KMART Jaclyn Smith Marion 3pc Rocker Set User manual

Marion 3pc Rocker Set
Product Code: 07704055-8
UPC Code: 885227005225

2
Thank you for your purchase
Table of Contents
Thank you for your purchase!
We are pleased that you have chosen Kmart for your outdoor furniture
purchase. We hope that you enjoy the unmatched quality, comfort, and
style of your new patio set. Every piece is meticulously considered all the
way down to the smallest details, exclusively for you, by our world class
design team. We know you have a choice when it comes to your patio
furniture needs, so from our team to yours, thank you for letting us be a part
of your outdoors.
Table of Contents.......................... 2
Safety Information......................... 3
Set Up Your Furniture Properly... 3
Examine your furniture................ 3
Warranty......................................... 3
Care and Maintenance.................. 4
Pre-Assembly................................. 4
Planning Assembly...................... 4
Observe weight Limits................. 4
Assembly Instructions
Rocking chair................................ 5
Side table....................................... 7

WARRANTY
EXAMINE YOUR FURNITURE
SET UP YOUR FURNITURE PROPERLY
Frames are warranted to be free from defects in material or workmanship for a
period of one (1) year.
Resin wicker is warranted to be free from defects in material or workmanship for
a period of one (1) year.
Cushions are covered for a period of one (1) year against defects in material or
workmanship
This limited warranty is extended to the original purchaser and applies to defects
in material and workmanship of your patio furniture, provided your furniture is
maintained with care and used only for personal, residential purposes.
Exclusions: Items used for commercial, contract, or other non-residential purposes,
or items damaged due to acts of nature, vandalism, misuse, or improper assembly is
not covered. Discoloration and fading of the finish or fabrics as a result of chemicals
or spills are not covered. Glass table top breakage and corrosion or rusting of
hardware is not covered. If, within the stated warranty period, this product is found to
be defective in material or workmanship, the purchaser must contact the customer
service department at 1-888-577-9825. The manufacturer retains the option to repair
or replace the defectives parts. Proof of purchase (date register receipt) is required
for warranty claims. It remains the customer’s responsibility to pay for freight and
packing charges to and from the service center. Warranty is to the original purchaser
and is non-transferable. Any replacement of warranted items will be in the original
style and color, or a similar style and color if the original is unavailable or has been
discontinued. As some states do not allow exclusions or limitations on an implied
warranty, the above exclusions and limitations may not apply. This warranty gives
you specific rights, and you may also have other rights, which vary from state to state.
Customer service 1-888-577-9825
Examine occasionally to ensure that there are no loose parts. If loose parts are
found, they must be retightened fully before additional use.
When placing in the desired location, ensure that all legs are resting on an even
surface. You may adjust the leg’s levelers as required to ensure that the item is
securely balanced.
Ensure that all parts are assembled properly and fully tightened as per the
instructions.
3
Warranty
Safety Information

PLANNING ASSEMBLY
OBSERVE WEIGHT LIMITS
When not in use, protecting furniture from the elements is highly recommended.
To prevent damage, place all parts on a soft surface during assembly. Remove all
protective caps before beginning assembly. It takes about 35 minutes for two
people to complete all the assembly.
The recommended weight limits for the following products are listed below:
Chair：250lbs
Swivel Chair：250lbs
Loveseat：450lbs
Ottoman：150lbs
Table：50lbs
Sofa：650lbs
Chaise：250lbs
Wipe frame with a lightly damp cloth and dry completely, do not use bleach or
solvents.
Wash cushions with mild solution of soap and water, rinse thoroughtly. Do not
machine wash.
4
Care and Maintenance
Pre-Assembly
CAUTION: If you overload your
furniture, injuries can occur.

1. EVERY BOLT NEEDS TO BE USED WITH A WASHER.
2 .DO NOT TIGHTEN BOLTS ALL THE WAY UNTIL YOU HAVE ASSEMBLED THE CHAIR.
ONCE ASSEMBLY IS COMPLETE, GO BACK AND TIGHTEN EACH BOLT.
5
E
F
H
I
J
CODE PARTS
M6x20mm
BOLTS
& WASHERS
RIGHT ARM
LEFT ARM
SEAT&
BACK PANEL
CONNECTING
TUBE
BOLTS
& WASHERS
CAPS FOR
BOLTS
NUTS
ALLEN
WRENCH
M6x35mm
M6
M6
M6
DESCRIPTION QTY.
32
1
4
GBOLTS
& WASHERS 8
8
8
A
B
C
CODE PARTS DESCRIPTION QTY.
2
D2
2
2
Assembly Instructions
Safety Information
M6x55mm
Package Contents

Step 1: Connect the arm A to the seat & back panel, use
bolts G to connect arm tube to the seat tube, then use
bolts F to connect to the back tube.
Step 3: Put the nuts I into connecting tube's holes carefully,
then inset the connecting tube D to the leg tubes with bolts E
to connected.
Step 4: Turn the assembling chair upward as
shown, fully tighten all the bolts then check
and make adjustment as needed. Cover the
bolts with caps H. Please note there are 6
pre-assemble bolts also need to be covered
with caps H.
F
I
A
C
6
Assembly Instructions
G
G
D
B
H
E
1Step 2: Connect the arm B to the seat & back
panel, use bolts G to connect arm tube to the
seat tube, then use bolts F to connect to the
back tube.
2
3 4
G
G
F

M6x20mm
1. EVERY BOLT NEEDS TO BE USED WITH A WASHER.
2 .DO NOT TIGHTEN BOLTS ALL THE WAY UNTIL YOU HAVE ASSEMBLED THE CHAIR.
ONCE ASSEMBLY IS COMPLETE, GO BACK AND TIGHTEN EACH BOLT.
7
D
CODE PARTS
TABLE TOP
SET COLLAR
LEGS
BOLTS
& WASHERS
CAPS FOR
BOLTS
DESCRIPTION QTY.
8
E8
A
B
CODE PARTS DESCRIPTION QTY.
4
C1
1
Assembly Instructions
Safety Information
Package Contents
M6

Step 1: Insert the table legs B under the
table ring one by one.
Step 2: Connect set collar C to the table legs.
Step2: Turn the assembling table upward as shown, check and make adjustment as needed. Cover the
bolts with caps E.
8
Assembly Instructions
1 2
3
B
A
B
B
B
C
E
D

Email: acs@americancustomerservice. com or Call toll-free:1-888-577-9825
SERVICE HOURS: Monday – Friday 8:00AM to 8:00PM EST
