Klark Teknik DN32-USB User manual

Quick Start Guide
Klark Teknik DN32-USB
USB 2.0 Expansion Module with up to 32 Bidirectional Channels
V 1.0

FEDERAL COMMUNICATIONS
COMMISSION COMPLIANCE
INFORMATION
Responsible Party Name: Music Tribe CommercialNVInc.
Address: 5270ProcyonStreet,
LasVegas NV89118,
United States
Phone Number: [phone]
DN32-USB
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment oand on, the user is encouraged to try to correct
the interference by one or more of the following measures:
•• Reorient or relocate the receiving antenna.
•• Increase the separation between the equipment and receiver.
•• Connect the equipment into an outlet on a circuit dierent from that to
which the receiver is connected.
•• Consult the dealer or an experienced radio/TV technician for help.
This equipment complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including
interference that may cause undesired operation.
Important information:
Changes or modications to the equipment not expressly approved by
Music Tribe can void the user's authority to use the equipment.
Hereby, Music Tribe declares that this product is in compliance with
Directive 2014/30/EU, Directive 2011/65/EU and Amendment 2015/863/
EU, Directive 2012/19/EU, Regulation 519/2012 REACH SVHC and Directive
1907/2006/EC.
Full text of EU DoC is available at https://community.musictribe.com/
EU Representative: Music Tribe Brands DK A/S
Address: Ib Spang Olsens Gade 17, DK - 8200 Aarhus N, Denmark
Klark Teknik
DN32-USB
30 31Quick Start GuideKlark Teknik DN32-USB
4. Specications
* depends on system performance and application
Recommended Minimum Hardware:
Windows-based - Core 2 Duo CPU, 2 GHz
application - USB 2.0 port
- 1 GB RAM
Mac - 1.5 GHz CPU
- USB 2.0 port
- 512 MB RAM
Recommended Operating Systems:
Windows: Windows XP 32-Bit SP2 or higher, Windows 7 32-bit, Windows 7 64-bit, Windows 8 64-bit
(DN32-USBASIO drivers supplied)
Mac OS X : 10.7 Lion, 10.8 Mountain Lion, 10.9 Mavericks
*10.6.8 (16 x 16 max)
(CoreAudio compatible)
Expansion Card Features:
Interface MIDI Audio input channels
24-Bit, 44.1/48 kHz
Audio output channels
24-Bit, 44.1/48 kHz
High Speed USB 2.0 1 in x 1 out 32, 16, 8 or 2 32, 16, 8 or 2
DAW remote control Generic MIDI, HUI and Mackie Control Universal emulation
Expansion Card Performance:
Interface Typical round-trip latency
High Speed USB 2.0 ~14 ms*
Physical
Dimensions 30 x 165 x 138 mm (1.18 x 6.5 x 5.4")
Weight 0.14 kg (0.31 lbs)
