Instruction Manual
MP007
Mobile Hydraulic Scissor Lift Table
770 lbs. (350 kg)

WARNING!
Read this operation manual carefully and understand fully the
operating instructions. Improper use of this unit could result in injury.
• DO NOT put foot or hand in scissor mechanism.
• Keep neighbouring persons away from the unit when in use.
• DO NOT stand in front or behind of lift table when it is in use.
• DO NOT crawl under the table.
• DO NOT put foot in front of rolling wheels.
• DO NOT use lift table on slope or inclined surfaces.
• DO NOT lift or ride people on this unit.
CAUTION!
• DO NOT move this unit when lifting or lowering the bed or when the bed is in an elevated
position. (Bed must be lowered when the unit is running)
• DO NOT use this table for any purpose other than it’s intended use and do not load with more
than the rated capacity.
• DO NOT allow persons to operate this table without complete understanding of its operation.
• DO NOT lower the bed too quickly.
• During loading/unloading operation, do not release the parking brake.
• Load should be distributed on at least 80% of the table area. Stop operation of lift table if load
becomes too unstable, do not place objects protruding off edge of the bed.
• DO NOT modify lift table without manufacturers written consent.
Daily Inspection
Daily inspection of this unit is critical in order to locate any malfunction or fault.
Check the following daily before operating your lift table.
1. Check for bending or cracking of the lift table.
2. Check for any oil leakage from the cylinder.
3. Check for vertical creep of the table.
4. Check for smooth movement of the wheels.
5. Ensure that brakes are fully functional.
6. Ensure that all nuts and bolts are rmly tightened.
Assembly method
The lift table is packed in a cardboard box. Assembling of the jack up pedal is required.
WARNING: Assembly work must be done on a at surface; wheels must be choked to prevent
accidental rolling of the unit.
1. Insert the jack pedal into the pedal pipe and position the tapered side pedal end to right. Tighten
the jack pedal using the removed nut and washer with the smallest hex key supplied in the box.

OPERATING THE LIFT TABLE
How to use the brake
The brake is located next to the swivel caster on right hand side.
1. To brake the lift table, press the brake pedal.
2. To release the brake, lift up the brake pedal.
CAUTION: Put lift table in brake mode when stationary in order to prevent sudden movement.
Lifting the Table
To lift the table, press the lifting pedal several times until the table reaches the desired height. The table
lowers slightly after reaching the highest position. Maximum Capacity of this table is 770 lbs. (350 kg).
WARNING: Do not overload lift table, stay within the rated capacity.
Do not load the table on sides or ends only. Load must be distributed on at least 80% of table area.
Lowering the Table
WARNING: DO NOT put foot or hand in scissor mechanism. The rotating knob lowers the table.
NOTE: The hydraulic cylinder is designed to hold table. As is the nature of the hydraulic system, table
lowers very slowly over an extended period of time. Please note that the table does not stay at the same
height indenitely.
Specification
Model Capacity Table Table
Height
Foot Pedal
Strokes to Elevate Wheel Weight
MP007 350 kg.
770 lbs.
500 x 910 mm
19.7" x 35.9"
350-1300 mm
13.8" x 51.1" ≤ 60 127 mm 5"
105 kg.
231.5 lbs.
Troubleshooting
If the table does not lift when pressing the lift pedal several times:
The pull rod is too loose and needs to be tightened.
• Using a wrench, loosen the nut holding the pull rod in place.
• With pliers, pull the end of the pull rod to tighten it,
and then use a wrench to tighten the nut.
If the table does not lower:
The pull rod is too tight and needs to be loosened.
• Using a wrench, loosen the nut holding the pull rod in place.
• With pliers, push the pull rod from the end back to
loosen it, then a wrench to tighten the nut.
Service Instructions
Change hydraulic oil every 12 months
Lubricate the following areas every month: Fitting of Cylinder/oil, Roller Friction Surface/grease,
Link Pin/oil, Pedal Fitting Point/oil, Grease Nipple/grease

LIFT TABLE PARTS LIST
Part
No.
Model
No. Description Qty.
2 SPIII.1-00 Handle bar 1
3 SPA.0-02 Washer 2
4 GB93-1987 Washer 6
5 GB5781-2000 Bolt 2
6 GB5781-2000 Bolt 8
7 GB95-1985 Washer 17
9 GB93-1987 Washer 9
10 GB41-86 Nut 9
11 MP021 Wheel 2
12 SPSC.3-00 Frame 1
13 SP.0-08 Shaft 2
14 MP021 Wheel 2
15 GB894.1-86 Retaining ring 2
17 SP.0-11 Shaft 1
18 SP.0-12 Bush 1
19 GB894.1-86 Retaining ring 1
20 SPS.0-03 Shaft 1
21 YQ-7 Retaining ring 1
22 GB894.1-86 Retaining ring 1
23 SPS.2.01B Connecting rod 1
24 SP.3-03 Cushion 1
Part
No.
Model
No. Description Qty.
25 GB5781-2000 Bolt 1
26 SP.3-02 Pedal bar 1
27 SPSC.6-00 Table 1
28 SP.6-11 Bush 2
29 SP.6-12 Roller 2
30 GB848-86 Washer 4
31 GB894.1-86 Retaining ring 6
32 SPS.0-01 Shaft 2
33 GB95-1985 Washer 4
34 GB95-1985 Washer 4
35 GB41-86 Nut 4
36 SP.6-10 Roller 2
37 SP.6-01 Bush 2
38 SP.0.02 L-pin 4
39 GB70-85 Bolt 4
40 SP.0-03 Shaft 1
41 SPS.4-00 Arm 1
42 SF-1.1612 Bush 2
Part
No.
Model
No. Description Qty.
47 MP030 Pump unit 1
48 SPC.6-07 Support 2
49 SPA.4-07 Washer 2
50 GB894.1-86 Retaining ring 2
51 GB93-1987 Washer 4
53 YQ-8 Retaining ring 1
54 SP.0-06 Bush 4
55 SP.0-07 Hollow shaft 2
56 GB276-86 Bearing 4
57 SPS.5-00 Arm 1
A MP025 Wheel assembly 2
A

PUMP PARTS LIST
Part
No.
Model
No. Description Qty.
1 GB3452.1-86 O-ring 1
2 SP.8-11A Pump cylinder 1
3 UHS14 YX - seal ting 1
4 DH14 Dust ring 1
5 SP.8-10A Pump plunger 1
6 SP.8-09 Spring 1
7 SP.8-08 Spring seat 1
8 GB894.1-86 Retaining ring 1
9 SP.0-13B Joint plate 2
10 SP.0-14 Pin 1
11 JF.1-17 Screw 1
12 JB982-77 Copper washer 1
13 6W804.1-12 Damp valve 1
14 YQ-03 Spring 1
15 YQ-02 Spring seat 1
16 GB308-77 Steel ball 2
17 GB308-77 Steel ball 1
18 SP.8-18 Spring seat 1
19 SP.8-17 Spring 1
20 SP.8-16 Adjusting screw 1
Part
No.
Model
No. Description Qty.
21 GB3452.1-86 O-ring 2
22 SP.8-15 Cover ring 1
23 GB308-77 Steel ball 1
24 SP.8-07 Spring 1
25 GB308-77 Steel ball 1
26 GB77-85 Screw 1
27 YQ-01 Strike pin 1
28 GB3452.1-82 O-ring 2
29 DF1.2-08 Shaft 1
30 Filter 1
31 GB3452.1-82 O-ring 1
32 SP.8-12 Rectangular
ring section
1
33 SP.8-04 Cylinder 1
34 SP.8-03 Housing 1
35 SP.8-02 Screw 1
36 GB894.1-86 Retaining ring 1
37 SP.8-13 Washer 1
38 GB3452.1-82 O-ring 1
39 SP.8-14 Cup packing 1
40 SP.8-06 Bush 1
Part
No.
Model
No. Description Qty.
41 GB3452.1-82 O-ring 1
42 SP.8-05 Piston rod 1
43 C01.2-16 Rectangular section sealing 1
44 SP.8-01 Cylinder cap 1
45 GB3452.1-82 O-ring 1
46 HG4-692-67 J shaped steel frame rubber sealing 1
47 YQ.6-300 Base 1
48 YQ-04 Lever plate 1
49 GB894.1-86 Retaining ring 1

HANDLE PARTS LIST
Part
No.
Model
No. Description Qty.
1 GB879-86 Spring pin 1
2 SPAIII.1.01 Handle bar 1
3 MP015 Knob 1
4 GB6172-86 Nut 1
5 SPIII.0-01 Screw 1
6 MP017 Pull rod 1
