KHADAS VIM4 User manual

To get started, visit
docs.khadas.com/vim4

OOWOW Introduction
•VIM4 comes with the OOWOW embedded service.
•Use OOWOW to install your preferred OS directly from the Cloud.
■ OOWOW will start automatically if the device storage is empty.
•Control VIM4 with a display and keyboard, or remotely overWiFi/LAN.
•With OOWOW you will always be in control of your VIM4.
Activate OOWOW: hold Funciton and press Reset
Activate Hotspot: press Function after OOWOW starts
Network Name: vim4-xxxxx (last 5 digits of serial no.)
Further information: https://docs.khadas.com/oowow
Website Introduction
•For more documentation and technical information, you can visit docs.khadas.com.
•If you encounter technical issues during development, seek help at forum.khadas.com.
•To purchase additional accessories, please visit shop.khadas.com.
Data Download Instruction
•Schematics: d I. khadas.com/prod ucts/vi m4/schematic/
•Datasheets: dl.khadas.com/products/vim4/datasheet/
•Specification: dl.khadas.com/products/Vim4/specs/
•2D DXF: dLkhadas.com/products/vim4/dx"
•3D CAD: dLkhadas.com/products/Vim4/cad/
After-Sales Service
Please email suppo[email protected]m if you have any after-sales related questions.
