LIGHTVAULT®-LTV Lens & Reflector LTV30, LTV730
Installation Instructions
Revision 7/16/10 ECN 100715008 Status 10 Part No. 95579
Tools Required:J” Hex Socket Wrench F” Hex Socket Wrench PhillipsScrewdriver
INSTRUCTIONS PERTAINING TO A RISK OF FIRE OR INJURY TO PERSONS
IMPORTANTSAFETY INSTRUCTIONS!
WARNING: Fixtures must be grounded in accordance with local codes or the National Electrical Code.
Failure to do so mayresult in serious personal injury. Lighted lamp is HOT! Do not touch hot lens, guard,
or enclosure. All work should be done by a qualified electrician.
MAINTENANCE: A regularly scheduled maintenance program should be established to retain optimum light
output and reduce heat retention.DO NOT operate luminaire with missing ordamaged lens.
KEEP THIS SHEET FOR FUTURE REFERENCE.
LENS FRAME / REFLECTOR INSTALLATION:
Make certain all electrical supply is
OFF before starting fixture installation.
1. Orient Eyeball in eyeball gasket so lens will be facing in
desired position. To do this, remove eyeball gasket from
eyeball. Take note where screw hole should end up so
that eyeball will be oriented in correct direction and install
gasket. NOTE: Eyeball will not physically rotate in
eyeball gasket because eyeball is actually sandwiched
between two layers of rubber.
2. Connect quick-disconnect on reflector assembly to
mating quick-disconnect inside housing. Make sure
gasket and
gasket surfaces are clean and dry. Make sure no dirt has
fallen into screw hole. Install Eyeball on housing.
3. Install Eyeball retainer over Eyeball. Coat screws with
silicone grease and tighten opposing screws
progressively and evenly to 30 inch lbs. torque (2K ft.
lbs.)
4. Remove lens frame, lens and gasket.
5. Install lamp of type and wattage shown on fixture label.
LTV30 / LTV730
15°
Tilt
Adjustment
Screws
Lens & Gasket
Quick-Disconnect
360°
Rotation
Eyeball
Gasket
Eyeball
Lens Frame
IMPORTANT: Condensation inside the fixture is a common occurrence due to the expanding and condensing of the
trapped air inside the fixture as it is cycled on and off. When the lamp is energized during the evening hours, moisture
on the inside of lens will burn off as fixture heats up. It will reappear after power is shut off and the inside air condenses
during cooling. A large majority of this moisture can be avoided by following the installation guidelines as described in
the housing installation instructions. Always relamp fixture during low humidity periods. Before closing fixture, energize
the lamp for approximately five (5) minutes to dry air inside fixture. Remove desiccant from zip lock bag and place in
reflector compartment. Install lens and lens frame as described below.
!
WARNING:
This HID / Fluorescent fixture utilizes a lamp that may
contain mercury. For information on disposal of lamp
go to website: www.lamprecycle.org
continued on page 2
!
P.O. Box 60080 •16555 East Gale Ave.
City of Industry, California 91716-0080
626/968-5666 • FAX [phone]

Page 2 Kim Lighting • 16555 E. Gale Ave. • P.O. Box 60080 • City of Industry, CA 91716-0080 • 626/968-5666 • FAX [phone]
LIGHTVAULT®- LTV Lens / Reflector
LTV30/730 Installation Instructions
How may we serve you better?
Please let us know. Visit our website at:
www.kimlighting.com
Your concerns are important to us.
MAINTENANCE Make certain electrical supply is OFF before starting lamp replacement.
1. A regularly scheduled maintenance program must be established to keep fixtures clean. Dried leaves and paper
can burn if allowed to accumulate on high temperature lenses. A buildup of dirt and other material on the lens may
cause excessive temperatures within the fixture.
2. To relamp, remove lens frame, lens and gasket. Install lamp of type and wattage shown on fixture label.
3. Clean lens gasket and frame inside and out. Before closing fixture, be sure gasket and gasket surfaces are clean
and dry. Make sure no dirt has fallen into screw holes.
4. Install lens gasket and lens frame. Coat screws with silicone grease and tighten progressively and evenly to 30
inch lbs. torque (2Kft. lbs.).
!
6. Loosen tilt adjustment screws, aim reflector to desired orientation and lock position by tightening tilt adjustment
screws.
7. Clean lens and gasket inside and out. Before closing fixture, be sure gasket and gasket surfaces are clean and
dry. Make sure no dirt has fallen into screw holes.
8. Install lens, gasket and lens frame. Coat screws with silicone grease and tighten opposing screws progressively
and evenly until tight.
KIM LIGHTING LIMITED WARRANTY
When installed in accordance with Kim Installation Instructions and accepted trade practices, the following shall apply:
General Product Limited Warranty Coverage
All material and component parts used in the manufacture of Kim Products, are warranted to be free from defects of material
and/or workmanship for a period of 1 year from date of sale, with the following exceptions:
Auxiliary Equipment:
All auxiliary equipment (such as lamps, ballasts, and transformers) provided by and/or included in Kim Products shall carry the
components manufacturer's warranty.
Copper, Bronze and Brass Landscape Components
Copper and Bronze Landscape fixture components shall be warranted against defects of material and/or workmanship, and
failure due to corrosion, for a period of 25 years from date of sale.
Kim Lighting's brass components are constructed from several brass parts that are manufactured by various methods at various
times. Since brass naturally deepens in color as it ages through the normal oxidation process, these parts may exhibit subtle
differences in coloration when the product is new. This is normal and expected. These color differences will be eliminated shortly
after installation through the normal brass oxidation process.
Composite In-Grade Components
Composite In-Grade fixture components installed below grade, shall be warranted against defects of material and/or
workmanship, and failure due to corrosion, for a period of 7 years from date of sale.
Aluminum Landscape Components
Aluminum Landscape fixture components not in direct contact with soil, shall be warranted against defects of material and/or
workmanship for a period of 3 years from date of sale. Aluminum fixture components in direct contact with soil shall be
warranted from defects of material and failure from corrosion for a period of 1 year from date of sale.
Stainless Steel Components
Stainless steel landscape components (Lens Rings) installed in the outdoor environment shall show signs of oxidation after 5 to 6
years of install and is dependent on the application and its environment. A proper maintenance and cleaning program will
extend the beauty of the stainless steel.
Limit of Liability and General Conditions
Only products which are installed, used and maintained in accordance with applicable Kim instructions, specifications and
accepted trade practices, are covered by the Kim Warranty. During the warranty period, with proof of purchase, Kim will repair
or replace with the same or similar product, at Kim's option without charge. Labor costs are the owner's responsibility and are
excluded from this warranty. This warranty is void if the product is modified, tampered with, misapplied, poorly installed,
improperly maintained, or subjected to abnormal conditions.
Repair or replacement as provided under this warranty is the exclusive remedy of the purchaser. This warranty is in lieu of all
other warranties, expressed, or implied, including any implied warranty of fitness for a particular application. Kim Lighting shall
not be liable to the purchaser for indirect or consequential damages.
