Kleenmaid KCRHSCK90 Installation guide

cooking collection
Instructions for use and warranty details

Model No.:KC

Dear Customer,
Thank you and congratulations for choosing
Kleenmaid.
Your new appliance has been designed
and meticulously tested to ensure that it
meets all your culinary requirements, and
has been carefully manufactured using top
quality materials to give you years of reliable
performance.
For best results, carefully read the instructions
on how your new appliance is to be installed.
Correct installation will avoid delays and
unnecessary service call costs.
Once installation is complete, please read this
instruction manual carefully and get to know
the controls and the features of your new
Kleenmaid appliance. These simple instructions
will enable you to achieve excellent results from
the very first time you use it.
Again, congratulations and thank you for
choosing The Best You Can Own.
KLEENMAID

can be installed on walls between 203mm and 229mm
tall.
.
610mm.
1. Read this manual carefully and completely.
2. The range hoods conform to related appliances standards. Please check your local building codes for any
additional requirements.
3. The appliance has been manufactured as class I, there?fore ground connection is necessary. The range hood
must be installed so that that the plug is easily accessible.
Before You Start...
Remove the packaging with the product in place. Cut off the packing ribbons and carefully cut open the packaging
(do not cut too deeply), remove the packaging. Check that the product is free from transport damage.
shall be reported immediately to the carrier or seller. Any damage
Damage, faults and missing parts must be reported immediately
to the seller.
UnpackingUnpacking

2. Install a roof or wall cap. Connect a 150mm round metal duct to the cap
and work backwards toward the hood. Ensure joints are completely sealed
with duct tape.
1. Plan where the ductwork will run between the hood and the outside.
The hoods exhaust vertically but can be ducted to the rear behind the
chimney duct through an outside wall or vertically up through the ceiling
to the roof. A short straight duct run will produce the most air flow.
Length and elbows will reduce the efficiency of the blower.
1. Before mounting the hood, plug in and test all functions for proper operation.
2. Removed the filters from the bottom of the hood to prevent damage during
the installation.
3. With assistance, hold the hood temporarily in position ensuring the bottom is
above the minimum clearance for the cooking surface. Mark on the wall the
holes for the two mounting screws.
4. Drill the holes (A) at the distances indicated. Use the appropriate screws and
screw anchors for your wall type (e.g. reinforced concrete, drywall, etc.).
If necessary, prepare back wall with cross framing for secure installation.
5. Mount the hood on the wall screws. Align it in a horizontal position relative to
cabinets. When the hood has been adjusted, secure unit by tightening screws (A).
6. Connect a 150mm aluminum duct tube (not included) to the exhaust piece using
duct tape on all seals. (C)
1. Carefully loosen but do not separate the telescopic chimney duct pieces.
2. Arrange the electrical power supply within the dimensions of the decorative
chimney duct.
3. Adjust the width of the support bracket to match the upper duct. Fix it to the
ceiling using the screws (B) so that it is centered in line with your hood and
at a distance from the ceiling indicated.
FixingtheDecorativeChimney
Flue
InstallingtheDuctwork
FixingtotheWall

Note: The above installation guideline is for reference only, please contact your local dealer for installation services.
When mounting hood on the wall,the level can be adjusted by turning the two screws on the motor housing.
InstallingGuideline
Leveling Device

The cooker hood can be installed in the following ways:
Circulating indoor air (A)
Outdoor venting (B)

Description of symbols
Using the dial control
- Push the rotary dial, the LED lights will illuminate
-
hood will select that setting after the indicating light illuminates twice.
- Push the rotary switch again at any setting to switch the hood off.
-
off after 3 min.
Description of symbols
Using the dial control
- Push the rotary dial, the LED lights will illuminate
- Turning the rotary switch clockwise or counter-clockwise, stop the indicating light at the setting you want to select. The
hood will select that setting after the indicating light illuminates twice.
- Push the rotary switch again at any setting to switch the hood off.
- When the indicator light stops at the ‘timer’ setting, the hood will be functioning at speed III and then automatically switch
off after 3 min.
speed I
speed II
speed III
speed I + light
light
speed II + light
speed III + light
3 min. delay-off at speed III
1. For optimum performance in removing cooking odors, it is recommended that you turn on your range hood prior
to cooking and you leave it operating for 15 minutes after cooking.
2. Clean the surfaces of the range hood regularly using a non-abrasive detergent.
3. The anti-grease filters capture the grease particles suspended in the air. They will accumulate grease and dirt
depending on the frequency of the use of your range/cook top.
4. In order to prevent a fire hazard, it is recommended that you clean the aluminum filter at least every 2 months
Operations
