KitchenAid 3KSM55 User manual

Stand Mixer - Bowl Lift
3KSM55, 3KSM60,
5KSM55, 5KSM60,
5KSM70
*Bowl type may vary. Bowls are also available for purchase as separate accessories.
**Included with select models. Picture/Style may vary from product depending on model.
***Can also be used to scrape your Bowl.
1Motor Head
2Attachment Hub
3Attachment Knob
4Hub Cover
5Bowl-Lift Lever
6Beater Shaft
7Bowl Handle*
8Bowl*
9Locating Pins
10 Bowl Support
11 Spring Latch and Bowl Pin
(Not Shown)
12 Beater Height Adjustment Screw
13 Speed Control Lever
14 Double Flex Edge Beater**
15 Flat Beater
16 Flex Edge Beater**
17 Wire Whip**
18 11-Wire Stainless Steel Elliptical
Whip**
19 Spiral Dough Hook
20 Pastry Beater** and Scraper** ***
21 Pouring Shield**
0 .5 1 2 3 4 5 6 7 8 9 10
1
3
2
6
13
12
5
10
9
87
14 15 16
19
17 18
21
4
11
20
W11556523B.indb 1W11556523B.indb 1 8/18/2022 11:34:26 AM8/18/2022 11:34:26 AM

2
PRODUCT SAFETY
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always
be followed, including the following:
1. Read all instructions. Misuse of appliance may result in personal injury.
2. To protect against the risk of electrical shock do not put Stand Mixer in water or
other liquid.
3. This appliance is not intended for use by persons (including children) with
reduced physical, sensory, or mental capabilities, or lack of experience and
knowledge unless they are closely supervised and instructed concerning the use
of the appliance by a person responsible for their safety.
4. Children should be supervised to ensure that they do not play with the appliance.
5. If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualied persons in order to avoid a hazard.
6. Turn the appliance off (OFF/0), then unplug from the outlet when not in use,
before assembling or disassembling parts and before cleaning. To unplug, grasp
the plug and pull from the outlet. Never pull from the power cord.
7. Avoid contacting moving parts. Keep hands, hair, and clothing, as well as
spatulas and other utensils, away from beater during operation to reduce the risk
of injury to persons and/or damage to the Stand Mixer.
8. Do not operate any appliance with a damaged cord or plug, or after the
appliance malfunctions, or is dropped or damaged in any manner. Return
appliance to the nearest Authorised Service Facility for examination, repair, or
electrical or mechanical adjustment.
9. The use of attachments not recommended or sold by KitchenAid may cause re,
electrical shock, or injury.
10. Never leave the appliance unattended while it is in operation.
11. Do not use the appliance outdoors.
12. Do not let the cord hang over the edge of table or counter.
13. Remove the Flat Beater, Wire Whip, Pastry Beater, Flex Edge Beater, Double Flex
Edge Beateror Spiral Dough Hook from the Stand Mixer before washing.
W11556523B.indb 2W11556523B.indb 2 8/18/2022 11:34:26 AM8/18/2022 11:34:26 AM

ENGLISH
3
PRODUCT SAFETY
ELECTRICAL REQUIREMENTS
Voltage: 220-240 V
Frequency: 50-60 Hz
NOTE: The power rating for your Stand
Mixer is printed on the serial plate.
Do not use an extension cord. If the
power supply cord is too short, have a
qualified electrician or service technician
install an outlet near the appliance.
14. To avoid product damage, do not use the mixer bowls in areas of high heat such
as an oven, microwave, or on a stovetop.
15. Allow the appliance to cool completely before putting on or taking off parts, and
before cleaning the appliance.
16. Refer to the “Care and Cleaning” section for instructions on cleaning the
surfaces in contact with food.
17. This appliance incorporates an earth connection for functional purposes only.
18. This appliance is intended to be used in household and similar applications such
as:
- staff kitchen areas in shops, ofces and other working environments;
- farmhouses;
- by clients in hotels, motels and other residential type environments;
- bed and breakfast type environments.
SAVE THESE INSTRUCTIONS
Electrical Shock Hazard
Plug into an earthed outlet.
Do not remove earth prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these
instructions can result in
death, fire, or electrical shock.
W11556523B.indb 3W11556523B.indb 3 8/18/2022 11:34:26 AM8/18/2022 11:34:26 AM

4
PRODUCT ASSEMBLY
Turn the Stand Mixer OFF/0 and then
unplug.
To attach the Bowl: Fit the Bowl
Supports over Locating Pins and press
down on back of the Bowl until Bowl Pin
snaps into Spring Latch.
1
Spring Latch
Locating Pin
0 .5 1 2 3 4 5 6 7 8 9 10
To Remove Bowl: Place Bowl-Lift Lever
in the down position. Grasp Bowl Handle
and lift straight up and off Locating Pins.
2
ACCESSORY/SPEED GUIDE
ACCESSORY USE FOR DESCRIPTION SPEED
Flat Beater
Mixing and
folding in
ingredients
Folding delicate ingredients,
egg whites, cream, and
avoiding overmixing.
Mixing cakes, frostings,
cookies, etc.
1/2 speed for
folding
Speed 1-6 for
mixing
Double Flex Edge
Beater*, Flex Edge
Beater*
Mixing
ingredients
Mixing cakes, frostings,
cookies, etc.
Speed 1-6 for
mixing
Spiral Dough
Hook Kneading Breads, rolls, pizza dough, etc. Speed 2 for
kneading
Wire Whip*,
11-Wire Stainless
Steel Elliptical
Whip*
Whipping Eggs, egg whites, cream, etc. Speed 4-10 for
whipping
Pastry Beater*
Cutting butter
into flour,
mashing fruits/
vegetables,
shredding
meats
Pie dough and other pastries;
mashed potatoes/fruits/
vegetables, shredded chicken
Pastries (Cutting
butter into flour):
Speed 2
Mashing Fruits/
Vegetables:
Up to speed 2
Mashing Potatoes,
Shredding Meat:
Speed 4
*Included with select models. Picture/Style may vary from product depending on model.
NOTE: Use speed 2 to mix or knead yeast doughs. Use of a higher speed creates high
potential for Stand Mixer failure. The PowerKnead Spiral Dough Hook efficiently kneads
most yeast dough within 4 minutes. The use of a lower speed might slow down the unit
and not thoroughly knead the dough.
W11556523B.indb 4W11556523B.indb 4 8/18/2022 11:34:26 AM8/18/2022 11:34:26 AM

ENGLISH
5
PRODUCT ASSEMBLY
IMPORTANT: If the Bowl is not securely snapped into place, it will be unstable and
wobble during use.
To raise the Bowl: Rotate the
Bowl-Lift Lever to the straight up
position. The Bowl must always be in the
raised position when mixing.
Test the Beater to Bowl Clearance: Turn
Stand Mixer ON and test each speed,
making sure the beater does not touch
the Bowl during operation. If the Beater
is too far away from the bottom or is
hitting the Bowl, proceed to next step to
make adjustments.
6
To attach the Accessory: Slip the
accessory onto the shaft. Turn to hook it
over the pin on the shaft.
3
Pin
To remove the Accessory: Turn Stand
Mixer to OFF/0 then unplug. Press
accessory upward and turn to the left. Pull
down the accessory from Beater Shaft.
4
IMPORTANT: When properly adjusted,
the Flat Beater will not strike on the
bottom or sides of the Bowl. If the Flat
Beater or the Wire Whip* is so close that
it strikes the bottom of the Bowl, coating
may wear off the beater or wires on the
whip may wear.
(OPTIONAL) To adjust Beater to Bowl
Clearance: Lower the Bowl to the
down position. Turn the screw slightly
counterclockwise (left) to raise the beater,
or clockwise (right) to lower it. Adjust the
beater so that it just clears the surface of
the Bowl. Check again the clearance of
the beater to the Bowl.
7
Raise Bowl
Raise Bowl
Lower Bowl
Lower Bowl
5
*Included with select models. Picture/Style may vary from product depending on model.
W11556523B.indb 5W11556523B.indb 5 8/18/2022 11:34:27 AM8/18/2022 11:34:27 AM

6
*Included with select models. Picture/Style may vary from product depending on model.
PRODUCT USAGE
1. Turn the Stand Mixer OFF/0 and unplug.
2. Attach Bowl and Flat Beater, Dough Hook, or Wire Whip* to the mixer. Attach Bowl
and raise into locked position.
3. Place the shield onto the Bowl so that the Motor Head covers the U-shaped gap in
the shield. This will position the pouring chute just to the right of the Attachment Hub
as you face the Mixer. Press lightly so that the tabs snap the shield onto the Bowl.
4. Pour ingredients into the Bowl through the Pouring Chute.
USING THE POURING SHIELD*
DISASSEMBLING THE PRODUCT
1. Turn the Stand Mixer OFF/0 and unplug.
2. Lift the front of the Pouring Shield* clear of the rim of the Bowl. Pull away from the
Stand Mixer. Lower the Bowl and scrape.
PRODUCT USAGE
Electrical Shock Hazard
Plug into an earthed outlet.
Do not remove earth prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these
instructions can result in
death, fire, or electrical shock.
1. Plug the Stand Mixer into an earthed
outlet. Start with lower speed to avoid
splashing and increase it gradually.
Refer to the “Accessory/Speed Guide”.
WARNING
Injury Hazard
Unplug mixer before touching
beaters.
Failure to do so can result in
broken bones, cuts, or bruises.
2. Do not scrape the Bowl while operating.
Scraping the Bowl once or twice during
mixing is usually sufficient.
PRODUCT ASSEMBLY
W11556523B.indb 6W11556523B.indb 6 8/18/2022 11:34:27 AM8/18/2022 11:34:27 AM

ENGLISH
7
OPTIONAL ATTACHMENTS
KitchenAid offers a wide range of optional attachments such as the Spiralizer, Pasta
Cutters, or Food Grinder that may be attached to the Stand Mixer attachment power
hub.
Turn the Stand Mixer to OFF/0 and then
unplug. Unscrew Attachment Hub Cover.
Insert attachment into Attachment Hub,
making certain that attachment power
shaft fits into the square Attachment Hub
socket.
1
Tighten the Attachment Knob by turning
it clockwise until the attachment is
secured to the Stand Mixer.
2
NOTE: See the Use and Care Guide of each specific attachment for more details.
CARE AND CLEANING
IMPORTANT: Allow the appliance to cool completely before putting on or taking off
parts, and before cleaning the appliance. Do not immerse the Stand Mixer body in
water or other liquids.
1. Turn the Stand Mixer OFF/0 and then unplug.
2. Wipe the Stand Mixer Body with a soft, damp cloth.
3. The following part is full dishwasher-safe: Bowl.
The following parts are top rack dishwasher-safe: Flat Beater, Double Flex Edge
Beater*, Flex Edge Beater*, Spiral Dough Hook, 11-Wire Stainless Steel Elliptical Whip*,
Pouring Shield*, Pastry Beater* and Scraper* **.
4. The following part should be hand-washed only, using warm, soapy water and drying
thoroughly: Wire Whip* only.
PRODUCT USAGE
*Included with select models. Picture/Style may vary from product depending on model.
**Can also be used to scrape your Bowl.
W11556523B.indb 7W11556523B.indb 7 8/18/2022 11:34:28 AM8/18/2022 11:34:28 AM

8
Problem Solution
If Stand Mixer warms up during
use:
Under heavy loads with extended mixing time periods, you
may not be able to comfortably touch the top of the Stand
Mixer. This is normal.
If Stand Mixer emits a pungent
odour during initial use: This is normal. This is common with electric motors.
If the Flat Beater hits the Bowl: Stop the Stand Mixer. See the “Product Assembly” section
and adjust the Beater to Bowl Clearance.
If the Speed Control Lever does
not move smoothly or easily:
To move the Speed Control Lever with ease, lift slightly up as
you move it across the settings in either direction.
If your Stand should fail to
operate, please check the
following:
Is the Stand Mixer plugged in?
Is the fuse in the circuit to the Stand Mixer in working order?
If you have a circuit breaker box, be sure the circuit is closed.
Turn off the Stand Mixer for 10-15 seconds, then turn it back
on. If the Stand Mixer still does not start, allow it to cool for
30 minutes before turning it back on.
If product shuts off after
extensive use:
Motor has automatic sensor that will keep motor from
overheating by shutting it off. If this occurs, turn speed
switch to Off and let Stand Mixer rest for 30 minutes before
restarting.
If the problem cannot be
corrected:
See the “Warranty and Service” section. Do not return the
Stand Mixer to the retailer; retailers do not provide service.
If mixer is slowing down or
appearing to struggle:
Are you using the appropriate beater and speed? See
“Accessory/Speed Guide” for more info. Using Fold Speed or
Speed 1 for bread doughs might slow down the unit. Breads
should knead with the dough hook at Speed 2.
©2022 All rights reserved.
KITCHENAID and the design of the stand mixer are trademarks in the U.S. and elsewhere.
TROUBLESHOOTING GUIDE
WARNING
Electrical Shock Hazard
Plug into an earthed outlet.
Do not remove an earth prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death, fire,
or electrical shock.
W11556523B.indb 8W11556523B.indb 8 8/18/2022 11:34:28 AM8/18/2022 11:34:28 AM

简体中文
9
台 式 搅 拌 机（ 升 降 式 ）
3KSM55, 3KSM60,
5KSM55, 5KSM60,
5KSM70
*搅拌碗类型可能会有所不同。搅拌碗也可作为单独的附件购买。
**包含在特定型号中。取决于型号，图片/风格可能因产品而异。
***也可用于刮擦搅拌碗。
1电动头
2附件套筒
3附件旋钮
4套筒盖
5搅拌碗升降杆
6搅拌轴
7搅拌碗手柄*
8搅拌碗*
9定位销
10 搅拌碗支架
11 弹簧闩锁和搅拌碗销（未显示）
12 搅拌器高度调整螺钉
13 速度控制杆
14 双曲边搅拌器**
15 平搅器
16 曲边搅拌器**
17 打蛋器**
18 11 线不锈钢椭圆打蛋器**
19 螺旋面团钩
20 糕点搅拌器**和刮刀** ***
21 导流罩**
0 .5 1 2 3 4 5 6 7 8 9 10
1
3
2
6
13
12
5
10
9
87
14 15 16
19
17 18
21
4
11
20
W11556523B.indb 9W11556523B.indb 9 8/18/2022 11:34:28 AM8/18/2022 11:34:28 AM

10
产品安全性
重要保护措施
使用电器时，应始终遵循基本的安全预防措施，包括：
1. 阅读所有说明。电器使用不当可能导致人身伤害。
2. 为了避免触电风险，切勿将台式搅拌机放入水中或其他液体中。
3. 身体行动不便、感官或智力障碍者，或缺乏相关经验和知识者（包括儿童），除非
受到其安全负责人关于本家电使用的贴身监督与指导，否则不得使用本家电。
4. 儿童需有成人看护，以确保其不会将本电器当做玩具。
5. 如果电源线损坏，必须让制造商、其服务代理或类似合格人员进行更换以避免发生
危险情况。
6. 不使用时、组装或拆卸部件前以及清洁前，请先将电器转向 OFF/0（关闭/0），然
后从插座上拔下插头。拔出时，抓牢插头并将其从插座中拔出。切勿拉扯电源线。
7. 避免接触运动部件。在操作期间让手、头发、衣物以及刮刀和其他餐具远离搅拌器
以降低人员受伤和/或损坏台式搅拌机的风险。
8. 若电源线或插头受损，或电器发生故障、跌落或任何形式的损坏，请勿操作电器。
请将电器退回至最近的授权服务中心进行检查、修理或进行电气或机械调整。
9. 使用非 KitchenAid 推荐或出售的附件可能会引起火灾、触电或损伤。
10. 切勿在无人看管的情况下运行本电器。
11. 请勿在室外使用本电器。
12. 请勿将电源线挂在桌子或橱柜边缘。
13. 清洗前，从台式搅拌机上拆除平搅器、打蛋器、糕点搅拌器、曲边搅拌器、双曲边
搅拌器或螺旋面团钩。
14. 为避免损坏本产品，请勿在高温物品（如烤箱、微波炉等）周围或在灶台上方使用
搅拌机的搅拌碗。
15. 待设备完全冷却后再安装或拆卸部件或者清洁设备。
16. 有关清洁表面接触食物的说明，请参阅“保养和清洁”部分。
17. 本家电包含的接地连接仅用于功能性目的。
警告
危险 如果不立即遵守说明，可能导致 死亡 或
重伤。
如果不遵守说明，可能导致死亡或重伤。
我们已在本手册以及您的家电上提供了许多重要的安全信息。请务必阅读并遵循
所有安全消息。
这是安全警示符号。
此符号警示您可能导致您和他人伤亡的潜在危险。
所有安全信息都有安全警示符号和警示语“危险”或“警告”。这
些词的含义是：
所有安全信息都将指出潜在危险是什么，如何降低受伤的几率，以及不遵守说明
将会发生什么。
您的安全和其他人的安全非常重要。
W11556523B.indb 10W11556523B.indb 10 8/18/2022 11:34:29 AM8/18/2022 11:34:29 AM
