KINZE Manufacturing, Inc. 3660 User manual

3660
This manual is applicable to: Model 3660 Pivot Fold Planter
2015 Production Year and on
Record the model number and serial number of your planter along with date purchased:
Model Number ____________ _____________________
Serial Number ___________________________________
Date Purchased__________________________________
Monitor Serial Number _______________________________________________
Measured Pulses Per Mile/Km (Radar Distance Sensor) ____________________
Measured Pulses Per Mile/ Km (Magnetic Distance Sensor) _________________
SERIAL NUMBER
The serial number plate is located on the planter frame as shown below. The serial number provides important information
about your planter and is needed to obtain correct replacement parts. Always provide model number and serial number
to your Kinze Dealer when ordering parts or when contacting Kinze Manufacturing, Inc.
Kinze®, and the Kinze®logo are registered trademarks of Kinze Manufacturing, Inc.
MODEL 3660
PIVOT FOLD PLANTER
OPERATOR MANUAL
M0260-01 Rev. 7/19

This page intentionally left blank.

TM
Model 3660M0260-01
Rev. 02/19 1
Predelivery/Delivery Checklist
TO THE DEALER
Predelivery service includes assembly, lubrication, adjustment and test. This service helps ensure planter is delivered
to retail customer/end user ready for field use.
PREDELIVERY CHECKLIST
Use the following checklist after planter is completely assembled. Check off each item as it is found satisfactory or after
proper adjustment is made.
Center pivot base mounting and transport wheel spindle hex head cap screws torqued to 450 ft-lb (610.1 n-m).
Row units properly spaced and optional attachments correctly assembled.
Row marker assemblies installed and adjusted at each end of the planter.
Vacuum and bulk fill components properly installed (as applicable).
All grease fittings in place and lubricated.
All working parts move freely, bolts are tight, and cotter pins are spread.
Check all drive chains for proper tension and alignment (as applicable).
Check for oil leaks and proper hydraulic operation.
Hydraulic hoses correctly routed to prevent damage.
Inflate tires to specified air pressure and torque wheel lug bolts and lug nuts as specified in the manual.
All safety decals correctly located and legible. Replace if damaged.
All reflective decals and SMV sign correctly located and visible when the planter is in transport position.
Safety/warning lights correctly installed and working properly.
Paint all parts scratched during shipment or assembly.
All safety lockup devices on the planter and correctly located.
Auxiliary safety chain properly installed and hardware torqued to specification.
Vacuum fan PTO-driven pump correctly attached to tractor. Oil reservoir filled to capacity and system inspected for
leaks (If applicable).
Control box properly installed in tractor. All cables correctly routed and secure (hydraulic drive only).
Planter has been thoroughly checked and to the best of my knowledge is ready for delivery to the customer.
(Signature Of Set-Up Person/Dealer Name/Date)
OWNER REGISTER
Name Delivery Date
Street Address Model No. 3660 Serial No.
City, State/Province Dealer Name
ZIP/Postal Code Dealer No.

M0260-01Model 3660
2 Rev. 02/19
TM
Predelivery/Delivery Checklist
DELIVERY CHECKLIST
Use the following checklist at time planter is delivered as a reminder of very important information which should be
conveyed to retail customer/end user. Check off each item as it is fully explained.
Check proper operation of vacuum fan, bulk fill fan, and PTO-driven pump (If applicable) with tractor used with planter.
Life expectancy of this or any other machine is dependent on regular lubrication as directed in the Operator Manual.
All applicable safety precautions.
Along with retail customer/end user, check reflective decals and SMV sign are clearly visible with planter in transport
position and attached to tractor. Check safety/warning lights are in working condition. Tell retail customer/end user
to check federal, state/provincial, and local regulations before towing or transporting on a road or highway.
Give Operator Manual, Parts Manual, and all Instruction Sheets to retail customer/end user and explain all operating
adjustments.
Read warranty to retail customer/end user.
Complete Warranty and Delivery Report form.
To the best of my knowledge this machine has been delivered ready for field use and customer has been fully
informed as to proper care and operation.
(Signature Of Delivery Person/Dealer Name/Date)
AFTER DELIVERY CHECKLIST
The following is a list of items we suggest to check during the first season of use of the equipment.
Check planter performance with retail customer/end user.
Check performance of vacuum or mechanical seed metering system with retail customer/end user.
Review importance of proper maintenance and adherence to all safety precautions with retail customer/end user.
Check for parts that may need to be adjusted or replaced.
Check all safety decals, reflective decals, and SMV sign are correctly located as shown in the Parts Manual and that
decals are legible. Replace if damaged or missing.
Check safety/warning lights are working properly.
(Signature Of Follow-Up Person/Dealer Name/Date)
All registrations must be submitted online at “business.kinze.com”within 5 business days of delivery.
Retain a copy of this form for auditing purposes.
Tear Along Perforation

TM
Model 3660M0260-01
Rev. 7/19 i
Table of Contents
OVERVIEW
To The Owner ..................................1-1
Warranty ......................................1-3
General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Overview ......................................1-3
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
Tractor Hydraulic Requirements. . . . . . . . . . . . . . . . . . . . . 1-5
General Safety Rules. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
Safety Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
MACHINE OPERATION
Planter Lift Safety Lockup .........................2-1
Row Marker Safety Lockup ........................2-1
Tongue Safety Pin ...............................2-2
Transport Latch Locking Pin .......................2-2
Initial Preparation................................2-3
Tractor Mount PTO Pump/Oil Cooler Opt (Hyd Drive) ....2-4
Tractor Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
Tractor Preparation and Hookup ....................2-5
Level Planter ...................................2-9
Ridge Planting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
True Depth Hydraulic System Overview .............2-11
True Depth Filter ...............................2-12
Control Console Operation .......................2-13
Hydraulic Seed Rate Drive. . . . . . . . . . . . . . . . . . . . . . . . 2-14
Hall Effect Sensor (Hydraulic Drive Only) ............2-14
Hydraulic Weight Transfer Toolbar ..................2-14
Ag Leader Electric Clutches ......................2-14
Transport to Field Sequence ......................2-15
Field Operation ................................2-17
Planting Speed ................................2-18
Field to Transport Sequence ......................2-18
Transport to Field Sequence Using Blue Vantage . . . . . . 2-21
Vacuum System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-22
Digital Vacuum Readout. . . . . . . . . . . . . . . . . . . . . . . . . . 2-22
Vacuum Fan and Bulk Fill Motor Valve Block Assembly . . . . 2-22
Analog Vacuum or Pressure Gauge. . . . . . . . . . . . . . . . . 2-22
Bulk Fill System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-23
Bulk Fill Entrainer Access ........................2-24
Bulk Fill Tanks - Clean Out. . . . . . . . . . . . . . . . . . . . . . . . 2-24
Bulk Fill Scale Package Option ....................2-25
Ag Leader Integra Display . . . . . . . . . . . . . . . . . . . . . . . . 2-27
Ag Leader Monitoring Control (PMM) ...............2-27
Ag Leader InCommand 1200 Display ...............2-27
Kinze ISOBUS Option ...........................2-28
Auxiliary Work Lights Package. . . . . . . . . . . . . . . . . . . . . 2-28
Kinze True Depth Display. . . . . . . . . . . . . . . . . . . . . . . . . 2-28
Kinze Blue Vantage .............................2-28
Row Marker Operation...........................2-29
Row Marker Speed Adjustment . . . . . . . . . . . . . . . . . . . . 2-30
Even-Row Push Row Unit ........................2-30
Row Marker Adjustments. . . . . . . . . . . . . . . . . . . . . . . . . 2-31
Row Marker Even-Row Length Adjustment ...........2-32
Offset Hitch Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . 2-32
Point Row Clutches .............................2-33
Auxiliary Hydraulic Option ........................2-34
Rear Trailer Hitch ...............................2-35
Field Test .....................................2-36
Field Check Seed Population. . . . . . . . . . . . . . . . . . . . . . 2-36
Determining Pounds Per Acre (Brush-Type Meter) .....2-37
Determining Bushels Per Acre. . . . . . . . . . . . . . . . . . . . . 2-37
Field Check Granular Chemical Application ..........2-38
ROW UNIT OPERATION
Planting Depth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
“V” Closing Wheel Adjustment (Rubber or Cast Iron) ....3-1
Closing Wheel Shield
(Rubber or Cast Iron “V” Closing Wheels) . . . . . . . . . . . 3-1
Drag Closing Attachment. . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
Covering Discs/Single Press Wheel Adjustment ........3-2
Seed Hoppers ..................................3-3
Seed Meter Drive Release. . . . . . . . . . . . . . . . . . . . . . . . . 3-3
Row Unit Extension Brackets. . . . . . . . . . . . . . . . . . . . . . . 3-3
Row Unit Chain Routing. . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
Quick Adjustable Down Force Springs Option
(Standard or Heavy Duty) .......................3-5
Interplant Push Row Unit Lockups. . . . . . . . . . . . . . . . . . 3-11
Brush-Type Seed Meter . . . . . . . . . . . . . . . . . . . . . . . . . . 3-14
Brush-Type Seed Meter 2.0 .......................3-15
Finger Pickup Seed Meter . . . . . . . . . . . . . . . . . . . . . . . . 3-16
Vacuum Settings ...............................3-17
Seed Meter Cleanout. . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-21
Frame Mounted Coulter (Pull Row) .................3-24
Residue Wheels (Frame Mounted Coulter) ...........3-24
Row Unit Mounted Disc Furrower (Pull Row) .........3-25
Row Unit Mounted Bed Leveler (Pull Row) ...........3-25
Row Unit Mounted Residue Wheel .................3-26
Spiked Closing Wheel ...........................3-27
Row Unit Mounted No Till Coulter ..................3-28
Coulter Mounted Residue Wheels . . . . . . . . . . . . . . . . . . 3-28
GFX Hydraulic Row Cleaners .....................3-29
Granular Chemical Hopper and Drive ...............3-30
Spring Tooth Incorporator ........................3-30
Granular Chemical Banding Options . . . . . . . . . . . . . . . . 3-31
Granular Chemical Bander Shield . . . . . . . . . . . . . . . . . . 3-31

M0260-01Model 3660
ii Rev. 7/19
TM
Table of Contents
FERTILIZER
Double Disc Fertilizer Opener ......................4-1
Notched Single Disc Openers ......................4-2
Residue Wheel Attachment for
Notched Single Disc Fertilizer Opener .............4-4
Depth/Gauge Wheel Attachment for
Notched Single Disc Fertilizer Opener .............4-4
HD Single Disc Fertilizer Opener....................4-5
Liquid Fertilizer Attachment ........................4-7
RATE CHARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
LUBRICATION AND MAINTENANCE
Lubrication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
Lubrication Symbols .............................6-1
Sealed Bearings ................................6-1
Bushings ......................................6-3
Center Post ....................................6-4
Liquid Fertilizer Piston Pump ......................6-4
Crankcase Oil Level. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4
PTO Pump Shaft Coupling
(Tractor Driven PTO Pump and Oil Cooler Option) . . . . . 6-5
Grease Fittings .................................6-6
Mounting Bolts and Hardware .....................6-10
Tractor Driven PTO Pump and Oil Cooler Option ......6-14
Finger Pickup Seed Meter Inspection/Adjustment. . . . . . 6-15
Cleaning Finger Pickup Seed Meter For Storage ......6-16
Brush-Type Seed Meter Maintenance ...............6-17
Cleaning Brush-Type Seed Meter For Storage ........6-18
Vacuum Manifold Maintenance ....................6-18
Vacuum Seed Meter Maintenance. . . . . . . . . . . . . . . . . . 6-19
Seed Meter Cleanout. . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-19
Drag Closing Attachment ........................6-20
Gauge Wheel Adjustment ........................6-20
Gauge Wheel Arm Bushing and/or Seal Replacement . . . . 6-21
Gauge Wheel Arm Pivot Spindle Replacement . . . . . . . . 6-21
15" Seed Opener Disc Blade/Bearing Assembly .......6-22
Seed Tube Guard/Inner Scraper ...................6-24
Frame Mounted Coulter .........................6-24
Residue Wheels
(For Use With Frame Mounted Coulter) ...........6-24
Row Unit Mounted Disc Furrower ..................6-25
Row Unit Mounted Bed Leveler . . . . . . . . . . . . . . . . . . . . 6-25
Row Unit Mounted No Till Coulter ..................6-25
Spiked Closing Wheel ...........................6-26
Coulter Mounted Residue Wheels . . . . . . . . . . . . . . . . . . 6-26
Row Unit Mounted Residue Wheel .................6-26
Granular Chemical Attachment ....................6-26
GFX Hydraulic Row Cleaners .....................6-27
Spring Tooth Incorporator ........................6-27
Pressure Reducing Relief Valve. . . . . . . . . . . . . . . . . . . . 6-28
Row Marker Bearing Lubrication or Replacement . . . . . . 6-30
Wheel Bearing Repack or Replacement .............6-31
Pneumatic Down Pressure Air Compressor Tank ......6-37
Fertilizer Check Valve Cleaning and Repair...........6-38
Piston Pump Storage. . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-38
Hydraulic Hose Life .............................6-46
ISOBUS Implement Cable . . . . . . . . . . . . . . . . . . . . . . . . 6-56
ISOBUS CAN Jumper Cable . . . . . . . . . . . . . . . . . . . . . . 6-56
Product Control Module Cable. . . . . . . . . . . . . . . . . . . . . 6-57
Implement Switch Extension Cable . . . . . . . . . . . . . . . . . 6-58
Section Adapter Cable - 12 Row ...................6-59
Section Adapter Cable - 16 Row ...................6-59
Clutch Cable - 12 Row ...........................6-60
Clutch Cable - 16 Row ...........................6-61
True Depth - Interconnect ........................6-62
True Depth Option- Hydraulic Schematic
Main Down Force Valve Block ...................6-63
True Depth Option - Hydraulic Schematic -
Push Units 1-8 ................................6-64
True Depth Option - Hydraulic Schematic -
Push Units 9-15 ...............................6-65
True Depth Option -
Hydraulic Schematic -
Row Units 1-8 .................................6-66
True Depth Option - Hydraulic Schematic -
Row Units 9-16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-67
True Depth Option - Hydraulic Schematic -
SCV Input Option ............................6-68
True Depth Option - Hydraulic Schematic -
Battery Pack Input Option . . . . . . . . . . . . . . . . . . . . . . 6-69
True Depth Option - Hydraulic Schematic -
Bulk Fill Input Option . . . . . . . . . . . . . . . . . . . . . . . . . . 6-70
True Depth Option - Hydraulic Schematic -
Even Row Option. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-71
TROUBLESHOOTING
Blue Drive ....................................7-10
Bulk Fill .......................................7-1
Closing Wheel ..................................7-1
GFX Hydraulic Row Cleaners ......................7-1
Lift Circuit Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . 7-2
Piston Pump ...................................7-3
PTO Pump Drive and Oil Cooler Option ..............7-3
Rotation Circuit .................................7-4
Row Marker Operation............................7-4
Seed Meter (Brush-Type). . . . . . . . . . . . . . . . . . . . . . . . . . 7-5
Seed Meter (Finger Pickup) .......................7-8
Solenoid Valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-9
Tongue Cylinder Circuit ...........................7-9
Vacuum Seed Meter .............................7-6
Wing Lock Cylinder Circuit. . . . . . . . . . . . . . . . . . . . . . . . 7-10

TM
Model 3660M0260-01
Rev. 02/19 1-1
To The Owner
Kinze Manufacturing, Inc. thanks you for your patronage. We appreciate your confidence in Kinze farm machinery. Your
Kinze planter has been carefully designed to provide dependable operation in return for your investment.
This manual has been prepared to aid you in the operation and maintenance of the planter. It should be
considered a permanent part of the machine and remain with the machine when you sell it.
It is the responsibility of the user to read and understand the Operator Manual in regards to safety, operation,
lubrication and maintenance before operation of this equipment. It is the user’s responsibility to inspect and service
the machine routinely as directed in the Operator Manual. We have attempted to cover all areas of safety, operation,
lubrication and maintenance; however, there may be times when special care must be taken to fit your conditions.
Throughout this manual the symbol and the words DANGER, WARNING, and CAUTION are used to call
attention to safety information that if not followed, will or could result in death or injury. NOTICE and NOTE are used to
call your attention to important information. The definition of each of these terms follows:
NOTE: Special point of information or machine adjustment instructions.
Indicates an imminently hazardous
situation that, if not avoided, will
result in death or serious injury. This
signal word is to be limited to the most
extreme situations, typically for machine
components which, for functional
purposes, cannot be guarded.
DANGER
Indicates a potentially hazardous
situation that, if not avoided, could result
in death or serious injury, and includes
hazards that are exposed when guards
are removed. It may also be used to alert
against unsafe practices.
WARNING
Indicates a potentially hazardous
situation that, if not avoided, may result
in minor or moderate injury. It may also
be used to alert against unsafe practices.
CAUTION
Used to address safety practices not
related to personal injury.
NOTICE

M0260-01Model 3660
1-2 Rev. 02/19
TM
To The Owner
Improperly operating or working on
this equipment could result in death
or serious injury. Read and follow all
instructions in Operator Manual before
operating or working on this equipment.
Some photos in this manual may show
safety covers, shields, or lockup devices
removed for visual clarity. NEVER
OPERATOR OR WORK ON machine
without all safety covers, shields, and
lockup device in place as required.
WARNING
NOTE: Some photos in this manual may have been taken of prototype machines. Production machines may
vary in appearance.
NOTE: Some photos and illustrations in this manual show optional attachments installed. Contact your Kinze
Dealer for purchase of optional attachments.
WARNING

TM
Model 3660M0260-01
Rev. 02/19 1-3
Overview
WARRANTY
The Model 3660 Twin-Line planter is available with vacuum or mechanical meters, conventional hoppers or bulk
fill, Interplant, liquid fertilizer, and various other options. Contact your Kinze Dealer for available options and
configurations. To obtain the most recent version of your publication, please contact your Kinze dealer.
Information used in these instructions was current at time of printing. However, due to Kinze’s ongoing product
improvement, production changes may cause your machine to appear slightly different in detail. Kinze Manufacturing,
Inc. reserves the right to change specifications or design without notice and without incurring obligation to install the
same on machines previously manufactured.
Right hand (R.H.) and left hand (L.H.), as used throughout this manual, are determined by facing direction machine
travels in use unless otherwise stated.
The Kinze Limited Warranty for your new machine is stated on the retail purchaser’s copy of the Warranty And Delivery
Receipt form. Additional copies of the Limited Warranty can be obtained through your Kinze Dealer.
Warranty, within the warranty period, is provided as part of Kinze’s support program for registered Kinze products
which have been operated and maintained as described in this manual. Evidence of equipment abuse or modification
beyond original factory specifications will void the warranty. Normal maintenance, service and repair is not covered by
Kinze warranty.
To register your Kinze product for warranty, a Warranty And Delivery Receipt form must be completed by the Kinze
Dealer and signed by the retail purchaser, with copies to the Dealer, and to the retail purchaser. Registration must be
completed and submitted to Kinze Manufacturing, Inc. within 5 business days of delivery of the Kinze product to the
retail purchaser. Kinze Manufacturing, Inc. reserves the right to refuse warranty on serial numbered products which
have not been properly registered.
If service or replacement of failed parts which are covered by the Limited Warranty are required, it is the user’s
responsibility to deliver the machine along with the retail purchaser’s copy of the Warranty And Delivery Receipt to
the Kinze Dealer for service. Kinze warranty does not include cost of travel time, mileage, hauling or labor. Any prior
arrangement made between the Dealer and the retail purchaser in which the Dealer agrees to absorb all or part of this
expense should be considered a courtesy to the retail purchaser.
Kinze warranty does not include cost of travel time, mileage, hauling, or labor.
GENERAL INFORMATION
Model 3660 16 Row Bulk Fill Planter

M0260-01Model 3660
1-4 Rev. 02/19
TM
Specifications
Specification Conventional Hoppers
Number of Rows 12R N 30 16R N 30
Weight Empty (Mechanical) 15,040 lb (6823 kg) 18,460 lb (8374 kg) - 19,100 lb (8663.61 kg)
Weight Empty (Vacuum) 15,450 lb (7008 kg) 18,400 lb (8347 kg)
Transport Height 11' 11" (3.6M) 11' 11" (3.6M)
Planting Length 23' 9" (7.2M) 26'3" (8M)
Transport Length 39' 2" (12M) 49'2" (15M)
Planting Width 32' 11" (10M) 42'11" (13.1M)
Transport Width 11' 2" (3.4M) 11'2" (3.4M)
Seed Capacity 1.75 bu. (Vacuum / Hopper); 1.90 bu. (Mechanical / Hopper)
Transport Tire Size Four 41" x 11" R22.5 radial load range 'H' tubeless rib implement.
Field Tire Size 7.50" x 20" 8 ply tubeless rib implement tires.
Field Lift Two master center rockshaft/four wing wheel slave rephasing cylinders.
Row Markers Independently controlled, three stage, low profile, w/disk blade depth bands.
Specification Bulk Fill
Number of Rows 12R N 30 16R N 30
Weight Empty (Mechanical) 17,120 lb (7766 kg) - 17,450 lb (7916 kg) 20,020 lb (9081 kg) - 20,400 lb (9254 kg)
Weight Empty (Vacuum) 17,120 lb (7766 kg) - 17,450 lb (7916 kg) 20,020 lb (9081 kg) - 20,400 lb (9254 kg)
Transport Height 12' 11" (4M) 12'11" (4M)
Planting Length 23' 9" (7.2M) 26'3" (8M)
Transport Length 39' 2" (12M) 49'2" (15M)
Panting Width 32' 11" (10M) 42'11" (13.1M)
Transport Width 11' 2" (3.4M) 11'2" (3.4M)
Seed Capacity 110 bu.
Bulk Fill Fill Height
(planting position)
8' 5" (2.6M)
Transport Tire Size Four 41" x 11" R22.5 radial load range 'H' tubeless rib implement.
Field Tire Size 7.50" x 20" 8 ply tubeless rib implement.
Field Lift Two master center rockshaft/four wing wheel slave rephasing cylinders.
Row Markers Independently controlled, three stage, low profile, w/disk blade depth bands.

TM
Model 3660M0260-01
Rev. 02/19 1-5
TRACTOR HYDRAULIC REQUIREMENTS
Configuration No Optional Pumps Tractor Mounted Pump2Planter Mounted Pump2
Mechanical Meter 3 SCV 20 gpm min.
Vacuum Meter14 SCV 40 gpm min. 3 SCV 25 gpm min.
Bulk Fill (with Mechanical
Meter)3
4 SCV 30 gpm min. 3 SCV 20 gpm min.
ASD (with Vacuum)35 SCV 50 gpm min. 4 SCV 40 gpm min. 3 SCV 25 gpm min.
1External case drain required for vacuum hydraulic circuits when no optional pumps are used.
2Pump PTO Requirements: Tractor mounted - 1000 rpm, 1" diameter shaft. Planter mounted - 1000 rpm, 1¾"
diameter shaft.
3Tractor Horsepower Requirement: 225 horsepower or greater class tractor is required to effectively operate a fully
optioned (Bulk Fill, Interplant, Vacuum) 3660 planter.
TRACTOR HYDRAULIC REQUIREMENTS - SPRING & PDP DOWN FORCE - 12R & 16R
Configuration No Optional Pumps Tractor Mounted Pump2
w/o Interplant w/ Interplant
Mechanical Meter 3 SCV 20 gpm min. NA
Vacuum Meter14 SCV 40 gpm min. 3 SCV 25 gpm min.
Bulk Fill (with Mechanical Meter)34 SCV 30 gpm min. 3 SCV 20 gpm min.
Bulk Fill (with Vacuum) 5 SCV 50 gpm min. 4 SCV 40 gpm min.
Bulk Fill, Vacuum, Blue Drive 5 SCV 50 gpm min. 4 SCV 40 gpm min.
1External case drain required for vacuum hydraulic circuits when no optional pumps are used.
2Pump PTO Requirements: Tractor mounted - 1000 rpm, 1" diameter shaft. Planter mounted - 1000 rpm, 1¾"
diameter shaft.
3Tractor Horsepower Requirement: 225 horsepower or greater class tractor is required to effectively operate a fully
optioned (Bulk Fill, Interplant, Vacuum) 3660 planter.
TRACTOR HYDRAULIC REQUIREMENTS - TRUE DEPTH DOWN FORCE - 16R
Configuration Without Interplant With Interplant
No
Optional
Pump
Tractor
Mounted
Pump2
No
Optional
Pump
Tractor
Mounted
Pump2
Mechanical Meter 3 SCV 24 gpm†NA 4 SCV 28 gpm†NA
Vacuum Meter14 SCV 44 gpm†4 SCV 29 gpm†5 SCV 48 gpm†4 SCV 33 gpm†
Bulk Fill (with Mechanical Meter)34 SCV 34 gpm†4 SCV 24 gpm†4 SCV 38 gpm†4 SCV 28 gpm†
Bulk Fill (with Vacuum) 5 SCV 54 gpm†4 SCV 44 gpm†5 SCV 58 gpm†4 SCV 48 gpm†
Bulk Fill, Vacuum, Blue Drive 5 SCV 54 gpm†4 SCV 44 gpm†5 SCV 58 gpm†4 SCV 48 gpm†
1External case drain required for vacuum hydraulic circuits when no optional pumps are used.
2Pump PTO Requirements: Tractor mounted - 1000 rpm, 1" diameter shaft. Planter mounted - 1000 rpm, 1¾"
diameter shaft.
3Tractor Horsepower Requirement: 225 horsepower or greater class tractor is required to effectively operate a fully
optioned (Bulk Fill, Interplant, Vacuum) 3660 planter.
†Minimum

M0260-01Model 3660
1-6 Rev. 02/19
TM
General Safety Rules
1. Read and understand instructions provided in this
manual and warning labels. Review these instructions
frequently!
2. This machine is designed and built with your safety
in mind. Do not make any alterations or changes to this
machine. Any alteration to design or construction may
create safety hazards.
3. A large portion of farm accidents happen from fatigue
or carelessness. Safe and careful operation of tractor
and planter will help prevent accidents.
4. Never allow planter to be operated by anyone
unfamiliar with operation of all functions of the unit.
Operators must read and thoroughly understand all
instructions given in this manual before operating or
working on equipment.
5. Be aware of bystanders, particularly children! Always
look around to make sure it is safe to start tow vehicle
engine or move planter. This is particularly important
with higher noise levels and quiet cabs, as you may not
hear people shouting.
6. Make sure planter weight does not exceed towing
capacity of tractor, or bridge and road limits. This is
critical to maintain safe control and prevent death or
injury, or property and equipment damage.
7. Never ride or allow others to ride on planter.
8. Store planter in an area away from human activity. DO
NOT permit children to play on or around the stored unit.
9. Keep hands, feet, and clothing away from moving
parts. Do not wear loose-fitting clothing which may catch
in moving parts.
10. Always wear protective clothing, shoes, gloves,
hearing, and eye protection applicable for the situation.
11. Do not allow anyone to stand between tongue or
hitch and towing vehicle when backing up to planter.
13. Prevent electrocution, other injuries, or property
and equipment damage. Watch for obstructions such as
wires, tree limbs, etc. when operating machine. Be aware
of clearances during turns and when folding/unfolding
planter.
14. Reinstall all guards removed for maintenance
activities. Never leave guards off during operation.
15. Use of aftermarket hydraulic, electric, or PTO drives
may create serious safety hazards to you and people
nearby. If you install such drives, follow all appropriate
safety standards and practices to protect you and others
near this planter from injury.
16. Follow all federal, state/provincial, and local
regulations when towing farm equipment on a public
highway. Use safety chain (not an elastic or nylon/plastic
tow strap) to retain connection between towing and
towed machines in the event of primary attaching system
separation.
17. Make sure all safety/warning lights, SMV sign, and
reflective decals are in place and working properly
before transporting the machine on public roads.
18. Limit towing speed to 15 MPH. Tow only with farm
tractor of a minimum 90 HP. Allow for unit length when
making turns.
19. Reduce speed prior to turns to avoid the risk of
overturning. Always drive at a safe speed relative to local
conditions and ensure your speed is slow enough for a
safe emergency stop.
20. Chemical application is often an integral part of
planting. Follow label instructions for proper chemical
mixing, handling and container disposal methods.
21. Be familiar with safety procedures for immediate first
aid should you accidentally contact chemical substances.
22. Use the proper protective clothing and safety
equipment when handling chemicals.
23. Chemicals are supplied with Material Safety Data
Sheets (MSDS) that provide full information about the
chemical, its effects on exposure, and first aid needs
in the event of an emergency. Keep your MSDS file
up-to-date and available for first responders in case of
emergency.
24. When servicing ground engaging components such
as opening disks and firming points, use special care to
avoid points and edges worn sharp during use.
25. Use professional help if you are unfamiliar with
working on hydraulic systems. Pressurized hydraulic fluid
can penetrate body tissue and result in death, serious
infection, or other injuries.

TM
Model 3660M0260-01
Rev. 02/19 1-7
Safety Precautions
Following are some common hazard warnings associated with this equipment. Pay close attention to all safety,
operating, and maintenance information in this manual and decals applied to your equipment.
Contacting or coming close to power
lines or other high energy sources will
cause death or serious injury.
Keep away from power lines or high
energy sources at all times.
DANGER
Improperly operating or working on
this equipment could result in death
or serious injury. Read and follow all
instructions in Operator Manual before
operating or working on this equipment.
WARNING
Falling equipment can cause death or
serious injury. Install all lockup devices
or lower planter to ground before
working on equipment.
WARNING
Explosive separation of rim and tire
parts can cause death or serious injury.
Overinflation, rim and tire servicing,
improper use of rims and tires, or worn
or improperly maintained tires could
result in a tire explosion.
WARNING

M0260-01Model 3660
1-8 Rev. 02/19
TM
Safety signs and decals are placed on the machine to warn of hazards and provide important operating and maintenance
instructions. Information on these signs are for your personal safety and the safety of those around you. FOLLOW ALL
SAFETY INSTRUCTIONS!
• Keep signs clean so they can be easily seen. Wash with soap and water or cleaning solution as required.
• Replace safety signs if damaged, painted over, or missing.
• Check reflective decals and SMV sign periodically. Replace if they show any loss of of reflective properties.
• When replacing decals, clean machine surface thoroughly with soap and water or cleaning solution to
remove all dirt and grease.
NOTE: Safety sign and decal locations are shown in the Parts Manual for this machine.
NOTE: Style and locations of SMV sign, reflective decals, and safety/warning lights conform to ANSI/ASABE
S279.14 JUL 2008 and ANSI/ASABE S276.6 JAN 2005.
SAFETY SIGNS AND DECALS
All safety/warning lights, reflective
decals, and SMV sign must be in place
and visible before transporting machine
on public roads or death, serious injury,
and damage to property and equipment
may result. Check federal, state/
provincial, and local regulations before
transporting equipment on public roads.
WARNING
Safety Precautions

TM
Model 3660M0260-01
Rev. 02/19 2-1
Machine Operation
PLANTER LIFT SAFETY LOCKUP
Always install row marker lockups when working or
transporting planter.
Connect chain between marker stand and second
stage of marker assembly.
Planter lift safety lockup is installed between center post and lift cylinder. It is held in place by a clevis pin near the base
of the lift cylinder rod. Remove safety lockup and store on hose take-up for field operation.
Safety lockup in transport/maintenance position
Safety lockup in storage position
ROW MARKER SAFETY LOCKUP
Row marker safety lockup installed
Uncontrolled movement of equipment
can cause loss of control and could
result in death, serious injury, or damage
to property and equipment. Install
all safety pins before transporting
equipment.
WARNING
Row marker can lower at any time and
could cause death or serious injury. Stay
away from row markers! Install safety
lockup device when not in use.
WARNING

M0260-01Model 3660
2-2 Rev. 02/19
TM
Machine Operation
TRANSPORT LATCH LOCKING PIN
TONGUE SAFETY PIN
Tongue safety pin installed for transport Tongue safety pin stored for field operation
Never transport planter without installing transport latch locking pin. Transport latch locking pin prevents latch bar from
disengaging and allowing planter frame to swing away.
Remove transport latch locking pin and store in location provided on latch post for field operation.
Never transport planter without installing tongue safety pin. Tongue safety pin prevents tongue cylinder from retracting
should hydraulic failure occur or a sudden stop be made when transporting planter.
Secure safety pin in hitch with snap pin. Remove tongue safety pin and store in bracket on transport latch post at center
of planter for field operation.
Transport latch locking pin stored Transport latch locking pin installed
Snap pin
Uncontrolled movement of equipment
can cause loss of control and could
result in death, serious injury, or damage
to property and equipment. Install
all safety pins before transporting
equipment.
WARNING

TM
Model 3660M0260-01
Rev. 02/19 2-3
Machine Operation
Following information is general in nature to aid in preparation of tractor and planter for use, and to provide general
operating procedures. Operator experience, familiarity with the machine, and the following information should combine
for efficient planter operation and good working habits.
INITIAL PREPARATION
Transporting planter with hoppers over
half full or unevenly loaded can cause
loss of control and could result in death,
serious injury, or damage to property and
equipment. Properly load planter when
transporting. Be aware of extra transport
weight, and road conditions and limits.
WARNING
Uncontrolled movement of equipment
can cause loss of control and could
result in death, serious injury, or damage
to property and equipment. Install
all safety pins before transporting
equipment.
WARNING
Uncontrolled machine movement can
crush or cause loss of control resulting
in death, serious injury, or damage to
property and equipment. Install all safety
lockup devices before working under or
transporting this equipment.
WARNING
To avoid unintended movement of
axle during transport, return all SCV
controls to the neutral position before
transporting machine. DO NOT operate
any hydraulic function while transporting
machine. Doing so could result in death,
serious injury, or damage to property and
equipment.
WARNING
Transport axle can lower from transport
position without the use of any
controller, causing death, serious injury,
or damage to property and equipment.
Do not operate any hydraulic function
while transporting the planter. Make sure
all transport safety lockups are installed
on the four transport cylinders and all
SCV controls are in their neutral state
before transporting, storing and working
on the planter.
WARNING

M0260-01Model 3660
2-4 Rev. 02/19
TM
Machine Operation
Tractor driven PTO pump and oil cooler option is for tractors with less than required hydraulic output needed to
operate hydraulic-driven vacuum fan and other planter hydraulic requirements.
A 1000 RPM PTO is required to operate PTO-driven hydraulic pump.
Option consists of a 1"-21 or 1¾"-20 spline,13.5 GPM 2000 PSI tractor mounted pump, 10 gallon capacity hydraulic
reservoir, 15 GPM-rated oil cooler, spin-on 10-micron oil filter, and required hydraulic valves and fittings.
Vacuum fan assembly
Oil cooler
TRACTOR MOUNT PTO PUMP/OIL COOLER OPT (HYD DRIVE)
Flow control valve*
* Electric Drive uses a relief valve rather than the flow
control valve shown.
Reservoir
Hydraulic reservoir assembly
Oil filter
Hydraulic
motor
1. Torque transport wheel "- 18 lug nuts to 180 ft-lb (244 N-m).
2. Inflate tires to the following specifications:
Transport (center section) 255-70R 22.5 (“224” rim)
75 psi (517.1 kPa) recommended/75 psi (517.1 kPa) max.
Transport (center section) 255-70R 22.5" (“276” rim)
75 psi (517.1 kPa) recommended/100 psi (689.4 kPa) max.
Ground drive (wings) 7.50" x 20" 40 psi (275.7 kPa)
Liquid fertilizer piston pump 7.60" x 15" 40 psi (275.7 kPa) Tire locations
Transport
Ground drive (wing)
3. Lubricate planter and row units following instructions in Lubrication and Maintenance section of this manual.
4. Check all row unit drive chains for proper tension, alignment, and lubrication.

TM
Model 3660M0260-01
Rev. 02/19 2-5
Machine Operation
TRACTOR REQUIREMENTS
Consult your dealer for information on horsepower requirements and tractor compatibility. Requirements vary with
planter options, tillage, and terrain.
A 12 volt DC electrical system is required on all sizes.
TRACTOR PREPARATION AND HOOKUP
1. Adjust tractor drawbar 13-17 inches above ground with hitch pin hole directly below PTO shaft center line. Make
sure drawbar is in a stationary position.
2. Install control console or Blue Vantage Display on tractor
in a convenient location within easy reach of operator and
close to hydraulic controls. Mount control console securely
and route power cord to power source. Control console
operates on 12 volt DC only. If two 12 volt batteries are
connected in series, ALWAYS make power connection on
battery grounded to tractor chassis.
If two 6 volt batteries are connected in series, make sure
power connection provides 12 volt DC across positive
terminal on one battery and negative terminal of second
battery.
3. Back tractor to planter and connect with 1¼" - 1½"
diameter hitch pin. If tractor is not equipped with a hitch
pin locking device, make sure hitch pin is secured with a
locking pin or cotter pin.
Kinze Blue Vantage

M0260-01Model 3660
2-6 Rev. 02/19
TM
Machine Operation
NOTE: DO NOT install safety chain using clevis mounting hardware. Safety chain MUST be installed
separately.
4. Safety chain must be used to keep planter and tractor connected in case of a hitch pin/drawbar failure. Attach
safety chain at an unused clevis mounting hole on the planter hitch. Torque hardware to 840 ft-lb (1138.8 N-m).
NOTE: A 2-Point Hitch Option converts planter from drawn to semi-mounted and is available for use with
Category 3N or 3 three-point hitch designs. Safety chain is not used with 2-point hitch.
Planter/safety chain hookup to tractor
Optional 2-point hitch
2019 Production 2020 Production and On2015 - 2018 Production
