
10.8 Playback/Archive For Smart Search .........................................................67
10.9 Playback For Archived Files .......................................................................67
10.10 Playback/Archive For POS Search ............................................................68
11 Remote Access......................................................................................................68
11.1 Remote Access via Internet Explorer (IE) ................................................68
11.1.1 Main Screen .............................................................................................70
11.1.2 Search & Playback ..................................................................................72
11.1.3 PTZ Control ..........................................................................................74
11.1.4 Server Configuration ...............................................................................75
11.1.5 POS Search .........................................................................................91
11.1.6 GPS Configuration...................................................................................92
11.1.7 POS Configuration ...............................................................................93
11.2 Remote Access via PDA ..............................................................................94
11.3 IE Remote Access via Vista.........................................................................96
12 CMS2000...............................................................................................................101
13 POS Connection..................................................................................................102
13.1 Connection Step & Diagram.........................................................................102
13.2 P.O.S. Setting of Standalone DVR...............................................................102
13.2.1 RS232/422/485 Setting via Local.........................................................102
13.2.2 RS232/422/485 Setting via Remote ....................................................106
Appendix A – POS Connection Diagram ....................................................................... 111
Appendix B – POS ............................................................................................................. 111
Appendix D – Detection Setting ......................................................................................113
Appendix E –Time Zone....................................................................................................114
Appendix F – Recording Table Reference (NTSC) ......................................................116
Appendix G – Recording Table Reference (PAL).........................................................117
Appendix H – RS422 / 485 Port .......................................................................................118
Appendix I – MAIN AUX & CALL AUX MONITOR CONNECTION DIAGRAM...........119
Appendix J – DVR 1- 8 IR Sensor Setup & Remote Controller Trouble Shooting 120
Appendix K – Standalone DVR Hardware Accessory Support List .........................122
Appendix L – Standalone DVR Firmware Update ........................................................123
Appendix M – IDE TO SATA Converter Board Installation Guide .............................125
ALL UPDATED DOCUMENTATION RELEASE IS AVAILABLE FOR DOWNLOAD AT KGUARD OFFICIAL
WEBSITE.

KGUARD Standalone (KG-SH330&SH-530) User Manual
www.kguardsecurity.com
4
1 Package Content
1-1. KG-SH330 ---------------------------------- x1
1-2. Remote Controller ------------------------ x1
1-3. Y-Cable -------------------------------------- x1
1-4. Terminal Block ----------------------------- x2
1-5. RS232 Terminal Cover ------------------- x1
1-6. Power Adapter ----------------------------- x1
1-7. Power Cable -------------------------------- x1
1-8. Bolt -------------------------------------------- x9
1-9. AAA Battery --------------------------------- x2
1-10. SATA Data Cable ------------------------- x2
1-11. CD ------------------------------------------- x1
1-12. User Manual ------------------------------- x1
1-13. Touch Board (optional) ------------------ x1
(Used to cover the POS/Printer connection terminal when the unit is not connected to any of this external device)
KG-SH330 Remote Controller Y-Cable Terminal Block RS232 Terminal Cover
Power Adapter Power Cable Bolt AAA Battery SATA Data Cable
CD User Manual Touch Board
(optional)

KGUARD Standalone (KG-SH330&SH530) User Manual
www.kguardsecurity.com
5
2 Feature
※ Embedded system design, provide reliable system.
※ H.264 video compress with configurable quality.
※ Support Multiplex operation – Live, Record, Playback, Backup, Control, Remote access.
※ Preview Up to 30 (NTSC) / 25 (PAL) IPS per channel.
※ Record – Full-D1: up to 60/50 IPS, Half-D1: up to 120/100 IPS, CIF: up to 240/200 IPS.
※ Support large storage with up to 4 HDD. Max. 2TB*4 of HDD storage size, external device
(IEEE1394) non-limited of capacity.
※ Backup: USB 2.0 devices, including HDD, DVD+RW, Pen Drive.
※ Support VGA display and I/R remote control.
※ Support Kguard CMS2000 (Central Management System).
※ Support audio recording function.
※ Support audio Broadcast function via IE.
※ Support two-way audio function
※ Remote access through mobile phone, PDA, IE.
※ Support POS (Multiple POS devices supported for RS-232 port, SH-330 up to 9 POS,
SH-530 up to 16 POS), GPS, PTZ, keyboard control via RS-232 and RS-485.
※ Optional IEEE 1394 connector for external HDD/RAID extension.
※ HDD failure action supported.
※ DDNS for static IP supported.
※ Multi-level password and authentication key protection to ensure high degree of security.
※ More user-friendly OSD with some new icons.
※ Multiple event playback/backup supported.
※ Multiple Scheduled Record Setup (Alarm, Motion, Normal etc..).
※ HDD storage for privacy law supported.
※ Self playback of backup files supported.
3 Specification
Model KG-SH330 KG-SH530
System
OS Embedded Linux 2.6
Operation Sixplex operation – Live, Record, Playback, Backup, Control,
Remote access
Format NTSC/EIA or PAL/CCIR
Certification CE, FCC etc.
Video
Input 9ch, BNC 16ch, 1Vp-p / 75 ohm, BNC
Output 1.0Vp-p, 75ohm, BNC (Main /
Call monitor) , S-video, BNC
x 9 video looping out, VGA
D-sub 15 pin output
1.0Vp-p, 75ohm, BNC (Main /
Call monitor) , S-video, BNC x 16
video looping out, VGA D-sub 15
pin output
Audio
Audio Input RCA 4 CH

KGUARD Standalone (KG-SH330&SH530) User Manual
www.kguardsecurity.com
6
Audio Output RCA 2 CH
Monitor
Display Channel 1/4/7/9 1/4/7/9/10/13/16
Digital Zoom x 2, x4
Sequence Display Available
Display Resolution NTSC:720(H)x 480(V) ; PAL : 720(H) x 576(V)
Display Rate Up to 30 (NTSC) / 25 (PAL)
IPS per display channel
Up to 30 (NTSC) / 25 (PAL) IPS
per display channel
Record
Compression H.264
Recording rate (IPS) NTSC:60IPS/720x480, 120IPS/720x240, 240IPS/360x240
PAL : 50IPS/720x576, 100IPS/720x288, 200IPS/360x288
Recording Mode Manual / Alarm / Motion / Schedule
Playback Mode Date / Time, Camera, Motion, Alarm
Pre-record time 0-60 seconds
Post-record time 0-60 minutes
Network Function
Ethernet RJ-45 x1
Protocol TCP/IP, HTTP, PPPoE, DHCP, DDNS, FTP
Remote Access IE ( up to 4 DVR) / CMS2000 (up to 600 channels)
Remote stations PDA, PC, Mobile Phone
Control
IR Remote Controller Yes
RS-232 1 x D-type female connector for PTZ, POS, GPS
RS-485 / 422 1 x RJ-45 for keyboard / PTZ control
Other Function
Motion Detect Configurable detection and sensitivity
Alarm Function 16 alarm In / 4 relay Out (NO x 2, NC x 2)
Back-Up USB 2.0 device x 2
Storage Internal, 3.5” SATA type HDD x2 ; 3.5” IDE HDD x 2
Watch Dog Yes
Security 3 level password protection, up to 18 accounts
Mechanical
Power Supply DC 12V@8A
Weight 3.4 kg
Dimension 280(D) x 357(W) x 90(H)mm
Operating Temperature 0oC ~ +45oC

KGUARD Standalone (KG-SH330&SH530) User Manual
www.kguardsecurity.com
7
4 Hardware Introduction
4.1 SH330 Front view / Back view
Name Description
1 IR Indicator LED illuminates when IR is on.
2 LAN Indicator LED illuminates when LAN cable is connected.
3 HDD Indicator LED illuminates when HDD is properly installed.
4 Power Indicator LED illuminates when power is turned on.
5 USB Port This is the connection terminal for USB port device.
Back view
Name Description
1 Video Input Connector Connect the unit to cameras video input terminal.
2 Video Output Connector Connect the unit to cameras video output terminal
3 Audio Input Connector Connect to the external audio device.
4
75 ΩTerminal Set each DIP switch to ON unless the corresponding video
output terminal is connected
5 Audio Output Connector Connect to devices such as speakers
6 COM (RS-232) Connect to GPS or POS.
7 RS422/485 switch Allow the selection of RS422 or RS485
8 RS422 / 485 port Connect this to the compatible PTZ camera or keyboard. Use in
accordance to the correct RS422/485 switch setting.
(Please cross reference to Appendix H for Pin Definition)
2
1
3
5
6
4
7
8
4
9
10
1
1
1
2
1
3
1
4
1
5
1
6
1
7
1
8
1
9
20
21
22
5
3 2 1 4

KGUARD Standalone (KG-SH330&SH530) User Manual
www.kguardsecurity.com
8
9 Alarm Input Connector Connect to the alarm triggering devices.
10 Alarm Output Connector Connect to the alarm triggering devices.
11 LAN port This is the LAN connection port.
12 NTSC / PAL switch Set the unit either as NTSC or PAL according to TV compatibility.
13 USB port This is the connection terminal for USB port device.
14 Main Output Connect to the main monitor for display for S-video.
15 IEEE 1394 connector
(Optional)
Connect to external hard disk box.
16 VGA connector Connect to VGA monitor.
17 AC Cord Inlet Connect the unit to the power source.
18 Main Out Connect to the main monitor for display for composite video.
19 Main AUX In/Out Used to daisy chain to TV monitor. This has the same output
function as Main Out but can be switched off via RS485
keyboard control.
(Please cross reference to Appendix I for connection detail)
20 Call Monitor Output Connect to the monitor for call monitor display.
21 CALL AUX In/Out Used to daisy chain to TV monitor. This functions similarly to Call
Out but can be switched off via RS485 keyboard control.
(Please cross reference to Appendix I for connection detail)
22 Power Switch Click to turn the system power on/off.

KGUARD Standalone (KG-SH330&SH530) User Manual
www.kguardsecurity.com
9
4.2 SH530 Front view / Back view
Name Description
1 IR Indicator LED illuminates when IR is on.
2 LAN Indicator LED illuminates when LAN cable is connected.
3 HDD Indicator LED illuminates when HDD is properly installed.
4 Power Indicator LED illuminates when power is turned on.
5 USB Port This is the connection terminal for USB port device.
Back view:
Name Description
1 Video Input Connector Connect the unit to cameras video input terminal.
2 Video Output Connector Connect the unit to cameras video output terminal
3 Audio Input Connector Connect to the external audio device.
4
75 ΩTerminal Set each DIP switch to ON unless the corresponding video
output terminal is connected
5 Audio Output Connector Connect to devices such as speakers
6 COM (RS-232) Connect to GPS or POS.
7 RS422/485 switch Allow the selection of RS422 or RS485
8 RS422 / 485 port Connect this to the compatible PTZ camera or keyboard. Use in
accordance to the correct RS422/485 switch setting.
(Please cross reference to Appendix H for Pin Definition)
9 Alarm Input Connector Connect to the alarm triggering devices.
10 Alarm Output Connector Connect to the alarm triggering devices.
5
6
4
8
4
9
4
10
1
1
1
2
1
2
3
7
4
1
3
1
4
1
5
1
6
1
7
1
9
20
21
1
8
22
5
3 2 1 4

KGUARD Standalone (KG-SH330&SH530) User Manual
www.kguardsecurity.com
10
11 LAN port This is the LAN connection port.
12 NTSC / PAL switch Set the unit either as NTSC or PAL according to TV compatibility.
13 USB port This is the connection terminal for USB port device.
14 Main Output Connect to the main monitor for display for S-video.
15 IEEE 1394 connector
(Optional)
Connect to external hard disk box.
16 VGA connector Connect to VGA monitor.
17 AC Cord Inlet Connect the unit to the power source.
18 Main Out Connect to the main monitor for display for composite video.
19 Main AUX In/Out Used to daisy chain to TV monitor. This has the same output
function as Main Out but can be switched off via RS485
keyboard control.
(Please cross reference to Appendix I for connection detail)
20 Call Monitor Output Connect to the monitor for call monitor display.
21 CALL AUX In/Out Used to daisy chain to TV monitor. This functions similarly to Call
Out but can be switched off via RS485 keyboard control.
(Please cross reference to Appendix I for connection detail)
22 Power Switch Click to turn the system power on/off.

KGUARD Standalone (KG-SH330&SH530) User Manual
www.kguardsecurity.com
11
4.3 Remote controller
Name Description
1 REC Press to start the recording.
2 Mode Press to switch between live and playback mode.
3 SEQ Press to turn on the sequence mode.
4 CALL Click to bring up the call monitor.
5
Search Click to search recorded data while in the playback
mode. There are three types of search modes:
search by time, search by event and smart search.
(Please refer to section 9 for detail information.)
6 Alarm Reset Press to restore the alarm status to default.
7
Numeric/
alpha button
Use these buttons to enter texts and numerical
values.
PTZ Click to access the PTZ control when there is a PTZ
camera supported.
Goto Click to view the image taken by PTZ camera at its
preset location.
Function Click to add an audio recording feature.
Set Click to switch between GPS and POS Display and
to reconfigure the display setting.
(Please refer to Appendix C for detail setup)
Zoom Press to adjust the zoom of the camera.
8
Adjust Click to switch between different display layouts.
9 Menu Press to access the menu dialog box.
10 Mute Press to either mute or un-mute audio.
11 Esc Press to exit the setting page.
12 X2 Press to adjust the zoom.
▲/Back Space: Click to move up the selection panel or backspace
during text/numeric entry.
◄; ►: Click to move left or right.
▼/DEL: Click to move down the selection panel or delete text during
text/numeric entry.
13
ENTER: Click to enter a feature setting/GPS & POS setting and to save
changes.
(Please refer to Appendix C for detail information on GPS/POS setting)

KGUARD Standalone (KG-SH330&SH530) User Manual
www.kguardsecurity.com
12
Use to adjust the volume.
14
Click to switch between different screen layouts.
: Rewind feature.
/ II: Click to play or pause the playback.
: Forward feature.
: Click to copy an image to an external storage device. Click again to
stop copying.
: Stop the playback.
I : Click to skip to the next image.
15
Page: Press to scroll up/down the log list.
16 DVR1 – DVR8
Click to access the respected DVR when there is more than one DVR
connected within a network.
(Please refer to Appendix J for setup detail)

KGUARD Standalone (KG-SH330&SH530) User Manual
www.kguardsecurity.com
13
4.4 HDD Installation
This system is specially designed to accommodate a maximum of 4 HDDs. Nevertheless, due to the
space limitation, either the 4th HDD or the VGA card can be applied once at a time.
Figure 1
↑
↑↑
↑Step 1 : Uncover the system case.
Figure 2
↑
↑↑
↑Step 2 : Screw both the SATA HDD tightly onto the HDD racks of the upper metal case as
shown in the figure above.
Figure 3
↑
↑↑
↑Step 3: Before attaching the 3rd & the 4th HDD to the lower metal case, carefully fold the IDE
cables in the orientation as shown.
SATA HDD
IDE cable
HDD rack for IDE

KGUARD Standalone (KG-SH330&SH530) User Manual
www.kguardsecurity.com
14
Figure 4
Step 4 : Then screw the IDE onto the HDD rack provided on top of the IDE cable as shown in
the figure.
Note: Although this system can support up to a maximal of 2 SATA HDD & 2 IDE HDD, the 4th HDD is
optional. If the 4th HDD is to be installed, VGA card must first be removed to accommodate for
space limitation.
IDEs
VGA Card

KGUARD Standalone (KG-SH330&SH530) User Manual
www.kguardsecurity.com
15
Figure 5- SATA connection
Figure 6- IDE connection
Step 5 : Properly connect all the appropriate cables & power cables to their respective HDD as
shown in figures 5 & 6 for both SATA & IDE.

KGUARD Standalone (KG-SH330&SH530) User Manual
www.kguardsecurity.com
16
Figure 7
NOT :
The SATA & ID cables must be carefully folded in the orientation as shown in the figure 7 before
attaching the ID to prevent disruption to other system components.
Figure 8
Step 6 : Carefully assemble the cases & screw the it tightly to complete the HDD installation.
Step 7: Make sure to install at least one hard disk drive inside the hard disk tray. If there are
two HDDs, please set both HDDs as (1) master for two independent cables, (2)
master/slave for one cable with two connectors, or (3) cable select. The settings
should be described on the HDDs or in the manuals come with the HDDs.
Note 1: Whether the upper HDD or the lower one is set as HDD#1 is fine for the
system. But it’s always a good habit to connect the upper one to HDD#1 cable or
set it as master for one cable with two connectors.

KGUARD Standalone (KG-SH330&SH530) User Manual
www.kguardsecurity.com
17
Note 2: Each of the HDDs must be formatted before it can be used to record
video/audio. Please refer to Section 7.7.6.1 HDD Format/Clear to format the
HDDs.
Note 3: Please refer to the following diagrams if IDE-to-SATA converter board
is used (Appendix M: IDE TO SATA Converter Board Installation Guide). Please
make sure to set the master/slave jumper on the board correctly.

KGUARD Standalone (KG-SH330&SH530) User Manual
www.kguardsecurity.com
18
5 Text Input
Press ▲▼◄► to highlight the text to be edited then press Enter to call up the alpha-numeric
text pad.
Name Description
1 1 Press to enter the available number.
2 3 Press to enter the available number and letter shown on the screen.
3 */Mark Press to bring up a list of punctuation and special symbols.
4 ►Press to enter the available number and letters shown on the screen.
5
Press to enter the available number and letters shown on the screen.
6 CALL Press to enter the available number and letters shown on the screen.
NOT : Call monitor button is not functional during text/numeric entry.
7 2 Press to enter the available number and letters shown on the screen.
8 4 Press to enter the available number and letters shown on the screen.
9 # Press to enter the code for the selected foreign languages.
A MUTE Press to enter the available number and letters shown on the screen.
NOT : Mute button is not functional during text/numeric entry.
B X2 Press to enter the available number and letters shown on the screen.
NOT : Zoom button is not functional during text/numeric entry.
C SEQ Press to enter number.
NOT : Sequence mode is not functional during text/numeric entry.
Attention:
For text and numeric entry using the controller press directly from the
alpha-numeric buttons.
1 2 3 4 5
C B A 9 8 7
6

KGUARD Standalone (KG-SH330&SH530) User Manual
www.kguardsecurity.com
19
6 Main Screen
Name Description
1 Video Screen Display live/playback video.
2 Camera ID Shows ID number of the camera.
3 Time / Date Shows the current recording time and date.
4 Audio When audio is turned on, audio icon will be displayed on the screen.
5 Alarm recording
percentage
Shows the percentage of alarm triggered recording.
6 Normal recording
percentage
Shows the percentage of normal recording.
1
2
1
3
4
5
6

KGUARD Standalone (KG-SH330&SH530) User Manual
www.kguardsecurity.com
20
7 Menu
Press to bring up a list of function setting menu.
Name Description
1 Login/Logout Press to login/logout of the system.
2 Status Allow user to view the overall status of the system.
3 Volume There are a maximum of 4 live audio inputs. User can choose to enable or
disable the audio feature and adjust the audio volume.
4 Video Adjustment User can adjust the color, hue, saturation, contrast of the video image.
5 VGA Display User can adjust the image output quality in terms of resolution, brightness,
contrast, hue and saturation.
6 Backup Device This window allows user to view the connection status of the backup
device and to initiate data backup.
7 Setup System features settings.
(Please refer to section 7.7 for detail information)
8 Software Upgrade This feature allows user to upgrade the software directly from the external
devices such as DVD and USB flash drive.
9 Shutdown Allows users to shutdown the system to prevent data loss.
1
3
5
7
2
4
6
8
9
