Kleton MP005 User manual

Instruction Manual
MP005
Mobile Hydraulic Scissor Lift Table
330 lbs. (150 kg)

WARNING!
Read this operation manual carefully and understand fully the
operating instructions. Improper use of this unit could result in injury.
• DO NOT put foot or hand in scissor mechanism.
• Keep neighbouring persons away from the unit when in use.
• DO NOT stand in front or behind of lift table when it is in use.
• DO NOT crawl under the table.
• DO NOT put foot in front of rolling wheels.
• DO NOT use lift table on slope or inclined surfaces.
• DO NOT lift or ride people on this unit.
CAUTION!
• DO NOT move this unit when lifting or lowering the bed or when the bed is in an elevated
position. (Bed must be lowered when the unit is running)
• DO NOT use this table for any purpose other than it’s intended use and do not load with more
than the rated capacity.
• DO NOT allow persons to operate this table without complete understanding of its operation.
• DO NOT lower the bed too quickly.
• During loading/unloading operation, do not release the parking brake.
• Load should be distributed on at least 80% of the table area. Stop operation of lift table if load
becomes too unstable, do not place objects protruding off edge of the bed.
• DO NOT modify lift table without manufacturers written consent.
Daily Inspection
Daily inspection of this unit is critical in order to locate any malfunction or fault.
Check the following daily before operating your lift table.
1. Check for bending or cracking of the lift table.
2. Check for any oil leakage from the cylinder.
3. Check for vertical creep of the table.
4. Check for smooth movement of the wheels.
5. Ensure that brakes are fully functional.
6. Ensure that all nuts and bolts are rmly tightened.
Assembly method
The lift table is packed in a cardboard box. Assembling of the jack up pedal is required.
WARNING: Assembly work must be done on a at surface; wheels must be choked to prevent
accidental rolling of the unit.
1. Insert the jack pedal into the pedal pipe and position the tapered side pedal end to right. Tighten
the jack pedal using the removed nut and washer with the smallest hex key supplied in the box.

OPERATING THE LIFT TABLE
How to use the brake
The brake is located next to the swivel caster on right hand side.
1. To brake the lift table, press the brake pedal.
2. To release the brake, lift up the brake pedal.
CAUTION: Put lift table in brake mode when stationary in order to prevent sudden movement.
Lifting the Table
To lift the table, press the lifting pedal several times until the table reaches the desired height. The table
lowers slightly after reaching the highest position. Maximum Capacity of this table is 330 lbs. (150kg).
WARNING: Do not overload lift table, stay within the rated capacity.
Do not load the table on sides or ends only. Load must be distributed on at least 80% of table area.
Lowering the Table
WARNING: DO NOT put foot or hand in scissor mechanism. The rotating knob lowers the table.
NOTE: The hydraulic cylinder is designed to hold table. As is the nature of the hydraulic system, table
lowers very slowly over an extended period of time. Please note that the table does not stay at the same
height indenitely.
Specifications
Model Capacity Table Table
Height
Foot Pedal Strokes
to Elevate Wheel Weight
MP005 150 kg.
330 lbs.
450 x 700 mm
17.7" x 27.5"
225-740 mm
8.8" x 29.1" ≤ 25 100 mm 4"
42 kg.
92.4 lbs.
Service Instructions
Change hydraulic oil every 12 months
Lubricate the following areas every month: Fitting of Cylinder/oil, Roller Friction Surface/grease,
Link Pin/oil, Pedal Fitting Point/oil, Grease Nipple/grease
A B
Troubleshooting
If the table does not lift when pressing the lift pedal several times:
The pull rod is too tight and needs to be loosened.
• Using a wrench, loosen the nut holding the pull rod in place.
• With pliers, push the pull rod from the end back to loosen it, then a
wrench to tighten the nut.
If the table does not lower, then the pull rod is too loose and needs
to be tightened.
• Using a wrench, loosen the nut holding the pull rod in place.
• When pliers, pull the end of the pull rod to tighten it, then
use a wrench to tighten the nut.

LIFT TABLE PARTS LIST
Part
No.
Model
No. Description Qty.
2 SPIII15.1.01 Handle bar 1
3 SP15.0.11 Pressing buckle 1
4 SP15.0-13 Spring 1
5 SP.1-02 Retaining ring 4
6 GB882-86 Pin 4
7 GB5781-2000 Bolt 8
8 GB96-85 Washer 8
9 GB95-85 Washer 9
10 GB93-87 Washer 9
11 GB41-86 Nut M8 9
12 MP020 Wheel 4" 2
13 SP15.7-00 Frame 1
14 GB5780-2000 Bolt 2
15 SP15.0-03 Wheel 2
16 GB889-86 Nut M8 2
18 SP.0-11 Shaft 1
19 SP.0-12 Bush 1
20 GB894.1-86 Retaining ring 1
21 SP15.0-09 Shaft 1
Part
No.
Model
No. Description Qty.
22 YQ-7-150 Retaining ring 1
23 GB894.1-86 Retaining ring 4
24 SP15.3.01B Connecting rod 1
25 SP.3-03 Cushion 1
26 GB5781-2000 Bolt 1
27 SP15.3.02/.03 Pedal bar 1
28 SP15.5-00 Table 1
29 SP15.6-12 Roller 4
30 GB894.1-86 Retaining ring 9
31 SP15.6-00 Arm 1
32 SP15.6-07 Support 2
33 SF1.1210 Bush 4
34 SP15.0-01 Pin 4
35 SP15.0-02 Pin 1
36 GB848-86 Washer 2
41 MP027 Pump unit 1
43 YQ-8-150 Retaining ring 1
44 SP15.6-09 Roller 2
45 SP15.0-12 Spring 1
Part
No.
Model
No. Description Qty.
46 SP15.0-05 Cover 4
47 SP15.0-06 Shaft 2
48 SP15.0-07 Needle roller and frame 2
A MP024 Wheel assembly 2
A

PUMP PARTS LIST
Part
No.
Model
No. Description Qty.
1 GB3542.1-86 O-ring 1
2 SP.8-11 Pump cylinder 1
3 UHS18 YX-seal ring 1
4 DH18 Dust ring 1
5 SP.8-10 Pump plunger 1
6 SP.8-09 Spring 1
7 SP.8-08 Spring seat 1
8 GB894.1-86 Retaining ring 1
9 SP15.0-10 Joint plate 2
10 SP.0-14 Pin 1
11 JF.1-17 Plug 1
12 JB982-77 Copper washer 1
13 6W804.1-12 Damp valve 1
14 YQ-03 Spring 1
15 YQ-02 Spring seat 1
16 GB308-77 Steel Ball 2
17 GB308-77 Steel Ball 1
18 SP.8-18 Spring seat 1
19 SP.8-17 Spring 1
Part
No.
Model
No. Description Qty.
20 SP.8-16 Adjusting screw 1
21 GB3452.1-86 O-ring 2
22 SP.8-15 Cover ring 1
23 GB308-77 Steel ball 1
24 SP.8-07 Spring 1
25 GB308-77 Steel Ball 1
26 GB77-85 Screw 1
27 YQ-01 Strike pin 1
28 GB3452.1-82 O-ring 2
29 DF1.2-08 Shaft 1
30 Filter 1
31 GB3452.1-82 O-ring 1
32 SP15.8-05 Rectangular
section ring
1
33 SP15.8-02 Cylinder 1
34 SP15.8-01 Housing 1
35 SP.8-02 Screw 1
36 GB894.1-86 Retaining ring 1
37 SP15.8-06 Washer 1
38 GB3452.1-82 O-ring 1
Part
No.
Model
No. Description Qty.
39 C01.02-20 Cup packing 1
40 SP15.8-04 Bush 1
41 GB3452.1-82 O-ring 1
42 SP15.8-03 Piston rod 1
43 C01.2-16 Rectangular section
sealing
1
44 C01.2-15 Cylinder cap 1
45 GB3452.1-82 O-ring 1
46 HG4-692-67 J-shaped steel frame
rubber sealing
1
47 YQ.6-150 Base 1
48 YQ-04 Lever plate 1
49 GB894.1-86 Retaining ring 1

HANDLE PARTS LIST
Part
No.
Model
No. Description Qty.
1 GB879-86 Spring pin 1
2 SPAIII.1.01 Handle bar 1
3 MO015 Handle Knob 1
4
MP016
Nut 1
5 Adjusting screw 1
6 Pull rod 1
