Kitagawa S1036 User manual

HIGHSPEEDROTARYHYDRAULIC
CYLINDEROPENCENTER
・This instructionmanual is for production engineers and
maintenancepersonnelinchargeofoperationofthisproduct.
Whenabeginnerusesthisproduct,receiveinstructionsfrom
experiencedpersonnel,thedistributororourcompany.
・Before installing, operating or maintainingthis equipment,
carefully read this manual and the safety labels attached to
theequipment.Failuretofollowtheseinstructionsandsafety
precautions could result in serious injury, death, or property
damage.
・Storethismanualnearequipmentforfuturereference.
・If any questions related to safetyarise about this manual,
pleaseconfirmthemwiththedistributororourcompany.
INSTRUCTIONMANUAL
S
type
Version 1.10 (2019.09.03)
Original instructions
