COOKTOP PARTS
1
For Models: KECC508GBL0, KECC508GWH0, KECC508GBT0
(Black) (White)
30" ELECTRIC
BUILT−IN
COOKTOP
1−99 Litho in U.S.A. (awm) Part No. 885441
(Biscuit)

COOKTOP PARTS
2
For Models: KECC508GBL0, KECC508GWH0, KECC508GBT0
(Black) (White)
(Biscuit)
885441
Illus. Part
No. No. DESCRIPTION
1 98997 Clip, Wire
2 Cooktop, Glass
3192564 Black
3192565 White
3192566 Biscuit
3 246119 Screw
5 3191354 Fan, Cooling
6 3191791 Spring Locator (8)
7 3191949 Guard, Fan
8 4449746 Screw (4)
11 3192369 Box, Burner
12 3191948 Seal, Burner Box
13 3192558 Board, Power
14 3196537 Screw
15 3191352 Board, Control
16 Switch, Limiter
3191990 Use W/3191984
R.F. Element
3191990 Use W/3191984
L.R. Element
3191988 Use W/3191982
R.R. Element
3191966 Use W/3191723
L.F. Element
18 3191913 Cable Ass’y, Flat
19 3191693 Support,
Power Board
20 3191515 Rail, Element (2)
21 3192268 Rail, Element (1)
22 3191907 Standoff,
Power Board
488734 Screw
24 Element, Surface
(Includes # 16)
3191984 1200W Right Front
3191984 1200W Left Rear
3191982 1800W Right Rear
3191723 2400W Left Front

MISCELLANEOUS PARTS
3
For Models: KECC508GBL0, KECC508GWH0, KECC508GBT0
(Black) (White)
(Biscuit)
885441
Illus. Part
No. No. DESCRIPTION
FOLLOWING PARTS
NOT ILLUSTRATED
LITERATURE PARTS
LIT3191771 Installation
Instructions
LIT3192472 Wiring Diagram
LIT3191524 Use & Care Guide
LIT3191638 Safer Cooking Tips
Miscellaneous
3172515 Mtg. Hardware Kit
SPLICING WIRES−−25FT.
LENGTH
242828 Wire, Black
12 Ga. 150 C
242820 Wire, Black
14 Ga. 150 C
242822 Wire, Blue
14 Ga. 150 C
242830 Wire, Brown
14 Ga. 200 C
242823 Wire, Green
14 Ga. 150 C
242824 Wire, Orange
14 Ga. 150 C
242829 Wire, Red
12 Ga. 150 C
242825 Wire, Red
14 Ga. 150 C
242831 Wire, Red
14 Ga. 200 C
242826 Wire, White
14 Ga. 150 C
242827 Wire, Yellow
14 Ga. 150 C
242832 Wire, Yellow
14 Ga. 200 C
ACCESSORY PARTS
3191048 Cleaner, Glass
WIRING HARNESS PARTS
3192474 Wiring Harness
Surface Unit
3400015 Screw, Ground
3192315 Harness, Hot
Surface Indicator
3191521 Harness, Fan
3179589 Wire, Tie
3192476 Conduit Assy.
