KMART MODULAR WALL SHELF 42889908 User manual

PAGE 1 OF 4
A
C
B
E
D
F
Assembly Instructions
42889908 MODULAR WALL SHELF
Please read instructions carefully. Remove all wrapping material, staples and packing staples from
the carton. See parts list and hardware list for guidance. Be sure you have all parts before you start
assembling. Place all wooden furniture parts on a clean and flat soft surface, such as carpet or a rug
to prevent from being scratched. When cleaning the surface, use a soft damp cloth or dry clean cloth.
-This wall shelf needs to be mounted securely. Please use appropriate fixing types for your wall type.
If in doubt, please consult a builder/DIY specialist.
-Attention: We recommend a periodic check on all fixing points to make sure they remain fully
tightened.
1. Hardware List
To Assemble:
-Check the contents to make sure that nothing is
missing.
-Pull out the parts and fittings as shown. Assemble
product step by step.
-It is preferable to rest the product on a soft surface to
avoid damage during assembly.
-Do not overtighten screws and fittings.
-Retighten all screws and fittings periodically.
WARNING:
-This package contains small parts and sharp points.
-Keep away from children and babies until assembly is
complete.
-Take care if using power tools to assemble the product.
-DO NOT STAND OR SIT ON THIS ITEM. DO NOT
USE THIS ITEM UNLESS ALL BOLTS, SCREWS AND
KNOBS ARE FIRMLY SECURED.
-DO NOT PLACE HOT ITEMS DIRECTLY ON THIS
ITEM.
-KEEP IT PROTECTED FROM DIRECT SUNLIGHT.
FOR INDOOR USE ONLY.
-MAXIMUM SAFE LOAD WEIGHT: 3KG PER LAYER,
5KG FOR WHOLE PRODUCT.
2. Parts List
G. 4 x screws (included)
H. 4 x expansion bolts (included)
GH

C
E
D
A
C
ED
F
F
PAGE 2 OF 4
STEP 1
STEP 2

A
C
E
D
F
B
PAGE 3 OF 4
STEP 3
STEP 4
Note:This tool is not included.
Before drilling, double check the measurements
of the drill holes and the position of the hooks to
ensure secure attachment of shelf to the wall.
Note: due to the many ways this can be
assembled, please measure the distance of
hooks accordingly.
H
G
H
G
H
G
H
G

PAGE 4 OF 4
STEP 5
Note: You can assemble this product in many different ways.
EXAMPLE 1 EXAMPLE 2 EXAMPLE 3
