KMART JACYN SMITH 140-01573859-4 User manual

OWNER’S MANUAL
9'EDISON FIR CASHMERE
Please refer to part numbers when reordering
For questions or comments about produ c t:
Email: [e-mail] or Call toll-free: [phone].
Made in / Hecho en CHINA. Distributed by Kmart Corporation, Hoffman Estates, IL 60179
PRODUCT CODE: 140-01573859-4
UPC CODE: 030539 032845
Date of purchase: / /

ASSEMBLY INSTRUCTIONS FOR TREE STAND 7. Allow the branches to fall into place or gently pull branches up and out. When adjusting branches be
sure that all wires are free of branch hinges. (See Fig.9)
Fig.1
Fig. 3
1. Tree stand consists of a
metal stand and a single
eye bolt. (See Fig.1)
3. Insert an eye bolt and
screw into the hole. (See
Fig.3)
Fig. 2
Fig. 4
2. Open the stand to a 90 degree
angle until the hole lines up with
the hole on the tube. (See Fig.2)
4. Insert the tree into the stand and
adjust accordingly. The tree
should be straight and balanced
correctly. (See Fig.4)
8. Shape the branches and tips working from the bottom to the top. Start with tips farthest from the trunk
and fan out one to the right, one to the left and one at the center of the main stem (see Fig. 9). After
shaping the entire tree, follow the previous step, slightly upsweep all branch tips for a uniform look.
Shift branches to fill any gaps. Your Christmas tree is now ready to be decorated.
9. Connect the plug of the extension cord from bottom section (D) to the wall outlet. Now your tree
should be completed with all lights illuminated. Your tree is ready to be enjoyed.
IMPORTANT SAFETY INSTRUCTIONS
a) READ AND FOLLOW ALL SAFETY INSTRUCTIONS
b) Do not use seasonal products outdoors unless marked suitable for indoor and outdoor use. When
products are used in outdoor applications, connect the product to a Ground Fault Circuit Interrupting
(GFCI) outlet. If one is not provided, contact a qualified electrician for proper installation.
c) This seasonal use product is not intended for permanent installation or use.
ASSEMBLY INSTRUCTIONS
1. Before you start to assemble your tree, place the tree stand on a level surface.
2. Assemble tree stand according to the assembly instruction for the tree stand.
3. Insert the bottom section (D) of the trunk into the assemble stand and tighten the screw. (See Fig.1)
4. Insert the lower middle section (C) into the bottom section (D), the upper middle section (B) into the
lower middle section (C), the top section (A) into upper middle section (B). (See Fig.2,3,4)
5. Connect light set plug from section (A) and (B) into outlet of extension cord (E1) mounted in upper
middle section (B). Then connect light set plugs from lower middle section (C) and bottom section (D)
into extension cord (E2, E3) hanging down from upper middle section (B).(See Fig.5,6,7)
IMPORTANT: Do not remove the tape wrapped around the outlets of the extension cord
mounted in upper middle section (B). Any outlets you need to plug into are not wrapped in tape. Only
remove tape when inspecting fuses (see Trouble Shooting section).
6. Open all the branches. (See Fig.8)
d) Do not mount or place near gas or electric heaters, fireplace, candles or other similar sources of heat.
e) Do not secure the wiring of the product with staples or nails, or place on sharp hooks or nails.
f) Do not let lamps rest on the supply cord or on any wire.
g) Unplug the product when leaving the house, when retiring for the night, or if left unattended.
h) This is an electric product –not a toy! To avoid risk of fire, burns, personal injury and electric shock it
should not be played with or placed where small children can reach it.
i) Do not use this product for other than its intended use.
j) Do not hang ornaments or other objects from cord, wire, or light string.
k) Do not cover the product with cloth, paper or any material not part of the product when in use.
l) This product is equipped with push-in type lamps. Do not twist lamps.
m) This product has a polarized plug (one blade is wider than the other) as a feature to reduce the risk of
electric shock. This plug will fit in a polarized outlet only one way. If the plug does not fit fully in the
outlet, reverse the plug. If it still does not fit, contact a qualified electrician. Do not use with an
extension cord unless plug can be fully inserted. Do not alter or replace the plug.
n) This product employs overload protection (fuse). A blown fuse indicates an overload or short-circuit
situation. If the fuse blows, unplug the product from the outlet. Also unplug any additional strings or
products that may be attached to the product. Replace the fuse as per the user servicing instructions
(follow product marking for proper fuse rating) and check the product. If the replacement fuse blows, a
short-circuit may be present and the product should be discarded.
o) Read and follow all instructions that are on the product or provided with the product.
p) SAVE THESE INSTRUCTIONS
TROUBLE SHOOTING (If Lights Do Not Work):
1. If entire tree does not light, make sure extension cord plug is securely inserted into a working
electrical outlet.
2. Check whether all bulbs are tightly fixed inside the lamp holder.
3. If a bulb is blown or broken, replace the faulty bulb according to bulb replacement instructions below.
4. If the fuse in the light set plug or extension cord plug is blown, replace the blown fuse according to
fuse replacement instructions below.
5. If you are still experiencing problems with the tree please call us.
CAUTION! –ALWAYS UNPLU3G YOUR TREE FROM ITS
POWER SOURCE BEFORE ATTEMPTING EITHER FUSE
OR BULB REPLACEMENT.
1 2

REPLACEMENT PARTS LIST A B
Part
Description
Part #
A
Fuses
W14T0316-F
B
Bulbs
W14T0316-B
FUSE REPLACEMENT
This product comes with overload protection (fuse). A blown fuse indicates an overload or short circuit. If
a fuse blows, unplug tree from wall outlet. Replace the fuse as per the fuse replacement instructions
below (follow product marking for proper fuse rating). If the fuse blows, a short circuit may be present
and the product should be reviewed to determine the cause.
(Inspect product carefully before using or re-using):
1. This is an electrical product –not a toy! To avoid risk of fire, burns, personal injury and electrical
shock it should not be played with.
2. Do not mount or place near gas or electric heaters, fireplaces, candles or other similar sources of heat.
3. Do not cover product with cloth, paper or any material when product is in use.
4. Do not hang ornaments or other objects from cord, wire, or light string. Hang ornaments only on the
tree itself.
5. For your safety, unplug the product when leaving the house, retiring for the night, or if left unattended.
6. Do not let bulbs rest on the supply cord or on any wire.
7. Do not close doors or windows on the product or extension cords as this may damage the wire
insulation.
8. Should you discover any of the following: a) cut, damaged, or frayed wire insulation; b) cracks in the
sockets; c) loose connections or exposed wires, please call us.
STORAGE: When storing the product, carefully remove the product from wherever it is placed, including
trees, branches, or bushes, to avoid any undue strain or stress on the product conductors, connections,
A)
1.
Extension cord fuse replacement (1 replaceable 5-amp 125V fuse is located in the plug):
Grasp plug and remove from its power source.
and wires. Disassembled tree can be stored in its original box.
temperature does not exceed 100 degrees Fahrenheit.
Store tree in a cool dry place where the
2.
Locate blown fuse by sliding access cover on top of plug towards prongs.
3.
Remove blown fuse by turning the plug over.
UL MODEL # TP9-1(2.72))
Fuses should fall into your hand (gentle tapping may be required).
4.
Locate spare replacement fuse included in plug.
5.
Replace blown fuse with the spare replacement fuse.
Close fuse cover by sliding fuse access cover towards the cord.
CAUTION: To reduce risk of fire –replace fuse in extension cord with only 5-amp 125 volt fuse.
Do not replace attachment plug. Discard product if the attachment plug is damaged.
B) Light set fuse replacement (2 replaceable 3-amp 125V fuses are located in the plastic bag)
1. Grasp plug and remove from its power source.
2. Locate blown fuse(s) by sliding access cover on top of plug towards prongs.
3. Remove blown fuse by turning the plug over.
Fuses should fall into your hand (gentle tapping may be required).
4. Locate spare replacement fuses provided in plastic bag.
5. Replace blown fuse with the spare replacement fuse.
Close fuse cover by sliding fuse access cover towards the cord.
CAUTION: To reduce risk of fire –replace fuse in mini light with only 3-amp 125 volt fuse. Do not
replace attachment plug. Discard product if the attachment plug is damaged.
BULB REPLACEMENT:
1. Grasp plug and remove from its power source
2. Pull bulb AND plastic base straight out of socket. Do not twist bulbs.
3. Replace burned bulb with 2.5 volt 0.425 watt bulb ONLY. (Additional bulbs are included for your
convenience).
BASIC PRECAUTIONS SHOULD BE FOLLOWED WHEN
USING THIS PRODUCT:
3 4
