KiCA MINI User manual

Massage Device
Instructions V2.1

Cone Head (Percuss deep
tissues like meridians and
acupoint, etc.)
Spherical Head
( Relax soft tissues
and sensitive
muscles
)
U-shaped Head
(Massage neck
and tendon)
Magnetic Massage
Head
(Massage flat
major muscle groups
on the back)
1 2 3 4 5
Start to Use
1. Install/ Replace Massage Head
Install a massage head into the hole in front of the device according to your need.
2. Power ON
Long press the Power button.
3. Power OFF
Single tap Power button to switch to
standby mode or long press
P ower button.
Overview
1. Massage Head (Replaceable)
2. Battery Indicator
3. Charging Port
4. Power Button
(Selecting gears/Power switch)
5.Gear Indicator (Breathing light)
Gentle Head
（ Promote the
absorption of
essential oil
）
1

4.Selecting Gears
Single tap power button to select gears after powering on.
5. Intelligent Protection
This product has intelligent protection function. In order to prevent muscle injury
caused by massaging for a long time, a beeping sound will be issued and gear
indicator turn off ( battery indicator remain ) after working for 10 minutes
continuously, and it can be restarted by pressing the function button. If there is no
operation within 5 seconds, it will power off automatically.
6. Locked Motor Protection
This product has Locked Motor Protection function. If the rotating is blocked for 3
seconds, the product will enter standby mode automatically. Users can restart it by
pressing the function button. If there is no operation in 10 seconds, the product will
power off automatically.
7. Gentle head introduction
Gentle head is used to gently massage sensitive part of body with gentle mode.
Gentle head is suitable for oil massage with the silicone brush design which
can promote the absorption of essential oil.
Constant green light
Green light flashes slowly
Green light flashes quickly
Fully charged
Medium level of battery
Low power
Description
Indicator while using
First gear
Second gear
Third gear
Fourth gear
Standby mode
（Auto power off after 2 seconds）
Gears
8. Battery Indicator
1500
2400
3200
650
0
Rated Rotate
Speed（rpm）
Gear Indicator
（breathing light）
Blue breathing light
Green breathing light
Red breathing light
Yellow breathing light
2
Function
Muscle arousal
Relax
Deeply massage
Gently massage

Constant red light
Constant green light
Charging
Charge completed
DescriptionIndicator while charging
USB-C
9. Charging
！Do not use it while charging
3
5V --- 2A
① ② ③ ④ ⑤ ⑥
⑦ ⑧ ⑨
10. Specifications
Product name: KiCA Massage Device
Model: MINI
Operating Voltage Range: 7.1V~8.4V
Battery Capacity: 1300mAh
Charging Time: ＞2h
Weight (Reference value): 248g
Size: 77×35×125.6mm
Theoretical Battery Life: About 8 Hours (Test in lab environment under the fourth gear)
List
① Main Body
② Magnetic Massage Head
③ Gentle head
④ Cone Head
⑤ Spherical Head
⑥ U-shaped Head
⑦ USB-C Cable
⑧ Storage Bag
⑨ Manual
x1
x1
x1
x1
x1
x1
x1
x1
x1

4
Disclaimer
Thanks for using the product. The information in this document affects your safety, legal rights, and
responsibilities. Read the entire document carefully to ensure proper configuration before using. Failure
to read and follow instructions and warnings in this document may result in serious injury to yourself or
others, or damage your products or other objects in the vicinity.
By using this product, you hereby signify that you have read this disclaimer and warning carefully and
that you understand and agree to abide by the terms and conditions herein. You agree that you are
solely responsible for your conduct while using this product, and for any consequences thereof. You
agree to use this product only for proper purposes and all applicable laws, rules, and regulations, and all
terms, precautions, practices, policies, and guidelines. Our company has made and may make available.
Our companyaccepts no liability for damage, injury or, any legal responsibility incurred directly or
indirectly from the use of the product. Our company will not provide any service for any product
obtained from abnormal channels.
Safety Instruction
1. This device is not recommended to directly massage the skin except gentle head to avoid to do
harm to the skin. Customer should massage body after wearing dry clothes or placing a clean and dry
towel on massage part, gently press and move the device.
2. High-speed and high-pressure massage can only be used to soft tissues without feeling pain or
maladjustments. Do not massage head and any skeletal sites with high speed and high pressure.
3. Massage the same part of the body with high speed and high pressure for a long time will.
4. Please keep your fingers, hair or, any other body hair away from the extendable part of the device to
prevent pinching and clipping.
5. Do not discard or misuse this device.
6. Do not modify this device by yourself without permission.
7. Do not operate or charge the device when nobody was around.
8. This device is for adults only.
9. People with contraindicated symptoms should use this device with doctor's permission.
Notice
1. Make sure the massage head is not blocked by external force when the device is power on. If it is
blocked, it will pause for a while and try to restart.
2. DO NOT contact the product with water or other liquid for the Massage Device is not waterproof.
3. DO NOT disassemble the product except marked detachable. It need send to after-sales or
authorized service center to fix it if you accidentally disassemble it and cause abnormal work. The
relevant costs are borne by users.
4. Prolonged continuous operation may cause the motor surface temperature to rise, please operate
carefully.
5. DO NOT drop or strike the product. If the product is abnormal, contact After-sales support.
Storage and Maintenance
1. Keep the product out of the reach of children and pets.
2. DO NOT leave the product near heat sources such as a furnace or heater. DO NOT leave the product
inside of a vehicle on hot days.
3. Please storage the product in a dry environment.
4. DO NOT overcharge or overuse the battery, otherwise, it will cause damage to the battery core.
5. Never use the product when the temperature is too high or too low.
Precautions when discarding the product
The lithium ion battery used by the product is a recyclable and renewable valuable resource.
When discarding it, please have it handled by a professional agency that can recycle chargeable
batteries. Before discarding the product, power it off and take the lithium ion battery out from it
following the steps below. The battery is to be disposed of safely.
1. Disassemble the top housing with help of a professional tool.
2. Pull out the batter terminals from the PCBA.
3. Use a professional cutter to cut off the bottom housing and then take out the battery.

Contraindications
(1) Cancers.
(2) Metal bone anastomosis (do not use
the device directly in the fracture area).
(3) Osteoporosis.
(4) Vein thrombosis and pulsation.
(5) Hypertension.
(6) Pregnant woman.
(7) Kidney stones (do not use the device
near the kidneys).
(8) Varicose veins.
(9) Acute inflammation.
(10) Do not massage one episode for
more than 5 minutes.
(11) Do not massage the bony area.
(12) Do not massage surgical site .
(13) Do not massage the cervical
vertebrae and spine.
Manufactured by: Guilin Feiyu Technology Incorporated Company
Website: www.kica-tech.com | Tel: [phone] | E-mail: [e-mail]
