Kicker I350 User manual


Congratulations! You have just purchased one of the latest in a long line of
exceptional car audio from Stillwater Designs. Your KICKE Impulse was
designed and engineered by the same team which created many other
international award winning KICKE components like the Solo-Baric®, XPL®,
esolution™ drivers. It contains a number of cutting-edge features to give you
outstanding performance and dependability when installed in a properly
designed system.Thanks for buying KICKE . Enjoy.
I350, I400, I402, I460, I410,
I525, I570, I600, I650, I690, & I6903
Coaxial & 3-Way Speaker Systems
KICKER IMPULSE COAXIAL/3-WAY FEATURES
•Titanium or Titanium-Deposit Dome Tweeter with Neodymium Magnet or smooth high
requency response
•Directional Sound Lens™ lets you tailor each driver’s high requency dispersion pattern
to suit your individual listening pre erences;
DSL not available on I350 & I402
•Felt Damping Plug behind dome or enhanced transient response
•Ferro-Fluid™ Cooled Tweeter Voice Coil or extended li e
• 2.5 inch midrange driver on I6903 3-way system
•Curvilinear Injection-Molded Polygraphite Woo er Cones or smooth extended
requency response
•Blackened Metal Parts and Kapton™ Voice Coil Formers in Woo ers or exceptional
thermal power handling capability
A justing the Directional Soun Lens
Most KICKER Impulse coaxials and the 3-way I6903 have a eature which allows tuning
the high requency response to your taste. The ront o the tweeter incorporates KICKER’s
Directional Sound Lens™ which can be rotated to shape the tweeter’s output. A ter
mounting and wiring your new speakers, and be ore securing the grills, you will want to lis-
ten to them with the DSL in di erent positions to determine which angle works best or
you. We suggest you start with the KICKER logo pointed toward the listener’s head, then
rotate until it sounds best to you. Have un and experiment … with a little work you’ll get
greatly superior imaging can is possible with conventional coaxial speakers.

INSTALLATION INSTRUCTIONS
Your KICKER drivers are speci ically designed or mounting in ree-air applications. While
the speakers don’t need a sealed box to work in, or optimum per ormance it is important
to isolate the sound coming o the ront o the driver rom the sound radiating rom the
back o the driver. This isolation is usually accomplished by using the correct size driver in a
actory speaker location.
Mounting
I custom door mounting locations are desired or your drivers, be care ul to avoid
inter erence rom window and door lock mechanisms. The irst step is to ind a location on
the door panel that will accept the size o speaker chosen. Then remove the door panel
rom the door, and check or the operation o the window all the way up and down.
I metal must be cut to mount the speakers, try to avoid structural metal and braces.
On models with grills included, mount as indicated in the ollowing diagram. There is a sup-
ply o butyl rubber adhesive included to help hold the grill on the ring.
I actory door speaker wiring is not available to tie into, it is necessary to run the sup-
plied wire through the door jamb. This wire should be kept away rom sharp edges and the
possibility o getting pinched. An existing boot in the door jamb is the ideal place to run
the wires, but sometimes this does not exist or is inaccessible. Drilling holes to run wires
through is very tricky, and caution must be exercised not to drill into other wiring or mech-
anisms. Any time a wire is run through a bare hole, it is necessary to insert a rubber grom-
met irst to protect the wire.
Door Body
Speaker
Grill Ring
w/Screws
Factory
Door Panel
Grill

(Mounting, continued)
Similar cautions must be observed when mounting speakers through the package tray
o a car. Watch or trunk springs, hinges, and olding seat mechanisms. When running the
wires be care ul not to crush them with seat bolts or door sill screws.
Wiring
Hooking up the supplied wires to your IMPULSE driver is very straight orward. The wires
come with di erent size ends that will only plug on one way. The larger connector is
crimped on the gray wire and connects to the positive terminal o the speaker. The other
end o these wires connects to your source in a similar manner. The gray wire connects to
the positive output o the ampli ier or radio. The black wire connects to the negative out-
put o the ampli ier or radio. These connections can be made with crimp-on connectors or
solder and good electrical tape.
If you have more questions about the installation of your KICKER component, see
the Authorized KICKER Dealer where you made your purchase You may also call our
Technical Services Line at [phone] or contact us via the Technical Services
page on www kicker com
Front Door Body
Front Dash
Kick Panel
To Crossover
Wiring Holes
w/Grommets
(Installed)
To Speaker
For superior midbass performance ask your Authorized Kicker Dealer for
the KICKER Impulse I6 0 midbass component system which comes with a two
way passive crossover network optimized for use with your coax or 3-way

HOW LONG WILL IT TAKE?
Stillwater Designs maintains a goal of 24-hour service for all returns. Delays may be incurred if
lack of replacement inventory or parts is encountered.
INTERNATIONAL WARRANTY
Contact your International Stillwater Designs dealer or distributor concerning specific
procedures for your country’s warranty policies.
P.O. Box 459 • Stillwater, Oklahoma 74076 • U.S.A. • 405 624-8510
• Install slips (screwdriver holes)
• Damage caused by exposure to water
and/or excessive heat.
• Damage through negligence, misuse, or
accident.
• Items physically damaged due to abuse.
• Freight damage.
• The cost of shipping product to Stillwater
Designs Service.
• Items previously repaired by any
unauthorized repair facility.
• Items returned from unauthorized
individuals or dealers.
• eturn shipping on non-defective items.
• Speakers damaged due to amplifier
clipping or distortion.
• Speakers with silicon caulk used for gasket
material.
KICKE drivers are capable of producing sound levels that can permanently
damage your hearing! Turning up a system to a level that has audible distortion is
more damaging to your ears than listening to an undistorted system at the same
volume level. The threshold of pain is always an indicator that the sound level is
too loud and may permanently damage your hearing.
Please use common sense when controlling volume!
WARNING:
MARCH 2000
SPEAKER SYSTEMS LIMITED WARRANTY
Stillwater Designs warrants this product to be free from defects in material and workmanship under
normal use for a period of one (1) year from date of original purchase, unless this product is labeled “B
Stock”, in which case it is warranted for ninety (90) days from date of purchase. Should service be neces-
sary under this warranty for any reason due to manufacturing defect or malfunction during the warranty
period, Stillwater Designs will replace or repair (at its discretion) the defective merchandise with equiva-
lent merchandise at no charge. Warranty replacements on “B-Stock” may have cosmetic scratches and
blemishes. Discontinued products may be replaced with equivalent products.
This warranty is valid only for the original purchaser and is not extended to owners of the product
subsequent to the original purchaser. Any applicable implied warranties are limited in duration to a peri-
od of the express warranty as provided herein beginning with the date of the original purchase at retail,
and no warranties, whether express or implied, shall apply to this product thereafter. Some states do not
allow limitations on implied warranties, therefore these exclusions may not apply to you.
This warranty gives you specific legal rights; however you may have other rights that vary from state
to state.
WHAT T D IF Y U NEED WARRANTY R SERVICE
Defective merchandise must be returned to your local Authorized Stillwater Designs
(Kicker/Impulse) Dealer for warranty. Assistance in locating an Authorized Dealer can be obtained by
writing or calling Stillwater Designs direct. You can confirm that a dealer is authorized by asking to see a
current authorized dealer window decal.
If it becomes necessary for you to return defective merchandise, call the Kicker Customer Service
Department at [phone] for a eturn Authorization ( A) number. Package all defective items in the
original container or in a package that will prevent shipping damage, and return to
Stillwater Designs, 5021 North Perkins Road, Stillwater, K 74075
The A number must be clearly marked on the outside of the package. eturn only defective compo-
nents. eturn of entire cabinets, system packs, pairs, etc. increases your return freight charges. Non-
defective items received will be returned freight collect.
Include a dated proof-of-purchase from an Authorized Dealer. Warranty expiration on items
returned without proof-of-purchase will be determined from the manufacturing date code. Coverage
may be invalidated if this date is greater than one (1) year previous to the date item is sent in. Freight
must be prepaid; items received freight collect will be refused.
Failure to follow these steps may void your warranty. Any questions can be directed to the Kicker
Customer Service Department at [phone].
WHAT IS NOT COVERED?
This warranty is valid only if the product is used for the purpose for which it was designed.
It does not cover:
