Instruction Manual
Universal Ceiling Fan Light Fixture
A Kichler®Select light fixture
™

1
1. SAFETY RULES
WARNING! RISK OF ELECTRIC SHOCK
All electrical connections must be made in
accordance with local codes, ordinances, or
national codes. If you are unfamiliar with
installing electrical wiring, secure the services
of a qualified electrician. Before starting this
installation, disconnect the power by turning
off the circuit breaker at your main panel or
removing the fuse at the fuse block. Turning
the power off using the ceiling fan switch
(speed control on/off) is not sufficient to
prevent electrical shock.
NOTE: The important safeguards and
instructions appearing in this manual are not
meant to cover all possible conditions and
situations that may occur. It must be
understood that common sense, caution and
care are factors which cannot be built into any
product. These factors must be supplied by the
person (s) caring for and operating the unit.
"CAUTION-RISK OF FIRE"
CONSULT A QUALIFIED ELECTRICIAN TO ENSURE
CORRECT BRANCH CIRCUIT CONDUCTOR.
2. PACKAGE CONTENTS
Unpack your fan and check the contents. You
should have the following items:
a. Light fixture
b. Glass shade
c. 1C, 22W lamp
d. Part bag contents:
Nut
Spring washer
Pull chains and fobs (2)
wire nuts (2)
ac
d
b

2
Outdoor Wet Light Kit
Fig. 2
Light kit
assembly
Square connectors
Screws
Mounting plate
o
-
o
-
o
-
o
-
o
-
o
-
o
-
o
-
o
-
o
-
o
-
o
-
o
-
o
-
o
-
o
-
o
-
o
-
o
-
o
-
o
-
o
-
o
-
o
-
o
-
o
-
o
-
o
-
o
-
o
-
o
-
o
-
o
Fig. 1
Light kit
Nut
Lock washer
Center
plug
Switch
housing
3. INSTALLING THE LIGHT KIT
1. Remove and discard the center plug from
the switch housing. Attach the light kit to the
switch housing by feeding the light kit wires
(black and white) through the hole in the
center of the switch housing, then screw the
light kit onto the switch housing.
Attach the nut & lock washer on the inside of
the switch housing making sure the light kit is
secure to prevent movement after installation.
(Fig. 1)
2. Locate the white and blue wires inside the
switch housing labeled FOR LIGHT.
3. Attach the wires from the light kit to the
wires inside the switch housing by pushing the
polarized connections together.
- White wire to White wire
- Black wire to Black wire
4. Raise and hold the light kit assembly close
to the mounting plate of the ceiling fan. Push
the square wire connectors together. (Fig. 2)
NOTE: The square connectors are color
coded. Match the color coded sides of each
plug and push. They will attach ONLY when
matched correctly.
5. Carefully push all wires back into the switch
housing, then install the light kit assembly onto
the mounting plate with 3 screws provided. Be
sure to tighten all screws. (Fig. 2)

Fig. 3
4. INSTALLING THE LIGHT BULB &
GLASS SHADE
1. Attach the wire connector from the
transformer to the florescent lamp. Now attach
the lamp to the lamp holders applying even
pressure to the lamp at each lamp holder. The
lamp will pop into place. NOTE: Sometimes it
helps to open the lamp holder by lifting the
end. This enlarges the holder allowing the
lamp to pop into place easier.
2. Insert the beaded pull chain from light kit
sterm through the hole in the glass shade.
Now place the glass shade over the light kit
stem. Secure the shade with a lock washer
and metal nut (rubber side touching the
shade). (Fig. 3)
3. Now slip the beaded pull chain from the light
kit sterm into the hole of the decorative glass
cap and place the cap onto the light kit stem.
Feed the beaded pull chain from the light kit
stem through the hole in the decorative nut
and thread the decorative nut on securely. DO
NOT OVER TIGHTEN.
4. Slip the beaded pull chain from switch
housing into the chain holder on the edge of
the light plate and place the cap onto the light
kit stem.
5. Your installation is now complete. Restore
electrical power and enjoy your new ceiling fan
light kit.
3
Light kit
assembly
Glass
shade
Glass cap
Metal nut
Lock washer
Decorative nut
Beaded pull chain
Wire connector
Lamp
Lamp holder
chain holder
