Kikusui OT01-PCR4000LA/2 User manual

Part No. Z1-002-892, IB004473
Feb. 2008
OPERATION MANUAL
OUTPUT EXPANSION KIT
PCR-LA Series
OT01-PCR4000LA/2
OT01-PCR8000LA/2
OT01-PCR12000LA/2

Use of Operation Manual
Please read through and understand this Operation Manual before operating the product. After reading,
always keep the manual nearby so that you may refer to it as needed. When moving the product to another
location, be sure to bring the manual as well.
If you find any incorrectly arranged or missing pages in this manual, they will be replaced. If the manual
gets lost or soiled, a new copy can be provided for a fee. In either case, please contact Kikusui distributor/
agent, and provide the “Kikusui Part No.” given on the cover.
This manual has been prepared with the utmost care; however, if you have any questions, or note any
errors or omissions, please contact Kikusui distributor/agent.
Reproduction and reprinting of this operation manual, whole or partially, without our permission is prohib-
ited.
Both unit specifications and manual contents are subject to change without notice.
Copyright© 2003-2008 Kikusui Electronics Corporation

OT01-PCR-LA/2 Safety Symbols I
Indicates an imminently hazardous situation which, if ignored,
will result in death or serious injury.
Indicates that a high voltage (over 1000 V) is used here. Touch-
ing the part causes a possibly fatal electric shock. If physical
contact is required by your work, start work only after you make
sure that no voltage is output here.
Indicates a potentially hazardous situation which, if ignored,
could result in death or serious injury.
Indicates a potentially hazardous situation which, if ignored, may
result in damage to the product and other property.
Shows that the act indicated is prohibited.
Is placed before the sign “DANGER,” “WARNING,” or “CAU-
TION” to emphasize these. When this symbol is marked on the
product, see the relevant sections in this manual.
Indicates a protective conductor terminal.
Indicates a chassis (frame) terminal.
OR
WARNING
CAUTION
DANGER
Safety Symbols
For the safe use and safe maintenance of this product, the following
symbols are used throughout this manual and on the product. Under-
stand the meanings of the symbols and observe the instructions they
indicate (the choice of symbols used depends on the products).

II Safety Precautions OT01-PCR-LA/2
Safety Precautions
The following are safety precautions to be observed in order to avoid fire hazard,
electric shock, accidents, and other failures. It is not possible to predict all poten-
tial hazards; however, the following describes all known possible hazardous condi-
tions. Keep them in mind and make sure that all of them are observed properly.
Users
• This product must be used only by qualified personnel who understand the con-
tents of this operation manual.
• If it is handled by disqualified personnel, personal injury may result. Be sure to han-
dle it under supervision of qualified personnel (those who have electrical knowl-
edge.)
• This product is not designed or manufactured for general home or consumer use.
Purposes of use
• Do not use the product for purposes other than those described in the operation
manual.
Input power
• Use the product with the specified input power voltage.
• For applying power, use the power cable provided. Note that the provided power
cable is not use with some products that can switch among different input power
voltages or use 100 V and 200 V without switching between them. In such a case,
use an appropriate power cable.
Fuse
• With products with a fuse holder on the exterior surface, the fuse can be replaced
with a new one. When replacing a fuse, use the one which has appropriate shape,
ratings, and specifications.
Cover
• There are parts inside the product which may cause physical hazards. Do not
remove the external cover.
Operation
Manual
Line
Voltage

OT01-PCR-LA/2 Safety Precautions III
Installation
• When installing products be sure to observe “Installation” described in this man-
ual.
• To avoid electrical shock, connect the protective ground terminal to electrical
ground (safety ground).
• When connecting the power cable to a switchboard, be sure work is performed by
a qualified and licensed electrician or is conducted under the direction of such a
person.
• When installing products with casters, be sure to lock the casters.
Relocation
• Turn off the power switch and then disconnect all cables when relocating the
product.
• Use two or more persons when relocating the product which weights more than
20 kg. The weight of the products can be found on the rear panel of the product
and/or in this operation manual.
• Use extra precautions such as using more people when relocating into or out of
present locations including inclines or steps. Also handle carefully when relocat-
ing tall products as they can fall over easily.
• Be sure the operation manual be included when the product is relocated.
Operation
• Check that the AC input voltage setting and the fuse rating are satisfied and that
there is no abnormality on the surface of the power cable. Be sure to unplug the
power cable or stop applying power before checking.
• If any abnormality or failure is detected in the products, stop using it immediately.
Unplug the power cable or disconnect the power cable from the switchboard. Be
careful not to allow the product to be used before it is completely repaired.
• For output wiring or load cables, use connection cables with larger current capac-
ity.
• Do not disassemble or modify the product. If it must be modified, contact Kikusui
distributor/agent.
Maintenance and checking
• To avoid electrical shock, be absolutely sure to unplug the power cable or stop
applying power before performing maintenance or checking.
• Do not remove the cover when performing maintenance or checking.
• To maintain performance and safe operation of the product, it is recommended
that periodic maintenance, checking, cleaning, and calibration be performed.
Service
• Internal service is to be done by Kikusui service engineers. If the product must be
adjusted or repaired, contact Kikusui distributor/agent.
Check?

IV Arrangement of this manual OT01-PCR-LA/2
Arrangement of this manual
This Operation Manual is made up of the following sections.
Chapter 1 General
Provides an overview and describes the features of the Single-phase/Single-phase,
Three-wire Output Expansion Kits.
Chapter 2 Installation and Preparation for Use
Describes the procedures necessary for unpacking the product for preparation prior
to use.
Chapter 3 Output Switching (Operation of the Output Terminal)
Describes output-switching operations of the Output Terminal configured as a sin-
gle phase/Single-phase, three-wire switching system.
Chapter 4 Part Names and Functions (Output Terminal)
Denotes the names of switches, displays, terminals, and other parts on the front and
rear panels of the Output Terminal. Also describes their functions.
Chapter 5 Single-phase Parallel Operation (Operations of PCR-LA
AC Power Supplies)
Describes the procedure for operation of the PCR-LA power supplies in single-
phase parallel operation. For the method of operating a PCR-LA power supply sin-
gly, see the PCR-LA AC Power Supply Operation Manual.
Chapter 6 Single-phase, Three-wire Operation (Operations of PCR-
LA AC Power Supplies)
Describes the procedure for operation of the PCR-LA power supplies in single-
phase, three-wire operation. For the method for operating a PCR-LA power supply
singly, see the PCR-LA AC Power Supply Operation Manual.
Chapter 7 Maintenance
Describes the maintenance procedure for the system, including the PCR-LA AC
power supplies. Also explains the remedies against possible malfunctions encoun-
tered during use of the system.
Chapter 8 Specifications
Shows the specifications and accessories for the Output Expansion Kits.

OT01-PCR-LA/2 Contents V
Contents
Safety Symbols ____________________________________________ I
Safety Precautions ________________________________________ II
Arrangement of this manual ________________________________ IV
Chapter 1 General 1-1
1.1 Outline of the Product - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1-2
1.2 Features - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1-3
1.3 Outline of the Operating Sections - - - - - - - - - - - - - - - - - - - - - - - - - - - 1-4
1.4 The Applicable ROM Version of the PCR-LA - - - - - - - - - - - - - - - - - - - - 1-5
1.5 Combination of Options - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1-5
Chapter 2 Installation and Preparation for Use 2-1
2.1 Check at Unpacking - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-2
2.2 Precautions on Installation - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-6
2.3 Moving Precautions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-7
2.4 Grounding - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-8
2.5 Connections for a Single-phase/
Single-phase, Three-wire Switching System - - - - - - - - - - - - - - - - - - - - 2-8
2.5.1 Input Power of PCR-LA Power Supplies (Two Units) - - - - - - - - 2-9
2.5.2 Connection of Power Connection Cables - - - - - - - - - - - - - - - - - 2-12
2.5.3 Signal Connection Cables - - - - - - - - - - - - - - - - - - - - - - - - - - 2-15
2.5.4 Parallel Operation Driver - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-17
2.5.5 Single-phase, Three-wire Output Driver - - - - - - - - - - - - - - - - - 2-19
2.5.6 Summary of System Connections - - - - - - - - - - - - - - - - - - - - - 2-20
2.6 Power ON - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-22
2.7 Operation Check - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-24
2.7.1 Single-phase Parallel Operation - - - - - - - - - - - - - - - - - - - - - - - 2-24
2.7.2 Single-phase, Three-wire Operation - - - - - - - - - - - - - - - - - - - - 2-25
2.8 Connecting a Load - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-26
Chapter 3 Output Switching
(Operation of the Output Terminal) 3-1
3.1 Panel Operation - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-2
3.1.1 Single-phase Parallel Operation - - - - - - - - - - - - - - - - - - - - - - - - 3-2
3.1.2 Single-phase, Three-wire Operation - - - - - - - - - - - - - - - - - - - - - 3-3
3.1.3 Shutting Down the Power in an Emergency - - - - - - - - - - - - - - - - 3-3
3.2 External Control - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-4
Chapter 4 Part Names and Functions
(Output Terminal) 4-1
4.1 OT01-PCR4000LA/2 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4-2
4.1.1 Front Panel - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4-2

VI Contents OT01-PCR-LA/2
4.1.2 Rear Panel - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4-3
4.2 OT01-PCR8000LA/2 or OT01-PCR12000LA/2 - - - - - - - - - - - - - - - - - - 4-5
4.2.1 Front Panel - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4-5
4.2.2 Rear Panel - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4-6
Chapter 5 Single-phase Parallel Operation
(Operations of PCR-LA AC Power Supplies) 5-1
5.1 Basic Operations - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5-2
5.2 Setting Limit Values - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5-2
5.3 Steps to be Taken in the Event of an Alarm - - - - - - - - - - - - - - - - - - - - - 5-3
5.4 Ammeter’s Zero Calibration Function - - - - - - - - - - - - - - - - - - - - - - - - - 5-6
5.4.1 Zero Calibration Procedure When Using RC04-PCR-LA - - - - - - 5-6
5.4.2 Messages Available When Using the RS-232C or GPIB Interface 5-7
Chapter 6 Single-phase, Three-wire Operation
(Operations of PCR-LA AC Power Supplies) 6-1
6.1 Basic Operations - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 6-2
6.2 Switching of Output Voltage Display - - - - - - - - - - - - - - - - - - - - - - - - - 6-2
6.3 Output Voltage Setting - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 6-3
6.4 Limit Value Setting - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 6-4
6.5 Current/Power Display Mode - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 6-4
6.6 Memory Function - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 6-5
6.7 Key-lock Function - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 6-5
6.8 Steps to be Taken in the Event of an Alarm - - - - - - - - - - - - - - - - - - - - - 6-6
6.9 Limitations on the PCR-LA Power Supplies - - - - - - - - - - - - - - - - - - - - 6-9
6.10 Using the Remote Controller - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 6-9
6.10.1 Switching between Phase Voltage and Line Voltage Displays - - - 6-10
6.10.2 Displaying the V-Phase Current and Voltage - - - - - - - - - - - - - - 6-10
6.10.3 Switching to the Current or Power Display Mode - - - - - - - - - - - 6-11
6.10.4 Sequence Operation - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 6-11
6.10.5 Harmonic Current Analysis Function - - - - - - - - - - - - - - - - - - - 6-11
6.11 Using the GPIB/RS-232C Interface - - - - - - - - - - - - - - - - - - - - - - - - - 6-12
6.11.1 Phase Voltage/Line Voltage Display Messages - - - - - - - - - - - - - 6-12
6.11.2 Output Voltage Setting Messages - - - - - - - - - - - - - - - - - - - - - 6-13
6.11.3 Output Measurement Messages - - - - - - - - - - - - - - - - - - - - - - - 6-15
6.11.4 Harmonic Current Analysis Messages - - - - - - - - - - - - - - - - - - - 6-17
Chapter 7 Maintenance 7-1
7.1 Maintenance - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 7-2
7.1.1 Cleaning the Panel Surface - - - - - - - - - - - - - - - - - - - - - - - - - - 7-2
7.1.2 Cleaning the Air-intake Filters in the PCR-LA Power Supplies - - 7-2
7.1.3 Inspecting the Power Connection Cables - - - - - - - - - - - - - - - - - 7-2
7.2 Malfunctions and Causes - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 7-3
7.2.1 Single-phase Parallel Operation - - - - - - - - - - - - - - - - - - - - - - - 7-3
7.2.2 Single-phase, Three-wire Operation - - - - - - - - - - - - - - - - - - - - - 7-5

OT01-PCR-LA/2 Contents VII
Chapter 8 Specifications 8-1
8.1 Specifications - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 8-2
8.1.1 Output Expansion Kits (Single-phase/Single-phase, Three-wire Switch-
ing) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 8-2
8.1.2 Parallel Operation - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 8-2
8.1.3 Single-phase, Three-wire Operation - - - - - - - - - - - - - - - - - - - - - 8-3
8.2 Dimensions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 8-4
Index 1- 1

VIII Contents OT01-PCR-LA/2

OT01-PCR-LA/2 General 1-1
Chapter 1 General
Provides an overview and describes the features of the Single-phase/Single-phase,
Three-wire Output Expansion Kits.
1
1

1-2 General OT01-PCR-LA/2
1.1 Outline of the Product
These products are Output Expansion Kits for the PCR-LA series AC power sup-
plies. An output expansion kit enables configuration of a system capable of switch-
ing the outputs of multiple PCR-LA power supplies to obtain single- or single-
phase, three-wire outputs. Output switching is performed at the Output Terminal
section. The customer should make connections between the respective units. All of
the cables required for connections are provided with the Output Expansion Kits.
A system is configured on the basis of the PCR-LA series single-phase output
power supplies. In single-phase parallel operations, two power supplies are operated
in parallel. In single-phase, three-wire operations, two power supplies generate out-
puts in respective phases.
■ List of the Output Expansion Kits
Fig. 1-1 Example of the Configuration of a Single-phase/Single-
phase, Three-wire Switching System, OT01-PCR8000LA/2
Model name Number of PCR-LA
power supplies Rated output capacity
OT01-PCR4000LA/2 Two PCR2000LAs 4 kVA
OT01-PCR8000LA/2 Two PCR4000LAs 8 kVA
OT01-PCR12000LA/2 Two PCR6000LAs 12 kVA
Two PCR4000LAs Output Terminal section

OT01-PCR-LA/2 General 1-3
1.2 Features
■ Single-phase/single-phase, three-wire switching system
Single-phase/single-phase, three-wire switching can be achieved without mod-
ifying cable connections. The Output Terminal has dedicated output terminals
for single-phase and single-phase, three-wire, respectively, which is conve-
nient for connecting and disconnecting a load.
■ Single-phase parallel operation
Control
A system of AC power supplies capable of generating high-quality, large-
capacity output can be realized. The two PCR-LA power supplies are operated
in parallel, one slave unit of which is controlled by the master unit.
■ Single-phase, three-wire operation
Control
For single-phase, three-wire outputs, two AC power supplies are assigned to
the U- and V-phases, respectively. The U-phase unit controls the V-phase unit.
Phase voltage unbalance
Generally, all phase voltages are set in one operation, but it is also possible to
set phase voltages on a phase basis.
Line voltage measurements
The system is capable of measuring not only phase voltages but also line volt-
ages.
Single-phase, three-wire power
The power and apparent power of a load can be displayed as the total value of
those measured by the two PCR-LA power supplies. The total power factor for
the single-phase three-wire is also calculated from the total of measured val-
ues. (Note that the measurement of apparent power or the power factor
requires the RS-232C Control, the optional RC04-PCR-LA, or the optional
IB03-PCR-LA.)
RC04-PCR-LA: Remote Controller
IB03-PCR-LA: GPIB Interface

1-4 General OT01-PCR-LA/2
1.3 Outline of the Operating Sections
The operating sections are the front panel of the Output Terminal and the PCR-LA
AC power supply’s control panel.
■ Output Terminal’s front panel operating section
Fig. 1-2 OT01-PCR4000LA/2
Fig. 1-3 OT01-PCR8000LA/2 or OT01-PCR12000LA/2
■ PCR-LA power supply’s control panel operating section
Fig. 1-4 PCR-LA Power Supply’s Control Panel

OT01-PCR-LA/2 General 1-5
1.4 The Applicable ROM Version of the PCR-LA
This Operation Manual applies to cases in which the expansion kit is connected to
PCR-LA AC power supplies with ROM of
version 3.35 or later.
When using above options with the PCR-LA in single-phase three-wire operation,
the PCR-LA must be required with the ROM version of 3.35 or later. If the ROM
version of the PCR-LA is 3.34 or previous version, the PCR-LA is required for the
ROM update.
To check the ROM version of the PCR-LA, refer to the operation manual of the
PCR-LA series.
In case, the PCR-LA needs the ROM update, contact your Kikusui agent or distrib-
utor.
When making an inquiry about the product, please provide us with the following
information:
• Model name of the PCR-LA power supplies
• ROM version of the PCR-LA power supplies
• Serial numbers and revision numbers of the PCR-LA power supplies (indicated
at the lower rear of the products)
• Model name of this expansion kit
• Serial number and revision number of the expansion kit (indicated at the rear of
the Output Terminal)
1.5 Combination of Options
The table below shows a combination of the options available. They can be installed
in the PCR-LA AC power supply in which the U-phase card has been installed.
Option name Model name
Remote Controller RC04-PCR-LA
GPIB Interface IB03-PCR-LA

1-6 General OT01-PCR-LA/2

OT01-PCR-LA/2 Installation and Preparation for Use 2-1
Chapter 2 Installation and
Preparation for Use
Describes the procedures necessary for unpacking the product for preparation prior
to use.
2
2

2-2 Installation and Preparation for Use OT01-PCR-LA/2
2.1 Check at Unpacking
Upon receiving the product, confirm that the package contains the necessary acces-
sories and has not been damaged during transportation.
If the output expansion kit is damaged or any accessory is missing, notify your
Kikusui distributor/agent.
• We recommend that all packing materials be saved, in case the product needs to
be transported at a later date.
■ Power connection cables
Fig. 2-1 Power Connection Cables, Six
■ Signal connection cables
Model name Description
OT01-PCR4000LA/2 5.5 mm
2
/2.5 m, 6 pcs. [91-80-7377 (three pcs.)x2]
OT01-PCR8000LA/2
14 mm
2
/2.5 m, 6 pcs. [91-80-7524 (three pcs.)x2]
OT01-PCR12000LA/2
Part name Description
Signal connection cable 1
For OT01-PCR4000LA/2
[91-87-8154]
For master J1
(4 poles – 4 poles),
one
NOTE

OT01-PCR-LA/2 Installation and Preparation for Use 2-3
Part name Description
Signal connection cable 1
For OT01-PCR8000LA/2
For OT01-PCR12000LA/2
[91-87-8155]
For master J1
(4 poles – 6 poles),
one
Signal connection cable 2
(Common to each model)
[91-87-8156]
For J4
(6 poles – 6 poles),
two
Signal connection cable 3
For OT01-PCR4000LA/2
[91-80-6900]
For J3 to J1
(4 poles – 4 poles),
one
Signal connection cable 3
For OT01-PCR8000LA/2
For OT01-PCR12000LA/2
[91-80-6901]
For J3 to J1
(6 poles – 6 poles),
one
Signal connection cable 4
(Common to each model)
[91-87-8167]
For sensing
(10 poles – 2 crimp
terminals),
one
Signal connection cable 5
(Common to each model)
[91-88-4453]
For the parallel-operation
master
With connectors at both
ends
(26 poles; length: 2.5 m),
one

2-4 Installation and Preparation for Use OT01-PCR-LA/2
■ Parallel Operation Driver: (common to each model)
*1
*1 These boards are dedicated for the expansion kits and are used when the PCR-LA AC power
supplies are used in combination with the Output Terminal. They cannot be used for parallel
or single-phase, three-wire operations of PCR-LA power supplies only.
Fig. 2-2 Complete Set of Parallel Operation Drivers
■ Single-phase, Three-wire Output Driver: 2P03-OT01-PCR-LA
(common to each model)
*1
Part name Description
Master-unit card
PD03M-OT01-PCR-LA 1
Slave-unit card
PD03S-OT01-PCR-LA 1
Drive-signal cable With drive-signal connectors (26 poles), one pc.
Mounting screw (M3) 4
Part name Description
U-phase card
*2
1
V-phase card
*2
1
Drive-signal cable With drive-signal connectors (34 poles), one pc.
Mounting screw (M3) 4
Master-unit card/slave-unit card (one each, total of two boards)
Drive-signal cable (26 poles; one pc.; length: 0.7 m)
[91-87-6330]
Card-mounting screws (two pcs. for each card, total of 4 pcs.)
[M3-101-001]
M3x6
