電動起子控制器操作手冊
OPERATION AND MAINTENANCE MANUAL
SKP-32B-60W
（in：100V~240V out：24V；32V）
奇力速工業股份有限公司
KILEWS INDUSTRIAL CO., LTD.
Y2F059-201010



Important safety information enclosed.
Read all these instructions before placing tool in service or operation this tool and save
these instructions. It is the responsibility of the employer to place the information in this
manual into the hands of the operator. Failure to observe the following warnings could
result in injury. When using electric tools, Basic safety precautions should always be
followed to reduce the risk of fire, electric shock and personal injury, including the
following:
1.Important Safety Instructions
2.Grounding Instructions
3.Installation Instructions
4.Operations Cautions
5.Specifications
6.Servicing
WARNING



WARNING! Read all instructions Failure to follow all instructions listed below may result
in electric shock fire and/or serious injure. The term “power tool” in all of the warning listed
below refer to your mains operated (corded) power tool or battery operated (cordless)
power tool.
SAVE THESE INSTRUCTIONS
1) Electrical Safety
a) Keep work area clean and well lit. Cluttered and dark areas invite accidents.
b) Do not operate power tools in explosive atmosphere, such as in the presence of
flammable liquids, gases or dust. Power tools creat sparks which may ignite the dust
of fumes..
c) Keep children, and bystanders away while operating a power tool. Distractions can
cause you to lose control.
2) Electrical Safety
a) Power tool plugs must match the outlet. Never modify the plug in any way. Do not
use any adapter plugs with earthed (grounded) power tools. Unmodified plugs and
matching outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces such as pipes, radiators,
ranges and refrigerators. There is an increased risk of electric shock if your body is
earthed or grounded.
c) Don’t expose power tools to rain or wet conditions. Water entering a power tool will
increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord to carrying, pulling or unplugging the
power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged
or entangled cords increase the risk of electric shock.
e) When operating a power tool outdoors, use an extension cord suitable for
outdoor use.Use of cord suitable for outdoor use reduces the risk of electric shock .
3) Personal Safety
a) Stay alert, watch what you are doing and use common sense when operating a
power tool. Do not use power tool while you are tired or under the influence of
drugs, alcohol, or medication. Amoment of inattention while operating power tools
may result in serious personal injury.
b) Use safety equipment. Always wear eye protection. Safety equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate
conditions will reduce personal injuries.
c) Avoid accidental starting. Ensure the switch is in the off position before plugging
in. Carrying power tools with your finger on the switch or plugging in power tools that
have the switch on invites accidents.
d) Remove any adjusting keys or wrench before turning the power tool on. A wrench
or a key that is left attached to a rotating part of the power tool may result in personal
injury.
e) Do not overreach. Keep proper footing and balance at all times. This enables better
control of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair,clothing,
and gloves away from moving parts. Loose clothes, jewellery, or long hair can be
caught in moving parts
1. Important Safety Instructions



g) If devices are provided for the connection of dust extraction and collection
facilitys, ensure these are connected and properly used. Use of these devices can
reduce dust related hazards.
4) Power tool Use and Care
a) Do not force the power tool. Use the correct power tool for your application. The
correct power tool will do the job better and safer at the rate for which it was designed.
b) Do not use power tool if switch does not turn it on or off. Any power tool that
cannot be controlled with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source before making any adjustments,
changing accessories, or storing the power tools. Such preventive safety measures
reduce the risk of starting the power tool accidentally.
d) Store idle power tools out of reach of children and do not allow persons
unfamiliar with the power tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained users.
e) Maintain power tools. Check for misalignment or binding of moving parts,
breakage of parts and any other condition that may affect the power tools
operation. If damaged, have the power tool repaired before use. Many accidents are
cause by poorly maintained power tools.
f) Keep cutting tools sharp and clean, Properly maintained cutting tools with sharp
cutting edges are less likely to bind and are easier to control.
g) Use the power tools, accessories and tool bits ect., in accordance with these
instructions and in the manner intended for the particular type of power tool,
taking into account the working conditions and the work to be performed. Use of
the power tool for operations different from intended could result in a hazardous
situation.
5) SERVICE
a) Have your power tool serviced by qualified repair person using only indentical
replacement parts, This will ensure that the safety of the power tool is maintained.
Additional information shall be provide
a) Instruction for putting into use
1.Setting-up or fixing power tool in a stable position as appropriate for power tools which
can be mounted on a support.
2.Assembly
3.Connection to power supply, cabling, fusing, socket type and earthing requirements.
4.Illustrated description of functions.
5.Limitations on ambient conditions.
6.List of contents.
b) Operating Instructions.
1.Setting and testing.
2.Tool changing.
3.Clamping of work.
4.Limits on size of work piece.
5.General instructions for use.
c) Maintenance and servicing.
1.Regular cleaning, maintenance, and lubrication.
2.Servicing by manufacture or agent, list of addresses.
3.List of user-replaceable parts.
4.Special tools which may be required.



1. Please read the operating manual thoroughly and comply with safety regulation to
operate this Multi-Function Controller.
2. Please grasp the plug of power cord while plugging in or out the plugs of connecting
cord of Electric Screwdriver and power cord.
3. Please fix the power controller to avoid any danger of pulling and dragging the power
cord.
4. Do not near oil, chemical materials or heated objects, also please be alert not to
scratch the power cord by sharp object.
5. This type of Controller can only be applied to Kilews Electric Screwdriver with Counter.
Do not use Electric Screwdriver Controller on other types of machinery.
6. In case of the Controller is overheated or overloaded with maximum current rating of
fuse, the high-speed fuse will be melt down and cut off the power. If the Controller
continues to jump off or has an abnormal switching reaction, please stop the operation
immediately and send back the Controller for repair.
7. When Electric Screwdriver is running, if slides Forward/Reverse Switch instantly,
device will generate the protection program to force Electric Screwdriver stop.
8. Please do not disassemble Electric Screwdriver casually and try to repair it by self.
9. When Controller is not in use, please turn the main power switch OFF and unplug the
power.
WARNING！
DO NOT OPERATE THIS TOOL WITHOUT
PROTECTIVE EARTH CONNECTED
The tool should be grounded while in use to protect the operator from electric shock. The
tool is equipped with a three-conductor cord and three-prong grounding-type plug to fit the
proper grounding-type receptacle. The green (or green and yellow) conductor in the cord is
the grounding wire. Never connect the green (or green and yellow) wire to a live terminal.
Green and yellow----- Earth
Blue ------Neutral
Brown ------Live
1. Use the controller voltage recommended in the specification of this manul.
2. When using a commercial power supply be sure to set up circuit and safety breakers.
You must also properly ground the mechanisms.
3. The temperature and humidity should be kept at appropriate levels.
4. Do not set up the power supply in a room that has poor ventilation and where it may be
exposed to dust and metallic flakes.
3. Grounding Instructions
4. Installation Instructions
2. Operations Cautions



5. Do not put heavy object on top of power supply or pile thing on it.
6. Attach the power supply securely to a flat, stable surface. If the power supply is put a
high place, take special care to ascertain that there is no danger of it falling.
7. Keep bystanders away. Do not permit unauthorized personnel to operate this controller.
8. Do not set up the power supply near high voltage machinery or in an excessively noisy
environment.
9. Avoid setting up or storing the power supply in wet or oily environments or where it
might be exposed to corrosive or flammable gases.
10. We emphasize that the power supply should be placed in stable, fixed location.
SAVE THESE INSTRUCTION
The use of other than genuine KILEWS replacement parts may result in
decreased controller performance and increased maintenance, and may
invalidate all warranties.
1) When plugging and unplugging the screwdriver’s connecting cord and the electrical cord of the
power supply, firmly grasp the plug portion of cord.
2) Do not tug on a cord to unplug it or put it near oil or hot objects. Also be sure that it does not
rub against sharp edges.
3) Do not drop the power supply or treat it roughly.
4) Use ONLY the designated KILEWS screwdriver. Do not use the power supply with any other
mechanisms.
5) If the power supply overheats; the breaker behaves abnormally stop the mechanism’s
operation and send it for repair.
6) Please do not recklessly dismantle the power supply and attempt to make repairs on your
own.
Model SKP-32B-60W
Input Voltage 100V ~220VAC
Downstream Output Voltage DC 24V/32V
Power Consumption 60W
Outside Dimensions(mm) 145*60*35(mm)
Weight(g) 250g
Suitable Model SKD-B203L；SKD-B207L；SKD-B210L
SKD-B512L；SKD-B519L；SKD-BE512L；SKD-BE519L
SKD-B512P；SKD-B519P；SKD-BE512P；SKD-BE519P
NOTICE
6. Specifications
5. Operations Cautions



Maintenance and Inspection :
1. The controller must be operated in top condition, one day working hour must be not
more than eight hours.
2. Please note don’t let the controller get over heated, every minute use 10~15 screws to
operate.
3. The frequency use of this electric screw driver is over eight hours a day, still it needs
periodically testing and treatment. Every 5-6 months.
1. The use of other than genuine KILEWS replacement parts may Result in decreased
tool performance and increased maintenance, and may invalidate all warranties.
2. All repairs and maintenance of this tool and its word must be performed by an
authorized service center.
3. KILEWS is not responsible for customer modification of tools for applications on which
KILEWS was not consulted.
4. Repairs should by made only by authorized, trained personnel. Consult your nearest
KILEWS authorized service center.
5. It is the responsibility of the employer to place the information in this manual into the
hands of the operator.
DO NOT ATTEMPT TO REPAIR THIS EQUIPMENT
All repairs and maintenance of the Controller and its cord
must be performed by authorized service center
SAVE THESE INSTRUCTIONS
DO NOT DESTROY
7. Servicing
CAUTION
CAUTION



操作前請閱讀全部說明
（內附零件分解圖）
警 告
為了安全起見，在使用電動螺絲起子控制器前請詳閱電動螺
絲起子控制器操作說明書，且務必依照說明書指示操作，並
注意所有的警示
重要安全說明事項
1. 1、使用電動螺絲起子控制器說明書規定的電壓。
2. 2、使用電源時請確定電流回路與安全開關裝置，並同時將地線接妥。
3. 3、電動螺絲起子控制器勿置重物或堆積物品，且保持在適當的溫度與濕度狀態下工
作。
4. 4、勿將電動螺絲起子控制器放在通風不良之室內，或暴露在塵埃和金屬屑中
5. 勿將電動螺絲起子控制器放在高溫潮濕的環境或易燃氣體的地方。
6. 勿將電動螺絲起子控制器裝置在高處，應放于安全、平穩、固定的位置，以防止掉落
的危險。
7. 不可用電源線拉提電動螺絲起子控制器，或將電源線從插座上猛拉開。
注 意
1、此控制器請搭配整組的專用電動起子使用。
2、此控制器請配合 KILEWS DC 低壓電動起子使用，控制器若搭配非 KILEWS 起子使
用，以及使用非 KILEWS 原廠的零配件維修，而造成控制器發生故障或品質不良，導
致一切保證失效本廠恕不負責。
操 作 須 知
1、當插入或拔開起子連接線和電源線之插頭時，需抓緊電纜線之插頭部分。
2、請勿用力拉扯電纜線，或使其靠近油 、化學物質或熱的物體，同時也注意不要讓電
纜線在工作中刮磨到銳利的物品。
3、此型控制器，只能專門供 KILEWS 電動起子使用，勿將電動螺絲起子控制器使用於
其他機械。
4、假如控制器過熱，或負載使用電流超過保險絲最大額定電流時，快速型保險絲會自動
熔斷，切斷電源，持續跳脫或開關動作不正常時，請立即停止操作，並將電動螺絲起
子控制器送回修理。
5、請勿任意拆卸電動螺絲起子控制器嘗試自行修復。
6、不使用時將主要電源開關 ＂OFF＂，並且拔掉電源插頭。



接 地 說 明
電動螺絲起子控制器使用時應接地以免操作者觸電。本控制器配有三條導線及三腳接地型插
頭以適合接地型插座用，插座本身的接地線必須確實和電源設備地線相連接才有接地作用。
電線黃綠色的導線是接地線。千萬不可將此黃綠色線接在通電的接頭上，此控制器內的接地
線除了有漏電安全接地外，還可將起子工作時所產生的 ESD 靜電靠著接地線來接地消除。



※主 要技術參數
型號 SKP-32B-60W
輸入電壓 AC 100V~240V 50/60HZ
輸出電壓 DC 24V/32V
輸出電流 1.8A Max
外形尺寸(mm) 145*60*35(mm)
重量 250g
適用之電動螺絲起子 SKD-B203L；SKD-B207L；SKD-B210L
SKD-B512L；SKD-B519L；SKD-BE512L；SKD-BE519L
SKD-B512P；SKD-B519P；SKD-BE512P；SKD-BE519P

No. PARTS No. PARTS NANE-E PART NANE-C Q.TY
AA60005-D CORD NS-26 1.5M-Australia 電源線 澳式三插 / NS-26 連接器1.5M 1
AA60005-A CORD NS-26 1.5M-American 電源線 美式三插 / NS-26 連接器1.5M 1
AA60005-E CORD NS-26 1.5M-Europe 電源線 歐式三插 / NS-26 連接器1.5M 1
AA60005-I CORD NS-26 1.5M-India 電源線 印式三插 / NS-26 連接器1.5M 1
AA60005-U CORD NS-26 1.5M-UK 電源線 英式三插 / NS-26 連接器1.5M 1
2 P11011-3 HOUSING 32B-60W 變壓器外殼 32B-60W 1
3 EG50101-22I PCB 32B-60W 機板成品 32B-60W 1
4 EG50101-28 PCB-4PIN+5V 機板成品 4PIN+5V 1
5 P11401-7 POWER SWITCH BR-12C-11L 電源開關BR-12C-11L 1
1
