Kingston Technology KTM-DC16 User manual

Kingston Technology
DataCard-16
Installation Guide
Model: KTM-DC16/xxx

DataCard-16 Installation Guide - Rev. C3 Kingston Technology Corporation
DataCard-16
Fixed Disk + Memory Expansion
Micro Channel Adapter
For IBM PS/2 Models
50, 50z, 55SX, 56, 57, 60 and 65SX
Installation Guide
Kingston Technology Corporation
17600 Newhope
Fountain Valley, CA 92708
[phone]

ii
Kingston Technology Corporation DataCard-16 Installation Guide - Rev. C3
Limited Warranty
KINGSTON TECHNOLOGY CORPORATION ("Kingston") warrants that this
product is free from defects in material and workmanship. Subject to the conditions
and limitations set forth below, Kingston will, at its option, either repair or replace any
part of this product which proves defective by reason of improper workmanship or
materials. Repair parts or replacement products will be furnished by Kingston on an
exchange basis, and will be either new or refurbished to be functionally equivalent to
new.
This warranty applies only to the original end user purchaser, and does not cover any
damage to this product which results from accident, abuse, misuse, natural or personal
disaster, or any unauthorized disassembly, repair or modification.
Duration Of Warranty
Lifetime Warranty:The following Kingston products are covered by this warranty
for life: solid state memory (e.g., Single Inline Memory Modules, or "SIMMs"),
network interface cards and adapters, solid state PCMCIA interface adapters, and x86-
based microprocessor upgrade products.
Five Year Warranty:The following Kingston products are covered by this warranty
for a period of five years from the date of original retail purchase: storage enclosures,
power supply units and subassemblies, Winchester hard disk drives with a capacity of
one gigabyte or more, and all other Kingston products (other than those products
covered by a two-year or one-year warranty, as provided below).
Two Year Warranty:The following Kingston products are covered by this warranty
for a period of two years from the date of original retail purchase: Winchester hard
disk drives in a 2.5 inch, 3.5 inch or 5.25 inch form factor and with a capacity of less
than one gigabyte.
One Year Warranty:The following Kingston products are covered by this warranty
for a period of one year from the date of original retail purchase: Winchester hard disk

iii
DataCard-16 Installation Guide - Rev. C3 Kingston Technology Corporation
drives in a 1.8 inch form factor, optical storage products, and magnetic tape storage
products.

iv
Kingston Technology Corporation DataCard-16 Installation Guide - Rev. C3
Warranty Claim Requirements
To obtain warranty service, return the defective product, freight prepaid and insured,
to your local authorized Kingston dealer or distributor, or to the Kingston factory
service center located at 17600 Newhope Street, Fountain Valley, California 92708,
U.S.A. You must include the product serial number (if applicable) and a detailed
description of the problem you are experiencing. For products covered by the five-
year, two-year or one-year warranty, you must also include proof of the date of
original retail purchase as evidence that the product is within the applicable warranty
period. If you return the product directly to the Kingston factory, you must first obtain
a Return Material Authorization ("RMA") number by calling Kingston Customer
Service at [phone], and include the RMA number prominently displayed on
the outside of your package. Products must be properly packaged to prevent damage
in transit.
Free Technical Support
Kingston provides free technical support. If you experience any difficulty during the
installation or subsequent use of a Kingston product, please contact Kingston's
Technical Support Department at [phone] prior to servicing your system. This
warranty covers only repair or replacement of defective Kingston products, as
provided above. Kingston is not liable for, and does not cover under warranty, any
costs associated with servicing and/or installation of Kingston products.
Disclaimers
The foregoing is the complete warranty for Kingston products and supersedes all other
warranties and representations, whether oral or written. Except as expressly set forth
above, no other warranties are made with respect to Kingston products and Kingston
expressly disclaims all warranties not stated herein, including, to the extent permitted
by applicable law, any implied warranty of merchantability or fitness for a particular
purpose.
In no event will Kingston be liable to the purchaser, or to any user of the Kingston
product, for any damages, expenses, lost revenues, lost savings, lost profits, or any
other incidental or consequential damages arising from the purchase, use or inability to
use the Kingston product, even if Kingston has been advised of the possibility of such
damages.

v
DataCard-16 Installation Guide - Rev. C3 Kingston Technology Corporation
Copyright © 1995 Kingston Technology Corporation. All rights reserved. Printed in the
U.S.A. Kingston Technology and the Kingston logo are trademarks of Kingston Technology
Corporation.

vi
Kingston Technology Corporation DataCard-16 Installation Guide - Rev. C3
TABLE OF CONTENTS
General Description...............................................................................................................1
Special Features...................................................................................................................2
Package Contents.................................................................................................................3
Packaging Materials..............................................................................................................3
Order Information..................................................................................................................3
Software Installation..............................................................................................................4
Updating Your Backup Copy of the Reference Diskette.............................................4
Running the INSTALL Program.................................................................................4
For OS/2 2.0 Users......................................................................................7
For OS/2 2.1 Users......................................................................................7
Hardware Installation.............................................................................................................9
Installing SIMM Modules...........................................................................................9
Installing the DataCard ...........................................................................................10
Configuring the System...........................................................................................11
Preparing the Disk..................................................................................................13
For DOS ....................................................................................................13
Running FDISK..............................................................................13
Running FORMAT.........................................................................17
For OS/2....................................................................................................19
Running FDISK..............................................................................19
Running FDISK..............................................................................22

vii
DataCard-16 Installation Guide - Rev. C3 Kingston Technology Corporation
Windows NT - New Installation .................................................................. 23
Windows NT Disk Partitioning ....................................................... 25
Windows NT - Adding Your Data Card....................................................... 25
Appendices......................................................................................................................... 27
Appendix A Manual Configuration........................................................................ 28
Appendix B Configuring DataCard as the Boot Drive........................................... 31
Appendix C How DOS Assigns Drive Letters....................................................... 34
Appendix D Special SCSI Adapters..................................................................... 38
Appendix E About Expanded Memory................................................................. 39
Appendix F Troubleshooting................................................................................ 41

General Information 1
DataCard-16 Installation Guide - Rev. C3 Kingston Technology Corporation
General Description
Congratulations on your purchase of the Kingston DataCard-16 Fixed Disk and
Memory Expansion Adapter for IBM PS/2 Micro Channel machines. The DataCard-
16 is designed for IBM PS/2 Models 50, 50z, 55SX, 56, 57, 60, and 65SX personal
computers. There are several models of the DataCard-16: KTM-DC16/127, KTM-
DC16/209,
KTM-DC16/260 and KTM-DC16/340. All models come with a 2 1/2" high-speed
Winchester Hard Drive in 127MB, 209MB, 260MB and 340MB disk capacities,
respectively.
The DataCard-16 is also a 16-bit memory expansion adapter which supports up to 16
Megabytes of onboard memory.It uses standard IBM 72-pin SIMM modules. The
DataCard-16 can be plugged into any 16-bit expansion slot, but should use the slot
closest to the fixed disk controller so as not to interfere with any other expansion slot.
Its onboard 2 1/2" 16ms fast access hard drive can replace the existing hard disk or be
configured as a second hard drive for increased data storage capacity. The DataCard-
16 can also be configured as the boot drive and may be partitioned into several logical
drives to run more than one operating system. The DataCard-16 supports DOS 3.3 or
higher, OS/2 2.0 or higher, and Windows NT 3.x.
For the remainder of this manual, these fixed disk memory expansion adapters will be
referred to collectively as the DataCard-16. When necessary for clarification, the three
models will be differentiated as follows:
KTM-DC16/127 16-bit memory adapter with 127MB hard drive
KTM-DC16/209 16-bit memory adapter with 209MB hard drive
KTM-DC16/260 16-bit memory adapter with 260MB hard drive
KTM-DC16/340 16-bit memory adapter with 340MB hard drive

2General Information
Kingston Technology Corporation DataCard-16 Installation Guide - Rev. C3
Special Features
Your DataCard-16 includes these important features:
•
16-Bit Fixed Disk and Memory Expansion Adapter
•
Available in 127MB, 209MB, 260MB or 340MB disk drive capacity
•
Small 2.5" Winchester hard drive
•
Fast 16 millisecond disk access speed
•
Can replace existing hard drive or add as secondary drive
•
Uses standard IBM-Type, 72-pin SIMM modules
•Memory expansion from zero to 16 megabytes
•
100% factory tested to ensure reliability
•
Supports the following operating systems:
DOS 3.3 or higher
OS/2 2.0 or higher
Windows NT 3.x

General Information 3
DataCard-16 Installation Guide - Rev. C3 Kingston Technology Corporation
Package Contents
The DataCard-16 package should contain the following items:
❏KTM-DC16 Fixed Disk and Memory Expansion Adapter
❏User's Manual
❏Kingston Option Diskette
If any of the items are missing or damaged, please contact your Kingston dealer for a
replacement. Be sure the items you receive are genuine Kingston Technology
products. The printed circuit board has the Kingston name silk screened on its surface.
If the Kingston name is missing, it’s not a genuine Kingston product.
Packaging Materials
The DataCard-16 is shipped in a special anti-static envelope which protects it from
shock and static electricity that could cause severe damage. You should save this
packaging material in case you need to reship the DataCard-16 in the future.
Before you remove any component from its packaging, be sure you discharge any
static electricity by touching a properly grounded metal object.
Order Information
The DataCard-16 can be expanded up to 16MB and supports 2MB or 4MB IBM
standard 72-pin SIMM modules. To add memory to your DataCard-16, order the
following SIMM modules through your local Kingston dealer:
Kingston Part Number Size
KTM2000/M70 2MB
KTM4000/M70 4MB
KTM0129 8MB

4Software Installation
Kingston Technology Corporation DataCard-16 Installation Guide - Rev. C3
Software Installation
Updating Your Backup Copy of the Reference Diskette
It is recommended that you never use your original IBM®Reference diskette when
installing hardware. If you have not already done so, follow the instructions below to
make a backup copy of your IBM Reference Diskette:
1. Boot from your most current Reference diskette.
2. From the Main Menu, select "Backup the Reference Diskette."
3. Follow the instructions until the process has completed.
The DataCard-16 package is supplied with a Kingston Option Diskette. There is an
installation program on the Kingston diskette. Use this program to copy the Kingston
option files to your backup IBM Reference diskette. Note: for REPLY®
motherboards, follow the special installation instructions located in "Appendix F
Troubleshooting".
Running the INSTALL Program
The Kingston Option diskette includes an INSTALL.EXE program which MUST be
run to correctly install the configuration files to your backup Reference diskette. If you
run "Copy an option diskette" from the IBM Reference Menu, it will recognize the
DataCard in its system configuration, but will not install the memory correctly.
Before you start, it's a good idea to backup your existing hard drive and have both the
Kingston Option diskette and your backup copy Reference diskette ready. This
portion of the installation requires the use of DOS. If you are running OS/2, opening a
DOS window will satisfy this requirement. If you use an operating system that cannot
simulate DOS, boot your system from a DOS diskette.
You must run the INSTALL program from the Kingston Option
diskette to copy the Kingston files to your backup Reference
diskette or the configuration will not complete successfully.
Do NOT use "Copy an option diskette" from the Reference Menu.

Software Installation 5
DataCard-16 Installation Guide - Rev. C3 Kingston Technology Corporation
The following steps show you how to install the option files from the Kingston
diskette to your backup copy Reference diskette.
1. Turn on or reboot your computer (from hard disk or bootable DOS
diskette) and get to the DOS prompt.
2. Remove the boot diskette from drive A, if present, and insert the
Kingston Option diskette. At the prompt, type:
A: and press [Enter].
3. To start the INSTALL program, type:
INSTALL and press [Enter].
You will see the following display on your computer screen:
F1 Install Configuration Files onto Reference Diskette
F2 Install KEMM.SYS EMS Driver onto a Working Disk.
F3 Change Existing EMS Driver Parameters
F4 Exit and Back to DOS
4. Select [F1]to copy the Kingston Option files to your backup
Reference Diskette
Note: Because the DataCard-16 does not have EMS hardware for Expanded Memory,
the F2 and F3 menu functions do not apply. This INSTALL program is also used for
other Kingston Memory boards which do contain EMS hardware.
Now that you have updated your backup Reference diskette with the Kingston option
files, you are now ready to install the DataCard-16 into your machine.
INSTALLATION Version 1.30
(C) Copyright 1990, 1992 KINGSTON TECHNOLOGY CORPORATION

6Software Installation
Kingston Technology Corporation DataCard-16 Installation Guide - Rev. C3
For OS/2 2.0 Users
The DataCard-16 is designed to run OS/2 2.0 or later. If you are running OS/2 1.3 or
earlier, you should first upgrade to version 2.0 before using the DataCard. Where
OS/2 2.0 is already installed on your internal hard drive, add the following line to your
CONFIG.SYS file before adding the DataCard-16:
1. Using your favorite text editor, edit the CONFIG.SYS file.
2. Look for a line that starts " BASEDEV= ".
3. At the end of this section, insert a blank line and add
BASEDEV=IBMINT13.I13
4. Reboot your system.
Now OS/2 will see the DataCard-16 as a secondary hard drive. If the BASEDEV line
is not added to your CONFIG.SYS file, OS/2 will report a COUNTRY.SYS error.
Note: When installing OS/2 onto the DataCard-16, after OS/2 has finished the
installation phase and prompts you to reboot the system, in some instances the reboot
does not fully reset the system and will cause a blank gray screen. To clear, simply
cold boot the machine by turning power off and then on.
For OS/2 2.1 Users
If you are installing the DataCard-16 in an IBM PS/2 Model 56, you will need to
remark out a "BASEDEV" line from the CONFIG.SYS file on the OS/2 diskette #1
PRIOR to OS/2 2.1 installation. Follow the steps below to modify the CONFIG.SYS
file:
1. Insert the OS/2 2.1 Diskette #1 into Drive A, and type:
A: [Enter]
2. Using your favorite text editor, edit the CONFIG.SYS file.
3. Go to the BASEDEV=IBM2M57.ADD line and remark it out by inserting a
REM statement as follows:
REM BASEDEV=IBM2M57.ADD
4. Save your changes and begin the OS/2 2.1 installation as instructed.

Software Installation 7
DataCard-16 Installation Guide - Rev. C3 Kingston Technology Corporation
The Software Installation is now complete. You are now ready to install the
DataCard-16 into your system. Continue with the next section, "Hardware
Installation."

8Hardware Installation
Kingston Technology Corporation DataCard-16 Installation Guide - Rev. C3
Hardware Installation
The DataCard-16 uses IBM standard 72-pin SIMMs and, in some cases, the memory
may already be installed. If you do not plan to add or remove any SIMMs, you can
skip this section and go to "Installing the DataCard."
Installing SIMM Modules
The DataCard-16 has four sockets labeled P1, P2, P3, and P4 into which you can plug
from one to four SIMM modules. The DataCard-16 uses 2MB and 4MB SIMMs. It
does not support: 1MB memory modules; or memory modules that are slower than 85
nanoseconds. These modules are incompatible with the DataCard-16.
Note: Do NOT use 1MB SIMMs (Kingston P/N: KTM1000/M70)
To install a SIMM module, carefully push the SIMM into the socket until it is firmly
seated. Then push the SIMM gently toward the memory board until the flanges shown
in Figure 1-1 snap over either end of the module.
Figure 1-1 Inserting a SIMM module

Hardware Installation 9
DataCard-16 Installation Guide - Rev. C3 Kingston Technology Corporation
Installing the DataCard
Now you are ready to install the DataCard-16 into your PS/2 computer. Keep in mind
the precautions on static electricity and magnetized tools and be sure that you are
grounded when touching any electrical components. The following steps will guide
you through the physical installation of the DataCard-16.
STEP 1
•Turn power off from the computer.
•Disconnect any cables from the unit.
STEP 2
•Open the chassis.
•Locate one available 16-bit expansion slot. Remember: the DataCard-16
can be plugged into any expansion slot, but should use the slot nearest the
fixed disk adapter so as not to interfere with any other cards.
•Remove the expansion slot bracket.
STEP 3
•Place the DataCard-16 into the 16-bit expansion slot.
•Make sure the DataCard-16 is inserted into the guide channels and properly
seated into the expansion slot.
•Secure the adapter card to the expansion slot with the thumb screw.
STEP 4
•Replace the cover and reattach any cables that were disconnected.
The hardware portion of the installation procedure is now complete. You may want to
leave the cover off during the remainder of the installation process in case it becomes
necessary to move the DataCard-16 for troubleshooting purposes.

10 Configuring the System
Kingston Technology Corporation DataCard-16 Installation Guide - Rev. C3
Configuring the System
At this point, the DataCard-16 is installed and needs to be configured before it can be
recognized by the system. Follow the steps below to add the DataCard-16 to your
system configuration. After rebooting, if you experience any conflicts with other
adapter cards currently in your machine, you may need to change the DataCard-16
settings to correct any address conflicts. To manually configure or change the default
settings of the DataCard-16, refer to "Appendix A Manual Configuration" in the
Appendices section of this manual.
1. Insert your backup Reference diskette (onto which you've already
copied the files from the Kingston Option diskette) into the floppy
drive.
2. Turn on or reboot your computer.
3. The system will boot up automatically from the backup Reference
diskette. When the IBM logo appears, press [ENTER] as prompted.
After a few seconds, the system will prompt you: "Do you want to
automatically configure the system? (Y/N)?" Press [N] for No.
4. From the main menu, select "Set Configuration."
5. Then select "Change Configuration."
6. If you have an internal IBM hard disk already installed and are adding
the DataCard as a second drive, it is important to know the drive type
number. Page down the Change Configuration menu to the last
expansion slot. It should look something like this:
slot x - IBM Hard Disk Adapter
Type of first drive..........[ 32]
Type of second drive.....[ 0]
In this example, the IBM internal hard drive type is 32. Write down
your drive type number below for future reference.
