Kikusui PAT-T Series User manual

PART NO. Z1-004-772, IB020522
Dec. 2010
Appx
1
2
3
4
5
6
7
8
General
Description
Installation and
Preparation
Connecting the Load
Basic Operation
External Control
Parallel/Series Operation
Remote Control
Maintenance
Specifications
PAT-T Series
User’s Manual
Regulated DC Power Supply
8 kW type
PAT20-400T
PAT30-266T
PAT40-200T
PAT60-133T
PAT80-100T
PAT160-50T
PAT250-32T
PAT350-22.8T
PAT500-16T
PAT650-12.3T
PAT850-9.4T

Thank youfor purchasing the PAT-T Series Regulated DC
Power Supply.
The operation manual for the PAT-T Series is consisting of the
“User’s Manual” (this manual) and the “Communication Inter-
face Manual”.
This manual is intended for users of the product or persons
teaching other users on howto operate the product.
The manual assumes that the reader has knowledge about
Power Supply.
• User’s manual (this manual)
The User’s manual is intended for first-time users of this
product. It provides an overviewof the product and notes on
usage. It also explains howto configure the product, oper-
ate the product, perform maintenance on the product, and
so on. Read this manual thoroughly to use the functions of
the product effectively.
This manual is designed to be read from beginning to end.
We recommend that youread it thoroughly before using this
product for the first time.
Youcan also reviewthis manual when youare confused
about an operation or when a problem occurs.
• The communication interface manual
The communication interface manual describes the content
of the commands.
The interface manual is written for readers with sufficient
basic knowledge of howto control instruments using a
personal computer.
The interface manual is provided in HTML format on the
accompanied CD-ROM (a portion of the manual is in PDF
format). Youcan viewthe Operating environment Windows
98or later. Youcan viewit using Microsoft Internet Explorer
5.5 or later. Youcan viewthe PDF file using Adobe Reader
6.0 or later.
If youfind any incorrectly arranged or missing pages in the
manual, they will be replaced. If the manual gets lost or soiled,
a newcopy can be provided for a fee. In either case, please
contact Kikusui distributor/agent, and provide the “Kikusui Part
No.” given on the cover.
The Operation Manual has been prepared with the utmost
care; however, if youhave any questions, or note any errors or
omissions, please contact Kikusui distributor/agent.
After reading, always keep the manual nearby so that youmay
refer to it as needed.
Applicable firmware version of the PAT-T
Series
This manual applies to PAT-T Series with firmware version
5.0x.
When making an inquiry about the product, please provide us
with the following information.
• Model (indicated at the top section on the front panel)
•Firmware version (See page 1-6 .)
•Serialnumber (indicated at the bottom section on the rear
panel)
This product information can also be obtained using the *IDN?
remote control command.
Trademarks
Microsoft and Windows are registered trademarks of Microsoft
Corporation in the United States and/or other countries.
Other company names and product names used in this man-
ual are generally trademarks or registered trademarks of the
respective companies.
Copyright
Reproduction and reprinting of this operation manual, whole or
partially, without our permission is prohibited.
Both unit specifications and manual contents are subject to
change without notice.
©2010 Kikusui Electronics Corporation
About Operation Manual

PAT-T 8kWi
For the safe use and safe maintenance of this product, the
following symbols are used throughout this manual and on the
product. Note the meaning of each of the symbols to ensure
safe use of the product. (Not all symbols may be used.)
or
Indicates that a high voltage (over 1000 V) is used here.
Touchingthe part causes a possibly fatal electric
shock. If physical contact is required by your work,
start work only after you make sure that no voltage is
output here.
DANGER
Indicates an imminently hazardous situation which, if
ignored, will result in death or serious injury.
WARNING
Indicates a potentially hazardous situation which, if
ignored, could result in death or serious injury.
CAUTION
Indicates a potentially hazardous situation which, if
ignored, may result in damage to the product and other
property.
• In this manual, the PAT-T Series regulated DC power supply
is often simply referred to as “the PAT.”
• The word “PC” used in this manual is a generic term for
personal computers and workstations.
• The following marks are used with the explanations in this
manual.
Indicates a potentially hazardous situation which, if
ignored, could result in death or serious injury.
Indicates a potentially hazardous situation which, if
ignored, may result in damage to the product and
other property.
Indicates information that youshould know.
Explanation of terminology or operation principle.
Indicates reference to detailed information.
SHIFT+key name (marked in blue)
Indicates an operation in which a switch marked in blue is
pressed while holding down the SHIFT switch.
CFxx : x
The first two characters “CF” indicates a configuration
setting, and the next two-digit number indicates the
CONFIG parameter number. The character after the colon
indicates the selected setting.
Shows that the act indicated is prohibited.
Indicates a general danger, warning, or caution.
When this symbol is marked on the product, see
the relevant sections in this manual.
Indicates a caution for hot surface of the product.
When this symbol is marked on the product, see
the relevant sections in this manual.
Protective conductor terminal.
Chassis (frame) terminal.
On (supply)
Off (supply)
In position of a bi-stable push control
Out position of a bi-stable push control
Safety Symbols
Notations Used in This Manual
WARNING
CAUTION
DESCRIPTION
See

ii PAT- T 8kW
The following safety precautions must be observed to avoid
fire hazards, electric shock, accidents, and other failures. Keep
them in mind and make sure to observe them.
Using the product in a manner that is not specified in this
manual may impair the protection functions provided by the
product.
Users
• This product must be used only by qualified personnel who
understand the contents of this operation manual.
• If an unqualified personnel is to use the product, be sure the
product is handled under the supervision of qualified
personnel (those who have electrical knowledge). This is to
prevent the possibility of personal injury.
Purpose of use
•Neveruse the product for purposes other than the product's
intended use.
• This product is not designed or manufactured for general
home or consumer use.
Input power
• Use the product within the rated input power voltage range.
• For applying power, use the power cable provided. For
details, see the respective page in the operation manual.
• This product is an equipment of IEC Overvoltage Category
II (energy-consuming equipment supplied from the fixed
installation).
Cover
• Some parts inside the product may cause physical hazards.
Do not remove the external cover.
Grounding
• This product is an IEC Safety Class I equipment (equipment
with a protective conductor terminal). To prevent electric
shock, be sure to connect the protective conductor terminal
of the product to electrical ground (safety ground).
Relocation
•Lower the POWER switch lever to turn it off.
• Remove all wiring.
•When transporting the product, be sure to use the original
packing materials.
• The product weighs over 20 kg. When moving the product,
have more than one person carry it. The weight of the
product is indicated on the rear panel of the product and in
the specification table in this manual.
•Besure to include the manual.
Operation
• Before using the product, be sure to check the input power
voltage and that there is no abnormality in the appearance
of the power cable. Be sure to turn off the switchboard
breaker before checking.
•Ifamalfunction or abnormality is detected on the product,
stop using it immediately, and remove the power cable from
the switchboard. Make sure the product is not used until it is
completely repaired.
• Use cables or wires with sufficiently large current capacity
for output wires and load cables.
• Do not disassemble or modify the product. If youneed to
modify the product, contact your Kikusui distributor/agent.
Maintenance and inspection
• To prevent electric shock, be sure to unplug the product
before carrying out maintenance or inspection. Do not
remove the external cover.
• Check periodically that there are no tears or breaks in the
power cord and the test lead covering.
• If the panel needs cleaning, gently wipe using a soft cloth
with water-diluted neutral detergent. Do not use volatile
chemicals such as benzene or thinner.
• To maintain the performance and safe operation of the
product, it is recommended that periodic maintenance,
inspection, cleaning, and calibration be performed.
Service
•Kikusui service engineers will perform internal service on
the product. If the product needs adjustment or repairs,
contact your Kikusui distributor/agent.
Safety Precautions
Operation
Manual
Line
Voltage
GNL
Check?

PAT-T 8kWiii
Warninglabel
• There is a warning label affixed to the product. If this label
tears or falls off, replace with a newlabel. If youneed a new
label, contact your Kikusui agent or distributor.
Be sure to observe the followingprecautions when
installingthe product.
• Do not use the product in a flammable atmosphere.
To prevent the possibility of explosion or fire, do not use the
product near alcohol, thinner or other combustible materials,
or in an atmosphere containing such vapors.
• Avoid locations where the product is exposed to high
temperature or direct sunlight.
Do not install the product near a heater or in areas subject
to drastic temperature changes.
Operating temperature range: 0 ° C to +50 ° C (32 ° F to 122 ° F )
Storage temperature range: -25
° C to +70 ° C (-13 ° F to 158 ° F)
•Avoidhumid environments.
Do not install the product in high-humidity locations–near a
boiler, humidifier, or water supply.
Operating humidity range: 20 %rh to 85 %rh (no condensation)
Storage humidity range: 90 %rh or less (no condensation)
Condensation may occur even within the operating relative
humidity range. If this happens, do not use the product until
the condensation dries up completely.
•Besure to use the product indoors.
This product is designed for safe indoor use.
• Do not install the product in a corrosive atmosphere.
Do not install the product in a corrosive atmosphere or in
environments containing sulfuric acid mist, etc. This may
cause corrosion of various conductors and bad contacts of
connectors leading to malfunction and failure, or in the worst
case, a fire.
However, operation in such environments may be possible
through alteration. If youwant to use the PAT in such
environments, consult your Kikusui agent or distributor.
• Do not install the product in a dusty location.
Accumulation of dust can lead to electric shock or fire.
• Do not use the product where ventilation is poor.
The product employs a forced air cooling system. Air is
taken in from the air inlet on the front panel and exhausted
from the air outlet on the rear panel. Secure adequate
space around the product to prevent the possibility of fire
caused by accumulation of heat.
Allowat least 20 cm of space between the air inlet/outlet
and the wall (or obstacles). Hot air (approximately 20
° C
higher than the ambient temperature) is exhausted from the
air outlet. Do not place objects that are affected by heat
near the air outlet.
• Do not place objects on the product.
Placing heavy objects on top of the product may cause
failures.
• Do not install the product on an inclined surface or location
subject to vibrations.
The product may fall or tip over causing damages and
injuries.
• Do not use the product in a location where strong magnetic
or electric fields are nearby or a location where large
amount of distortion and noise is present on the input power
supply waveform.
The product may malfunction.
• Do not use the product near highly sensitive measuring
instruments or transceivers.
The noise generated by the product may affect them.
PAT- T Top panel Label
Precautions ConcerningInstallation

iv PAT- T 8kW
The PAT is a low-noise, highly efficient Constant Voltage (CV)/
Constant Current (CC) automatic crossover power supply that
employs a software switching system.
Capable to expand the system up to a maximum output of 40
kWby the master-slave parallel operation.
Communication functions for remote control also come
standard with the product.
The all models can also receive three-phase 200 Vac and
inputthree-phase 400 Vac input. In this manual, the three-
phase 400 Vac input models are often simply referred to as
“400 V input model.”
• Reduction of harmonic current and power transmission
loss
The power-factor improvement circuit reduces the effects of
harmonic currents on the input power line. It also
suppresses the peak current and reduces the power
transmission loss.
• Master-Slave parallel operation
Up to five power supplies can be connected in parallel to
expand the output power to 40 kW.
(Youcan expand the output power to 16 kWby connecting
two PAT850-9.4T power supplies in parallel.)
• Output limit function
Yo ucan set the upper limit of current and voltage that is
applied when setting the output.
This function is used to prevent setting inappropriate value
by mistake.
• Remote interface
Equipped with RS232C as standard. Youcan select the
GPIB, USB or LAN interface as a factory option.
The remote interface complies with IEEE 488.2 std 1992
and SCPI Specification 1999.0. Because the LAN interface
complies with the LXI standard, the construction of a highly
cost-effective system is possible.
•High efficiency and low noise
The PAT is a highly efficient, low-noise power supply that
employs a software switching system.
High power conversion efficiency has reduced the rise in the
internal temperature and has contributed to the product’s
compact and light design.
• Downsized input distribution device
The input distribution device (breaker) can be downsized,
because the built-in power-factor improvement circuit
reduces the required input current.
• Preset memory function of settings
Up to three output setting presets (combination of current
and voltage) can be saved.
Yo ucan simply select a preset to set the output without
having to set the voltage and current every time youuse the
PAT.
• Output on/off delay function
Yo ucan set a delay until the output is actually turned on or
off after turning the OUTPUT switch on or off.
For example, this feature is useful if youwant to turn the
output on/off by setting a time offset according to the load
characteristics.
Product Overview
Features

PAT-T 8kWv
Contents
Safety Symbols .........................................................................................................i
Notations Used in This Manual .................................................................................i
Safety Precautions ...................................................................................................ii
Precautions Concerning Installation ........................................................................ iii
Product Overview....................................................................................................iv
Features ..................................................................................................................iv
Contents by Function ............................................................................................. vii
Front panel ............................................................................................................ viii
Rear panel ................................................................................................................x
1Installation and Preparation
1.1 Checking the Package Contents..............................................................................1-2
1.2 Rack Mounting the Product......................................................................................1-3
1.3 Connecting the Power Cable ...................................................................................1-4
1.4 Turning On ..............................................................................................................1-6
2Connecting the Load
2.1 Load Considerations ................................................................................................2-2
2.2 Load Cable...............................................................................................................2-4
2.3 Connecting to the Output terminal ...........................................................................2-6
3Basic Operation
3.1 Measured Value Display and Setting Display (Setting the Output Voltage and Output
Current)....................................................................................................................3-2
3.2 Output Operation .....................................................................................................3-3
3.3 Constant Voltage (CV) and Constant Current (CC) Power Supplies .......................3-5
3.4 Using the PAT as a CV or CC Power Supply (Setting the Output Voltage and Output
Current)....................................................................................................................3-7
3.5 Protection Functions and Alarms .............................................................................3-8
3.5.1 Overvoltage protection (OVP) and overcurrent protection (OCP) ................3-9
3.5.2 Other Protection Functions .........................................................................3-12
3.6 CONFIG Settings ...................................................................................................3-14
3.7 Preset Memory Function........................................................................................3-23
3.8Lock Function.........................................................................................................3-24
3.9 Switching from Remote to Local Mode ..................................................................3-25
3.10 Remote Sensing Function......................................................................................3-25
3.11 Factory Default Settings.........................................................................................3-28
4External Control
4.1 Overviewof External Control ...................................................................................4-2
4.2 J1 Connector............................................................................................................4-2
4.3 Output terminal Insulation ........................................................................................4-5
4.3.1 When the Output terminal Is Not Grounded (Floating) .................................4-6
4.3.2 When the Output terminal Is Grounded ........................................................4-7
4.4 Controlling the Output Voltage.................................................................................4-9
4.4.1 External Voltage (Vext) Control ....................................................................4-9
4.4.2 External resistance (Rext) control...............................................................4-11

vi PAT-T 8kW
4.5 Controlling the Output Current............................................................................... 4-13
4.5.1 External Voltage (Vext) Control.................................................................. 4-13
4.5.2 External Resistance (Rext) Control ............................................................ 4-15
4.6 Controlling the Output On/Off ................................................................................ 4-17
4.7 Shutdown Control Using External Contact ............................................................ 4-19
4.8External Monitoring................................................................................................ 4-21
5Parallel/Series Operation
5.1 Master-Slave Parallel Operation.............................................................................. 5-2
5.1.1 Functions during Master-Slave Parallel Operation....................................... 5-2
5.1.2 Connection (Parallel Operation) ................................................................... 5-4
5.1.3 Master-Slave Parallel Operation Setup ........................................................ 5-7
5.1.4 Starting the Master-Slave Parallel Operation ............................................... 5-8
5.2 Series Operation...................................................................................................... 5-9
5.2.1 Functions during series operation ................................................................ 5-9
5.2.2 Load Connection (Series Operation).......................................................... 5-11
5.2.3 Series Operation Setup .............................................................................. 5-12
5.2.4 Starting the Series Operation ..................................................................... 5-12
6Remote Control
6.1 Remote Control Overview........................................................................................ 6-2
6.2 Interface Setup ........................................................................................................ 6-3
6.2.1 RS232C Control (Standard Equipped) ......................................................... 6-3
6.2.2 GPIB Interface (Option)................................................................................ 6-5
6.2.3 USB Interface (Option) ................................................................................. 6-6
6.2.4 LAN interface (Option).................................................................................. 6-7
6.3 Contents of the Included CD-ROM .......................................................................... 6-9
6.4 Installing the VISA library....................................................................................... 6-10
6.5 Command Details .................................................................................................. 6-11
7Maintenance
7.1 Inspection ................................................................................................................ 7-2
7.2 Cleaning................................................................................................................... 7-2
7.3 Calibration................................................................................................................ 7-5
7.3.1 Calibration Overview.................................................................................... 7-5
7.3.2 Calibration Procedure................................................................................... 7-6
8Specifications
Appendix A.1 Options ....................................................................................................................A-2
A.2 Troubleshooting.......................................................................................................A-4
Index

PAT-T 8kWvii
Contents by Function
Trobleshooting... See “A.2 Troubleshooting” on page A-4
•Iwant to check the accessories. ➔1.1, “Checking the Package Contents” p. 1-2
• The installation space is limited. Howmuch space is
needed around the air inlet and outlet?
➔“Precautions Concerning Installation” p. iii
•Howdo I connect the AC power supply? ➔1.3, “Connecting the Power Cable” p. 1-4
•What kind of wires should be used to connect to the AC
power supply?
➔1.3, “Connecting the Power Cable” p. 1-4
•What kind of wires should be used to connect the load? ➔2.2, “Load Cable” p. 2-4
• The wire connecting the load is long (distance to the load
is long), but stable voltage is required.
➔3.10, “Remote Sensing Function” p. 3-25
•Howdo I rack mount the PAT? What kind of parts is
needed?
➔“ Options” p. A-2
•Howdo I set the communication conditions for remote
control?
➔6.2, “Interface Setup” p. 6-3
•Howdo I control the output voltage using an external DC
voltage?
➔4.4.1, “External Voltage (Vext) Control” p. 4-9
•Howdo I increase the current capacity in parallel
operation?
➔5.1, “Master-Slave Parallel Operation” p. 5-2
•Howdo I reset the PAT to factory default settings? ➔3.11, “Factory Default Settings” p. 3-28
•Howcan I use the PAT as a constant voltage power supply
(CV)?
➔
3.4, “Using the PAT as a CV or CC Power
Supply (Setting the Output Voltage and
Output Current)” p. 3-7
•Howcan I use the PAT as a constant voltage current
supply (CC)?
•Iwould like to operate the PAT at a given voltage. Howdo
I register the voltage in the preset memory?
➔3.7, “Preset Memory Function” p. 3-23
•Howdo I set the upper limit to prevent the voltage from
being increased too much?
➔“ Setting limit function” p. 3-10
•Howdo I set the voltage in fine resolution? ➔“ Fine adjustment function” p. 3-7
•Howdo I set the protection function to prevent damage to
the load?
➔3.5, “Protection Functions and Alarms” p. 3-8
➔3.5.1, “Overvoltage protection (OVP) and
overcurrent protection (OCP)” p. 3-9
•Howdo I cut off the output at a different time from other
power supplies?
➔“ Output on/off delay functions” p. 3-4
•Howcan I monitor the output voltage and output current? ➔4.8, “External Monitoring” p. 4-21
•Howdo I temporarily lock the keys? ➔3.8, “Lock Function” p. 3-24
•Howdo I use the sample program for remote control? ➔For information about remote control, see
the accompanying CD-ROM. ---
•Howdo I display a slave unit's current during parallel
operation?
5.1.1, “Functions during Master-Slave
Parallel Operation” p. 5-2
•Howdo I clean the dust filter? ➔“Cleaning the Dust Filter” p. 7-2
•Howdo I check for breaks and tears in the insulation? ➔7.1, “Inspection” p. 7-2
•Howdo I calibrate the PAT-T series? ➔7.3, “Calibration” p. 7-5
Preparation
Setting
Operation
Maintenance

viii PAT-T 8kW
Front panel
Examples of PAT20-400T
CV
EXTEXT
RMTRMT
LOCK
PRESET
ABC
AV
OUTPUT
ALARM
CCCC
CC
V
0-
16
679
13
14
15
21
20
19
18
17
12
11
810
0-
1
234
5
Display and swiches

PAT-T 8kWix
No.
Name
Function
Page
+SHIFT
1POWER Power on/off lever
Raise the lever to turn the power on ( ). Lower to turn the power off ( ). 1-6
2OUTPUT Output on/off switch. 3-3
3CURRENT knob Used to set the current value or select the CONFIG parameter number. –
FINE Current adjustment knob when the fine adjustment function is enabled. 3-7
4VOLTAGE knob Used set the voltage value or change the CONFIG parameter setting. –
FINE Voltage adjustment knob when the fine adjustment function is enabled. 3-7
5Air inlet (louver) Inlet for taking in air from the outside. A dust filter is built in. 7-2
6Ammeter Displays the current value or the CONFIG parameter number. –
7CC Illuminates in constant current mode. 3-7
8Voltmeter Displays the voltage value or the CONFIG parameter setting. –
9PRESET The LED of the preset memory in use illuminates. 3-23
10 CV Illuminates during constant voltage mode. 3-7
11 OUTPUT LED Illuminates when output is on and turns off when output is off. 3-2
12 ALARM LED Illuminates when a protection circuit is activated. 3-8
13 RMT LED Illuminates when operating in remote control. 3-25
14 EXT LED Illuminates when operating in external control. 4-2
15 LOCK LED Illuminates when panel operations except turning the output on/off and viewing
settings. 3-24
16 SET Switch with an LED for setting and checking the output voltage or output
current. 3-7
–RECALL A Switch for recalling the value of preset memory A 3-23
ASwitch for saving the value to preset memory A. Press STORE and then A. 3-23
17 OVP•OCP Switch with an LED for setting and checking the trip points of the overvoltage
protection (OVP) and overcurrent protection (OCP). 3-9
–RECALL B Switch for recalling the value of preset memory B 3-23
BSwitch for saving the value to preset memory B. Press STORE and then B. 3-23
18CONFIG Switch with an LED for setting various conditions concerning the operation. 3-14
–RECALL C Switch for recalling the value of preset memory C 3-23
CSwitch for saving the value to preset memory C. Press STORE and then C. 3-23
19 –––
STORE Switch for storing the preset memory 3-23
20 SHIFT Switch for calling up the functions marked in blue characters. i
21 LOCAL Switch for changing between remote and local modes. 3-25
LOCK Switch for disabling only the operations that change the settings (keeping the
display and recall operations enabled). 3-24
See

xPAT-T 8kW
Rear panel
No. Name Function
Page
22 J1 Connector for external analog control. 4-2
23 J2 Connector for parallel operation. 5-4
24 Option slot Slot for installing the optional interface board (GPIB, USB or LAN). A factory
option.
6-5
6-6
25 Chassis terminal Terminal used to ground the output. 2-6
26 DC OUTPUT Output terminal. 2-4
2-6
27 Air outlet Exhaust port for cooling. iii
28AC INPUT Input terminal. 1-4
29 Serial number The serial number of the PAT. –
30 Sensing terminal A terminal used to connect the sensing wires. 3-25
31 Sensing switch Switch for enabling/disabling remote sensing.
32 RS232C Connector for the RS-232C cable. 6-3
32
25
22 23
31
27
28
26
29
24
30
See

Installation and Preparation
This chapter describes the procedures
of unpacking and preparation of the
PAT before use.
1

1-2 PAT-T 8kW
1.1 Checkingthe Package Contents
When you receive the product, check that all accessories are included and that the
accessories have not been damaged during transportation.
If any of the accessories are damaged or missing, contact your Kikusui agent or
distributor.
We recommend that all packing materials be saved, in case the product needs to be
transported at a later date.
Fig.1-1 Accessories
Pins 30 pcs.
[84-49-0100]
Socket
2 pcs.
[84-49-0160]
Protection cover
2 sets
[84-49-0161]
OUTPUT terminal cover set (2 sets)
Output terminal bolt (M12) (2 sets)
(PAT20-400T/30-266T)
J1/J2 connector kit
[M1-100-027]
[M5-101-009]
[M4-100-009]
Chassis connection wire set (1 set)
User’s manual (This manual, 1 pc. )
[Z1-004-772]
[M1-100-013]
[M5-101-007]
[M4-100-007]
Output terminal bolt (M8) (2 sets)
(PAT250-32T/350-22.8T/500-16T
/650-12.3T/850-9.4T)
[M1-100-019]
[M5-101-008]
[M4-100-008]
Output terminal bolt (M10) (2 sets)
(PAT40-200T/60-133T/80-100T/160-50T)
[M5-100-012]
[M3-111-010]
OUTPUT terminal cover
[Q1-500-106]
[91-80-6940]
[M3-112-027]
CD-ROM ( 1 pc. )
［SA-6038］

PAT-T 8kW1-3
1
Installation and Preparation
1.2 Rack Mountingthe Product
Remove the rubber feet before rack mounting the product to a frame. Fig.1-2 shows
how to remove the rubber feet.
p. 1-3 For details on rack mounting, see the KRB3-TOS or KRB150-TOS Operation
Manual.
Install the suitable support angles applying to the used rack system to support the
instrument.
We recommend that you keep all the parts so that you can use them again when you
detach the product from the frame.
To reattach the rubber feet, use the screws that you removed.
Fig.1-2 Removing the rubber feet
Removingthe rubber feet
Unfasten the screws and remove the four rubber feet.
See
Rubber feet (4 locations)
Collars (4 locations)
Attachment screws
(4 locations)
M4 screw
Maximum depth: 16 mm
( )

1-4 PAT-T 8kW
1.3 Connectingthe Power Cable
This product is designed as an equipment of IEC Overvoltage Category II (energy-
consuming equipment supplied from the fixed installation).
p. 1-4 This product does not come with a power cable. The optional power cable (AC8-
4P4M-M6C) has crimping terminals (round M6 terminals, 12 mm wide) attached on
its PAT end. However, the switchboard end of the power cable has not been prepared
for connection. When you use the cable, attach crimping terminals to it that match
the screws of the switchboard that you will connect it to.
Fig.1-3 Optional power cable
Exercise the following precautions when preparing the power cable.
Possible electric shock.
• Turn off the switchboard breaker (switch that cuts off the power
supply from the switchboard) before makingthe connection.
• This product is an IEC Safety Class I equipment (equipment with a
protective conductor terminal). Be sure to ground the product to
prevent electric shock.
• Connect the ground terminal to earth ground.
• Be sure to have a qualified engineer connect the power cable to the
switchboard.
• Inside the power supply, an appropriate protective circuit is connected to
the input terminal. Be sure to connect the wires correctly by matching the
U, V, W, and (GND) between the switchboard and the product.
• The POWER switch of the product can be used to disconnect the product from
the AC line in an emergency. Provide adequate space around the POWER switch
so that the POWER switch can be turned off at any time.
Use a four-core PVC insulated cable for 600 Vac with a nominal cross-sectional
area of at least 8 mm2(At least 5 mm2for 400 V input model.)
See
Three-phase power cable
(AC8-4P4M-M6C)
WARNING
CAUTION

PAT-T 8kW1-5
1
Installation and Preparation
Connection procedure
Fig.1-4 Connecting the power cable
(example in which the optional power cable is used)
1 Check that the AC power line meets the nominal input rating of the
product.
A model with a nominal input rating of 200 Vac to 240 Vac can receive voltages within
the range of 180 Vac to 250 Vac. 400 V input models (whose nominal input rating is
400 Vac) can receive voltages within the range of 360 Vac to 440 Vac. The frequency is
50 Hz or 60 Hz.
Fig.1-5 Required power supply equipment
The PAT may be damaged.
• Do not connect a 400 V input model to a power line if the voltage between
any of the line’s phase terminals and the ground shown in Fig.1-5
exceeds 254 Vac.
2 Check that the POWER switch is turned off.
3 Attach crimping terminals to the cable that are appropriate for the PAT,
and then connect the cable to the AC INPUT terminal block as shown in
Fig.1-4.
GND
AC INPUT terminal block
(GND)
(GND): Green
W: Black
V: White
U: Red
W
V
U
Terminal cover
M6 screws
Be sure to ground the neutral point.
Power supply equipment
Neutral
point
Input voltage between U-G, V-G and W-G : ±254 Vac max *
V
U
W
PAT
N
Not used
Three-phase three wire
Three-phase four wire
G
* Only 400 Vinput models
CAUTION

1-6 PAT-T 8kW
4 Attach appropriate crimp terminals to the switchboard end of the power
cable.
5 Turn off the switchboard breaker.
6 Connect the power cable by matching the U, V, W, and (GND) of the
switchboard.
Precautions ConcerningGrounding(Earth)
Be sure to ground the product for your safety.
Make sure to connect the GND terminal of the AC INPUT terminal block to the
GND terminal of the switchboard.
1.4 TurningOn
• The CONFIG parameters can be configured so that the output is
automatically turned on when the POWER switch is turned on. When this
function is enabled, the PAT powers up with the output turned on even if
the output was off when the PAT was turned off the last time. However,
there is a possibility that a load may break, if youconnect a different load
and turn the POWER and output on simultaneously without changing the
OVP and OCP settings to appropriate values.
Turningthe POWER switch on
1 Check that the power cable is correctly connected.
2 Raise the lever and turn the POWER switch on.
If an odd sound, odd odor, fire, or smoke occurs around or in the PAT, lower the
POWER lever to turn it off.
3 Check the firmware version on the front panel display.
p. 3-2
The voltmeter and ammeter show the PAT firmware version for approximately 1
second. The measuring value will be shown after the firmware version is displayed.
Fig.1-6 Firmware version display at power-on (example for Ver.3.00)
p. 3-28If the POWER switch is turned on for the first time after purchasing the PAT, the
PAT starts up in a factory default condition.
An inrush current flows up to 100 Amax. (40 Amax. for 400 V input model) when
the POWER switch is turned on. In particular, check that sufficient current capacity
CAUTION
See
EXTEXT
RMT
LOCK
PRESET
ABC
AV
OUTPUT
ALARM
Indicates the version Firmware version
See

PAT-T 8kW1-7
1
Installation and Preparation
is available in the AC power line and the switchboard if you are using multiple PATs
and turning on the POWER switches simultaneously.
If front panel display shows indicated in Table 1-1 after power-on, follow the
corresponding remedy. If the remedy does not correct the problem, contact your
Kikusui agent or distributor.
Table 1-1 Panel display during and after power-on
Turningthe POWER switch off
Lower the POWER switch lever to turn it off.
When the POWER switch is turned off, the front panel display shows the characters
indicated in the following figure for about 10 to 15 seconds.
Fig.1-7 Display at power-off
The PAT stores the panel settings (excluding output on/off condition) immediately
before the POWER switch is turned off. For these items, the PAT starts up using the
settings that existed when the POWER switch was turned off the last time.
If the POWER switch is turned off immediately after changing the settings, the last
settings may not be stored.
•When turning the POWER switch off and then back on, allowat least 10
seconds (40 seconds for 400 V input model) after the fan stops.
Repeated ON/OFF of the POWER switch at short intervals can cause
damage to the inrush current limiter or shorten the service life of the
POWER switch and the internal input fuse.
Panel Display Cause and Remedy
SYS1 ERR The PAT may have malfunctioned. Contact your
Kikusui agent.
SYS2 ERR
The calibration has not been completed normally.
Recalibrate. If “SYS2 ERR” appears even after
recalibration, the PAT may have malfunctioned.
Contact your Kikusui agent. ( p. 7-5)
CLR ABC
Preset memories A, B, and C have been reset to
factory default settings because the values were
abnormal. To continue the operation, press any panel
switch.
CLR SET
The voltage and current calibration values have been
reset to factory default settings, because the values
were abnormal. To continue the operation, press any
panel switch.
CLR CONF
The CONFIG settings have been reset to factory
default values, because the values were abnormal.To
continue the operation, press any panel switch.
AV
AV
See
AV
AV
AV
EXTEXT
RMT
LOCK
PRESET
ABC
AV
OUTPUT
ALARM
CV
CAUTION

1-8PAT-T 8kW
